OWNER’S HANDBOOK

Publication Part No. JJM 10 02 16 801

This handbook forms part of the Owner literature supplied with your vehicle. Right-hand

drive and left-hand drive situations are shown in the graphics and where information is

specific to a particular country, it is indicated as such.

The Quick Overview section is designed to rapidly familiarise the driver with the initial

set up and also explain some of the unique features. Please take the time to study the

operating instructions with your vehicle as soon as you can.

Important

The information contained in this handbook covers all vehicle derivatives and optional

equipment. Some of the options will not be fitted to your vehicle unless they formed part

of the original vehicle specification. Therefore, some parts of this handbook may not

apply to your vehicle. Furthermore, due to printing cycles, it may include descriptions of

options before they become generally available.

The information contained in this publication was correct when it went to print. Vehicle

design changes may have been made after this handbook was printed. When this occurs

a handbook supplement is added to the literature pack. Subsequent updates can be

viewed on the Jaguar internet site at: http://www.ownerinfo.jaguar.com.

In the interest of development, the right is reserved to change specifications, design or

equipment at any time without notice and without incurring any obligations. This

publication, or part thereof, may not be produced nor translated without our approval.

Errors and omissions excepted.

©Jaguar Cars Limited 2007.

Published by Jaguar Cars Limited Technical Communications.

Handbook Contents

Quick Overview

Quick Overview . . . . . . . . . . . . . . . . . . . 7

Filling Station Information . . . . . . . . . . 29

Owner Information

General Information. . . . . . . . . . . . . . . 32

Security and Locks

Ignition Switch. . . . . . . . . . . . . . . . . . . 37

Vehicle Security. . . . . . . . . . . . . . . . . . 38

Door Locks . . . . . . . . . . . . . . . . . . . . . 41

Luggage Compartment Locks . . . . . . 46

Alarm Systems . . . . . . . . . . . . . . . . . . 47

Garage Door Opener. . . . . . . . . . . . . . 50

Before Driving

Occupant Protection . . . . . . . . . . . . . . 56

Child Safety. . . . . . . . . . . . . . . . . . . . . 68

Seats . . . . . . . . . . . . . . . . . . . . . . . . . . 76

Clock . . . . . . . . . . . . . . . . . . . . . . . . . . 80

Steering Column . . . . . . . . . . . . . . . . . 81

Door Windows. . . . . . . . . . . . . . . . . . . 83

Mirrors . . . . . . . . . . . . . . . . . . . . . . . . . 85

Driving Position Memory . . . . . . . . . . . 87

Luggage Compartment . . . . . . . . . . . . 89

On the Road

Instruments . . . . . . . . . . . . . . . . . . . . . 92

Warning Indicators . . . . . . . . . . . . . . . 94

Audible Warnings . . . . . . . . . . . . . . . . 98

Message Centre . . . . . . . . . . . . . . . . . 99

Trip Computer . . . . . . . . . . . . . . . . . . 106

Cruise (Speed) Control . . . . . . . . . . . 109

Adaptive Cruise Control . . . . . . . . . . 111

Exterior Lighting . . . . . . . . . . . . . . . . 117

Interior Lighting . . . . . . . . . . . . . . . . . 122

Parking Assist . . . . . . . . . . . . . . . . . . 123

Horn. . . . . . . . . . . . . . . . . . . . . . . . . . 126

Sunroof . . . . . . . . . . . . . . . . . . . . . . . 127

Wipers and Washers . . . . . . . . . . . . . 128

Parkbrake . . . . . . . . . . . . . . . . . . . . . 130

Interior Features . . . . . . . . . . . . . . . . 132

Engine Starting . . . . . . . . . . . . . . . . . 135

Transmission . . . . . . . . . . . . . . . . . . . 138

Braking System . . . . . . . . . . . . . . . . 141

Stability Control . . . . . . . . . . . . . . . . 143

Driving Information . . . . . . . . . . . . . 144

Fuel and Refuelling . . . . . . . . . . . . . 149

Climate Control

Climate Control . . . . . . . . . . . . . . . . 156

Automatic Climate Control . . . . . . . 159

Roadside Emergency

Inertia Switch . . . . . . . . . . . . . . . . . . 164

Emergency Starting . . . . . . . . . . . . . 165

Wheel Changing . . . . . . . . . . . . . . . 167

Vehicle Recovery . . . . . . . . . . . . . . . 171

Bulb Renewal. . . . . . . . . . . . . . . . . . 174

Fuses . . . . . . . . . . . . . . . . . . . . . . . . 179

Fire Extinguisher . . . . . . . . . . . . . . . 189

Maintenance

General Maintenance. . . . . . . . . . . . 190

Bonnet Release . . . . . . . . . . . . . . . . 191

Regular Checks . . . . . . . . . . . . . . . . 192

Checking and Topping up . . . . . . . . 196

Battery . . . . . . . . . . . . . . . . . . . . . . . 202

Wiper Blades . . . . . . . . . . . . . . . . . . 205

Tyres . . . . . . . . . . . . . . . . . . . . . . . . 206

Vehicle Care. . . . . . . . . . . . . . . . . . . 211

Electrical Accessories . . . . . . . . . . . 214

Specifications

Engine Data . . . . . . . . . . . . . . . . . . . 215

Dimensions . . . . . . . . . . . . . . . . . . . 216

Weights . . . . . . . . . . . . . . . . . . . . . . 217

Load Weights. . . . . . . . . . . . . . . . . . 219

Wheels and Tyres . . . . . . . . . . . . . . 220

Fuel Consumption . . . . . . . . . . . . . . 221

A comprehensive index is located at the

back of this handbook.

Quick Overview

LOCKING AND UNLOCKING . . . . . . . . 7

CENTRAL DOOR LOCKING . . . . . . . . . 8

LUGGAGE COMPARTMENT . . . . . . . . 8

CLOCK ADJUSTMENT . . . . . . . . . . . . . 9

SEATS . . . . . . . . . . . . . . . . . . . . . . . . . 10

STEERING COLUMN . . . . . . . . . . . . . 11

ELECTROCHROMATIC REAR

VIEW MIRROR . . . . . . . . . . . . . . . . . . 11

WINDOWS AND DOOR MIRRORS . . . 11

DRIVING POSITION MEMORY . . . . . . 12

SEAT BELTS AND CHILD

RESTRAINTS . . . . . . . . . . . . . . . . . . . 13

OVERHEAD CONSOLE . . . . . . . . . . . 13

CLIMATE CONTROL . . . . . . . . . . . . . 14

FACIA AND CONTROLS . . . . . . . . . . . 16

EXTERIOR LAMPS AND

TRIP COMPUTER . . . . . . . . . . . . . . . . 17

WIPERS AND WASHERS . . . . . . . . . . 18

WARNING INDICATORS . . . . . . . . . . 19

AUTOMATIC TRANSMISSION . . . . . . 20

PARKBRAKE . . . . . . . . . . . . . . . . . . . 21

CRUISE (SPEED) CONTROL . . . . . . . 21

ADAPTIVE CRUISE CONTROL (ACC) 22

AUDIO SYSTEM KEY FEATURES . . . 23

RADIO OPERATION . . . . . . . . . . . . . . 24

CD OPERATION . . . . . . . . . . . . . . . . . 24

NAVIGATION . . . . . . . . . . . . . . . . . . . 26

TELEPHONE - BLUETOOTH®

SYSTEM . . . . . . . . . . . . . . . . . . . . . . . 27

Filling Station Information

FUEL TYPE . . . . . . . . . . . . . . . . . . . . . 29

FUEL FILLING . . . . . . . . . . . . . . . . . . . 29

BONNET RELEASE . . . . . . . . . . . . . . 30

UNDERBONNET TOP UP . . . . . . . . . . 30

TYRE PRESSURES . . . . . . . . . . . . . . . 31

Quick Overview

LOCKING AND UNLOCKING

Note: Dependent upon vehicle

configuration, the operation of the remote

handset may differ from the following:

Remote handset

Press to release the door key.

Press once to lock the vehicle

and arm the alarm.

Press twice within three

seconds to double-lock the vehicle.

Press and hold to close the sunroof and

any windows that are open (Global

closing).

Press once to disarm the alarm,

unlock the driver’s door and

unlock the luggage

compartment.

Press again to unlock remaining doors.

Press and hold to open the sunroof and

windows (Global opening).

Press once to switch the

headlamps on for 25 seconds.

Press to unlock and open

luggage compartment.

Single and two stage unlocking may be

changed by pressing and holding the lock

and unlock buttons on the remote

handset simultaneously for four seconds.

Unlocking with the door key

If the vehicle is unlocked manually via the

door lock, the key must be inserted in the

ignition switch within 15 seconds to

prevent the alarm being activated.

JOL4689

Quick Overview

CENTRAL DOOR LOCKING

With the ignition switch in position II,

press the facia switch (arrowed in

illustration) to lock or unlock all the doors

and the luggage compartment.

To also close or open the windows and

sunroof, press and hold the switch.

Drive away door locking

The doors and luggage compartment will

automatically lock when the vehicle’s

forward speed exceeds 7 km/h (5 mph).

This feature can be disabled by your

Jaguar Dealer/Authorised Repairer.

Fuel filler flap

The driver’s door must be unlocked, or

the key in the ignition switch, before

operating the fuel filler flap release button.

See page 29.

LUGGAGE COMPARTMENT

The luggage compartment is electrically

locked and unlocked in conjunction with

the driver’s door.

To open the luggage compartment with

the vehicle locked:

•Press the luggage compartment

button on the remote handset.

To open the luggage compartment with

the vehicle unlocked:

•Press the button on the facia 1.

•Press the release button on the

luggage compartment lid 2.

In the event of a flat battery, or other

problem opening the luggage

compartment, use the ignition key in the

luggage compartment lock (arrowed in

illustration).

Care Points

•Release buttons on the facia and

luggage compartment lid are disabled

when the vehicle is alarmed.

•The vehicle alarm will sound if the

luggage compartment is opened with

the key when the vehicle is

double-locked.

JOL4690

JOL4691

Quick Overview

CLOCK ADJUSTMENT

Touch-screen

1. Touch the time display for three

seconds to access clock setting

mode.

2. To adjust the clock, touch the up or

down arrow icons.

3. Touch the 12/24 icon to select

between twelve or twenty-four hour

display.

4. Touch Set to confirm.

Non-touch-screen

1. Press and hold MODE until CLOCK

SET is displayed with the 12/24 hours

indicator flashing.

2. To set 12 or 24 hour display, rotate the

volume control knob clockwise for 24

hour display; anti-clockwise for 12

hour display. AM or PM is,

subsequently, automatically

displayed.

3. Press MODE to select the hour

setting.

4. Rotate the volume control knob

clockwise to increase the hour,

anti-clockwise to decrease the hour.

5. Press MODE to select the minute

setting. Rotate the volume control

knob clockwise to increase the

minute; anti-clockwise to decrease

the minute.

6. To exit, press and hold MODE until

the display reverts to audio mode.

12/24 Set

Cancel

SET CLOCK

JOL4692

TP ST

JOL4693

Quick Overview

SEATS

Front seats

Note: Driving Position Memory provides

more information on automatic seat

movement, see page 12.

1. Seat forwards and rearwards, cushion

height and front tilt control switch.

2. Seat cushion extension switch.

3. Lumbar support switch.

4. Seat recline and head restraint height

adjustment switch.

Rear folding seat

To provide a larger luggage compartment

area, the backs of the rear seats can be

folded down.

Pull the respective handle, located in the

luggage compartment under the parcel

shelf, to release the back of the seat.

When returning the seat to the upright

position make sure seat belts are routed

correctly and the back is securely locked

in place.

JOL4694

JOL4695

Quick Overview

STEERING COLUMN

Steering column

Turn the control on the left-handside of

steering column to COLUMN and move

the control to adjust the height and reach.

Automatic seat movement

To prevent automatic movement of the

driver's seat when the ignition switch is

turned on or off, turn the control to

COLUMN.

Driver’s seat movement at ignition

switch off

If the control is set to AUTO, the position

of the steering column and driver's seat

will automatically adjust to provide

greater clearance for exit and entry when:

•the key is in the ignition switch and the

driver’s door is opened;

•the ignition key is removed.

ELECTROCHROMATIC REAR

VIEW MIRROR

With the ignition switch on, the rear view

mirror will automatically darken in

proportion to the amount of glare

detected from the following vehicles'

headlamps. This feature is automatically

switched off when reverse gear is

selected.

WINDOWS AND DOOR

MIRRORS

Windows

The windows are fitted with a facility that

allows them to be fully opened or closed

by briefly pressing the respective window

switch. Press the switch again to stop

window movement.

•To open the window, press and hold

the rear of the switch until the desired

position is reached, then release.

JAG0564

JOL4698

Quick Overview

•To close the window, press and hold

the front of the switch until the desired

position is reached, then release.

Press button 3 to inhibit the operation of

the rear window switches.

Door mirrors

To adjust the door mirrors, press the

mirror selector switch 2 left or right to

select the appropriate mirror. Use the

four-way switch 1 to adjust the position.

Power fold mirrors

The mirrors can be folded towards the

door for better clearance and protection.

With the mirror selector switch 2 in the

centre position, briefly press the rear of

the four-way switch 1. Press the rear of

switch 1 again to unfold.

Global closing

If a window has been left open when

leaving the vehicle, it can be closed by

pressing and holding the lock button on

the remote handset (this will also close

the sunroof).

DRIVING POSITION MEMORY

Once you have adjusted the driver’s seat,

steering column and exterior mirrors for

your ideal driving position, the vehicle can

memorise these settings for future use.

• Push the MEMORY button and a red

indicator in the switch will illuminate

for five seconds.

•Whilst the indicator is illuminated,

press button 1 or 2 to memorise the

current settings.

The indicator will extinguish and an

audible chime will sound to confirm that

the settings are memorised. Any existing

settings will be overwritten.

To recall a memorised driving position

press button 1 or 2.

Remote handset programming

With the MEMORY button illuminated

you can programme a remote handset to

a memory position by pressing any button

on the remote handset and then pressing

button 1 or 2.

JOL4699

Quick Overview

SEAT BELTS AND CHILD

RESTRAINTS

!WARNING:

The use of front and rear seat belts is

mandatory in most countries. Using

seat belts saves lives. They should be

worn by all occupants, whenever the

vehicle is in use.

A warning indicator on the

instrument pack will illuminate

to alert you that the driver’s

and/or front passenger’s seat belt is

unbuckled. Dependent upon specification

this may be accompanied by an

intermittent chime.

Child Seats

It is important to remember that your

child’s weight, rather than age,

determines the type of seat that is

required.

Refer to Child Safety to determine the

correct seat for your child, see page 68.

Recommended child seat

Jaguar’s recommended Group 1 seat is

the Jaguar ISOFIX child restraint with a

top tether.

The ISOFIX child seat can only be fitted in

the outer rear seating positions.

OVERHEAD CONSOLE

Rear window blind

Press button 1 to raise the rear window

blind. Press the button again to lower the

blind.

Parking assist

Press button 2 to turn off the front and

rear parking sensors.

Care points

•Sensors may activate on detection of

water, snow or ice on their surface.

This is entirely normal and regular

cleaning will aid performance.

•Parking assist may sound if it detects

a signal operating at the same

frequency to that of the sensors (e.g.

motorcycles, airbrakes).

Sunroof

The sunroof is fitted with a facility that

allows it to be fully opened or closed with

a single operation of switch 3.

1 2

JOL4700

Quick Overview

Closing remotely

•If the sunroof has been left open when

leaving the vehicle, it can be closed by

pressing and holding the lock button

on the remote handset.

Garage door opener

The buttons 4 on the overhead console

can be programmed to transmit radio

frequencies that can operate external

devices, i.e. garage doors, entry gates,

security systems, etc.

For more information, see page 50.

CLIMATE CONTROL

These are the primary functions of the

climate control system:

For those vehicles fitted with

the touch-screen navigation

system, the advanced climate

control functions can be accessed by

pressing the Climate button.

AUTO (automatic) mode

Press to select automatic

operation of the climate

control system. The system

will automatically adjust the heat output,

blower speed, air intake and airflow

distribution to maintain the selected

temperature(s) and reduce misting,

without constant adjustments by the

driver or passengers.

JOL4701

˚C / ˚ F

6 :46 PM

JOL4702

Quick Overview

Screen heaters and timed air recirculation

may be selected whilst in AUTO mode.

Selecting any other function will cancel

AUTO operation.

Recommended mode

•Select AUTO as the normal operating

mode.This will help prevent window

misting and odours from the climate

control system.

Dual temperature zones

With the DUAL button LED

illuminated, the system

provides separate temperature

control of the driver and front passenger

zones.

Press the button to de-select dual mode.

The temperature of the passenger zone

will automatically adjust to that of the

driver’s zone and the temperature of both

zones will be controlled by the driver’s

temperature control buttons.

Temperature selection

Press the red buttons to

increase temperature

and the blue buttons to

decrease temperature.

To quickly jump from HI or LO to a

mid-range temperature setting, press and

hold the AUTO button for a few seconds.

Air conditioning (A/C)

Air conditioning is an integral

part of the climate control

system, providing cooled and

dehumidified air for occupant comfort;

the dry airflow is also effective in

preventing misting of the windows.

Press the button to switch the air

conditioning system on or off. Air

conditioning is controlled automatically

when the vehicle is in AUTO mode.

De-selecting A/C will cancel AUTO mode.

External water deposits

•The air conditioning system removes

moisture from the air and deposits the

excess water beneath the vehicle.

Puddles may form, but this is normal

and no cause for concern.

Windscreen defrost and demist

Press the DEF (defrost) button

to remove frost or heavy

misting from the windscreen.

The rear screen and windscreen heaters

will be activated.

To de-select defrost mode, press AUTO.

The rear screen and windscreen heaters

will remain on.

Heated screens and door mirrors

The front and rear

screen heaters can be

switched on or off in any

mode, even when the climate control

system is off, but will only operate when

the engine is running.

Operating the DEF button will

automatically activate the front and rear

screen heaters.

The door mirror heaters are controlled by

the rear screen heater button.

Quick Overview

FACIA AND CONTROLS

1. Passenger airbag deactivation switch

(67)

2. Heating and ventilation system (156)

3. Audio system

4. Direction indicators, exterior lamps

and trip computer switch (117)

5. Instrument pack and warning

indicators (94)

6. Wiper and washer switch (128)

7. Rear fog lamp switch (119)

8. Luggage compartment switch (46)

9. Adaptive Cruise Control (ACC)

forward alert switch (111)

10. Fuel filler flap switch (149)

11. Bonnet release switch (191)

12. Ignition switch (37)

13. Cruise control switches (109)

14. Audio and telephone switches

15. Dynamic Stability Control (DSC)

switch (143)

16. Gear selector lever (138, 140)

17. Parkbrake (130)

18. Sport mode switch (139)

19. Hazard warning switch (97)

20. Master locking switch (43)

21. Navigation screen (see Navigation

System Handbook)

Page numbers (shown in brackets) refer

to pages in this Handbook that have

further relevant information.

JAG0573

1 2 3 4 5 6

1112

1314

Quick Overview

Passenger airbag deactivation

indicator

Based upon the weight and

size of the occupant or object

on the seat, the passenger

airbag deactivation indicator may

illuminate to confirm the airbag has been

deactivated. THIS IS NORMAL.

For further information refer to Occupant

Protection, see page 56.

Automatic exterior lamps

If Autolamps is selected, and the

windscreen wipers are operated

continuously for more than 20 seconds,

then the exterior lamps will be switched

ON automatically.

Diesel Particulate Filter (DPF)

indicators

If the AMBER warning indicator 2 is

illuminated, accompanied by the

message DPF FULL SEE HANDBOOK in

the message centre 1, regeneration of the

DPF is required. See page 153.

If the RED warning indicator 3 is

illuminated, accompanied by the same

warning message, seek qualified

assistance as soon as possible. See page

153.

EXTERIOR LAMPS AND TRIP

COMPUTER

Move the lever up or down to activate the

direction indicators. Press the button on

the end of the lever to cycle through trip

computer displays.

Rotate the collar on the lever to select:

• Side lamps

• Headlamps

• Autolamps

• Headlamp exit delay

In AUTO mode, a sensor monitors the

exterior light levels and will automatically

switch the side lamps and dipped

headlamps ON and OFF.

JOL4603

Quick Overview

WIPERS AND WASHERS

A. Intermittent wipe.

B. Slow speed operation.

C. High speed operation.

Press the button for windscreen wash and

wipe. Rotate collar to adjust the speed of

intermittent wipe or to select AUTO for

automatic operation of wipers.

Enabling automatic operation

•The wiper lever must be in position A

and AUTO selected on the collar to

enable automatic operation of the

wipers.

JOL4604

Quick Overview

WARNING INDICATORS

Low oil pressure (Red)

Battery charge indicator (Red)

Seat belt reminder

Parkbrake on

Engine malfunction detected

Dynamic Stability Control

(DSC) off

Adaptive Cruise Control (ACC)

active

Airbag system fault detected

Diesel glow plugs active

Side lamps on

Headlamp main beam on

Rear fog lamps on

Overspeed warning indicator

Direction indicators

Low outside temperature

Quick Overview

AUTOMATIC TRANSMISSION

Gearshift interlock

The ignition switch must be in position II

and the foot brake applied before the gear

selector can be moved from (Park) to P R

(Reverse). The lever can be moved into P

with the ignition switch off.

Gear selector

The gear selector lever is designed to

accommodate two different driving

techniques as follows:

Automatic selection: the right-hand side

of the selector gate.

Manual selection: the left-hand side of the

selector gate, to individually select 5th,

4th, 3rd or 2nd gear.

With the gear selector in D (Drive) and

Sports mode active, the transmission will

use 6th gear less at higher cruising

speeds.

Fuel consumption will be adversely

affected.

After selecting R (Reverse) or D (Drive)

from N (Neutral) or P (Park), wait briefly for

the transmission to engage before

accelerating.

Sport mode

Press the switch (arrowed) to select Sport

mode. A red indicator in the switch will

illuminate to indicate that Sport mode is

active. When Sport mode is selected, the

gear change points are modified to make

full use of the engine’s power.

JOL4707

Quick Overview

PARKBRAKE

Applying the parkbrake

•With the vehicle stationary, pull up the

parkbrake lever and then release. The

parkbrake red warning indicator in the

instrument pack will illuminate.

•The parkbrake will automatically apply

when the ignition key is removed from

the lock.

Releasing the parkbrake

•On manual transmission vehicles,

with the ignition switch in position II,

press down on the parkbrake lever.

•On automatic transmission vehicles,

with the ignition switch in position II,

apply the foot brake and press down

on the parkbrake lever.

•On automatic transmission vehicles, if

the vehicle is stationary with the

parkbrake applied and either D (Drive)

or R (Reverse) is selected, pressing

the accelerator pedal will

automatically release the parkbrake.

•The parkbrake will automatically

release when the gear selector is

moved from P (Park).

CRUISE (SPEED) CONTROL

Speed control

Speed control is the standard cruise

control system where the vehicle will

maintain a SET road speed until either

cruise control is cancelled or the brake

pedal is used.

The system is controlled via switches on

the steering wheel:

1. RESUME - to resume a set speed

retained in memory.

2. SET - to set the road speed to be

maintained, or increase or decrease

the speed in 2 km/h (1 mph) steps

when cruise control is operating.

3. CANCEL - cancels cruise control, but

retains the set speed in memory.

Brake pedal override

•Cruise control will automatically

disengage when the brake pedal is

pressed or when the vehicle speed

falls below 26 km/h (16 mph).

JOL4708

JOL4709

Quick Overview

AUDIO SYSTEM KEY

FEATURES

General operation

Press the control knob A to switch on or

off and rotate to adjust the volume.

To adjust the sound settings, press the

MODE button B repeatedly, until the

required setting is displayed. Turn the

control knob A to adjust the level or rating.

After approximately five seconds, the

system will return to normal control mode.

Steering wheel controls

1. Press to mute the audio unit.

2. Press, as required, to increase or

decrease volume.

3. Press and release to cycle through

Radio, FM, AM, CD, and CD

multichanger.

4. Press and release to cycle through

preset radio stations, the next CD/MD

track or to use cassette AMS

(Automatic Music Search).

Press and hold for at least two seconds to

cycle to the next strongest station, next

CD or to change cassette side.

JOL4711

A B

JOL4712

Quick Overview

RADIO OPERATION

To switch on the radio

function, press the AM/FM

button. Pressing this button

repeatedly scrolls through FM, MW and

LW wavebands.

To search for a radio

station, press the Seek

arrow buttons.

Setting the radio presets

Once a radio station

has been tuned,

press and hold the

desired preset

button (or touch a

station position on

the touch-screen) until a beep is heard.

The preset is now stored.

A total of nine presets can be stored for

each waveband.

The radio presets can be

automatically set by using the

Auto Memory function. Press

and hold the AMEM button for two

seconds. The radio will be briefly muted

while it searches the waveband for the

nine strongest stations.

Activating TA (Traffic Announcements)

To activate this function, press

and release the TA button. With

TA activated, traffic

announcements will interrupt radio or CD

play. To de-activate this feature, press

and release the TA button again.

Press and hold the TA button for two

seconds to display the radio station name

instead of the frequency.

CD OPERATION

Single CD player

If the radio or CD multichanger is

being used, pressing the CD

button will resume playing any

CD installed in the player mechanism.

When a CD is loaded into the aperture, it

will begin to load and play automatically.

Pressing the CD button, while in CD play

mode, will pause the current track. A

subsequent press of the CD button will

resume play mode.

Six discs can be loaded into the

multichanger unit, and a further single

disc in the audio console.

To skip tracks, continually

press the Seek arrow

buttons to move back or

forward accordingly. Pressing and

holding these buttons will search through

the selected track.

When a disc is inserted, the CD

icon is displayed. Press the

Disc eject button to eject the

CD. The display will show DISC EJECT

and the CD icon will be turned off.

Quick Overview

CD Multichanger

Care point

•Remember to close the multichanger

door. This will prevent dirt getting into

the unit and help reduce skipping.

The CD multichanger is located in the

luggage compartment. To load a CD into

the multichanger:

1. Slide open the multichanger door;

press the Eject button and remove

the magazine. Close the door.

2. Pull a tray out from the magazine and

insert a CD (label side up). Slide the

tray into the magazine until a click is

heard.

3. Slide open the multichanger door and

ensure correct orientation, replace the

magazine. Make sure that the

magazine clicks into position.

CD selection

1. Press the CDC button to

select the CD multichanger

mode.

2. Press preset buttons 1 to 6 to select

the appropriate CD loaded in the

multichanger.

If a touch-screen is fitted to the

vehicle, disc selection can be made

by touching the relevant numbered

disc icon.

3. When playing a CD, press the CDC

button to pause play. Press again to

continue play.

Playing random tracks

To play random tracks from the

disc, press and release the MIX

button. To cancel, press the MIX

button again.

To play random tracks from all discs

loaded in the multichanger, press the MIX

button for two seconds. To cancel, press

and hold the MIX button.

JOL4713

Quick Overview

NAVIGATION

Caution: The screen allows touch

control of the navigation system. The

screen only requires a light touch to

operate the function. Excess pressure

on the screen could result in damage.

On initial activation, make sure that

both the correct country and area have

been selected.

Setting a destination

To set a destination and start using the

the navigation system, use the following

procedure:

1. Press the NAV button (arrowed in

illustration) and, when prompted,

touch Agree on the touch-screen to

access the initial map screen.

2. Touch Nav menu to access the

navigation menu and then touch

Destination Entry.

3. Touch either Address or Postcode.

4. Enter the address or postcode using

the on-screen keypad, making sure

that a space is entered in the

postcode. The space character can

be found after the Z character on the

bottom line of the keypad. Touch OK

to enter.

5. Touch Dest to calculate the route.

6. Once the most appropriate route is

calculated, the screen will display the

route. To scroll through alternative

routes, touch Next on the screen.

Note: Route Preferences should be

selected prior to setting a destination.

Access is via the Nav menu and then

Route Options.

7. Touch Start to commence navigation.

Drive away following the voice

guidance.

Note: Press the Audible repeat

button to hear the last voice

guidance instruction again.

Voice guidance can be selected or

de-selected via the Nav menu.

8. When your destination is reached,

voice and visual confirmation is given.

Cancelling guidance

To cancel guidance during navigation,

touch the zoom icon, select Change

Route then Cancel Guidance.

JOL4714

JOL4715v

JOL4716

Quick Overview

TELEPHONE - BLUETOOTH®

SYSTEM

Mobile phones with Bluetooth capability

can communicate with the vehicle’s

inbuilt telephone system.

The following procedure demonstrates

how to connect the most popular brands

of mobile phone.

Pairing a handset to the vehicle

1. Turn the ignition switch to position II.

2. Press the telephone button on the

audio panel. The touch-screen will

display the message No BT phone

on. On touch-screen systems the

message SIG will be displayed.

3. Either using the on-screen or the

audio panel keyboard, press ##3#*#.

4. Touch the on-screen call icon or press

the call button on the audio panel.

5. Prepare the handset for pairing to the

system.

See the telephone manufacturer’s

instructions for further details, or follow

the table below for generic commands.

When the handset has been successfully

paired to the system, the touch-screen

message changes to REGISTERED. On

systems without a touch-screen the audio

system message changes to SIG.

Note: For best results when pairing your

handset to the system, ensure the

handset is fully charged.

Nokia Motorola Ericsson

1. Select menu Select menu Select menu

2. Select settings Select settings Select connectivity

3. Select Bluetooth OR

Select Connectivity

then Bluetooth

Select Connection Select Bluetooth

4. Select On Select Bluetooth link Select My Devices

5. Select Search for Audio

devices

Select Hands-free With New Device

highlighted, select Add.

Press OK to confirm

6. After search select

Jaguar

Select Look for

devices

After search select Jaguar

7. Enter pass code 1313.

Press OK to confirm

After search select

Jaguar

Select Connect

8. No connection? Select

Bluetooth (Menu) then

Paired devices Jaguar

Permission to bond?

Select Yes and enter

pass code 1313

Enter pass code 1313 after

prompt

Quick Overview

Mobile phone compatibility

There are a number of mobile phones that

have been tested to function correctly

with the Jaguar system, however, not all

mobile phones are compatible. For the

latest list of compatible phones and

software versions, please refer to

www.ownerinfo.jaguar.com.

Alternatively consult your Jaguar

Dealer/Authorised Repairer.

Downloading phone book entries

1. Turn the ignition switch to position II,

and make sure that the handset is

paired to the vehicle’s system.

2. Press the telephone button on the

audio panel.

3. Either using the on-screen keypad or

the audio panel keyboard, press

##2#*#.

4. Touch the on-screen call icon or press

the call button on the audio panel.

5. Switch off the ignition switch for six

minutes to allow the system to

complete the download process.

Making a call

1. Press and hold the SELECT switch on

the steering wheel control, or press

the call button on the audio panel.

Phone will be displayed.

2. Key in the phone number required on

the touch-screen or audio panel

keyboard.

3. Press the call button on the steering

wheel control, or on the audio panel.

Calling will be displayed.

4. To end the call, press the call button

on the steering wheel control, or on

the audio panel.

Receiving a call

To answer or end a call, press the call

button on the steering wheel control or on

the audio panel.

JOL4717

Filling Station Information

Filling Sta tion Inf or ma t ion

FUEL TYPE

Petrol models - Unleaded 95 RON.

Diesel models - Diesel fuel to EN 590 or

equivalent.

Caution: DIESEL ENGINES - If you

inadvertently fill your vehicle with

petrol instead of diesel; do not attempt

to start the engine.

Contact your Jaguar Dealer/

Authorised Repairer immediately.

Attempting to start the engine with

petrol in the fuel tank will cause

extensive damage to the engine and

fuel system, which will not be covered

by your Jaguar warranty.

Jaguar can accept no responsibility for

any damage caused by running your

vehicle with petrol or vegetable oil in

the fuel tank.

Diesel engines only: Drivers should

expect above normal fuel consumption

when the engine is new and bedding-in.

After a period, the fuel consumption will

gradually improve to expected fuel

consumption levels.

Caution: Do not use RME (bio-diesel)

except in the case of proprietary diesel

fuels which contain a mix of up to 5%.

Note: Vehicles with a diesel engine have a

yellow filler cap.

FUEL FILLING

Press the fuel filler flap release (arrowed in

the illustration). This is located on the

driver’s knee bolster switch below the

facia, see page 149.

The filler flap is located on the right-hand

side of the vehicle.

For quickness and to completely fill the

tank, make sure that the fuel nozzle rests

on the bottom of the filler neck.

Incorrect closure of the fuel filler cap may

result in the check engine indicator

(malfunction indicator lamp) illuminating.

After refuelling, refit the fuel filler cap in

the filler neck. Twist the filler cap

clockwise until it clicks and close the flap,

which automatically locks shut.

Filling Station Information

BONNET RELEASE

Pull the release lever located below the

facia on the driver’s side of the vehicle

(see page 191).

UNDERBONNET TOP UP

Recommended Engine Oil.

See page 197.

Petrol models -

Castrol 5W-30 to Jaguar specification

WSS M2C913 - A or B.

Diesel models -

An oil of 5W-30 viscosity to Jaguar

specification WSS M2C913 - B must be

used in all vehicles with a diesel engine.

For top up purposes only, where the

WSS M2C913 - B specification cannot be

found, ACEA B1 or ACEA B3 specification

oils may be used.

Windscreen and Headlamp Washer

Reservoir.

See page 201.

Coolant System

50% water/50% anti-freeze, see page

198.

Filling Station Information

TYRE PRESSURES

The tyre pressures for all normal

operating conditions are shown on a label

fixed to the inside of the right-hand side

door front pillar.

Check pressures when the tyres are cold

(see page 206). Deflating air from a warm

tyre to the recommended pressure will

result in under inflation, which may be

dangerous.

For your convenience, you may wish to

record the tyre pressures in the boxes

provided below. If you are unsure of the

correct pressures, please contact your

Jaguar Dealer/Authorised Repairer.

!WARNING:

When using tyres other than those

recommended by Jaguar, do not

exceed the speed capacity

recommended by the manufacturer.

FRONT

Normal Driving

Laden/High Speed

Spare Wheel

REAR

Normal Driving

Laden/High Speed

Spare Wheel

General Information

Owner Inf ormatio n

WARNINGS, CAUTIONS AND

NOTES

Take particular note of WARNINGS,

Cautions and Notes given throughout this

handbook.

!WARNING:

A warning is a procedure, which must

be followed precisely, to help avoid the

risk of personal injury.

Caution: A caution is a procedure,

which must be followed precisely, to

reduce the possibility of damage to the

vehicle.

Note: A note is a procedure which will

help avoid difficulties in the operation of

the vehicle.

Warning symbols on the vehicle

On encountering the warning triangle or

open book symbol on the vehicle, it is

important that, before touching this part

of the vehicle or attempting adjustments

of any kind, you consult the relevant

section of this handbook.

Caution: Do not remove any warning

labels from the area or inside the

vehicle.

JAGUAR DEALERS/

AUTHORISED REPAIRERS

Jaguar Dealers/Authorised Repairers are

chosen with care. Each is dedicated to

providing a Sales, Service and Spare

Parts facility of the highest standard.

Jaguar are provided with full technical

support from the factory, with

comprehensive training for all their

technicians. Workshops operate to a high

standard and have all the necessary tools

and equipment essential to maintain or

repair Jaguar vehicles.

Genuine Jaguar parts and accessories

Your Jaguar Dealer/Authorised Repairer

can supply you with genuine replacement

parts and accessories which are fully

approved to Jaguar’s original equipment

specification. This will ensure that the

safety and performance of your vehicle is

maintained for your complete peace of

mind.

Please note that fitment of non-genuine

parts may invalidate the vehicle warranty

if a subsequent fault occurs due to fitting

sub-standard replacement parts or

accessories.

Jaguar parts distribution service

Jaguar stock a large number of parts to

keep your vehicle maintained and get you

back on the road as quickly as possible.

Their service is supported by six

strategically positioned Jaguar parts

distribution centres in the United

Kingdom, Germany, Japan, Australia and

two in North America, providing next-day

delivery to the vast majority of worldwide

Dealers/Authorised Repairers.

General Information

Accessories

A full range of Jaguar Engineering

approved accessories, including: safety,

stowage, touring, leisure and lifestyle

products are just some of those available

from your Jaguar Dealer.

Please ask your Jaguar Dealer for an

up-to-date brochure so you can select

your requirements from the latest range.

VEHICLE IDENTIFICATION

Vehicle Identification Number (VIN)

It is essential that the Vehicle

Identification Number (VIN) is quoted in all

correspondence and when ordering

replacement parts.

The number is visible from outside the

vehicle; on a plate in the lower left edge of

the windscreen.

Certification label

Vehicles have the Certification Label

adhered to the left-hand front door hinge

post. Vehicle weights, paint code,

manufacture date and the VIN are shown

on this plate.

Engine number

V6: The number is located on the lower

left-hand side of the cylinder block near

the bedplate.

V8: The number is located on the rear

left-hand side of the cylinder block, either

adjacent to the transmission flange, or on

the left-hand side web towards the rear of

the cylinder block.

Diesel engines:

The number is located on a metal label

attached to the top of the left-hand

camshaft cover.

Transmission number

On a metal label or bar code label

attached to the transmission casing.

REGULAR SERVICING

Each vehicle is given a full Pre-Delivery

Inspection to ensure that all systems

function correctly and that the vehicle

meets its specification.

Owners are responsible for the regular

maintenance and servicing of the vehicle.

Jaguar will be pleased to arrange periodic

servicing and can provide you with details

of tasks carried out at each service

interval.

Failure to implement maintenance at the

recommended intervals could result in

deterioration of vehicle performance and

possible infringement of regulations.

Regular routine maintenance not only

helps to prevent unnecessary

breakdowns and inconvenience, but

enhances the trade-in or resale value of

the vehicle.

JAGUAR DIAGNOSTIC SYSTEM

Many of the vehicle systems are

controlled by complex electronic devices.

Specialist equipment is required to trace

and rectify faults in the systems and to

make sure that only faulty components

are repaired or renewed.

Caution: Severe damage to the

electrical system and electronic

components can occur if any attempt

is made to diagnose faults in the

electrical system using conventional

diagnostic equipment (for example, the

use of test lamps or low impedance

voltmeters). The fitting of any electrical

accessory should only be entrusted to

a Jaguar Dealer/Authorised Repairer.

General Information

PROTECT THE ENVIRONMENT

We must all play our part in protecting the

environment. Correct vehicle usage and

disposal of waste cleaning and lubrication

materials are significant steps towards

this aim.

Avoid using high engine speeds. You will

then protect your engine, reduce fuel

consumption, lower the engine noise level

and help towards reducing the

environmental burden.

Dispose of batteries, tyres, engine, brake

and coolant fluids at your local authorised

waste disposal facilities.

WINDOW TINTING

Caution: Do not have your vehicle

windows tinted with a metal oxide

tinting (for maximum heat reduction

from sun load) if you have a telephone

or navigation system fitted to your

vehicle.

Metal oxide tinting prevents the reception

of the Global Positioning System (GPS)

signals by the antenna, causing the

navigation system to stop functioning.

A non-metal tinting should be used if you

require window tinting and if in doubt,

contact your Jaguar Dealer for advice.

FLOOR MAT RETENTION

Make sure that the driver’s floor mat is

correctly positioned and secured under

the tongues on the retention posts (A,

only one post shown), so that the mat

does not interfere with the operation of

the accelerator, clutch or brake pedals.

In particular, check the position of the mat

when refitting after cleaning or servicing.

General Information

ON-BOARD EVENT DATA

Service data recording

Service data recorders in your vehicle are

capable of collecting and storing

diagnostic information about your vehicle.

This potentially includes information

about the performance or status of

various systems and modules in the

vehicle, such as engine, throttle, steering

or brake systems.

In order to properly diagnose and service

your vehicle, Jaguar Cars Limited and

service and repair facilities may access

vehicle diagnostic information through a

direct connection to your vehicle when

diagnosing or servicing your vehicle.

Event data recording

Other modules in your vehicle - event data

recorders - are capable of collecting and

storing data during a crash or near-crash

event. The recorded information may

assist in the investigation of such an

event. The modules may record

information about both the vehicle and

the occupants, potentially including

information such as:

•How various systems in your vehicle

were operating.

•Whether or not the driver and

passenger seat belts were buckled.

•How far, if at all, the driver was

depressing the accelerator and/or the

brake pedal.

•How fast the vehicle was travelling.

•Where the driver was positioning the

steering wheel.

To access this information, special

equipment must be directly connected to

the recording modules. Jaguar Cars

Limited do not access event data

recorder information without obtaining

consent, unless pursuant to court order or

where required by law enforcement, other

government authorities or third parties

acting with lawful authority.

Other parties may seek to access the

information independently of Jaguar Cars

Limited.

Ignition Switch

Securit y and Loc ks

IGNITION SWITCH

The facia-mounted ignition switch, on the

right-hand side of the steering column,

has four key positions:

When the key is turned back to the OFF

position, the delayed accessory feature

becomes active, so long as the driver’s

and front passenger’s doors are shut and

remain shut. The circuits available in the

auxiliary position remain activated for a

preset timed period.

Position 0: Is the only position in which

the key can be inserted and removed.

When the key is removed the steering

lock is engaged.

Position I: Allows use of some electrical

circuits, for example, radio operation.

Position II: All electrical circuits except

the starter motor are activated. The key

remains in this position when driving.

Position III: The starter motor is operated

for as long as the key is held in this

position, against spring pressure.

TO REMOVE THE IGNITION KEY

Manual transmission vehicles only

Apply the parkbrake and turn the key to

position 0. The key can then be removed

from the switch.

Automatic transmission vehicles only

Automatic transmission vehicles have a

key interlock feature.

Apply the parkbrake, place the gear

selector in (Park) P and turn the key to

position 0.

The automatic transmission gear selector

must be placed in (Park) P before the key

can be removed from the ignition switch.

When the key is removed, the gear

selector will be locked in Park.

GEARSHIFT INTERLOCK

A brake pedal and gearshift interlock

system is incorporated in the automatic

transmission gear selector mechanism.

See page 138.

STEERING COLUMN LOCK

Manual transmission vehicles only

The steering column lock is remote from

the ignition switch and controlled

electronically. The lock will engage when

the key is removed from the ignition

switch while the vehicle is stationary. The

lock will disengage when the key is

placed in the ignition switch.

The lock can be heard as it engages and

disengages.

0Ignition OFF

IAuxiliary

II Ignition ON

III Engine start

Vehicle Security

Vehic le S ec urit y

INTRODUCTION

When leaving the vehicle unoccupied,

remember the following:

•Apply the parkbrake and, with

automatic transmission, move the

gear selector to (Park) P.

•Do not leave children or pets in the

vehicle unattended.

•Do not leave luggage or valuables on

view. Always take your valuables with

you or lock them in the luggage

compartment.

•Remove the ignition key and spare

keys, even when the vehicle is in your

garage.

•Close all windows and lock all doors

securely.

•Park the vehicle where it can be seen.

At night, park in a well-lit area.

•When leaving the vehicle unattended,

for maximum security make sure that

the doors are double-locked.

•Make sure that all key transmitters are

removed from the vehicle before

locking the doors, and that all doors,

the luggage compartment and the

bonnet are closed.

It is important to keep your keys in safe

places at all times. Leaving them in

conspicuous places is an invitation for a

thief to steal them and, consequently,

your vehicle or belongings. Keep them as

secure as you would your wallet or purse,

both at home and away.

IMMOBILISATION SYSTEM

This vehicle is equipped with an

immobilisation system which prevents it

from being driven away by an

unauthorised person.

An electronic device is fitted in the head of

each key, which is programmed to the

vehicle electronics. When the key is

placed in the ignition switch, a

sophisticated decoding process is used

to validate the key transponder code. The

engine cannot be started unless the key is

programmed to the vehicle electronic

systems.

When turning the key in the ignition switch

to start the engine, if the security status

light on the centre console remains

flashing, a fault condition is indicated and

it is possible that the engine will not start.

Please contact a Jaguar Dealer/

Authorised Repairer to investigate the

cause of the light flashing even if the

engine starts.

KEYS

Vehicles are supplied with two key

transmitters, which comprise the key

body integrated with the remote

transmitter. Separate keys, without the

transmitter, are also available from Jaguar

Dealers/Authorised Repairers.

The key operates all the locks on your

vehicle. The key number is recorded on

an adhesive label which is fixed to the

back of each key. Peel off the label and

attach it to the designated area on the

Security Card supplied in the vehicle

literature pack. It is recommended that

the Security Card is kept safely, not in the

vehicle.

Vehicle Security

A maximum of eight keys can be used, of

which up to four may be key transmitters.

All the keys and transmitters used must

be programmed to the vehicle by a Jaguar

Dealer/Authorised Repairer.

RADIO FREQUENCY

APPROVAL

If the type approval of your key transmitter

requires inspection, refer to the table

below.

Type Exam. Certificate Number:

CERT 980154–01

KEY TRANSMITTER

The security system can be controlled

remotely by a radio frequency,

battery-operated, integrated key

transmitter.

Unlocks and disarms the vehicle.

Pressing and holding the button

will globally open the vehicle

windows and sunroof.

Releases the luggage

compartment lock.

Activates the convenience

headlamp feature and sounds the

panic alarm.

Locks and double-locks and

arms the vehicle.

Locks and unlocks the key. To

free the key, press the release

button. When not required, press

and hold the button and fold the key into

the transmitter housing.

Note: Key transmitters will not operate if a

key is in the ignition.

Each integrated key will operate the

ignition switch, and lock the doors and

glove compartment.

Caution: Should a key transmitter be

lost, a new one can be obtained and

programmed to the vehicle by a Jaguar

Dealer/Authorised Repairer, who will

ask for proof of vehicle ownership. It is

advisable to notify a Dealer/Repairer as

soon as a key transmitter is lost or

stolen and have the remaining key

transmitter(s) reprogrammed. This will

then prevent the lost or stolen key

transmitter from being used to disarm

and unlock the vehicle.

Note: Jaguar Dealers/Authorised

Repairers keep a log of all enquiries for

replacement keys and notify Jaguar Cars

Limited of any such requests.

Country Approval Number

All EU and

EFTA

countries

Vehicle Security

Care of key transmitters

The key transmitters must be treated with

care and not exposed to extremes of

heat, dust, humidity or be in contact with

fluids. Do not leave the transmitter

exposed to direct sunlight.

The battery is the only serviceable part.

KEY TRANSMITTER BATTERY

RENEWAL

When the battery needs renewal there will

be a significant decrease in the effective

range of the key transmitter. To renew the

battery, follow the procedure below:

•Insert a small, flat-blade, screwdriver

at an angle of about 45 degrees, into

the slot on the back of the key

transmitter as shown (1). Apply light

pressure to the screwdriver and lever

the screwdriver forward to separate

the two halves of the key transmitter.

Pull the transmitter from the key body.

•Insert the screwdriver into the slot

between the transmitter covers

adjacent to the key stowage area as

shown (2). Apply light pressure to the

screwdriver and lever the screwdriver

downward to separate the covers.

•Unscrew and remove the small screw

(3) and remove the printed circuit

board, taking care not to touch the

battery terminals. Remove the battery

and dispose of it safely.

•Fit a new battery cell, type CR2032

(available from your Jaguar Dealer/

Authorised Repairer), with the side

marked with the positive symbol (+)

downwards in the battery receptacle.

Avoid touching the new battery as

moisture or oil from the fingers can

reduce the life of the battery and

corrode the contacts.

•Replace the printed circuit board

making sure to engage the board

under the securing tabs (4), and

secure with the screw.

•Refit the cover and click into place

with thumb pressure.

•Slide the transmitter back onto the

key body until it clicks into place.

Door Locks

Doo r Loc ks

KEY TRANSMITTER USE

All doors can be locked and unlocked

either remotely using the key transmitter

buttons, or by using the integrated key.

SMART LOCKING

This feature helps prevent locking the key

in the vehicle.

If the driver’s door is open and an attempt

is made to lock the doors using the

driver’s door interior locking lever, all

doors will lock, and then unlock.

If the front passenger door locking lever is

used to lock the doors when the front

passenger door is open, all doors will lock

and then unlock. (The vehicle can only be

locked from the outside by using the key

in the driver’s door lock or remotely using

the key transmitter.)

VEHICLE LOCKING AND

UNLOCKING

To lock the vehicle and set alarm

•Press the lock button on the key

transmitter, or;

•Put the key in the driver’s door lock,

turn the key towards the rear of the

vehicle and release.

The direction indicators will flash once,

the security light on the top of the facia

will start flashing and, after 20 seconds,

the alarm will be set.

If a door, the bonnet or the luggage

compartment lid are open and an attempt

is made to lock the vehicle with the key in

the driver’s door lock, the direction

indicators will flash five times as a

warning that the vehicle is not secure.

If a door is open and an attempt is made

to lock the vehicle with the transmitter,

the direction indicators will flash seven

times as a warning that the vehicle is not

secure.

If the bonnet or luggage compartment lid

are open and an attempt is made to lock

the vehicle with the transmitter, the

direction indicators will flash five times

indicating that the vehicle is not secure.

Door Locks

TO UNLOCK THE VEHICLE AND

DISARM THE ALARM SYSTEM

Using a key transmitter

•Press the unlock button on the key

transmitter.

Single stage unlocking - This unlocks all

doors and the luggage compartment and

turns on the interior lamps.

Two stage unlocking - This only unlocks

the driver’s door and luggage

compartment and turns on the interior

lamps. A second press is required to

unlock all doors.

The direction indicators will flash twice as

unlocking takes place. If a fault exists with

the intrusion sensing system, the

direction indicators will flash five times.

Using a key

•Put the key in the driver’s door lock,

turn the key towards the front of the

vehicle and release.

Single stage unlocking - This unlocks all

doors and the luggage compartment and

turns on the interior lamps.

Two stage unlocking - This only unlocks

the driver’s door and luggage

compartment and turns on the interior

lamps. A second turn of the key is

required to unlock the remaining doors.

European countries and the United

Kingdom only: If the vehicle is unlocked

with a key when it is armed, a ticking

sound will be heard when the driver’s

door is opened. This is a warning to

indicate that the vehicle alarm will activate

after 15 seconds unless the security

system is disarmed by either pressing the

unlock button on the key transmitter or by

inserting the key in the ignition switch.

Note:

•

If any door other than the driver’s door

is opened during this period, before

the vehicle is disarmed, the alarm will

sound.

•

The security system is not disarmed

when unlocking with the key as

additional protection against vehicle

theft.

For all other countries: unlocking the

vehicle using a key in the driver’s door

disarms the alarm system.

Select single or two stage unlocking

The procedure for changing from single

stage to two stage unlocking, or vice

versa, is as follows:

•Press and hold the lock and unlock

buttons on the key transmitter

simultaneously for four seconds.

Note: A double flash of the external

direction indicators will confirm the

required selection. This feature is not

available in the Japanese market.

GLOBAL OPEN AND CLOSE

Global closing

!WARNING:

Make sure that all occupants are kept

clear of the windows and sunroof

aperture.

Key in the driver’s door lock: turn and hold

in the lock position to close all the

electrically operated windows and

sunroof.

Door Locks

DOUBLE-LOCKING

!WARNING:

When the vehicle is double-locked the

doors cannot be opened, either from

inside or outside the vehicle, except

with the correct key or key transmitter.

Breaking a window will not allow a thief

access by opening a door. Therefore,

double-locking should not be used

when persons are inside the vehicle as

they will not be able to vacate, or be

released from the vehicle if an

emergency arises.

Note: It will not be possible to

double-lock the vehicle if any door is

open.

With all doors closed, press the lock

button on the key transmitter twice within

three seconds to double-lock the vehicle

and set the alarm. Alternatively, place the

key in the driver’s door lock, turn the key

towards the front of the vehicle and then

towards the rear within three seconds.

The exterior direction indicators will flash

once as locking takes place and a longer,

second flash, as double-locking takes

place.

DRIVE-AWAY DOOR LOCKING

This feature is an additional occupant

safeguard, which locks all the doors and

the luggage compartment after a journey

has been started.

For the feature to operate, the ignition

switch must be in position II, the

parkbrake released and the vehicle

moving forward at a speed above 5 km/h

(3 mph).

Note: For vehicles with automatic

transmission, the gear selector lever must

be moved out of the (Park) P or (Neutral) N

position.

The doors will remain locked, even when

the vehicle is stopped, unless the driver or

front passenger unlocks a door. A rear

passenger can only unlock their own

individual door.

If a door is opened during a journey, the

doors will automatically lock again when

the vehicle starts to move.

All vehicles have the drive-away door

locking feature installed during

manufacture. This feature can be

disabled, or reinstated, by a Jaguar

Dealer/Authorised Repairer, if required.

Door Locks

CHILD SAFETY LOCKS

Child safety locks are fitted to the rear

doors. The operating lever is fitted above

the door lock mechanism.

To operate: Open the door and move the

lever a quarter-turn. This immobilises the

interior handle.

The door can then only be opened using

the exterior door handle.

Open the door and move the lever to its

original position to remove the child lock

feature.

Luggage Compartment Locks

Luggage Co mpart ment Loc ks

LID LOCKING AND

UNLOCKING

To open the luggage compartment:

•Press the luggage compartment lid

release switch (1) on the facia

switchpack, or;

•Press the luggage compartment

button (2) on the key transmitter, or;

•With the vehicle unlocked, press the

release button (3) on the compartment

lid.

Note: An ignition key can be used to open

the luggage compartment lid release lock

(4), (turn clockwise to release), but

opening with the key when the vehicle is

armed will cause the alarm to sound. Use

a transmitter, or place the key in the

ignition, to turn the alarm off if it sounds as

a result of opening with a key.

If the vehicle alarm system is armed and

the luggage compartment is opened

using the key transmitter, the alarm will

not sound. The system will be rearmed

when the lid is closed, provided the

vehicle has not been disarmed.

Neither the luggage compartment lid

release switch on the facia switchpack,

nor the lid release button will operate

when the vehicle is armed.

Alarm Systems

Alarm Syst ems

ALARMS AND AUDIBLE

SIGNALS

Note: In certain markets, legislation

prohibits the use of audible confirmation

signals. In such cases, the sound source

has been removed from the system.

AUDIBLE SIGNALS

Two horn chirps will sound if an attempt is

made to lock the vehicle if a door is not

fully closed. There will be no audible

signal if the vehicle is locked when the

bonnet or luggage compartment is not

fully closed.

European countries and United

Kingdom only

If the vehicle is unlocked with a key when

it is armed, a ticking sound will be heard

when the driver’s door is opened. This is

a warning to indicate that the vehicle

alarm will activate after 15 seconds unless

the security system is disarmed with

either the key transmitter or by inserting

the key in the ignition switch.

If the vehicle is unlocked with a key when

it is armed and any door, other than the

driver’s door, is opened, the alarm will

sound immediately.

Error signal

The direction indicators will flash five

times whenever the key is out of the

ignition and one of the following

conditions is present:

•If any door is open when an attempt is

made to lock the vehicle by inserting a

key in the driver’s door lock.

•If, after 15 seconds from opening the

driver’s door with a key (European

countries and United Kingdom only),

the key is not inserted into the ignition

switch.

•The luggage compartment or the

bonnet is not properly closed when an

attempt is made to lock the vehicle,

either by inserting a key in the driver’s

door lock or by using the key

transmitter.

•If there is an electrical failure within

the intrusion sensing or inclination

sensing systems (where fitted), and an

attempt to disarm the security system

is made.

The direction indicators will flash seven

times whenever the key is out of the

ignition and one of the following

conditions is present:

•If any door is open when an attempt is

made to arm the security system

using the key transmitter.

•If either of the front doors is open

when an attempt is made to lock the

vehicle using the lock levers on the

front two doors.

FULL ALARM

Once armed, any of the following

circumstances will create a full alarm

state; sounding the horns and flashing the

direction indicators:

•Opening a door, luggage

compartment lid (except with

transmitter) or bonnet.

•Intrusion sensors detect movement in

the passenger area.

Alarm Systems

•Using a key in the ignition switch

which is not programmed to the

vehicle.

•If the inclination sensor (if fitted) is

activated.

•Any attempt is made to remove the

radio.

SECURITY SYSTEM

The security system has been designed

for:

•Prevention of theft of the vehicle.

•Prevention of theft of items from the

vehicle.

•Personal security.

The security system is integrated with the

vehicle electronics and engine

management systems making it far more

difficult for a thief to penetrate and steal

the vehicle.

BATTERY RECONNECTION

If the battery has been disconnected and

is subsequently reconnected, the alarm

system will rearm as the battery is

reconnected.

Note: Make sure that a key transmitter is

available to disarm the system when

reconnecting the battery. Either press the

unlock button on the transmitter, or insert

the key in the ignition switch.

REMOTE HEADLAMP

CONVENIENCE

By pressing the key transmitter button

with the dipped headlamp symbol once,

the headlamps will come on for 25

seconds, unless the headlamp button is

pressed again, or if the key is inserted in

the ignition switch and turned to

position II.

BATTERY-BACKED SOUNDER

In certain markets a separate,

self-contained, battery-backed sounder

is fitted. This device will sound the full

alarm if the vehicle alarm is activated, or if

the vehicle battery or the sounder is

disconnected when the security system is

armed.

INTRUSION SENSING

When the vehicle is armed and

double-locked, movement within the

vehicle interior will activate the alarm. The

luggage compartment can be unlocked,

using the key transmitter button, without

sounding the alarm. When the security

system is disarmed the intrusion sensors

are also disarmed.

INCLINATION (TILT) SENSING

PROTECTION

This feature protects against

unauthorised towing away or jacking up.

When the vehicle is double-locked and

armed, any tilting of the vehicle, such as

jacking or lifting, will activate the alarm.

Note: If the vehicle is being transported

by road, rail or sea, the vehicle should not

be double-locked. This prevents the

inclination system from being armed and

sounding the alarm as the vehicle pitches

and rolls.

When the security system is disarmed the

inclination sensor is also disarmed.

Alarm Systems

PANIC ALARM

When in, or near the vehicle, the panic

alarm can be set off to deter a possible

offender. For this feature to operate, the

key must not be in the ignition switch.

Pressing the headlamp convenience and

panic button on the key transmitter three

times within three seconds will activate

the Panic Alarm.

The alarm is stopped by inserting the key

in the ignition switch or by pressing the

headlamp convenience and panic button

on the key transmitter three times within

three seconds.

Garage Door Opener

Garage Do or Ope ner

GARAGE DOOR OPENER

TRANSCEIVER

The garage door opener transceiver is

located in the roof console. This

transceiver can be programmed to

transmit the radio frequencies of up to

three different transmitters, which can be

used to activate garage doors, entry

gates, home lighting, security systems, or

other radio frequency operated devices.

Although this section mainly describes

the procedures for a garage door opener,

it also equally applies to the previously

mentioned applications.

In some countries this feature is also

known as the HomeLink® Universal

Transceiver.

For further information, or for assistance,

contact your Jaguar Dealer/Authorised

Repairer, or the supplier, by phone or via

the internet. For details, see Information

and Assistance on page 53.

!WARNING:

•Do not use the transceiver with any

garage door opener that lacks the

safety stop and reverse feature, as

required by safety standards. A

garage door opener which cannot

detect an object, signalling the

door to stop and reverse, does not

meet current safety standards.

Using a garage door opener

without these features increases

the risk of serious injuries or death.

•When programming the transceiver

to a garage door opener or entry

gate, make sure that people,

vehicles and objects are out of the

way to prevent potential harm or

damage, as the gate or garage door

will activate during the programme.

•This device may suffer from

interference if operated in the

vicinity of a mobile or fixed station

transmitter. This interference is

likely to affect the hand-held

transmitter as well as the in-car

transceiver.

Garage Door Opener

Before programming

Caution: When programming a garage

door opener or entry gate, that may

require you to press and re-press the

hand-held transmitter (cycle), unplug

the device during the cycling process

to prevent possible motor failure.

It is recommended that for best results, fit

a new battery to the hand-held transmitter

of the garage door opener (or other

device) before programming. If your

garage door opener receiver (located in

the garage) is equipped with an antenna,

make sure that the antenna is hanging

straight down.

To erase all programming

For first time programming, make sure

that the engine is switched off:

1. Turn the ignition switch to position I.

2. Press and hold the two outer buttons

on the garage door opener in the

overhead console. Keep the buttons

pressed; the indicator lamp will

illuminate. The indicator lamp is part

of the middle button in the garage

door opener in the overhead console.

3. Release the buttons when the lamp

begins to flash (this will take

approximately 20 seconds).

All memories in the garage door opener

have now been cleared.

Note: Do not perform this procedure

when programming the additional garage

door opener buttons.

Programming the vehicle

Ensuring that the engine is switched off:

1. Turn the ignition switch to position I.

2. Hold the end of the original garage

door opener hand-held transmitter

approximately 50 to 150 mm (2 to 6

inches) away from the transceiver in

the roof console, keeping the

indicator lamp in view.

3. Using both hands, simultaneously

press and hold both the desired

garage door opener button on the

overhead console and the hand-held

transmitter button. Keep both buttons

pressed. The lamp will flash slowly at

first and then change to a fast flash.

When the indicator lamp flashes

rapidly, release both buttons. The

rapid flashing lamp indicates

successful programming.

Garage Door Opener

4. If, after 60 seconds, the indicator lamp

does not flash rapidly, release both

the transceiver and the hand-held

transmitter buttons and repeat the

procedure starting with Step 2.

Position the hand-held transmitter at

a different angle and/or distance.

5. Press and hold the programmed

overhead console garage door opener

button and observe the indicator

lamp.

•If the indicator lamp is solid or

continuous, programming is complete

and your device should activate when

the garage door opener button is

pressed and held for approximately

one to two seconds and then

released.

•If the indicator lamp blinks rapidly for

two seconds and then turns a solid or

continuous light, proceed with the

following programming instructions

for rolling-code device equipment.

Note: To programme additional

garage door opener buttons, begin at

Step 2.

Rolling-code device equipment

programming

Note: A second person may make the

following steps quicker and easier, as

once the button has been pressed there

are only 30 seconds in which to complete

Step 3.

1. At the garage door opener receiver

(motor head unit) in the garage, locate

the learn or smart button or switch.

Note: The name of the button or

switch may vary between

manufacturers.

2. Press and release the learn or smart

button.

3. Return to the vehicle and firmly press

and hold the programmed garage

door opener button for two seconds

and release.

4. Repeat the press and hold and

release sequence three times to

complete the training process.

The garage door opener in the overhead

console should now activate the

rolling-code device.

Reprogramming a single garage door

opener button

To programme a device to a previously

trained button:

1. Press and hold the desired

pre-programmed garage door opener

button for at least 20 seconds, but no

longer than 30 seconds, until the

indicator lamp begins to flash.

2. Without releasing the overhead

console button, position the

hand-held transmitter approximately

50 to 150 mm (2 to 6 inches) away

from the transceiver in the overhead

console, keeping the indicator lamp in

view.

3. Carry out Step 3 of Programming the

Vehicle on page 51.

Entry gate programming

The technology of some entry gates

requires you to press and re-press (cycle)

the hand-held transmitter button every

two seconds during programming.

Continue to press and hold the desired

overhead console button while you cycle

your hand-held transmitter, until the

indicator lamp flashes rapidly.

Garage Door Opener

APPROVALS FOR RADIO

TRANSCEIVER

Country Approval Number

Country Approval Number Country Approval Number

TA Exempt

No number required

CAN: 2145 101 790A

WT/3176/2000

129/9520/2001

ENG 3/2/RFS29

Garage Door Opener

TA Exempt

FCC: K8597 R315

N/A

TA Exempt

Country Approval Number Country Approval Number

Occupant Protection

Before Driving

SEAT BELTS

The use of front and rear seat belts is

mandatory in most countries. Using seat

belts saves lives. They should be worn by

all occupants whenever the vehicle is in

use, for maximum protection. Lap and

shoulder inertia reel seat belts are

provided for both front occupants and

three rear seat positions.

The inertia operating mechanism of the

seat belts allows the wearers to move

their upper bodies to reach various

controls. The seat belts lock automatically

with accelerated body movement, or in

the event of emergency braking.

The seat belt assemblies incorporate

additional safety devices. All have belt

pre-tensioners and the front belts also

have force limiters. These devices provide

increased protection in the event of a

severe frontal impact.

The pre-tensioners operate in conjunction

with the airbags as part of the Advanced

Restraints Technology System (ARTS),

refer to page 60.

Beltminder

The beltminder feature is a supplemental

warning to the seat belt warning function,

see page 95. This feature provides

additional reminders to the driver that the

driver’s and or, passenger’s seat belt is

unbuckled, by intermittently sounding a

chime and illuminating the seat belt

warning lamp in the instrument pack.

Note: Not all countries have the warning

chime.

Front belt height adjustment

To adjust the front seat belt heights, press

the locking button and slide the

anchorage so that the seat belt webbing

passes over the shoulder without pulling

against the neck. Release the button and

check that the anchorage point is locked.

Always check the anchorage point after

the seat has been adjusted to ensure that

the belt is correctly positioned.

Occupant Protection

!WARNING:

• Belts should not be worn with the

straps twisted.

• Always make sure that the webbing

is midway between the neck and

the edge of the shoulder.

• Each seat belt assembly must only

be used by one occupant; it is

dangerous to put a seat belt around

a child being carried on the

occupant’s lap.

• Seat belts are designed to bear

upon the bony structure of the body

and should be worn low across the

front of the pelvis or the pelvis,

chest and shoulders, as applicable;

wearing the lap section of the belt

across the abdominal area must be

avoided.

• Seat belts should be adjusted as

firmly as possible, consistent with

comfort, to provide the protection

for which they have been designed.

A slack belt will greatly reduce the

protection afforded to the wearer.

• Care should be taken to avoid

contamination of the webbing with

polishes, oils and chemicals, and

particularly battery acid. Cleaning

may safely be carried out using mild

soap and water. The belt should be

replaced if webbing becomes

frayed, contaminated or damaged.

• It is essential to replace the entire

assembly after it has been worn in a

severe impact, even if damage to

the assembly is not obvious.

• No modifications or additions

should be made by the user, which

will either prevent the seat belt

adjusting devices from operating to

remove slack, or prevent the seat

belt assembly from being adjusted

to remove slack.

• Should the seat belt not retract and

remain at its static length, consult

your nearest Jaguar Dealer/

Authorised Repairer immediately.

• Replacement or renewal of seat

belts should be carried out by

Jaguar Dealers/Authorised

Repairers only.

Occupant Protection

Pregnant women

!WARNING:

• Pregnant women must wear a

correctly positioned seat belt; it is

safer for the mother and unborn

child.

• Never wear just the lap strap of a

lap and shoulder diagonal seat belt

and never sit on the lap strap using

just the shoulder strap. Both of

these actions are extremely

dangerous and may increase your

risk of serious injuries.

There are many ways that the seat belt

can be misused for the sake of comfort.

However, there is only one way of wearing

it safely.

The lap strap should be fitted comfortably

across the hips, low beneath the pregnant

abdomen. The diagonal part of the seat

belt should be placed between the

breasts, and worn above and to the side

of the pregnant abdomen.

Never place anything between you and

the seat belt in an attempt to cushion the

impact in the event of an accident. It can

be dangerous and reduce the

effectiveness of the seat belt in preventing

injuries.

Always wear seat belts without slack or

twists, since slackness in a seat belt

drastically reduces the effectiveness of

the belt and the level of protection it can

provide. For optimum protection, the seat

belts should fit tightly around the body.

Do not recline the front seats excessively,

as the belts provide maximum protection

when the seats are in the near upright

position.

Occupant Protection

ADVANCED RESTRAINTS

TECHNOLOGY SYSTEM (ARTS)

!WARNING:

The airbag is a supplementary restraint

system that provides ADDITIONAL

protection in a severe impact only - it

does NOT replace the need to wear

seat belts. For maximum safety

protection in all crash situations, a seat

belt must be worn.

Provided occupants are correctly

seated, with seat belts worn, the

airbags will provide additional

protection to the chest and facial areas

of the front seat occupants in the event

of a vehicle receiving severe frontal

impact, and also to the head and side

of the body facing the impact if a

severe side collision occurs.

Important information

To do their life-saving job, airbags must

inflate rapidly and with considerable

force. There is, therefore, a risk of death

or serious injuries such as fractures, facial

and eye injuries or internal injuries,

particularly to occupants who are not

properly restrained by seat belts or sitting

correctly when the airbag deploys.

The risk of injuries from a deploying

airbag, is greatest close to the trim

covering the airbag.

The whole sequence of events from

sensing the impact to full inflation of the

bag takes place in a fraction of a second.

After airbag deployment, it is normal to

notice a smoke-like, powdery residue or

smell the burnt propellant. This may

consist of cornstarch, talcum powder or

sodium compounds that result from the

combustion process that inflates the

airbag.

Small amounts of other chemicals may be

present which may irritate the skin and

eyes, but none of the residue is toxic.

While the system is designed to help

reduce serious injuries, it may also cause

minor burns, abrasions, swelling or

temporary hearing loss.

!WARNING:

•No objects, whatsoever, should be

attached to the centre cover of the

steering wheel, the passenger facia

panel, the sides of the front seats or

the interior trim immediately above

the door openings. Do not put

anything on or over the airbag

inflation area. Placing objects on or

over the airbag inflation area may

cause those objects to be propelled

by the airbag into your face and

torso causing serious injuries.

•Occupants with disabilities that

may require the vehicle to be

modified must contact a Jaguar

Dealer/Authorised Repairer before

any modifications are made.

•Safety experts recommend a

minimum distance of at least 254

mm (10 inches) between an

occupant's chest and a front

airbag.

Occupant Protection

• Children 12 years old and younger

can be killed or seriously injured by

the airbag. The rear seat is the

safest place for children.

• Do not try to put an adult seat belt

around two children.

• Several airbag system components

get hot after inflation. Do not touch

them after they have deployed.

• If an airbag is inflated, the airbag

will not function again and must be

renewed immediately. If a new

airbag is not fitted, the unrepaired

area will increase the risk of injuries

in a collision.

Warning label

Airbag warning information is printed on

the driver’s and passenger’s sun visor

(see illustration).

Airbag fault warning indicator

The airbag warning indicator in

the driver’s instrument pack will

be lit for approximately six

seconds when the ignition is turned on.

If the indicator remains on or flashes, it

indicates a fault within the electrical

circuits. Report the fault to a Jaguar

Dealer/Authorised Repairer immediately.

It is safe to drive the vehicle; however, in

an accident the airbags may not operate.

The following components are monitored

by the air bag system:

• Driver’s dual stage airbag (steering

wheel)

• Driver’s thorax airbag

• Driver’s pre-tensioner

• Driver’s side crash sensor - 2 off

• Passenger’s dual stage airbag

• Passenger’s thorax airbag

• Passenger’s pre-tensioner

• Passenger’s side crash sensor - 2 off

• Passenger’s seat occupancy sensor

• Restraint control module

Airbag warning indicator information is

shown on page 96.

IR BA

AIR BA G

Occupant Protection

Air bag deployment

The airbag supplementary restraint

system incorporates front, side thorax

and side head airbags for the driver and

front passenger and side head bags for

rear seat passengers. These are indicated

by the word AIRBAG on the trim. They are

used in conjunction with the seat belts to

help protect occupants from upper body

(thorax) and head injuries.

1. The front passenger airbag is located

in the facia panel immediately in front

of the passenger seat.

2. The driver front airbag is located in the

centre of the steering wheel.

3. Curtain airbags are fitted on each

side, above the front and rear doors.

4. Thorax side airbags are fitted within

the outboard bolsters of both front

seats, and are identified by labels.

The airbags and seat belt pre-tensioners

are electrically controlled by the

Advanced Restraints Technology System.

Occupant Protection

Both front airbags use a dual inflation

technology which means, if activated, the

bag(s) will deploy at either a normal or

reduced level of inflation, depending on

crash severity. Lower inflation level is also

selected if the restraint system senses

that the driver is too close to the steering

wheel.

Various sensors determine the direction

and severity of an impact and the

presence and position of front seat

occupants, see page 66. The system

analyses this information then deploys

only the appropriate airbag(s), e.g. the

side airbags where the impact is on that

side only.

Airbags will not deploy at very low speeds

or in rear impacts.

Front protection

With a front impact of sufficient force,

the restraints system will trigger the front

airbag(s) and seat belt pre-tensioners,

which immediately tighten the seat belts.

For front occupants, the seat belt then

slackens with increasing chest load,

allowing the head and chest to gradually

come into contact with the inflated airbag.

The airbag absorbs the remaining energy

of the impact and then deflates rapidly via

vent holes.

Front airbags are designed to inflate in

frontal and near-frontal collisions, not low

speed impacts, rollover, side impact or

rear impact.

Where the airbags are not deployed,

protection is provided by the seat belts.

Occupant Protection

Side protection

!WARNING:

To ensure that the side airbags are fully

effective:

• DO NOT sit too close to, or lean

against the door trim. The side

airbag could injure you as it deploys

from the side of the seat.

• DO NOT lean out of the window

aperture.

• Only use JAGUAR APPROVED

accessories (e.g. seat covers).

The side protection system utilizes four

airbags: two mounted in the front seats,

and two curtain airbags located just

above the front and rear door openings

under the headlining trim.

When the seat-mounted thorax airbag

inflates upon a vehicle side impact, it

breaks through the seat bolster stitching,

protecting the side of the rib cage of the

driver or front seat passenger.

When the curtain airbag inflates upon a

vehicle side impact, it breaks through the

headlining and deploys downwards,

giving head protection to the front and

rear seat occupants on the impact side.

The curtain airbag on the front passenger

side is always deployed in a side impact,

even if the front passenger seat airbags

are deactivated. This is to maintain

protection for a rear occupant.

Seat-mounted thorax and curtain airbags

are designed to inflate in a side impact

collision, not rollover, rear impact, frontal

or near-frontal collisions, unless the

collision causes sufficient lateral

deceleration.

The airbags, in combination with the seat

belts, can help reduce the risk of severe

injuries in the event of a significant side

impact collision.

Occupant Protection

Rear impact protection

Both front seats have active, energy

absorbent back restraints which, with

correctly positioned head restraints,

reduce the risk of neck and spinal injury

(whiplash) in the event of a rear impact.

When activated, the seat back restraints

automatically move back and recline,

altering the occupants’ posture and

reducing relative motion between the

body and head.

The degree of back restraint movement in

a rear collision depends on the angle,

speed and nature of the colliding vehicle.

After activation, the whiplash protection

mechanism will not work again and the

seat must be serviced by a Jaguar

Dealer/Authorised Repairer to restore the

protective function.

Note: The amount of back restraint

movement depends on the severity of the

impact and for a minor collision there may

be no apparent change to the seat, even

where the protective system has been

activated. After any rear collision,

therefore, the seat must always be

inspected by a Jaguar Dealer/Authorised

Repairer.

!WARNING:

• For optimum protection, the driver

and passenger should sit in the

centre of the seat with the head as

close as possible to the head

restraint.

• Do not wedge objects (e.g.

luggage) between the front seat

back reststraint and the rear seat

cushion.

• After a rear collision, the front seats

must be inspected by a Jaguar

Dealer/Authorised Repairer, even

where there is no apparent damage

or change to the seat.

• Do not attempt to service or tamper

with the seat recliner mechanism.

• Adjust the head restraint so that it

is just behind your head and never

behind your neck.

Occupant Protection

Occupancy sensing

The front passenger seat is monitored by

ultra-sonic sensors, see above, and a

seat weight sensor to determine the

presence, weight and position of the front

passenger. In certain conditions, e.g.

where no passenger is present, the

appropriate airbag(s) will be deactivated.

In a collision these airbags would not be

deployed.

!WARNING:

It is important that the passenger

position sensors are not obscured in

any way which could affect airbag

deployment, e.g. fitting non-approved

accessories.

The occupancy sensor operates as

follows:

*It is possible to receive an intermittent

indicator lamp see page 67, with an

empty seat condition. This is part of the

system’s adaptive behaviour, and does

not affect the status of the passenger

airbag. However, if the indicator lamp

becomes permanently illuminated when

the seat is definitely empty and the seat

belt is unbuckled, then contact your

nearest Jaguar Dealer/Authorised

Repairer immediately.

•If the seat is empty and the seat belt

unbuckled, the front airbag will not be

activated and the AIRBAG indicator

lamp will not be illuminated.

•If the seat is occupied by; for

example, a small child or object with

the seat belt buckled, the front airbag

will not be activated and the indicator

lamp will be illuminated.

Passenger

occupancy

status

Passenger

airbag

status

Indicator

lamp

active

Completely

empty

Deactivated No*

Low weight

occupant/

object

Deactivated Yes

Heavy

occupant/

object

Activated No

Passenger

head too

close to

airbag door

Deactivated Yes

Occupant Protection

•If the seat is occupied by a larger child

or adult, the front airbag will be

activated and the AIRBAG indicator

lamp will not be illuminated.

•If the passenger adopts a posture

(e.g. leaning very far forward) which

could cause injuries from an inflating

airbag, the front passenger airbag will

not be activated and the AIRBAG

indicator lamp will be illuminated.

Note: The occupancy sensing system is

designed to confirm that a front

passenger is properly seated as

recommended:

•

Always sit centrally in the seat,

remaining in contact with the seat

back, which for comfort should be

rearwards of the vertical position.

•

Adjust the seat to be as far back from

the facia as is practical.

•

Always wear seat belts.

The seat adjustment controls are

described on page 76.

Airbag deactivation indicator lamp

The AIRBAG indicator lamp on the

passenger facia is associated with the

deployment conditions for front seat

passenger airbags only.

Whenever the AIRBAG indicator lamp on

the passenger facia is illuminated, the

front passenger airbag will not be

deployed in the event of an impact. Where

the airbags are not deployed, protection

is provided by the seat belts.

Airbag disposal

!WARNING:

Do not attempt to service, repair or

modify the airbag system, or its

electrical fuses. All work on the airbag

system, including renewal after

deployment, must be carried out by a

Jaguar Dealer/Authorised Repairer.

Instructions can be obtained from a

Jaguar Dealer/Authorised Repairer.

In the event of the vehicle being

dismantled, airbag module removal and

disposal MUST be made by a qualified

person.

Child Safety

Child Saf et y

GENERAL SAFETY

INFORMATION

Jaguar Cars Limited strongly

recommends that at all times children

should be carried in the rear seats.

!WARNING:

•Children must be restrained by a

child safety restraint that is suitable

for their weight and size.

•Extreme hazard! Do not use a

rearward facing child restraint on a

seat protected by an airbag in front

of it!

•DO NOT install a rearward-facing

child seat in the front passenger

seat position since deployment of

the passenger facia airbag could

cause death or serious injury to the

child.

This is emphasised by the label

displayed on the end of the facia on

the front passenger side, as shown

in the illustration.

If, however, you have no alternative

but to place a child in the front

passenger seat, use only a

forward-facing child seat with the

passenger seat set fully rearward

and in its lowest position.

•Always follow the fitting

instructions supplied with the

appropriate child restraint system.

It is important to read and

understand all the information

contained in this handbook relating

to child safety before carrying a

child in your vehicle.

If you are unsure about any aspect

of this information, contact your

Jaguar Dealer/Authorised Repairer.

In many countries, legislation governs

how and where children should be carried

when travelling in a vehicle.

It is the responsibility of the driver to

comply with all regulations in force in the

country where the vehicle is being used.

Holding a baby or child in a person’s arms

is not a substitute for a child restraint

system. Do not use a seat belt to restrain

more than one person.

In an accident, a baby or child held in a

person’s arms can be crushed between

the vehicle’s interior and a restrained

person.

Child Safety

The child can also be injured by hitting the

interior, or by being thrown from the

vehicle during a sudden manoeuvre or

impact.

Injuries can also be caused if the baby or

child is allowed to ride on the seat

unrestrained. Other occupants should

also be properly restrained to help reduce

the chance of injuring the child.

Do not allow children to stand in the

space between the front seats, or on the

passenger seats.

!WARNING:

•Do not put an adult seat belt around

two children.

Summary of the law

In all countries there are regulations

governing the use of restraint systems for

children and babies. Infants and children

must be seated in an approved safety

device, which is suitable for the weight

and size of the child. A child restraint must

meet the regulations enforced in the

country where it is used and the approval

number and the weight category have to

be clearly labelled on the seat. Generally,

the following law applies:

•Children under three years of age

must be secured in an appropriate

child restraint.

•Children aged 3 to 11 years and less

than approx. 1.35 metres (approx.

4.43 feet) in height should be secured

in an appropriate child restraint if

available. Otherwise, the adult seat

belt must be used.

•For children age 12 or 13 years, or a

younger child approx. 1.35 metres

(approx. 4.43 feet) or more in height,

the adult seat belt must be used.

•In all three cases above, it is the

responsibility of the driver to make

sure that the safety of children

travelling with them is adequately

provided for.

•From 14 years of age, all passengers

should use the adult seat belts

provided and it is their own

responsibility to do so.

Caution: Failure to comply with the law

could result in prosecution and could

affect insurance cover. Remember the

driver has responsibility for other

passengers under 14 years and the

careful stowage of luggage and loose

items.

Child restraint systems

Look for the following when selecting a

child restraint system:

•It should have a label certifying that it

meets the applicable Regulations.

•Carefully read the instructions

supplied with the restraint. Be sure

you understand them and can install

and use the device properly and

safely in the vehicle.

•Make sure that the child restraint

system is appropriate for the child’s

weight and development refer to page

71.

Infant safety

Babies and small children who cannot sit

up by themselves should be carried in an

approved rear facing infant carrier, which

should always be installed in a rear

seating position.

Child Safety

Child safety seating and positioning

Suitability of each passenger seat position for the carriage of children up to 12 years

of age or 1.35 m (approx. 4.43 feet) tall and the installation of child restraint systems.

Mass Group (with approximate age)

as indicated on child restraint

Vehicle Seating Position

Front

Passenger*

Rear

Outboard

Rear

Centre

0= Up to 10 kg (22 lb) (birth to 10 months) X U U

0+ = Up to 13 kg (28 lb) (birth to 18 months) X U U

I= 9 to 18 kg (20 to 40 lb) (9 months to 5

years)

UF U & L U

II = 15 to 25 kg (33 to 55 lb) (4 to 7 years) U U U

III = 22 to 36 kg (48 to 80 lb) (6 to 12 years) U U U

Key:

USuitable for Universal category restraints approved for use in this mass group.

UF Suitable for forward-facing Universal category restraints approved for use in

this mass group.

LSuitable for particular vehicle specific child restraint given below. These

restraints may be of the specific-vehicle, restricted or semi-universal

categories.

XSeat position not suitable for child restraint in this mass group.

Note: * When installing child restraints, Jaguar recommends that the front passenger

seat be positioned fully rearward with the cushion height adjustment set to front fully

down and rear fully up. Also the back restraint must be set as far forward as possible,

or adapted to the child restraint, as required. The seat belt upper adjustable

anchorage should also be set to its lowest position.

The safest place to transport children is the rear seat.

Type L Child Restraint = Britax Roemer Duo Plus ISOFIX Group 1 restraint –

specific-vehicle restraint approved by Jaguar Cars Limited.

Child Safety

CHILD SEATS

Choosing a suitable child seat

Before you buy a child seat, it is important

to note that your child’s weight, rather

than age, determines the type of seat that

is required.

Child safety seats are divided into five

categories, by the weight range for which

they are suitable. Refer to page 70.

Jaguar recommends that a rear-facing

seat with a harness is used for as long

as your infant’s development allows.

Do not use a forward-facing seat until

your child is above the minimum weight of

9 kg (20 lb) and able to sit up unaided. Up

to the age of two, a child’s spine and neck

are not sufficiently developed to avoid

injuries in a frontal impact.

It is also important to consider how you

plan to use the child seat. For longer

journeys, a reclining seat may offer added

comfort and support for a sleeping child,

while a lightweight design may be easier

to lift in and out of the vehicle.

It is also worth noting that some children

are more suited to a harness-style seat

than a booster seat during their toddler

years.

We strongly advise that you do not buy or

use a second-hand child seat. The seat

may have been used inappropriately, or

involved in an accident. In such

circumstances, the seat may not protect

your child.

Because child seats vary in shape, certain

designs may be more stable when

mounted on the outer rear seating

positions, rather than in the centre.

Always check that the child seat can be

mounted securely in the required

position: if in doubt, speak to your Jaguar

Dealer/Authorised Repairer.

Fitting the child seat

Always use and keep the manufacturer’s

fitting instructions.

The following checks should always be

carried out:

•Fit the child seat in the correct

position and secure with the seat belt

in accordance with the

manufacturer’s instructions.

•Regularly check and refit the child

seat to make sure there is no slack in

the installation.

•Make sure the child seat is fitted firmly

to the car seat. There should not be

excessive forward or sideways

movement.

•The seat belt must not be twisted and

the buckle must not rest on the child

seat frame, as it may snap open in an

accident.

•Never modify the seat or install it

differently to the instructions.

Always secure an unoccupied child seat

safely. In an accident, an unsecured child

seat may pose a risk to the vehicle’s

occupants.

Booster seats

If a booster seat is used, position the lap

section of the adult seat belt over the

child’s pelvis. The diagonal seat belt

should rest on the child’s shoulder, not

the neck.

Child Safety

CHILD RESTRAINTS

Safe use of child restraints

Make sure that there is no slack in the

webbing and the restraint fits the child

snugly across the rib cage and hips.

These are the parts of the body most able

to take the force of an impact.

•Make sure that the path and position

of an integral harness across the

shoulders is appropriate for your

child’s development – consult the

manufacturer’s instructions.

•The lap strap should pass across the

top of the child’s thighs, bearing on

the pelvis, not the abdominal area.

•Adjust the harness every time, so that

one or two fingers only can be

inserted between the child and

harness. Different clothing on a child

can make a difference to the correct

fitting of the harness.

•Make sure the harness webbing is not

twisted.

•Never modify the seat harness or

buckles, as this may affect the quick

release mechanism.

•Always secure your child correctly,

even for the shortest journey.

•Follow the seat manufacturer’s

instructions for harness adjustments.

Make sure the child seat is securely fitted,

and follow the check list on page 75.

ISOFIX child restraint system

Your vehicle is fitted with a set of ISOFIX

brackets that allow the ISOFIX child seat

to be secured directly and easily to the

vehicle body without the use of adult seat

belts.

Many injuries to children in accidents are

caused by the incorrect fitting and

tensioning of the adult seat belts, which

are normally used to secure child seats.

Child Safety

The ISOFIX system reduces the likelihood

of incorrect fitting and is also quicker and

simpler to use.

The ISOFIX system uses two anchorage

loops and a top tether bracket fixed to the

vehicle body. The ISOFIX child seat has

two retractable lower catches that lock

onto the anchorage loops and a strap that

clips onto the top tether bracket. The

child seat has a quick release mechanism

to allow it to be removed easily.

This symbol on the seats

indicates the location of the

ISOFIX lower anchorages.

The anchorage loops are accessible

through two trimmed apertures at the

back of the rear seat cushion. The

anchorage loops are located

approximately 60 mm (2.5 inches) below

each label. Pull back the side panel of the

trim as indicated, see illustration on page

72, to reveal the aperture and the

anchorage loops.

The seat is a forward-facing Group 1 seat,

approved to ECE R44.03 and suitable for

children weighing between 9 – 18 kg (20

to 40 lb).

To ensure that the ISOFIX child seat is

installed safely, read all the information

provided in this section.

Fitting the ISOFIX plastic guides

Open up the trimmed aperture to expose

an anchorage loop (see previous page).

Locate the cut-outs at the rear of the

guide onto the anchorage loop and push

the guide fully in until it clips in place on

the anchorage loop.

Fit the second guide.

If correctly fitted, the guides will normally

remain in place when the child seat is

removed.

Pull out the guides to remove.

The plastic guides make it easier to fit the

child seat using the ISOFIX anchors and

avoid damage to the seat cover. The

plastic guides must be removed before

folding down the seat backs.

Always make sure that the child seat

anchorage legs and the vehicle

anchorage loops are kept clean and free

of dirt.

Installing the ISOFIX seat

Caution: Always follow the

manufacturer’s instructions supplied

with the ISOFIX child seat. The

following is to be considered only as a

guide.

ISOFIX seats can only be installed in the

rear outboard seating positions. If

necessary, remove the head restraint.

Fit the seat as follows:

1. Push the adult seat belt buckles into

their stowage recesses, to make sure

they do not interfere with the fitment

of the child seat.

Child Safety

2. Make sure there is nothing

obstructing the seat mounting

mechanism at the anchorage points.

3. Release the lever on the rear of the

seat and fully extend the two

attachment legs on the child seat.

Make sure that the hook at the end of

each leg is open.

4. Position the attachment legs just in

front of the trimmed apertures for the

ISOFIX anchorage loops (see previous

diagram). Push the anchorage leg

through the trimmed aperture to

engage with the vehicle’s anchorage

loop. There should be an audible

click.

5. Repeat Step 4 for the seat’s second

anchorage leg.

6. Using firm and even pressure on both

sides, push the child seat rearwards

until it is secured firmly against the

seat back. Make sure you do NOT

trap the top tether strap behind the

child seat.

7. Attach the top tether, refer to the

following section.

8. As a final check, firmly pull both sides

of the seat to confirm that it is

correctly locked in position.

!WARNING:

The top tether must always be used to

secure the ISOFIX child seat. Refer to

the following section.

Child restraint top tether anchorages

and brackets

The top of the child seat is connected by

a short strap to the top tether bracket to

prevent the seat from rotating about the

lower anchorages. The top tether

brackets are positioned on the rear parcel

shelf, under access covers, at the

centre-line of each rear seating position.

Pass the top tether strap under the

vehicle rear head restraint to connect to

the top tether bracket on the parcel shelf.

Adjust the length of the top tether strap to

hold the top of the child seat against the

vehicle seat back.

Make sure the child seat is securely fitted,

and follow the check list on page 75.

Child Safety

!WARNING:

Child restraint anchorages are

designed to withstand only those loads

imposed by correctly fitted child

restraints. Under no circumstances are

they to be used for adult seat belts,

harnesses, or for attaching other items

or equipment to the vehicle.

CHILD RESTRAINT CHECK

LIST

General check list

Follow the check list each time your child

travels in the vehicle:

• Carefully follow the instructions

provided by the manufacturer of the

restraint system.

• Make sure your child falls into the

correct weight range for the seat.

• Always use the appropriate child

restraints and adjust harnesses for

every child, every trip.

• Avoid dressing your child in bulky

clothing and do not place any objects

between the child and the restraint

system.

• Regularly check the fit of your child

seat and replace seats or harnesses

that show signs of wear.

• No child seat is completely

child-proof. Encourage your child not

to play with the buckle or harness.

• Never leave a child unsupervised in

the vehicle.

• Activate the rear door child safety

locks, refer to page 45.

• Make sure your child does not exit the

vehicle from the side where there is

traffic.

• Set your child a good example –

always wear your seat belt.

• Make sure that you have removed all

slack from the adult seat belt

(non-ISOFIX restraint only).

Additional checks for ISOFIX child

restraints:

• Always attach the top tether when

installing the ISOFIX seat.

• Always give the ISOFIX seat a final

pull to make sure that the lower

anchors are secure, even if the green

buttons indicate that the seat

connectors are latched.

Seats

SEAT ADJUSTMENT

!WARNING:

• Do not make adjustments when the

vehicle is moving.

• Front passengers must not ride

with the seat fully reclined.

Front seat adjustment

The front seats are adjusted electrically by

switches on the side of the seat cushion.

Adjustment can be made with or without

the ignition key inserted.

The number of seat adjustments varies

with the vehicle specification, but all

options are described in this section. If a

seat movement is not specified for your

vehicle, the control switch will either not

be fitted or will not include that seat

function (switch movement will be

inhibited).

Seat adjustments for two people may be

stored and recalled by the driver position

memory system. Refer to MEMORY

SETTING on page 87.

The full range of seat adjustments are:

Back resttraint angle (recline) and, if

specified, head restraint height (A):

Seat forwards and rearwards position

and, if specified, cushion height and

front tilt (B):

• Move the switch forward or rearward

to change the seat forewards and

rearwards position.

• Move the centre or rear of the switch

up or down to adjust cushion height.

• Move the front of the switch up or

down to tilt the front of the cushion.

If specified, varies the cushion length

(C):

Moving the control will change the

distance between the front of the cushion

and the back restraint.

Seats

Lumbar (D):

If specified, provides adjustable lumbar

support in the lower back restraint. Either

of two options may be fitted:

• 2-way or 4-way switch: Press the

front or back of the switch to increase

or decrease lumbar support.

• 4-way switch only: Press the top or

bottom of the switch to adjust lumbar

support upwards or downwards.

Manual head restraint adjustment

!WARNING:

Adjust the head restraint so that it is

just behind your head and never behind

your neck.

All head restraints may be removed, e.g.

to fit a large child seat. Hold the button

down and pull out the head restraint.

Where electrically adjusted head

restraints, refer to SEAT ADJUSTMENT

on page 76, are not fitted, the front head

restraints are manually adjustable:

• To lower: Press the button and push

the head restraint into the seat back,

to the required height.

• To raise: Pull the head restraint

upwards.

• Swivel the head restraint forwards or

backwards until it is comfortably

positioned behind your head.

Rear head restraints – All rear head

restraints are adjustable for height only.

Seats

DRIVING POSITION

!WARNING:

• Driver and front seat passenger

should always move their seats as

far rearwards as is practical.

• Adjust the head restraint so that it

is behind your head and never

behind your neck.

• An inflating airbag may cause

serious injuries or death if the seats

are positioned, or adjusted

incorrectly.

The seats, head restraints, seat belts and

airbags all contribute to the protection of

the occupants. Optimal use of these

components will maximise protection.

Therefore, observe the following points:

• Sit in the most upright position with

the base of your spine as far back as

possible and the back restraint

reclined not more than 30 degrees, A.

• Adjust the head restraints so that the

top of the head restraint is behind

your head and never behind your

neck.

• Do not move the driver’s seat too

close to the steering wheel. Ideally, a

minimum distance of at least 254mm

(10 inches), B, between the centre of

the breastbone and the cover of the

steering wheel airbag is

recommended. The driver should hold

the steering wheel with slightly bent

arms. The legs should be slightly bent

so that the pedals can be pressed to

the floor.

• The seat belt should rest in the centre

of the shoulder. The lap part should fit

tightly across the hips and not the

stomach.

The front seats are adjusted by switches

on the seat.

The driver and front passenger seats

should be positioned as far rearwards as

is practical.

Make sure your driving position is

comfortable and enables you to maintain

full control of the vehicle.

Note: Seat and steering wheel

adjustments are described on pages 76

and 81.

JAG0100L

Seats

FRONT SEAT HEATERS

Each seat has a heater switch on the

centre console. With the ignition switch in

position II, press a switch to select the

heat setting:

• A first press selects the higher

temperature setting, indicated by two

red lights on the switch.

• A second press selects the lower

temperature setting, indicated by one

red light.

• A third press turns the seat heater off;

both indicator lamps off.

The optional heated front seats

incorporate heaters in the back restraint

and cushions and have two heat settings.

The heater will automatically switch OFF

after ten minutes or if the ignition is turned

OFF or a fault is detected.

The heater will maintain a preset

temperature while it is switched on.

Storage of the vehicle in a heated garage,

body heat or warm ambient temperatures

may prevent operation of the seat heater.

Clock

CLOCK ADJUSTMENT

The position of the digital clock depends

on the equipment fitted to the vehicle.

If a touch-screen is fitted, the clock will be

incorporated in the touch-screen display.

• For more information concerning the

operation of the touch-screen, refer to

the touch-screen display handbook.

If the vehicle is not equipped with a

touch-screen, the clock is included in the

audio display.

• For more information concerning the

operation of the audio system

controls, refer to the audio systems

handbook.

Non-touch-screen

Adjust the clock using the audio

system MODE control button as

follows:

1. Press and hold MODE until CLOCK

SET is displayed with the 12/24 hours

indicator flashing.

2. To set 12 or 24 hour display rotate the

volume control knob clockwise for 24

hour display, counter clockwise for 12

hour display. AM or PM is,

subsequently, automatically

displayed.

3. Press MODE to select hour setting.

4. Rotate the volume control knob

clockwise to increase the hour,

anti-clockwise to decrease the hour.

5. Press MODE to select the minute

setting. Rotate the volume control

knob clockwise to increase the

minute, anti-clockwise to decrease

the minute.

6. To exit, press and hold MODE until

the display reverts to audio mode.

Touch-screen

If the vehicle is fitted with a touch-screen,

the clock is adjusted as follows:

1. Press the MENU button on the

touch-screen control panel. The

system menu screen will be

displayed.

2. Touch the System Setup button on

the MENU screen.

3. Touch the SET CLOCK button on the

SYSTEM SETUP screen.

4. Clock adjustment is made by

touching the hour or minute, up or

down arrow buttons.

5. Touch the 12/24 button to select

twelve or twenty-four hour display.

6. Confirm your setting by touching Set.

Steering Column

Entry - When the key is next inserted into

the ignition switch and the door is closed,

the steering column and seat will return to

their previous positions. If, however, the

memorised driver position has been

changed (using the door MEMORY

switch or another key transmitter), the

steering wheel and seat will move to the

new position.

Notes on entry or exit mode operation

• If the adjustment switch is moved

away from AUTO whilst the steering

column is tilted away, the steering

column will move back to its

memorised position when the key is

next inserted into the ignition and

entry or exit mode is then cancelled.

• If the adjustment switch is moved

during entry or exit operation, steering

column movement will stop.

Door Windows

WINDOW OPERATION

The front and rear door windows are

electrically operated.

Switches on the driver’s door control all

door windows.

Passengers are provided with a switch to

control their door window only.

These switches will only operate the

windows when the ignition switch is in

position I or II or for up to ten minutes

when the ignition switch is moved to

position 0 (key in or out), so long as the

driver’s and front passenger’s doors

remain closed.

!WARNING:

• When raising windows make sure

all occupants are clear.

• When leaving the vehicle take the

ignition keys to prevent misuse of

the window switches by remaining

occupants, especially children.

Raise or lower

To lower a window, press and hold the

rear of the switch until the desired

position is reached, then release.

To raise a window, press and hold the

front of the switch until the desired

position is reached, then release.

If the switches are held for longer than six

seconds; for example, when attempting

to overcome frozen or jammed windows,

the window drive will be switched off for a

few seconds to protect the window drive

motors.

One-touch operation

Each window has a one-touch facility

enabling the occupant to fully open or

close the window in one quick movement.

Press the switch briefly to close or open

the window in one movement. Window

travel can be stopped at any time by

pressing the switch again.

Immobilising the rear windows

The rear windows can be immobilised

from the driver’s door controls to prevent

passengers from operating their

windows.

To immobilise the rear windows, press

button (1) down to the latched position i.e.

flush with the surround.

To enable rear window operation, press

button (1) again so that it is in the raised

position with the white band showing.

Wind resonance with lowered windows

Due to the sleek exterior of the vehicle, it

is possible for a resonance, booming

sound to occur when one or both rear

windows are open; this is eliminated by

slightly opening an adjacent front

window.

Door Windows

WINDOW ANTI-TRAP

PROTECTION

Each electrically operated window has an

anti-trap protection feature. If the upward

movement of the window detects an

obstacle, the anti-trap system will

immediately stop the window closing,

then move it downwards for a short

distance.

!WARNING:

If the battery is disconnected or

discharged the window anti-trap

feature is lost. When the battery is

reconnected or recharged the window

anti-trap system must be reset.

To reset the electrically operated

windows anti-trap system:

• Fully close the window, hold the

switch in the close position for two

seconds and then release the switch.

Wait for two seconds. Do not open the

window.

• Again, select the same window to

close, holding the switch for a further

two seconds.

• Check to confirm the operation by

opening the window and then use

one-touch operation to close the

window.

• Repeat for the remaining electrically

operated windows.

To override the anti-trap protection

The anti-trap system will also stop the

window closing if a blockage or

resistance occurs e.g. in the window

guide channels. Typically, this might be

due to icing in winter but could also be

caused by damage or misalignment of the

guide channels or seals.

To override the anti-trap action:

• After the initial attempt to close the

window, operate the close switch a

second time.

• When the window has reversed from

the blockage, operate the switch

(within ten seconds) until the window

stops again (it will not reverse on the

third attempt).

• Immediately operate the close switch

again. The window will now move up

a short distance with increased force

to override the blockage.

• Repeat the override action until the

window has closed. Each time the

window stops, the switch must be

operated immediately to initiate

further override action.

If this procedure fails to move the

blockage, the anti-trap feature will be lost

and must be reset (see first column) after

the blockage has been cleared.

Thermal overload

If the windows are repeatedly opened and

closed (e.g. by a child), a protection

system will deactivate window operation

for a short period to avoid overheating of

the window motors.

Mirrors

DOOR REAR VIEW MIRRORS

Both door mirrors are adjusted from the

driver’s door switchpack.

The four-way adjustment button (1)

moves the mirrors to the required

position. The selector switch (2) selects

the mirror to be moved, left for the

left-hand side mirror and right for the

right-hand side mirror. When the selector

switch is in the centre position,

adjustment to either mirror is inhibited.

The mirror housings are designed to pivot

against the vehicle upon impact. To return

the mirror to its normal position, manually

reposition the housing until it locks into

place.

Door mirrors – power foldback

To assist parking by reducing the overall

vehicle width, an optional facility enables

the door mirrors to be folded back.

Set mirror selector switch (2) to the centre

position.

To fold the mirrors inwards, briefly press

the rear of button (1). Press the rear of

button (1) again to return the mirrors to

their normal driving position.

Note:

•

If the button is pressed repeatedly, a

thermal cut-out will prevent damage

to the vehicle’s electronics. If this

occurs, wait for five minutes for the

cut-out to reset before operating the

button.

•

If the thermal cut-out operates and

leaves the mirrors in the folded

position, the mirrors can be folded

outwards manually.

•

If the door mirrors are repositioned

manually (or knocked out of position),

the mirror head will be loose. To

re-engage the mechanism, power the

mirror to the foldback position, then

outwards to the drive position.

!WARNING:

Do not drive the vehicle with the door

mirrors in the folded position, except

when parking.

Caution: If door mirrors have been

folded against the vehicle due to an

impact:

• Reposition power foldback mirrors

using the door switches.

• Reposition non-power foldback

mirrors manually.

Mirror heating

The door mirrors have heating elements

which work when the rear screen heater is

switched ON. The mirror heater will clear

all ice from the mirror surface.

Caution: Do not use a scraper to

remove ice from the mirrors as this will

damage the surface.

Mirrors

Electrochromatic door mirrors

Electrochromatic door mirrors are only

fitted together with an electrochromatic

rear view interior mirror. The switches on

the interior mirror control the

electrochromatic function for both door

and interior mirrors (see following

section).

Note: The right-hand mirror is convex,

providing a wider field of vision. As a

result, objects viewed in the mirror are

closer than they appear.

INTERIOR REAR VIEW MIRROR

Interior mirrors are either the manual dip

or electrochromatic type.

Manual dip mirror

The interior rear view mirror can be

dipped to prevent glare from a following

vehicle’s headlamps by pulling lever (1).

Pushing the lever returns the mirror to its

daytime setting.

Adjusting the mirror – The mirror is

mounted on an adjustable arm (2) which

can be angled to change the mirror height

and lateral position.

Hold the arm and move to the desired

position and then re-adjust the mirror

itself.

Interior rear view mirror –

electrochromatic

The interior rear view mirror is of the

electrochromatic type, and is operated

automatically when the ignition switch is

turned on.

The mirror darkens automatically to

prevent glare from a following vehicle’s

headlamps, and clears when light levels

return to normal or when reverse gear is

selected.

Where electrochromatic door mirrors are

fitted, they are operated automatically in

conjunction with the interior mirror, when

the ignition switch is turned on.

Note:

•

Should a mirror assembly become

detached from the windscreen, it

must be refitted by a Jaguar Dealer/

Authorised Repairer.

•

Make sure that the windscreen in front

of the mirror is kept clean. Where

fitted, the moisture sensor for wiper

operation is located to the front of the

mirror casing. Any dirt may affect the

operation of this sensor.

Driving Position Memory

MEMORY SETTING

This optional facility enables the position

of the driver’s seat, steering column and

exterior rear view mirrors to be

memorised and recalled. Two different

driving position profiles can be entered

into the memory.

A key does not have to be in the ignition

switch for seat, mirror, steering column

adjustments, nor for memory setting.

Setting a driving position

To store a driving position in the memory:

1. Adjust the seat, steering column and

exterior rear view mirrors to the

desired positions.

2. Push the MEMORY button (A), and

the red LED in the switchpack will

illuminate for a five second period.

3. While the red LED is illuminated, push

button 1, or 2 to memorise the

configuration. The LED will go out and

a chime will indicate that the setting

procedure is complete. Additionally, if

the ignition is on (position II), the

message centre will display a

message that the settings have been

saved.

By repeating these three steps and

pressing the unused button (1 or 2), a

further driving position can be stored in

the memory.

To set a new driving position, adjust to the

desired position and perform steps 2 and

3. The previous memory will be erased

and the new position will be set.

Recalling a memorised position from

the door switchpack

The gear selector lever in automatic

transmission vehicles must be in P, and

for manual transmission vehicles the

parkbrake must be applied.

Press and release the appropriate

memory button (1 or 2). The seat, steering

column and door mirrors will move

automatically to the memorised position.

Memory recall using a key transmitter

The key transmitter will recall a memory

position when the unlock button is

pressed, when set as follows:

1. Adjust the seat, steering column and

exterior rear view mirrors to the

desired positions.

2. Press the MEMORY button: the red

LED will illuminate for a five second

period.

3. Press any button on the key

transmitter and then press button 1 or

2. Both button presses must occur

while the red LED is illuminated.

4. Repeat for the other transmitter,

pressing the remaining memory

button.

Driving Position Memory

To cancel key transmitter memory recall:

1. Press the MEMORY button: the red

LED will illuminate for a five second

period.

2. Press any button on the key

transmitter (except the panic button),

then press the MEMORY button

again. Both button presses must

occur while the red LED is illuminated.

Driving position memory system

operating tips

• When making adjustments to a set

driving position, reset the new

position in the same memory channel.

• A driving position will only be

memorised during the five second

period when the red memory LED is

illuminated.

• Previous memory is erased when a

new driving position is entered.

• Make sure that the seat has

completed moving into the required

memory position before shifting the

gear selector from the P position, or in

the case of manual transmission,

releasing the parkbrake.

• If the seat memory does not recall

correctly, the seat may require to be

recalibrated. This may be due to an

interruption in the electrical supply. To

recalibrate the seat it should be

powered fully forwards and

backwards, and fully upwards and

downwards.

Luggage Compartment

LUGGAGE TIE-DOWN LOOPS

!WARNING:

• Locate heavy loads in the luggage

compartment towards the front of

the vehicle and secure them to stop

them sliding. Loose items can be a

hazard.

• Do not drive with the luggage

compartment lid open, as exhaust

fumes can be drawn into the

passenger compartment.

Four metal loops are positioned in the

luggage compartment for attaching

straps to secure loads, and prevent them

from sliding over the luggage

compartment floor.

These loops are not to be used for

securing passengers or animals, nor as

anchorages for child restraints.

A range of Jaguar storage accessories,

including a luggage retaining net, are

available from your Jaguar

Dealer/Authorised Repairer.

It is advisable to distribute luggage weight

evenly over the entire luggage

compartment floor area, particularly to

prevent permanent damage to the seat

trim when a seat has been folded down.

Luggage Compartment

REAR SEAT BACK

FOLD-DOWN

To provide a longer luggage compartment

area, the backs of the rear seats on most

models can be folded down in two parts

to give a 60/40 width split.

Release handles for each seat back are in

the luggage compartment under the

parcel shelf.

Pull the selected side handle to release

the seat back and then fold it onto the

seat cushion.

Make sure when folding the seat back

down, that the armrest is stowed and that

there is sufficient clearance between the

seat back, including the head restraint,

and the back of the front seat.

When returning the seat back to the

upright position, make sure that the seat

belts are routed correctly and are not

trapped by the seat back. Press the seat

back firmly and check that it is locked

securely into place.

Luggage Compartment

SKI HATCH A two-door hatch is fitted to the rear seat

on some models, providing an opening

between the passenger and luggage

compartments. This allows space for skis

or similar objects to be stowed in the

vehicle. Both doors have a single catch.

The inner door is accessible after folding

down the armrest. To open the door, pull

the leather flap forward, press the catch

(1) downwards and gently lower the door

on to the armrest.

A bag for retaining the skis can now be

pulled from the receptacle into the

passenger compartment, and the strap (3)

loosened ready to accept the skis.

The other door is accessible from inside

the luggage compartment and is opened

by pushing the catch (2) and lowering the

door.

Push the skis into the bag from the

luggage compartment and then secure

the skis using the strap provided on the

bag. Clip the strap connector (4) to the

centre rear seat belt buckle.

Instruments

Should the pointer move into the red

segment (H) of the coolant gauge, a RED

priority indicator within the temperature

gauge is displayed. Stop the vehicle as

soon as it is safely possible. Turn off the

engine and open the bonnet to allow the

engine to cool.

Note: To assist cooling, high engine

temperature automatically turns off the air

conditioning. To maintain some cooling, it

is advisable to switch the air distribution to

recirculation.

Tachometer - petrol (2), diesel (7)

The tachometer indicates engine speed in

revolutions per minute and is calibrated in

increments of 250 rev/min.

• For petrol models, the scale extends

to 8 000 rev/min.

• For diesel models, the scale extends

to 5 000 rev/min.

Caution: Do not allow the needle to

enter the red sector.

Speedometer (3)

Speed indication is in either:

• miles per hour, the outer figures, and

kilometres per hour, the inner figures

or;

• kilometres per hour, the outer figures,

and miles per hour, the inner figures

or;

• kilometres per hour only.

Fuel level gauge (4)

Indicates the amount of fuel in the tank.

An amber warning indicator is displayed

within the fuel gauge when the fuel in the

tank is at a low level and should be

refilled.

The small arrow, shown beside the fuel

pump symbol, identifies on which side of

the vehicle the filler cap is located.

Message centre - clock display (5)

The clock is permanently displayed on the

bottom line of the speedometer message

centre. To set the clock time, refer to

page 80.

Message centre - odometer (6)

Records the total distance covered by the

vehicle. The kilometre or mileage reading

is displayed on the bottom line of the

tachometer message centre.

Warning Indicators

PRIORITY INDICATORS

Warning indicators are arranged within

the instrument pack.

There are two warning indicators, one red,

the other amber, located within the

tachometer above the message centre.

AMBER (1) warning indicators are for

secondary warnings when the driver must

take action and then report the fault to a

Dealer /Authorised Repairer at the earliest

opportunity.

RED (2) warning indicators are for primary

warnings. A primary warning must be

investigated immediately by the driver or

a Jaguar Dealer/Authorised Repairer.

Other indicators within the instrument

pack indicate system status; such as blue

for main beam and green for direction

indicators.

WARNING INDICATOR CHECK

A warning indicator check is initiated

when the ignition is switched ON and

lasts for three seconds (excepting the

airbag warning indicator which will remain

ON for six seconds). If any warning

indicator remains ON after this period,

investigate the cause before driving.

When activated, some warning indicators

have associated messages displayed on

the message centre.

Note: Not all indicators are included in the

check, for example, main beam

headlamps or direction indicators.

WARNING INDICATORS

Low oil pressure (Red)

This lights up when the ignition

is switched ON and should go

out once the engine is running.

If the warning indicator remains ON once

the engine has started, or comes ON

while driving, loss of oil pressure is

indicated. STOP the engine immediately

and investigate the cause.

Caution: Do not restart the engine until

the cause of loss of oil pressure has

been identified and rectified.

First check the engine oil level, refer to

page 196.

Charge indicator (Red)

Diesel only: The charge

warning indicator will light up

when the ignition is ON and

should go out when the engine is running.

Diesel and petrol vehicles:

If the warning indicator stays ON when

the engine is running it indicates that

there is either a battery voltage fault or an

alternator fault.

Turn OFF all electrical accessories, radio,

climate control, rear screen heater etc.

Try to use the minimum electrical load as

possible, such as power windows,

electric sunroof etc.

Report the fault to a Jaguar Dealer/

Authorised Repairer.

JAG0571

Warning Indicators

If the red brake warning indicator also

flashes, the parkbrake cannot be applied.

Should the warning indicator come on or

stay on after the bulb check cycle, stop

the vehicle at the first opportunity, turn

the engine OFF and then restart.

If the ABS warning indicator comes on

again at the next driving event, the vehicle

should be driven to a Jaguar

Dealer/Authorised Repairer at the earliest

opportunity.

Engine malfunction (Amber)

This warning indicator

illuminates when there is an

engine malfunction.

Specialised diagnostic equipment is

required to repair such faults. Report the

fault to a Jaguar Dealer /Authorised

Repairer.

The vehicle may go to limp home mode,

with the possibility of reduced engine

performance. Drive the vehicle with

caution.

Rear fog lamps (Amber)

Illuminates when the rear fog

lamps are switched ON.

Dynamic Stability Control (DSC)

(Amber)

The indicator will flash at the

rate of twice a second when

DSC is operating.

The message DSC NOT AVAILABLE will

be displayed and the indicator will be ON

continuously when a fault is detected in

the system.

If the system is turned OFF, a message

DSC OFF will be displayed for four

seconds and the warning indicator will

remain ON.

When the system is turned back ON the

warning indicator goes out and a

message DSC ON will be displayed for

four seconds.

Adaptive Cruise Control (ACC) (Amber)

If Adaptive Cruise Control is

active, the warning indicator is

illuminated to indicate that the

vehicle is in follow mode and

automatically maintaining the desired gap

to the vehicle immediately ahead.

Only applicable to vehicles fitted with

Adaptive Cruise Control.

Airbag (Amber)

If the airbag system develops a

fault, the warning indicator will

flash and then come ON and

remain on until the fault has been

diagnosed and cleared.

Report the fault to a Jaguar Dealer/

Authorised Repairer immediately.

It is safe to drive the vehicle; however, in

an accident the airbags may not operate.

Glow plugs (diesel only) (Amber)

Illuminates when the ignition is

switched ON and switches

OFF as soon as the glow plugs

reach their operating temperature,

indicating that the engine may be started.

For more information on starting a diesel

engine, refer to page 136.

Warning Indicators

Low outside temperature (Amber)

Illuminates when frost or ice is

likely to form on road surfaces.

The indicator will continue to

be illuminated until the outside

temperature rises to a safer level.

!WARNING:

Even if the indicator is not illuminated,

there is no guarantee that at low

temperatures the road is free from ice.

If required, the low outside temperature

warning indicator can be disabled by a

Jaguar Dealer/Authorised Repairer.

Main beam (Blue)

Illuminates when the main

beam headlamps are switched

ON or flashed ON.

Cruise (speed) control activated

(Green)

Illuminates when cruise control

is ENGAGED.

Side lamps (Green)

Illuminates when the side

lamps are switched ON.

Direction indicators (Green)

The appropriate

indicator arrow will flash

when the column switch

is moved up or down to signal a

right-hand or left-hand turn. If a direction

indicator fails, the arrow will flash at twice

the normal rate when that indicator is

selected. Fit a new bulb immediately.

Note: If a bulb has failed, the audible

ticking will sound at twice the normal rate.

Hazard warning lamps

When the hazard warning is selected,

both direction indicator arrows flash

simultaneously.

Overspeed warning (Red)

(Middle East countries only).

Illuminates if the vehicle speed

exceeds 120 km/h (75 mph).

Audible Warnings

Audib le Warn ings

AUDIBLE WARNINGS

Various sounds are produced for warning and notification purposes as follows:

Hazard or Condition Remedy - chime or tone

External lamps remain

ON when the driver’s

door is opened.

A chime will sound until the lamps are switched OFF or the

driver’s door is closed.

Note: The chime will not sound if the switch is in the AUTO

position.

Hazard warning

indicators ON.

A ticking will sound until the hazard indicators are switched

OFF.

Left or right direction

indicators ON.

If the switch has not turned itself OFF, switch the turn

indicator OFF when the manoeuvre is completed. A ticking

will sound until the indicators are switched OFF.

Memory 1 or 2

configuration saved.

A short tone as the memory selection is saved.

Airbag system failure. A tone sequence is repeated five times. Report the fault to

a Jaguar Dealer/Authorised Repairer as soon as possible.

Beltminder. If the vehicle’s forward speed exceeds 16 km/h (10 mph)

and the seat belt for an occupied front seat is not fastened,

an intermittent chime will sound. This will continue for 10

seconds and then repeat every 30 seconds for five

minutes, or until the belt is fastened or the vehicle stops.

Electric parkbrake. If the parkbrake is applied whilst the vehicle is moving a

continuous chime is initiated; push the switch to release

the parkbrake. If there is a fault with the system which

would prevent the application of the electric parkbrake, a

brief sequence of chimes is initiated.

Adaptive Cruise Control

(ACC) Driver intervene.

Action is required by the driver to apply the brakes.

ACC low speed

automatic switch off.

A chime will sound to indicate that the ACC system is no

longer operating.

Gear selector is not in

Park with ignition OFF.

A chime will sound if the gear selector is not in Park when

the ignition is switched to I or OFF (automatic transmission

only).

101

Message Centre

MESSAGES

The tables on the following pages list all

messages and warning indicators and

explain their meaning.

Message Warning

Indicator

Priority

Indicator

Meaning

LOW BRAKE FLUID Brake Red Displayed when the brake fluid

level is low. Complete loss of

braking may occur.

ENGINE

COOLANT LOW

None Red Displayed when engine

temperature becomes excessive.

Pull off the road when safe to do

so and allow the engine to cool.

RESTRICTED

PERFORMANCE

None Red or

Amber

This will be displayed when the

vehicle has possible loss of power

or driveability. Report the fault to a

Jaguar Dealer/Authorised Repairer.

ENGINE SYSTEM

FAULT

Malfunction

indicator

lamp

Red Displayed when the engine has

defaulted to limp-home mode.

Report the fault to a Jaguar

Dealer/Authorised Repairer at the

earliest opportunity.

DPF (Diesel

Particulate Filter)

FULL

SEE HANDBOOK

(Diesel models only)

None Red or

Amber

Amber displayed when the Diesel

Particulate Filter (DPF) requires to

be regenerated, carry out DPF

regeneration, see page 153. If Red

priority is indicated, contact a

Jaguar Dealer/ Authorised Repairer

as soon as possible.

DRIVER’S or

PASSENGER’S

FRONT OR REAR

DOOR OPEN

None Red Check that all doors are closed

before driving.

BONNET OPEN None Red Check that the bonnet is closed

before driving.

BOOT OPEN None Red Check that the luggage

compartment lid is closed before

driving.

103

Message Centre

FUEL PUMP SYSTEM

FAULT

None Amber Displayed when a fault is detected

in the fuel system. The total fuel

capacity may not be able to be

used. Report the fault to a Jaguar

Dealer/Authorised Repairer at the

earliest opportunity.

CATS SYSTEM FAULT

(Computer Activated

Technology System)

None Amber Displayed when a fault is detected

in the adaptive damping system

(only those vehicles fitted with

adaptive damping suspension).

Report the fault to a Jaguar Dealer/

Authorised Repairer at the earliest

opportunity.

WASHER

FLUID LOW

None Amber Replenish the washer fluid at the

earliest opportunity.

SERVICE

REQUIRED

None Red Displayed when vehicle service is

required.

SERVICE REQ’D

IN XXXX km

(XXXX MLS)

None Amber Displayed when there is 3 400 km

(2 000 miles) and less, to next

vehicle service.

Note: In most countries it is illegal to use a vehicle with a defective exterior lamp

bulb. Bulb replacement information is shown on page 174.

LEFT or RIGHT

BRAKE LAMP FAILED

None Amber Check for failed brake lamps and

replace.

LEFT or RIGHT TAIL

LAMP FAILED

None Amber Check for any failed tail lamps and

replace.

FAILED LEFT or

RIGHT FRONT

INDICATOR

None Amber Check for any failed front direction

indicator lamps and replace.

FAILED LEFT or

RIGHT REAR

INDICATOR

None Amber Check for any failed rear direction

indicator lamps and replace.

FAILED LEFT or

RIGHT SIDE

REPEATER

None Amber Check for failed side direction

indicator repeater lamps and

replace.

APPLY FOOT AND

PARKBRAKE

None Amber If the battery has been

disconnected then the footbrake

and parkbrake must be applied to

reset the system.

Message Warning

Indicator

Priority

Indicator

Meaning

Message Centre

104

PARKBRAKE FAULT None Amber Displayed when there is a fault in

the parkbrake system. If the

warning lamp is flashing the

parkbrake cannot be applied.

PARKBRAKE ON None None Displayed if the parkbrake is

applied whilst the vehicle is

moving above 5 km/h (3 mph).

COLUMN ADJUST None Amber The column adjust switch has

been moved to this position.

COLUMN ADJUST

AUTO

None Amber The column adjust switch has

been moved to this position.

AUTOLAMP DELAY

OFF

None None Autolamp delay function has been

turned OFF.

AUTOLAMP DELAY

X:XX

None None Changing the time delay will

display the newly set time that the

headlamps will remain ON after

exiting the vehicle.

MEMORY 1 or 2

RECALLED

MEMORY 1 or 2

SETTINGS SAVED

None None When a memory is set or recalled,

a corresponding message will be

displayed.

CRUISE

ENGAGED

None None Displayed when cruise control

system is operating.

CRUISE

OVERRIDE

None None Driver is pressing the accelerator

pedal overriding cruise control

function. Message will disappear

when accelerator pedal is released

and cruise control speed is

resumed.

CRUISE

CANCELLED

None None Driver has cancelled cruise control

or is braking.

CRUISE NOT

AVAILABLE

None None Cruise control or adaptive cruise

malfunction.

The following messages only apply to vehicles fitted with Adaptive Cruise Control.

DRIVER

INTERVENE

None Action by the driver to apply the

brakes is required.

SETSPEED

XXX KM/H

None Speed set for Adaptive Cruise

Control.

Message Warning

Indicator

Priority

Indicator

Meaning

Trip Computer

108

SETTING THE TRIP COMPUTER

At the start of the journey (or series of

journeys) to be recorded, reset the

computer memory to zero as follows:

1. Press the TRIP button on the end of

the left column lever switch to select a

trip function. The computer will

display either TRIP A: or TRIP B: data.

2. Press the A/B switch to select the trip

(A or B) to be reset.

3. Press the RESET switch and hold for

three seconds.

The display will read:

RESETTING TRIP A (or B).

Then it will reset and display:

A: 0 (or B: 0), or the new value.

Note: All trip functions for A or B,

depending on which was selected, will be

reset.

CLEARING MESSAGES

Messages can be hidden by pressing

RESET on the trip computer switchpack.

One press will hide one message. Once all

messages have been hidden, the display

will show trip data.

If RESET is pressed again, all active

messages will be re-displayed.

Repeatedly pressing the RESET button

will cycle through the trip and message

modes.

If a fault occurs when in trip computer, the

relevant message will be displayed

immediately.

If a trip computer function is selected by

pressing the TRIP button while messages

are displayed, the trip data will be

displayed for ten seconds then the

message will reappear.

Hidden messages reappear after an

ignition OFF and ON cycle, if the fault

remains.

109

Cruise (Speed) Control

Cruis e ( Sp eed) Con t ro l

STEERING WHEEL SWITCHES

The cruise (speed) control system can be

used by the driver to maintain a selected

vehicle speed above 25 km/h (16 mph),

without the driver having to use the

accelerator.

Switches on the steering wheel allow the

driver manual control of the system.

Brake and clutch operations also

influence the cruise control system.

RESUME (1) to resume the set speed

retained in the memory.

SET (2) to set the speed, or increase or

decrease the set speed when the speed

has been set.

CANCEL (3) cancels cruise control, but

retains the set speed in the memory.

Setting vehicle speed

!WARNING:

Only use cruise control when

conditions are favourable; for example,

straight, dry, open roads with light

traffic.

When you are travelling at the speed you

require, which must be above 25 km/h (16

mph), press the SET button.

Cruise control will engage and maintain

the set speed and you can remove your

foot from the accelerator pedal.

Note: Cruise control will automatically

disengage when the brake pedal is

pressed or when the vehicle speed falls

below 25 km/h (16 mph). If the vehicle has

a manual gearbox, pressing the clutch

pedal will also disengage the cruise

control.

Changing the set speed

There are three ways to change the set

speed:

•Accelerate or decelerate to the

desired speed then press the SET (+)

button.

•Increase or decrease the speed by

pressing and holding either SET (+) or

(-) until the desired speed is obtained,

then release the switch.

•Increase or decrease the speed in

steps of 2 km/h (1 mph) by pressing

either the SET (+) or (-) until the

desired speed is obtained.

Cruise (Speed) Control

110

Resuming the set speed

If the vehicle is accelerated above the set

speed, then the set speed will be resumed

when the accelerator pedal is released.

If CANCEL is pressed, or the brake or

clutch pedal is pressed, the cruise control

will disengage, but the set speed memory

will be retained. Press RESUME and the

vehicle will return to the set speed.

Note: Cruise control will not resume at

speeds below 25 km/h (16 mph).

RESUME will not operate if the ignition

has been turned OFF.

Caution:

•RESUME should only be used if the

driver is aware of the set speed and

intends to return to it.

•It is not recommended to resume a

set speed when a low gear is

selected as excessive engine

speeds will occur.

Cruise control will switch OFF and clear

the memory when:

•The ignition is switched to position 0.

•A fault occurs. The cruise control

system will switch OFF and cannot be

used until the fault is cleared.

Cruise control automatic switch off

Cruise control will switch off, but the set

speed will remain in the memory when:

•The CANCEL button is pressed.

•The brake pedal is pressed.

•Speed falls below 25 km/h (16 mph).

•Neutral, Park or Reverse gear

positions are selected.

•Dynamic Stability Control is

operating.

•The difference between the actual and

set speed is too great.

•When the vehicle reaches a maximum

speed of:

Manual: 200 km/h (125 mph).

Auto:192 km/h (120 mph).

•The accelerator pedal is used to

accelerate beyond the set speed for

too long a period.

•If the vehicle has a manual gearbox,

pressing the clutch pedal will also

disengage the cruise control.

111

Adaptive Cruise Control

Adap t ive Cruis e Co nt rol

ADAPTIVE CRUISE CONTROL

(ACC)

The Adaptive Cruise Control system is

designed to aid the driver to maintain a

gap from the vehicle ahead, or a set road

speed if there is no slower vehicle ahead.

The system is intended to provide

enhanced operation of the vehicle, when

following other vehicles which are in the

same lane and travelling in the same

direction.

!WARNING:

Adaptive Cruise Control is not a

collision warning or avoidance system.

Additionally, Adaptive Cruise Control

will not detect:

•Stationary or slow moving vehicles

below 10 km/h (6 mph).

•Pedestrians or objects in the

roadway.

•Oncoming vehicles in the same

lane.

The Adaptive Cruise Control system is

based on the use of a radar sensor, which

projects a beam directly forward of the

vehicle so as to detect objects ahead.

The radar sensor is mounted behind a

cover on the left-hand side of the lower

cooling aperture, to provide a clear view

forward for the radar beam.

•Only use ACC when conditions are

favourable, that is, straight, dry, open

roads with light traffic.

•Do not use in poor visibility,

specifically fog, heavy rain, spray or

snow.

•Do not use on icy or slippery roads.

•It is the driver’s responsibility to stay

alert, drive safely and be in control of

the vehicle at all times.

•Keep the front of the vehicle free from

dirt, metal badges or objects,

including vehicle front protectors,

which may prevent the sensor from

operating.

•Do not use ACC when entering or

leaving a motorway.

Adaptive Cruise Control

112

Steering wheel switches

The system is operated by switches

mounted on the steering wheel. The driver

can also intervene at any time by use of

the brake or accelerator pedals.

The steering wheel switches operate as

follows:

RESUME (1): Resumes set speed.

SET + or SET - (2): Sets the speed, or

increase (+) or decrease (-) the set speed.

CANCEL (3): Cancels without erasing the

memorised speed.

(4): Gap increase or decrease.

Setting a speed

Accelerate as normal until the required

speed is reached.

Press the SET + button (2) briefly and the

vehicle speed will then be stored in the

memory and the system engaged. The set

speed will be displayed on the message

centre.

Entering the follow mode

!WARNING:

When in follow mode, the vehicle will

not decelerate automatically to a stop,

nor will the vehicle always decelerate

quickly enough to avoid a collision

without driver intervention.

Once a set speed has been selected, the

driver can release the accelerator and the

set road speed will be maintained.

When a vehicle ahead enters the same

lane or a slower vehicle is ahead in the

same lane, the vehicle speed will be

adjusted automatically until the gap to the

vehicle ahead corresponds to the preset

gap. The vehicle is now in follow mode.

The warning indicator in the

instrument pack will be

illuminated.

The vehicle will then maintain the

constant time gap to the vehicle ahead

until:

•The vehicle ahead accelerates to a

speed above the set speed.

•The vehicle ahead moves out of lane

or out of view.

•The vehicle ahead slows so that low

speed automatic switch off occurs.

•A new gap distance is set.

If necessary, the vehicle brakes will be

automatically applied to slow the vehicle,

in order to maintain the gap to the vehicle

in front.

SETSPEED

80 KM/H (50 MPH)

GAP The message centre will

display the gap set.

113

Adaptive Cruise Control

The maximum braking which is applied by

the ACC system is limited and can be

overridden by the driver applying the

brakes, if required.

Note: Driver braking will cancel Adaptive

Cruise Control.

If the ACC system predicts that its

maximum braking level will not be

sufficient, then an audible warning will

sound while the ACC continues to brake.

DRIVER INTERVENE will be displayed on

the message centre. The driver should

take IMMEDIATE action.

When in follow mode, the vehicle will

automatically return to the set speed

when the road ahead is clear, for instance

when:

•The vehicle in front accelerates or

changes lane.

•The driver changes lane to either side

or enters an exit lane.

The driver should intervene if appropriate.

Low speed automatic switch off

If the speed of the vehicle decreases

below 30 km/h (18 mph), the ACC system

will be automatically switched OFF and

the instrument warning indicator will go

out.

If the brakes were being applied by the

ACC system, they will be slowly released.

This will be accompanied by an audible

warning, and DRIVER INTERVENE will

be displayed on the message centre. The

driver must take control.

Overriding the set speed or follow

mode

!WARNING:

Whenever the driver is overriding the

ACC by depressing the accelerator

pedal, the ACC will not automatically

apply the brakes to maintain

separation from any vehicle ahead.

The set speed and gap can be overridden

by pressing the accelerator pedal when

cruising at constant speed, or in follow

mode. If the vehicle is in follow mode, the

instrument warning indicator will go out

when the ACC is overridden by the driver

using the accelerator, and CRUISE

OVERRIDE will be displayed on the

message centre. When the accelerator is

released, the ACC function will operate

again and vehicle speed will decrease to

the set speed, or a lower speed if follow

mode is active.

Changing the gap

The gap from the vehicle ahead can be

decreased or increased by pressing the

rocker switch (4), see page 112, on the

steering wheel. Four gaps are available

and the selected gap setting will be

displayed on the message centre when

either button is pressed. After the ignition

is switched ON, the default gap will be

automatically selected ready for ACC

operation.

Note: It is the driver’s responsibility to

select a gap appropriate to the driving

conditions.

117

Exterior Lighting

Exte rio r Light ing

MASTER LIGHTING SWITCH

The exterior lamps are controlled by the

left-hand column lever switch.

The rotary collar on the lever has three

positions for turning the exterior lamps on

or off and positions for autolamps and exit

delay. These are:

OFF

All exterior lamps OFF (except vehicles

provided with daylight running lights).

Side lamps

Switches on front side lamps, tail, number

plate and any other marker lamps

required by local legislation. When the

external lamps are ON the instruments

will also be lit.

Headlamps

With the ignition in position II, this

position switches on dipped headlamps

in addition to the lamps switched on in

side lamp position.

The left-hand column lever switch has

two positions for controlling the main

beam.

Pulling the switch towards the steering

wheel and releasing causes the main

beam to flash on and off. The main beam

can be flashed at any time when the

switch is pulled and will remain ON for as

long as the switch is held.

The second position is to switch main

beam headlamps ON. With the ignition in

position II, first select dipped beam

lamps, and then push the column lamp

switch away from the steering wheel.

The blue warning indicator on the

instrument pack and main beam

headlamps will come ON.

To turn main beam OFF, pull the column

switch towards the steering wheel to

return to dipped beam.

Note: If dipped beam is switched OFF

with main beam still activated, both

dipped and main beam will be

extinguished. Both dipped and main

beam will illuminate if dipped is turned on

again.

Parking Assist

124

(1) is approximately 600 mm (24 inches).

(2) is approximately 1 600 mm (63 inches).

Front and rear parking assist

When both front and rear parking assist

are fitted, a switch is located in the

overhead console.

Pressing the switch turns front and rear

parking assist on or off together. The

integral warning indicator switch will

come on when the system is turned off or

if a fault is detected in the system. A

switch is not provided when only rear

parking assist is fitted.

Note: The front parking assist will also

operate when reverse gear is selected.

Front parking assist provides an audible

proximity warning when driving forwards.

The front sensors only operate within a

fixed speed range in forward gears and

are not effective when moving forwards

above 15 km/h (9 mph) or when slowing

down until below 7 km/h (4½ mph).

Objects are detected within the operating

range, shown in the illustration above,

between approximately 600 mm (24

inches) (1), 1 600 mm (63 inches) (2) and

800 mm (31 inches) (3).

If an obstacle is detected at the front or

rear of the vehicle, a beep tone will be

heard from the front or rear speaker

respectively.

The bleep tone increases in rate as the

vehicle approaches the obstacle.

The front or rear parking assist beep will

become continuous when the obstacle is

detected at or within 300 mm (12 inches)

(1) from the rear or approximate 250 mm

(10 inches) (1) from the front of the

vehicle.

If the system has a fault when engaging

reverse gear or turning on the ignition,

then a single, three second tone will be

heard (only once per ignition cycle) and, if

fitted, the switch lamp will come on. The

system is automatically disabled when a

fault is detected.

125

Parking Assist

Towing

Where approved Jaguar towbar electrics

are fitted, the reverse parking assist is

automatically switched off if a caravan or

trailer is attached to the vehicle. The front

parking assist will remain active.

Rear fitted accessories

Particular care must be taken when

reversing with rear fitted accessories e.g.

towbar or bicycle carrier, as the rear park

assist will only indicate the distance from

the bumper to the obstacle.

Horn

126

Horn

HORN OPERATION

The dual-tone horn is operated by

pressing the centre pad on the steering

wheel.

The horn also operates as a warning horn

if the vehicle alarm system is activated.

127

Sunroof

SUNROOF OPERATION

!WARNING:

• Before opening or closing the

sunroof check that all occupants

are clear.

• When leaving the vehicle take the

ignition key to prevent misuse of

the sunroof switch by remaining

occupants, especially children.

The sunroof switch is located in the

overhead console. The ignition switch

must be in position I or II for the sunroof

to operate.

To open the sunroof

• Push the rear of the switch gently

upwards to the first position and hold

until the sunroof is fully open. The

sunroof can be stopped at any open

position by releasing the switch.

• To fully open the sunroof with

one-touch operation, briefly push the

rear of the switch fully upwards to the

second position and then release. To

stop the sunroof opening, briefly

press the switch upwards, forwards or

rearwards.

To close the sunroof

• Push the front of the switch upwards

to the first position and hold until the

sunroof is closed. It can be stopped at

any position by releasing the switch.

• To close the sunroof with one-touch

operation, briefly push the front of the

switch upwards to the second

position and then release. To stop the

sunroof closing, press the switch

upwards, forwards or rearwards.

To tilt the sunroof open

• Push the front of the switch upwards

and hold until the required position is

reached, or until the tilt is fully open,

and then release the switch.

To tilt open with one-touch operation

• To tilt open with one-touch operation,

briefly push the switch upwards to the

second position.

To close the tilted sunroof

• Push and hold the rear of the switch

until the sunroof is closed. Briefly

push the rear of the switch upwards to

the second position to tilt closed with

one-touch operation.

Sunshade operation

The sunshade can be manually opened

and closed using the handle.

When the sunroof is fully open, the

sunshade is also fully open and the

handle is hidden, therefore, it cannot be

manually closed from this position.

Note: The sunroof will need to be fully

closed to gain access to the handle.

131

Parkbrake

If the battery has been discharged or

disconnected, a message APPLY

PARKBRAKE will be displayed when the

ignition is next turned on. Depress the

footbrake and pull the parkbrake switch

up to apply the parkbrake. This is required

to reset the parkbrake system. The

parkbrake will now function correctly.

135

Engine Starting

BEFORE STARTING

Before starting the engine, new owners

and drivers should familiarise themselves

with the layout and operation of the

controls and instruments.

!WARNING:

Before attempting to start the engine,

check that the parkbrake is ON and the

gear selector lever (automatic

transmission) is in position P or N or

(manual transmission) in Neutral.

Automatic transmission

When the vehicle is stationary the

automatic gear selector may be left in D,

2 3 4, or , unless the vehicle is to be

parked. When stopping for traffic lights,

junctions etc., either select P or apply the

parkbrake and select N.

Manual transmission

When the vehicle is stationary it is

advisable to apply the parkbrake and to

move the gear selector to the Neutral

position.

STARTING A PETROL ENGINE

The engine cannot be started until the

automatic transmission gear selector is in

N P or .

Insert the key into the ignition switch and

turn clockwise to position II to switch on

the ignition.

When the key is turned to position III the

starter motor will turn the engine until:

• The key is released and automatically

returns to position II.

• The ignition switch is turned to 0 I or .

• The gear selector is moved out of P or

N (automatic transmission vehicles).

• The engine starts.

Do not use the starter continuously for

longer than six seconds. Continued use of

the starter will discharge the battery and

may damage the starter mechanism.

When the engine starts, release the key.

Wait until the engine stops turning before

re-using the starter.

The red charge warning indicator in the

instrument pack should go out when the

engine is running.

If the engine fails to start

If an ignition key is placed in the ignition

switch and turned to position II and the

alarm security lamp is flashing, it is

possible that the engine will not start. In

any event, please contact a Jaguar Dealer

/Authorised Repairer to investigate the

cause of the lamp flashing.

It is possible that the fuel system inertia

switch may have tripped, see page 164

for the resetting procedure.

If the engine persistently fails to start and

flooding is suspected, depress the

accelerator pedal fully, hold it in this

position and turn the key to position III for

six seconds. Release the key, remove

your foot from the accelerator pedal and

then attempt to restart the engine.

Note: The engine cannot start while the

pedal is fully depressed; it must be

released to enable the engine to start.

If the engine still fails to start, turn the

ignition OFF and contact a Jaguar Dealer/

Authorised Repairer.

Engine Starting

136

Stopping a petrol engine and locking

the steering

Turn the key from position II to the lock

position 0. This turns off the ignition and

stops the engine. The steering will be

locked when the key is removed from the

switch.

Leaving the key in position I or II will

discharge the battery.

STARTING A DIESEL ENGINE

Insert the key into the ignition

switch and turn clockwise to

position II. Make sure that the

glow plug indicator illuminates.

Once the indicator has extinguished,

depress the clutch and do not touch the

accelerator pedal. Turn the key to position

III to turn the starter motor. Continue to

operate the starter motor without

pausing, until the engine starts. Once the

engine has started, release the key, which

will return to position II.

If the engine stalls or fails to start, the key

must be turned to position I before

attempting to restart.

At extremely low temperatures it may be

necessary to crank the engine for up to 30

seconds.

Caution: Do not let the engine run

under full load immediately after

starting. Give the lubricating oil time to

reach the oiling points to prevent

damage to the engine.

Stopping a diesel engine and locking

the steering

Caution: Especially after driving at high

engine speeds for any length of time, it

is important to let the engine run for a

time (1 minute) while stationary before

switching it off. This allows the

turbocharger turbine blades to cool off,

while lubrication is still being fed to the

turbocharger bearings.

Release the accelerator pedal. Wait until

the engine has reached idle speed, then

turn the key from position II to the lock

position 0. This will turn off the engine.

The steering will be locked when the key

is removed from the switch.

Caution: Do not depress the

accelerator pedal. If the engine is

switched off at high speed, the

turbocharger will continue running

after the engine oil pressure has

dropped to zero. This will cause

premature wear of the turbocharger

bearings.

Leaving the key in position I or II will

discharge the battery.

Braking System

142

Emergency Brake Assist (EBA)

The EBA system measures the rate at

which the brake pressure increases. If the

system detects an emergency braking

situation, EBA automatically initiates the

full braking effect. This can reduce

stopping distances in critical situations,

which can help an inexperienced driver to

stop in the same distance as an

experienced driver.

!WARNING:

The EBA system is an additional safety

system; it is not intended to relieve the

driver of his or her responsibility for

exercising due care and attention when

driving.

Advice on ABS braking techniques

For optimum ABS performance, these

instructions on braking techniques during

ABS operation should be followed:

• Do not release brake pressure when

the pulsating effect is felt. Maintain a

constant pressure until the

manoeuvre is completed.

• To familiarise yourself with the feel of

the brake pedal during ABS braking,

practise an emergency stop

procedure, always making sure it is

safe to do so. With the seat belts fitted

to all occupants, drive the vehicle at

32 km/h (20 mph) and brake sharply.

• ABS enables the driver to steer

around obstacles during emergency

braking. However, the consequences

of turning sharply at high speed

cannot be overcome by the ABS.

• Do not attempt to pump the brakes to

avoid skidding, as this can interfere

with the ABS operation. The ABS will

not allow the wheels to skid under

normal road conditions.

• The ABS will tend to keep the vehicle

straight during braking. Braking

distances may increase under certain

road conditions, therefore, it is

necessary to plan and make turning

manoeuvres as early as possible.

Driving Information

148

Towbar fixing points

The left-hand and right-hand rear

longitudinal members are factory

pre-marked for drilling for towbar

mountings. On each side, there are two

upper drilling points (accessed from

inside the luggage compartment) and two

lower drilling points (accessed from the

underside of the vehicle). The illustration

shows the right-hand side upper and

lower drilling points, indicated by arrows.

The left-hand and right-hand rear

tie-down brackets are fixed to the body

by four bolts (1).

When the towbar is fitted, bracket (2) is

discarded.

Tow ball centre height from the ground at

Gross Vehicle Weight (GVW):

(A) = 370 mm to 382mm (14.57 to 15.2

inches).

Tow ball centre distance from centre line

of rear axle:

(B) = 1165 mm (45.87 inches).

157

Climate Control

Use of air recirculation

The air conditioner and heater system is

supplied with fresh air via an intake flap.

Closing the flap causes the air inside the

vehicle to be recirculated. This helps to

prevent unpleasant odours from being

drawn into the vehicle and also to improve

the performance of the air conditioner in

very hot conditions. However, the use of

recirculated air will cause screen misting

after a short period and should only be

used as necessary.

In AUTO mode, the air intake flap is

controlled automatically. If required, air

recirculation may be manually selected

for either a short or indefinite period.

!WARNING:

To prevent humidity build up inside the

vehicle and possible screen misting,

avoid driving with the air conditioning

system off, or in manual air

recirculation, for prolonged periods.

GENERAL POINTS

To ensure the satisfactory operation of

the climate control system, note the

following points:

• Make sure that the external grille at

the base of the windscreen, which

provides fresh air for the climate

control system, is kept clear of leaves,

snow or obstructions.

• A solar sensor is mounted on the

centre top of the facia, as shown on

the next page (1). Make sure that this

sensor is not covered.

• Temperature and humidity sensors

are located behind the small grille, as

shown to the next page (2). Do not

cover or obstruct the opening.

• Air ducts under the front seats supply

the rear passenger footwells (see

illustration opposite). Objects or

material placed under the seats may

block or obstruct the open ducts.

• The external air intake to the air

conditioner and heater system is fitted

with a filter. Make sure that the filter is

changed at the specified service

intervals to maintain efficient

operation.

• If the air conditioning system is not

used frequently, it should be run

briefly at least once each week, with a

cold setting, to prevent the seals from

drying out with subsequent refrigerant

leaks.

• Moisture removed from the air by the

air conditioning unit is discharged

onto the road underneath the vehicle.

After stopping, puddles of water may

form underneath the vehicle. This is

normal.

AUXILIARY FUEL FIRED

HEATER - DIESEL ONLY

The auxiliary heater aids in warming the

engine and interior compartment. It is

integrated into the cooling system and is

automatically switched on or off

depending on the coolant and ambient

temperatures, while the engine is running.

It is possible that when the fuel-fired

heater is activated, vapour may appear

from under the front of the vehicle for a

short time, during which a slight odour

may be detected. This is normal.

Note: The auxiliary heater will not function

if the climate control system is switched

off.

Specyfikacje produktu

Marka:	Jaguar
Kategoria:	Automatyczny
Model:	S-Type (2008)

Potrzebujesz pomocy?

Jeśli potrzebujesz pomocy z Jaguar S-Type (2008), zadaj pytanie poniżej, a inni użytkownicy Ci odpowiedzą

Twoje imię*

Twój email*

Napisz tutaj swoje pytanie

Instrukcje Automatyczny Jaguar

Jaguar XJ6 (1978) Instrukcja

8 Września 2024

Jaguar F-Type (2015) Instrukcja

7 Września 2024

Jaguar E-Pace (2020) Instrukcja

30 Sierpnia 2024

Jaguar XJ (2014) Instrukcja

30 Sierpnia 2024

Jaguar S-Type (2007) Instrukcja

29 Sierpnia 2024

Jaguar S-Type (2008) Instrukcja

27 Sierpnia 2024

Jaguar XK (2012) Instrukcja

23 Sierpnia 2024

Jaguar F-Type (2014) Instrukcja

7 Sierpnia 2024

Jaguar XJ6 (1997) Instrukcja

7 Sierpnia 2024

Jaguar XK (2015) Instrukcja

7 Sierpnia 2024

Instrukcje Automatyczny

Najnowsze instrukcje dla Automatyczny

Honda Jazz Hybrid (2023) Instrukcja

7 Kwietnia 2025

Ford Focus Electric (2012) Instrukcja

3 Kwietnia 2025

Dodge Challenger SRT (2017) Instrukcja

2 Kwietnia 2025

Audi SQ5 (2024) Instrukcja

26 Marca 2025

Opel Rocks-e (2021) Instrukcja

13 Marca 2025

Aguilar DCB-4PJ Instrukcja

10 Marca 2025

Aguilar DCB-5J Instrukcja

10 Marca 2025

Aguilar DCB-4J Instrukcja

10 Marca 2025

Mercury Mountaineer (1998) Instrukcja

9 Marca 2025

Aguilar AG 4J-HC Instrukcja

9 Marca 2025
