Strona 1/11
ILVE
ILREF256i
Integrated Refrigerator
Manual
V140220
EN 12
Thank you for purchasing this product.
Before using your refrigerator, please carefully read this instruction manual in order to maximize its performance. Store all documentation for
subsequent use or for other owners. This product is intended solely for household use or similar applications such as:
- the kitchen area for personnel in shops, offi ces and other working environments
- on farms, by clientele of hotels, motels and other environments of a residential type
- at bed and breakfasts (B & B)
- for catering services and similar applications not for retail sale.
This appliance must be used only for purposes of storage of food, any other use is considered dangerous and the manufacturer will not be respon-
sible for any omissions. Also, it is recommended that you take note of the warranty conditions.
The refrigerator contains a refrigerant gas (R600a: isobutane) and insulating gas (cyclopentane), with
high compatibility with the environment, that are, however, inflammable.
We recommend that you follow the following regulations so as to avoid situations dangerous to you:
• Before performing any operation, unplug the power cord from the power socket.
• The refrigeration system positioned behind and inside the refrigerator contains refrigerant. Therefore,
avoid damaging the tubes.
• If in the refrigeration system a leak is noted, do not touch the wall outlet and do not use open flames.
Open the window and let air into the room. Then call a service centre to ask for repair.
• Do not scrape with a knife or sharp object to remove frost or ice that occurs. With these, the refrigerant
circuit can be damaged, the spill from which can cause a fire or damage your eyes.
• Do not install the appliance in humid, oily or dusty places, nor expose it to direct sunlight and to water.
• Do not install the appliance near heaters or inflammable materials.
• Do not use extension cords or adapters.
• Do not excessively pull or fold the power cord or touch the plug with wet hands.
• Do not damage the plug and/or the power cord; this could cause electrical shocks or fires.
• It is recommended to keep the plug clean, any excessive dust residues on the plug can be the cause fire.
• Do not use mechanical devices or other equipment to hasten the defrosting process.
• Absolutely avoid the use of open flame or electrical equipment, such as heaters, steam cleaners,
candles, oil lamps and the like in order to speed up the defrosting phase.
• Do not use or store inflammable sprays, such as spray paint, near the refrigerator. It could cause an
explosion or fire.
• Do not use electrical appliances inside the food storage compartments, unless they are of the type
recommended by the manufacturer.
• Do not place or store inflammable and highly volatile materials such as ether, petrol, LPG, propane gas,
aerosol spray cans, adhesives, pure alcohol, etc. These materials may cause an explosion.
• Do not store medicine or research materials in the refrigerator. When the material that requires a strict
control of storage temperatures is to be stored, it is possible that it will deteriorate or an uncontrolled
reaction may occur that can cause risks.
• Maintain the ventilation openings in the appliance enclosure or in the built-in structure, free of
obstruction.
• Do not place objects and/or containers filled with water on the top of the appliance.
• Do not perform repairs on this refrigerator. All interventions must be performed solely by qualified
personnel.
• This appliance can be used by children aged from 8 years and above and by persons with reduced
physical, sensory or mental capabilities or with a lack of experience and knowledge, provided that they
have been given adequate supervision or instruction concerning how to use the appliance in a safe way
and understand the hazards involved.
Children should not play with the appliance. Cleaning and user maintenance should not be made by
children without supervision.
Turning the knob fully counterclockwise, you will hear a click which corresponds to the switch-off of
the product.
When the appliance is installed, the electrical cord and the current socket must be easily reached.
The socket is compatible with the plug of the appliance. If not, request replacement of the plug
by an authorized technician; do not use extension cords and/or multiple connectors.
Do not touch the internal parts or frozen food with moist or wet hands as it can cause burns.
SAFET INFORMATION
EN 13
Fig. 1
Remove all wrapping/packaging present inside the appliance and clean
with water and baking soda or neutral soap.
After the installation, wait 2 - 3 hours to allow time for the refrigerator/
freezer to stabilize at normal working temperature, before placing fresh
or frozen foods inside.
If the power cord becomes disconnected, wait at least five minutes
before restarting the refrigerator/ freezer. At this point, the appliance is
ready for use.
Press the button for setting the temperature until you reach the level you
want where level 1 is the warmest and level 4 is the coldest. Under
normal operating conditions, we recommend using an intermediate
setting (level 2)
If you do not press the button (2) for more than 5 seconds, the settings
will be saved.
The temperature levels in advanced settings are set from warmest to
coldest e.g. 2/2.1/2.3/2.4 which means there are 4 sub-levels for every
main level.
Door open alarm
If the door is left open for longer than 90 seconds, an alarm is sounded. To
turn it o , simply close the door or press button 2.
On/O 1 3 42
Press button (2) for less than 2 seconds to change the temperature level.
On/O 1 2 4 3
Advanced settings menu:
Use this menu to set an intermediate level.
On/O 1 3 4 2
Press button (2) for more than 2 seconds. When you release it, LED
2 will flash
On/O 1 4 2 3
The next time you press button (2) for less than 2 seconds, the
intermediate level will be set. This operation works in cycles every time
you press the button.
On/O 1 3 2 4
On/O 1 2 3 4
By placing the mark on this product, we are confirming compliance to
all relevant European safety, health and environmental requirements which
are applicable in legislation for this product.
Scrapping old appliance
Conformity
Appliance start-up
Turning On/Off
Setting the temperature
OPERATION
Control panel
1. Temperature indicator LED
2. Temperature control
3. ON/OFF button
Turning the appliance ON:
Plug the appliance in, if all the temperature indicators LEDs are off, press
ON/OFF (3) for 1 second. When you release the ON/OFF button (3) a
temperature light will come on and the appliance will beep.
Turning the appliance OFF:
Press the ON/OFF button (3) for 1 second, when you release it, the
temperature light will go out and the appliance will beep. In the event of a
power failure, when the power comes back on, the appliance will run
using the last saved setting.
23
1
WARNINGS:
• Do not install the appliance in a damp or wet location as this could
compromise the insulation and result in leakage.
Furthermore, on the exterior of the same, condensate could accumulate
• Do not place the appliance in locations outside or near sources of heat
or exposed to direct sunlight.
The appliance operates properly within the range of environmental
temperatures indicated:
+10 +32’C for the climatic class SN
+16 +32’C for the climatic class N
+16 +38’C for the climatic class ST
+16 +43’C for the climatic class T
(See the nameplate of the product)
• Do not place containers with liquids on top of the appliance.
• Wait at least 3 hours after final placement before placing the appliance
in operation.
After shipping, place the appliance vertically and wait at least 2 - 3 hours
before connecting it to the electrical system. Before inserting the plug
into the electrical socket, make sure that:
• The socket is earthed and in compliance with the law.
• The socket can withstand the maximum power load of the appliance, as
indicated on the nameplate of the refrigerator.
• The power supply voltage is within the amounts indicated on the
nameplate of the refrigerator.
• The cord must not be folded or compressed.
• The cord must be checked regularly and replaced solely by authorized
technicians.
• The manufacturer declines any liability whenever these safety
measures are not respected.
Electrical connection
INSTALLATION
This appliance is marked according to the European directive
2012/19/EU on Waste Electrical and Electronic Equipment (WEEE).
WEEE contains both polluting substances (which can cause negative
consequences for the environment) and basic components (which
can be re-used). It is important to have WEEE subjected to specific
treatments, in order to remove and dispose properly all pollutants,
and recover and recycle all materials.
Individuals can play an important role in ensuring that WEEE does
not become an environmental issue; it is essential to follow some
basic rules:
- WEEE should not be treated as household waste;
- WEEE should be handed over to the relevant collection points
managed by the municipality or by registered companies. In
many countries, for large WEEE, home collection could be
present.
In many countries, when you buy a new appliance, the old one may
be returned to the retailer who has to collect it free of charge on a
one-to-one basis, as long as the equipment is of equivalent type and
has the same functions as the supplied equipment.
