USB WebCam
USE R MANUAL
Precautions For USE
1. Use environment requirements
● Away from hot sources and environments; Avoid direct
sunlight.
● Avoid contacting with water, if water contact equipment,
must power it o immediately.
● Avoid using in too humid environment, please use in the
applicable humidity range (20% 85% non condensation).～
● Avoid using in too hot or too cold environment, please use
within the reference applicable temperature range (0°C ～
55°C ).
● Please protect the USB cord from trampling or pressing.
Product Specications
● 1/2.9" color CMOS sensor
● Support H.264 image compression
● Max Resolution: 1920*1080P
● Max Image frame: 60fps
● Built-in 48dB microphone
● Support USB2.0\USB1.0, fast and full automatic
switching
● Support Windows multiple system
● USB no drive, plug and play
FAQ
1. Camera cannot be detected
● Firstly, please conrm whether the USB port of the
computer is in good condition. Also you can plug and
unplug the USB port or replace the USB port to have a
try.If the computer prompts the “drive error”, please check
whether the USB drive of the computer system is
complete. The device does not need to install a drive
separately, just update the computer drive.
2. The color of video pre-display image is not correct
● The camera adjusts automatically.Please wait 20-30
seconds, to make Auto White balance to adjust or correct
itself.For ordinary cameras, needs manual adjustment by
holding a white paper until the camera to whiten.
Guarantee
1. The warranty period is 1 year.
2. The company is responsible for the repair and
replacement of the damaged parts of the original
products, customers should keep the damaged parts and
accessories.
3. If the products sold by the company are damaged due
to quality problems, the company is responsible for
maintenance or replacement, and bear the transportation,
installation and other costs arising therefrom.
4. Damages caused by natural disasters such as typhoon,
ood and earthquake, are not covered in the company's
warranty.
5. Damages caused by improper use or man-made
damage, such as violent collision, missing parts, etc., are
not covered in the company's warranty.
Product Introduction
1. Product description Function
This type of camera is a plug and play camera product
developed by our company. It adopts H. 264 code format,
and can be connected to a computer for use without
complicated settings.
Product diagram Installation and use
Win XP
This product does not require installing a drive. Only need
to connect the device with computer through USB port.
2. Packaging 58mm
Microphone
USB cable
Camera lens
Bracket
60mm
Note: when the user receives the product, please check
whether there is any obvious damage to the appearance
of the equipment, and check whether the accessories are
complete. Please refer to the below list for inspection
The accessories list:
c, Prevent the damage caused by press, violent vibration,
soaking, etc during transportation, storage, and
installation.
d, Avoid moving the camera between the supercooled and
overheated places, so as to avoid condensation inside the
machine and aect the machine life.
2.Transportation and handling
a, The packaging of the machine has been designed and
tested to ensure that the camera will not be accidentally
damaged during transportation
b, When handling the machine, it is best to use the original
packaging materials and cartons;
3.Notes
a, Do not drop the product or receive a strong knock.
b, Please use glabrous soft cloth or glasses cloth to clean machine,
do not use volatile solvents such as alcohol, benzene or diluent, or
abrasive cleaner. Otherwise, will damage the product surface or
reduce the performance of the camera.
c, Avoid focusing on bright light (such as lighting, sunlight, etc.),
otherwise it is easy to cause too bright or are phenomenon (this
is not camera fault), will also aect the life of the image sensor.
d, The laser beam may burn the image sensor, so please make sure
the surface of image sensor not exposed under laser beam.
e, Do not attempt to disassemble the product, which may cause
damage to the product and invalidate the warranty you are
entitled to.
f, Keep the machine out of reach of children, and do not allow
children to play.
Accessories Name Unit Qty
Webcam(USB and pcs 1
holder included)
User manual pcs 1
Detailed Parameters
Win 7
Note: some computers cannot read after connecting to the camera. This is
not the camera problem. It is because the computer does not have a USB
drive (this drive is system’s own drive), which needs to be installed by the user.
Item Specifications
sensor
Image sensor
Resolution
1/2.9" color CMOS sensor
60°
1920*1080/1280*720/640*360
Lens Lens type
Wide angle
6P+1R, F/NO 4.4mm, EFL 2.0mm,
BFL 1.0mm
USB audio support Class 1.0, ADC 16 bit
Audio Microphone
Audio format
Built-in 48dB microphone
60fps
Video
Image compression
Image frame rate
HD1080P(1920*1080 25fps), HD 720P
(1280*720 30fps), VGA (640*480 60fps)
Resolution
Adaptor DC 5VPower supply
Environ-
ment
0°C 55°C (32°F 131°F)～ ～
Working
temperature
Supported
system
Windows10 32bit/64bit; Windows8 32bit/64bit;
Windows7 32bit/64bit; Windows Vista 32bit/64bit;
Windows XP SP2 32bit/64bit
Warranty 1 year
20% 85% non condensation～
Working humidity
-10°C 60°C (14°F 140°F)～ ～
Storage
temperature
0% 90% non condensation～
Storage humidity
Cable length:120CMUSB
H.264
51mm
