Control Panel
1. Display
2. Power/Source: Press and hold to power ON/
OFF. Press to change play mode: (Bluetooth/
Aux/Micro SD/FM).
3. Press to change turn display Display ON/OFF:
ON/OFF. Press and hold for 5 seconds to turn
voice prompts ON/OFF.
4. Press to skip audio tracks :
(BLUETOOTH/SD). Press to change FM radio
station.
5. : Press to play or pause tracks /
(BLUETOOTH/SD). Press and hold to manually
enter into pairing mode. Press and hold to scan
radio frequencies and save radio stations (FM
radio).
6. Volume
7. Micro SD port
8. Aux In (3.5mm Audio Input)
9. DC Power Input: Use to charge the internal
battery and power the speaker.
Important Safety Instructions
• Read these Instructions.
• Keep these Instructions.
• Heed all Warnings.
• Follow all instructions.
• Do not use this apparatus near water.
• Clean only with a dry cloth.
• Do not block any ventilation openings. Install in accordance with the
manufacturer’s instructions.
• Do not install near any heat sources such as radiators, heat registers, stoves, or
other apparatus (including ampliers) that produce heat.
• Do not defeat the safety purpose of the polarized or grounding - type plug. A
polarized plug has two blades with one wider than the other. A grounding type
plug has two blades and a third grounding prong. The wide blade or the third
prong are provided for your safety. When the provided plug does not t into
your outlet, consult an electrician for replacement of the obsolete outlet.
• Protect the power cord from being walked on or pinched particularly at plugs,
convenience receptacles, and the point where they exit from the apparatus.
• Only use attachments/accessories specied by the manufacturer.
• Unplug this apparatus during lightning storms or when unused for long
periods of time.
• Refer all servicing to qualied service personnel. Servicing is required
when the apparatus has been damaged in any way, such as power-supply
cord or plug is damaged, liquid has been spilled or objects have fallen into
the apparatus, the apparatus has been exposed to rain or moisture, does not
operate normally, or has been dropped.
• Use only with a cart, stand, tripod, bracket, or table specied by
the manufacturer, or sold with the apparatus. When a cart is used,
use caution when moving the cart/apparatus combination to avoid
injury from tip-over.
FCC Warnings
Warning: Changes or modications to this unit not expressly approved by the
party responsible for compliance could void the user’s authority to operate the
equipment.
NOTE: This equipment has been tested and found to comply with the limits
for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits
are designed to provide reasonable protection against harmful interference in
Overview
13” Portable Bluetooth Speaker
User’s Guide for Model ISB330 v2740-01
a residential installation. This equipment generates, uses, and can radiate radio
frequency energy and, if not installed and used in accordance with the instructions,
may cause harmful interference to radio communications. However, there is
no guarantee that interference will not occur in a particular installation. If this
equipment does cause harmful interference to radio or television reception, which
can be determined by turning the equipment o and on, the user is encouraged to
try to correct the interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit dierent from
that to which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
Additional Warnings and Precautions
• CAUTION: TO PREVENT ELECTRIC SHOCK, MATCH WIDE BLADE
OF PLUG TO WIDE SLOT, FULLY INSERT.
• Mains plug is used as disconnect device and it should remain readily operable
during intended use. In order to disconnect the apparatus from the mains
completely, the mains plug should be disconnected from the mains socket
outlet completely.
• WARNING: Shock hazard - Do Not Open.
• CAUTION: Use of controls or adjustments or performance of procedures
other than those specied may result in hazardous radiation exposure.
• WARNING: Changes or modications to this unit not expressly approved by
the party responsible for compliance could void the user’s authority to operate
the equipment.
• WARNING: Do not place this unit directly onto furniture surfaces with any
type of soft, porous, or sensitive nish. As with any rubber compound made
with oils, the feet could cause marks or staining where the feet reside. We
recommend using a protective barrier such as a cloth or a piece of glass
between the unit and the surface to reduce the risk of damage and/or staining.
• WARNING: Do not ingest battery, chemical burn hazard.
• Battery shall not be exposed to excessive heat such as sunshine, re or the
like.
• Lithium batteries, like all rechargeable batteries, are recyclable and should
be recycled or disposed of according to state and local guidelines. They
should never be disposed of in normal household waste and they should never
be incinerated, as they might explode. Contact your local government for
disposal or recycling practices in your area.
WARNING: To reduce the risk of electric
shock, do not remove cover (or back). No
user-serviceable parts inside. Refer servicing
to qualied service personnel.
WARNING: This product can expose you to
chemicals including lead, which is known to
the State of California to cause cancer. For
more information go to: www.P65Warnings.
ca.gov This product meets and complies with
required Federal product guidelines.
ATTENTION
RISQUE D' ÉLECTROCUTION
NE PAS OUVRIR
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
The exclamation point within an equilateral
triangle is intended to alert the user to
the presence of important operating and
maintenance (servicing) instructions in the
literature accompanying the appliance.
This symbol indicates that this product
incorporates double insulation between
hazardous mains voltage and user accessible
parts.
The lightning ash with arrowhead symbol,
within an equilateral triangle, is intended to
alert the user to the presence of un-insulated
“dangerous voltage” within the product’s
enclosure that may be of sucient magnitude
to constitute a risk of electric shock to persons.
Features
• Bluetooth 5.0 wireless - range 60 ft.
• Voice prompts
• FM radio
• 3.5mm Aux In
• Micro SD port
• Built-in rechargeable battery
• Battery life: approx. 15 hrs playtime at 50%
volume
Includes
• USB cable for battery recharge
SOURCE DISPLAY
ON /OFF
POWER
V
O
L
U
M
E
DISPL OFFAY
21
3
4
5
6
AUX IN DC IN
97 8
To download this User’s Guide in English, Spanish, or French, or to get answers to frequently asked questions, visit the support section at:
www.iLiveElectronics.com
Para descargar este Manual del Usuario en inglés, español y francés, o para obtener respuestas a preguntas frecuentes, visite la sección de
apoyo en: www.iLiveElectronics.com
Pour télécharger ce guide de l’utilisateur en anglais, espagnol ou français, ou pour obtenir des réponses à des questions fréquemment
posées, consultez la rubrique d’assistance sur: www.iLiveElectronics.com
For Warranty Information and the most up-to-date version of this User’s Guide, go to www.iLiveElectronics.com
Customer Service: Email Support: Email Parts:1-888-999-4215 | prodinfo@dpiinc.com | partsinfo@dpiinc.com
Copyright © 2021 Digital Products International (DPI, Inc.) All other trademarks appearing herein are the property of their respective owners.
Specications are subject to change without notice.
Customer Support
Protect for Today
Sustain for Tomorrow
Made
Green
Aux In
Requires a 3.5mm audio cable (not included).
1. Connect a 3.5mm audio cable to the on the unit and the Aux In
audio output on an audio device.
2. The Speaker will automatically switch to Aux mode.
3. Use the controls on the connected device to select and play audio. Be sure
the volume on your connected device is audible when you begin playing.
AUX IN DC IN
Micro SD
1. Load a Micro SD drive into the The speaker will Micro SD port.
automatically switch to SD card mode, indicated by a voice prompt, and
begin playing media on the drive.
2. Use the controls on the speaker to select and play audio from the
connected drive.
FM Radio
Radio Reception
An FM receiver is built into the speaker. Adjust the position of the speaker to
improve FM radio reception.
Radio Tuning and Saving Station Presets
1. Press the Source FM Radio Mode, button to select indicated by a voice
prompt.
2. Press and hold the button to scan radio stations automatically.
3. Press and hold the buttons to tune radio frequencies.
AUX IN DC IN
Charging the Battery
To charge the internal battery, plug the USB charging cable into the DC Power
Input on the speaker and a USB power adapter (not included) and standard power
outlet. Charging time is approximately 5 hours. Battery life is approximately 15
hours at 50% volume. Battery life can be extended by playing at lower volume
levels.
AUX IN DC IN
Bluetooth Wireless
Pairing & Playing Audio
When rst powered on, the speaker defaults to Bluetooth Mode, indicated by a
voice prompt.
1. Power ON the speaker by adjusting the Power Switch to the ON position.
The speaker defaults to Bluetooth Mode and is ready to pair automatically.
When pairing, remain within 3 feet of the Bluetooth device. the symbol
on the display will begin ashing, indicating it is ready to be paired.
2. Using the controls on your Bluetooth device, select in the Bluetooth ISB330
Settings to pair. If need be, refer to the user’s manual for your specic device
for more information.
3. When successfully paired, a voice will announce, “Bluetooth is connected.”
The symbol will turn solid. Your Bluetooth device will now be heard
through the speaker.
4. Use the controls on the connected Bluetooth device to select and play
audio. Use the speaker controls or the connected Bluetooth device to play,
pause, and adjust the volume level.
5. After initial pairing, the speaker will automatically connect to the last
Bluetooth device used whenever it is in Bluetooth Mode. If your Note:
device should become unpaired or you nd it is unable to connect, press
& hold the button to enter to manually enter Pairing Mode. A voice will
announce, “Bluetooth is connecting,” and you can connect to the speaker
following the steps above..

Specyfikacje produktu

Marka: ILive
Kategoria: głośnik
Model: ISB330

Potrzebujesz pomocy?

Jeśli potrzebujesz pomocy z ILive ISB330, zadaj pytanie poniżej, a inni użytkownicy Ci odpowiedzą


Instrukcje głośnik ILive

ILive

ILive IBDJ883 Instrukcja

4 Października 2024
ILive

ILive ISB352 Instrukcja

4 Października 2024
ILive

ILive ISBW519 Instrukcja

4 Października 2024
ILive

ILive ISBW157 Instrukcja

4 Października 2024
ILive

ILive ISB659 Instrukcja

4 Października 2024
ILive

ILive ISB2133 Instrukcja

4 Października 2024
ILive

ILive ISB202 Instrukcja

4 Października 2024
ILive

ILive IHB26W= Instrukcja

4 Października 2024
ILive

ILive ISB143 Instrukcja

4 Października 2024
ILive

ILive IJBS90 Instrukcja

4 Października 2024

Instrukcje głośnik

Najnowsze instrukcje dla głośnik

Teufel

Teufel Rockster Air Instrukcja

15 Października 2024
Alpine

Alpine PSS-22WRA Instrukcja

15 Października 2024
Bauhn

Bauhn APPS-0724 Instrukcja

15 Października 2024
Aiwa

Aiwa SP-A100 Instrukcja

15 Października 2024
Harman Kardon

Harman Kardon Citation One Instrukcja

14 Października 2024
Alpine

Alpine 30MC Instrukcja

14 Października 2024
Magnat

Magnat Needle 9000 ALU Instrukcja

14 Października 2024
Pioneer

Pioneer SP-T22A-LR Instrukcja

14 Października 2024
Sharp

Sharp PS-932 Instrukcja

14 Października 2024
Pyle

Pyle PDWR64BTW Instrukcja

13 Października 2024
