Overview
Wireless Speaker System with Subwoofer
User’s Guide for Model IHB26B v1616-01
Features
• 2.1 channel stereo sound
• Built-in amplier
• 3 speakers: left, right, and subwoofer
• LED light eects
• Supports Bluetooth
• Bluetooth Wireless range: 60 ft
• Analog volume control
• Bass and Treble controls
• Aux In 3.5 mm audio input
• USB port for device charging
• AC power: built-in AC power cable
Includes
• 3.5mm audio cable
• User’s guide
FCC WARNINGS
Warning: Changes or modications to this unit not expressly approved by the party responsible for
compliance could void the user’s authority to operate the equipment.
NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device,
pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against
harmful interference in a residential installation. This equipment generates, uses, and can radiate radio
frequency energy and, if not installed and used in accordance with the instructions, may cause harmful
interference to radio communications. However, there is no guarantee that interference will not occur in a
particular installation. If this equipment does cause harmful interference to radio or television reception,
which can be determined by turning the equipment off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
ADDITIONAL WARNINGS
• WARNING: Changes or modications to this unit not expressly approved by the party responsible for
compliance could void the user’s authority to operate the equipment.
• WARNING: Shock hazard - Do Not Open.
• Caution and marking information is located at the rear or bottom of the apparatus.
• Mains plug is used as disconnect device and it should remain readily operable during intended use. In
order to disconnect the apparatus from the mains completely, the mains plug should be disconnected
form the mains socket outlet completely.
• CAUTION: TO PREVENT ELECTRIC SHOCK, MATCH WIDE BLADE OF PLUG TO WIDE
SLOT, FULLY INSERT.
• Objects lled with liquids, such as vases, shall not be placed on the apparatus
• WARNING: Do not place this unit directly onto furniture surfaces with any type of soft, porous, or
sensitive nish. As with any rubber compound made with oils, the feet could cause marks or staining
where the feet reside. We recommend using a protective barrier such as a cloth or a piece of glass
between the unit and the surface to reduce the risk of damage and/or staining.
• WARNING: This product may contain chemicals known to the State of California to cause birth
defects, or other reproductive harm (California Prop 65). Wash hands after handling.
• This product meets and complies with all Federal regulations.
Volume Up/Down
Treble Up/Down
Bass Up/Down
Stereo Speaker Outputs
Pair Bluetooth/Lights
Press and hold to pair.
Short press to turn lights ON or OFF.
120V 60Hz
POWER
ON
OFF
AUX IN
SPEAKER
OUTPUT
R L
TREBLE VOLUME BASS
USB
CHARGER ~
PAIR / LIGHTS
Rear View
Power ON/OFF
USB Power Port
Aux In 3.5mm Audio Input
Aux In
Requires a 3.5mm audio cable (included).
1. Connect a 3.5mm audio cable to the Aux In on the unit and the Input audio
output on an audio device.
2. Use the controls on the connected device to select audio, play, pause, skip,
and adjust the volume.
To download this User’s Guide in English, Spanish, or French, or to get answers to frequently asked questions, visit the support
section at: www.iLiveElectronics.com
Para descargar este Manual del Usuario en inglés, español y francés, o para obtener respuestas a preguntas frecuentes, visite la
sección de apoyo en: www.iLiveElectronics.com
Pour télécharger ce guide de l’utilisateur en anglais, espagnol ou français, ou pour obtenir des réponses à des questions
fréquemment posées, consultez la rubrique d’assistance sur: www.iLiveElectronics.com
For Warranty Information and the most up-to-date version of this User’s Guide, go to www.iLiveElectronics.com
Customer Service: | Email Support: | Email Parts: 1-888-999-4215 prodinfo@dpiinc.com partsinfo@dpiinc.com
Copyright © 2016 Digital Products International (DPI, Inc.) All other trademarks appearing herein are the property of their
respective owners. Specications are subject to change without notice.
INTERNATIONAL SUPPORT
Protect for Today
Sustain for Tomorrow
Made
Green
120V 60Hz
POWER
ON
OFF
AU IN
SPEAKER
OU TPUT
R L
TREBLE VOLUME BASS
USB
CHARGER ~
PAIR / LIGHTS
120V 60Hz
POWER
ON
OFF
AUX IN
SPEAKER
OUT PUT
R L
TREBLE VOLUME BASS
USB
CHARGER ~
PA R / LIGHTS
AUX IN
S
RUSB
CHARGER
LIGHTS
USB
CHARGER
120V 60Hz
POWER
ON
OFF
AUX IN
SPEAKER
OUTPUT
R L
TREBLE VOLUME BAS S
USB
CHARGER ~
PAIR / LIGHTS
12
SPEAKER
OUTPUT
R L
Power & Charging
Connect the power plug to a standard power outlet.
Connect Speakers
Connect the left and right speaker cables to the left and right on audio outputs
the subwoofer.
Charge Devices
Using an appropriate USB power cable (not included), connect your device to the
USB Power Port on the rear of the subwoofer.
120 V 6 0Hz
POWE R
ON
OF
AUX IN
SPEAKER
OU TP U T
R L
TREBL E VOL UME BA S S
USB
CHARGE R ~
PAI R / LIGHT S
Bluetooth Wireless Audio
Pairing to a Device & Playing Audio
After initial pairing, the unit will stay paired unless unpaired manually by
the user or erased due to a reset of the device. If your device should become
unpaired or you nd it is unable to connect, repeat the steps listed here.
1. Power ON the unit and press and hold the to begin pairing.Pair button The
LED lights will begin ashing quickly. The lights will always ash during the
pairing process, even if they are set to OFF. Once the pairing process is complete,
the lights will return to OFF. When pairing, remain within 3 feet of the unit.
2. Using the controls on your Bluetooth device, search for and select IHB26
in your Bluetooth settings to pair. If your device requests a password, enter
the default password . 0 0 0 0 Refer to the user’s manual for your specic
device for instructions on pairing and connecting Bluetooth devices.
3. When successfully paired, the will turn solid and an audible LED lights
chime will sound from the speaker. Use the controls on the connected
device to select audio, play, pause, skip, and adjust the volume.
