ENQuick Guide

THANK YOU FOR BUYING AN IGNIS PRODUCT.

CONTROL PANEL

FIRST TIME USE

Before using the appliance carefully read Safety Instructions

guide.

PROGRAMS TABLE

PLEASE SCAN THE QR CODE ON YOUR

APPLIANCE IN ORDER TO HAVE MORE

DETAILED INFORMATION

FILLING THE SALT RESERVOIR

The use of salt prevents the formation of LIMESCALE on the dishes and on

the machine’s functional components.

• It is mandatory that the salt reservoir never be empty.

• It is important to set the water hardness.

The salt reservoir is located in the lower part of the dishwasher and must be

lled when the SALT REFILL indicator light in the control panel is lit.

1. Remove the lower rack and unscrew the reservoir cap

(anticlockwise).

2. Position the funnel and ll the salt reservoir (see gure)

right up to its edge (approximately 1 kg); it is not unu-

sual for a little water to leak out.

3. Only the rst time you do this: ll the salt reservoir

with water.

4. Remove the funnel and wipe any salt residue away from the opening.

Make sure the cap is screwed on tightly, so that no detergent can get into

the container during the wash program (this could damage the water

softener beyond repair).

Whenever you need to add salt, it is mandatory to complete the proce-

dure before the beginning of the washing cycle to avoid corrosion.

FILLING THE RINSE AID DISPENSER

Rinse aid makes dish DRYING easier. The rinse aid

dispenser A should be lled when the RINSE AID

REFILL indicator light in the control panel is lit.

NEVER pour the rinse aid directly into the appliance

tub.

FILLING THE DETERGENT DISPENSER

To open the detergent dispenser use the opening device C. Introduce the

detergent into the dry dispenser only. Place the amount of detergent for D

pre-washing directly inside the tub.

If all-in-one detergents are used, we recommend using the TABLET button,

because it adjusts the program so that the best washing and drying results

are always achieved.

Usage of detergent not designed for dishwashers may cause

malfunction or damage to the appliance.

WATER SOFTENING SYSTEM

Water softener automatically reduces water hardness, consequently pre-

venting scale buildup on heater, contributing also to better cleaning e-

ciency. This system regenerates itself with salt, therefore it is required

to rell salt container when empty.

Frequency of regeneration depends on water hardness level setting - regen-

eration takes place once per 6 Eco cycles with water hardness level set to 3.

Regeneration process starts in nal rinse and nishes in drying phase, be-

fore cycle ends.

• Single regeneration consumes: ~3.5L of water;

• Takes up to 5 additional minutes for the cycle;

• Consumes below 0.005kWh of energy.

1. ON-OFF/Reset button with indicator light

2. Program selection button

3. Salt rell indicator light

4. Rinse Aid rell indicator light

5. Program number and delay time indicator

6. Tablet indicator light

7. Display

8. Half Load indicator lights

9. Half Load button

10. Delay button

11. START/Pause button with

indicator light / Tablet (Tab)

Program Programs description

Drying

phase

Available

options *)

Duration

of wash

program

(h:min)**)

Water

consumption

(litres/cycle)

Energy

consumption

(kWh/cycle)

Eco 50°- Eco program is suitable to clean normally soiled tableware.

that for this use. it is the most ecient program in terms of its

combined energy and water consumption. and that it is used to

assess compliance with the EU Ecodesign legislation.

3:35 9.5 0.95

2. Intensive 65° - Program recommended for heavily soiled crockery.

especially suitable for pans and saucepans (not to be used for

delicate items). 2:40 18.0 1.60

Mixed 55° - Mixed soil. For normally soiled dishes with dried food residues.

2:15 16.0 1.40

Fast Wash&Dry 50° - Normally soiled crockery. Everyday cycle, that

ensures optimal cleaning and drying performance in shorter time.

1:30 11.5 1.30

5. Fast&Clean 28’

50° -

Program to be used for half load of lightly-

soiled dishes with no dried food residues. Does not have

drying phase. - 0:28 9.0 0.50

Night 50° - Suitable for night-time operation of the appliance.

Ensures optimal cleaning and drying performance with the lowest

noise emission.

3:35 16.6 1.30

7. Extra Hygiene 65° - Normally or heavily soiled crockery, with

additional antibacterial wash. Can be used to perform maintenance

of the dishwasher. 2:00 12.0 1.50

8. Prewash - Use to refresh crockery planned to be washed later. No

detergent to be used with this program. - 0:12 4.7 0.01

Self-Clean

65°

- Program to be used to perform maintenance of the

dishwasher, to be carried out only when the dishwasher is EMPTY using

specic detergents designed for dishwasher maintenance. - 0:50 10.0 0.80

1 2 3 4 5 6 7 8 9 10 11

PROBLEMS POSSIBLE CAUSES SOLUTIONS

The dishwasher does

not ll the water.

Display shows: H,

6 and On/O LED is

blinking rapidly

No water in the water supply or the tap is closed.

Make sure there is water in the water supply or the tap running.

The inlet hose is bent. Make sure the inlet hose is not bent (see INSTALLATION) reprogram the dishwa-

sher and reboot.

The sieve in the water inlet hose is clogged;

it is necessary to clean it

After having carried out the verication and cleaning, turn o and turn on the

dishwasher and restart a new program.

Dishwasher nishes the

cycle prematurely. Display

shows: and On/O 15

LED is blinking rapidly

Drain hose positioned too low or siphoning

into home sewage system.

Check if end of drain hose is placed at correct height (see INSTALLATION).Check

for siphoning into home sewage system, install air admittance valve if necessary.

Air in water supply. Check water supply for leaks or other issues letting air inside.

In case your dishwasher doesn’t work properly, check if the problem can be solved by going through the following list. For other errors or issues

please contact authorized After-sales Service which contact details can be found in the warranty booklet. Spare parts will be available for a period

of either up to 7 or up to 10 years, according to the specic Regulation requirements.

TROUBLESHOOTING

Policies, standard documentation, ordering of spare parts and additional product information can be found by:

• Using QR code on your product.

• Visiting our website docs.whirlpool.eu and parts-selfservice.whirlpool.com

• Alternatively, contact our After-sales Service (See phone number in the warranty booklet). When contacting our After-

sales Service, please state the codes provided on your product‘s identication plate.

The model information can be retrieved using the QR-Code reported in the energy label. The label also includes the model

identier that can be used to consult the portal of the registry at https://eprel.ec.europa.eu.

IEC 436

Please scan the on your product in order to have more detailed information. QR code

DELAY -The start of the program may be delayed for a period of time

between and hours.1 12

The DELAY function cannot be set once a wash cycle has been started.

TABLET (Tab) If you use powder or liquid detergent, this option -

should be o.

OPTIONS AND FUNCTIONS

OPTIONS can be selected directly by pressing the corresponding button (see CONTROL PANEL). If an option is not compatible with the selected

program (see PROGRAMS TABLE), the corresponding LED ashes rapidly 3 times and beeps will sound. The option will not be enabled.

HALF LOAD - If there are not many dishes to be washed, a half loading

may be used in order to save water, electricity and detergent.

Remember to halve the amount of detergent.

Please scan the on your product in order to have more detailed information. QR code

ECO program data is measured under laboratory conditions according to European Standard EN 60436:2020. Note for Test Laboratories: For information on

comparative EN testing conditions, please send an email to the following address: dw_test_support@whirlpool.com

Pre-treatment of the dishes is not needed before any of the programs.

*) Not all options can be used simultaneously.

**) Values given for programs other than the program Eco are indicative only. The actual time may vary depending on many factors such as temperature and

pressure of the incoming water, room temperature, amount of detergent, quantity and type of load, load balancing, additional selected options and sensor cali-

bration. The sensor calibration can increase program duration up to 20 min.

CUTLERY BASKET

The basket is equipped with top

grilles for improved cutlery

arrangement.

The cutlery basket should be positioned only

at the front of the lower rack.

Knives and other utensils with sharp edges must be

placed in the cutlery basket with the points facing

downwards or they must be positioned horizontally in

the tip-up compartments on the upper rack.

LOADING THE RACKS CAPACITY: 14 standard place-settings

More information in the Daily Reference Guide on website.

CLEANING AND MAINTENANCE

CLEANING THE FILTER ASSEMBLY CLEANING THE SPRAY ARMS

In case you nd foreign objects (such as broken glass, porcelain, bones, fruit seeds

etc.) please remove them carefully.

NEVER REMOVE the wash-cycle pump protection (black detail) (Fig 4).

To remove the upper spray arm,

turn the plastic locking ring in a

clockwise direction.

The lower spray arm may

be removed by pulling it

upwards.

UPPER RACK

(loading example for

the upper rack)

Load delicate and light dishes:

glasses, cups, saucers, low

salad bowls.

LOWER RACK

(loading example for the lower rack)

For pots, lids, plates, salad bowls, cutlery

etc.. Large plates and lids should ideally

be placed at the sides to avoid interferen-

ces with the spray arm.

FOLDABLE

FLAPS WITH

ADJUSTABLE

POSITION

400011660357

01/2023 ks - Xerox Fabriano

Specyfikacje produktu

Marka:	Ignis
Kategoria:	zmywarka
Model:	G2I HD526 A
Typ kontroli:	Przyciski
Wbudowany wyświetlacz:	Tak
Długość przewodu:	1.3 m
Położenie urządzenia:	W pełni wbudowany
Częstotliwość wejściowa AC:	50 Hz
Napięcie wejściowe AC:	220 - 240 V
Wysokość produktu:	820 mm
Szerokość produktu:	598 mm
Głębokość produktu:	555 mm
Waga produktu:	35500 g
Rozmiar produktu:	Pełny rozmiar (60 cm)
Kolor drzwiczek:	Nie dotyczy
Kolor panelu sterowania:	Biały
Długość węża dopływowego:	1.55 m
Długość węża odpływowego:	1.5 m
Regulowana wysokość górnego koszyka:	Tak
Programy mycia:	Eco 50°C, Hygiene, Intensive 65°C, Mixed, Night, Pre-wash, Quick
Liczba miejsc:	14 komplet.
Ilość programów piorących:	9
Poziom hałasu:	46 dB
Opóźniony start czasomierza:	Tak
Opóźniony start:	12 h
Czas cyklu:	215 min
Temperatura (maks):	60 °C
Klasa emisji hałasu:	C
Prąd:	10 A
Obciążenie:	1900 W
Pobór wody na cykl:	9.5 l
Klasa wydajności energetycznej:	E
Skala efektywności energetycznej:	Od A do G
Zużycie energii na 100 cykli:	95 kWh
Regulowane nóżki:	Tak
Wskaźnik konieczności płukania:	Tak
Wskaźnik soli:	Tak
Waga wraz z opakowaniem:	37500 g
Samoczyszczący:	Tak
Typ wtyczki zasilającej:	Typu F
Programy automatyczne:	Nie
Czas cyklu (program szybki):	28 min
Panel drzwi w komplecie:	Nie
Wskaźnik efektywności energetycznej (UE 2017/1369):	55.9
