PROMIX20 1 VELLEMAN
PROMIX20 – 2-CHANNEL MIXING PANEL
1. Introduction & Features
To all residents of the European Union
Important environmental information about this product
This symbol on the device or the package indicates that disposal of the device after its lifecycle could harm the environment.
Do not dispose of the unit (or batteries) as unsorted municipal waste; it should be taken to a specialised company for recycling.
This device should be returned to your distributor or to a local recycling service.
Respect the local environmental rules.
If in doubt, contact your local waste disposal authorities.
Thank you for buying the PROMIX20! Please read the manual thoroughly before bringing this device into service. Make
sure that the device was not damaged in transit. If the device is damaged, do not install it and contact your dealer.
2. Safety Instructions
Be very careful during the installation: touching live wires can cause life-threatening electroshocks.
Keep this device away from rain and moisture.
Unplug the mains lead before opening the housing.
• Damage caused by disregard of certain guidelines in this manual is not covered by the warranty and the dealer
will not accept responsibility for any ensuing defects or problems.
• Do not switch the device on immediately after it has been exposed to changes in temperature. Protect the device
against damage by leaving it switched off until it has reached room temperature.
• Make sure that the available voltage does not exceed the voltage stated in the specifications of this manual.
• Do not crimp the power cord and protect it against damage. Have an authorised dealer replace it if necessary.
• Disconnect the device from the mains to clean it or when it is not in use. Handle the power cord by the plug only.
• Note that damage caused by user modifications to the device is not covered by the warranty.
• Keep the device away from children and unauthorised users.
3. General Guidelines
• This device is designed for professional use on stage, in discos, theatres, etc. The should only be PROMIX20
used indoors. Always set all faders and volume controls to 0 before switching on the device.
• Do not shake the device. Avoid brute force when installing or operating the device.
• Select a location where the device is protected against extreme heat, dust and moisture.
• Familiarise yourself with the functions of the device before actually using it. Do not allow operation by unqualified
people. Any damage that may occur will most probably be due to unprofessional use of the device.
• Use the original packaging if the device is to be transported.
• All modifications of the device are forbidden for safety reasons. Do not remove the serial number sticker.
• Only use the device for its intended purpose. All other uses may lead to short circuits, burns, electroshocks,
crash, etc. Using the device in an unauthorised way will void the warranty.
PROMIX20 2 VELLEMAN
4. Device Layout
a. Top Panel
1. Master output level control
2. Microphone volume control
3. PH1/LN1 - LN2 selector
4. Channel 1 fader
5. Master level stereo VU LED meter
6. CUE (1 channel, cf. #9) or PAN (live output) selector for
headphones
7. Headphones volume control
8. PH3/LN3 - LN4 selector
9. Channel 1 / 2 cue selector
10. Channel 2 fader
11. 6.35mm microphone input on the front panel
12. Channel 1 / 2 crossfader
13. 6.35mm headphones output on the front panel
b. Rear Panel
14. Power Switch
15. Fuse holder for fuse F 0.5A / 250V (5 x 20mm)
16. PHONO3/LINE3 selector
17. PHONO1/LINE1 selector
18. Power cord
19. REC stereo RCA output
20. MAIN stereo RCA output
21. LINE4 stereo RCA input
22. PHONO3/LINE3 stereo RCA input
23. LINE2 stereo RCA input
24. PHONO1/LINE1 stereo RCA input
5. Connections
• Make sure the power switch (#14) is set to “OFF” before making any connections.
• Use only high quality audio cables to minimize sound quality losses.
• Connect your amplifier to the MAIN output (#20) and any recording device to the REC output (#19)
• Connect your microphone to the MIC input (#11) and your headphones to the PHONES output (#13).
• Connect your record players to the PHONO inputs (#22 & 24) and set the selectors (#16 or 17) to PH.
• Connect any line signals to the LINE (LN) inputs (#21 & 23 are line inputs only ; for inputs #22 & 24 you need to
set the switches 16 and 17 to the LN side).
6. Cleaning and Maintenance
1. All screws should be tightened and free of corrosion.
2. The housing, visible parts and the installation location should not be deformed, modified or tampered with.
3. The electric power supply cables must not show any damage. Have a qualified technician maintain the device.
4. Disconnect the device from the mains prior to maintenance activities.
5. Wipe the device regularly with a moist, lint-free cloth. Do not use alcohol or solvents.
6. There are no user-serviceable parts.
7. Contact your dealer for spare parts if necessary.
PROMIX20 3 VELLEMAN
7. Technical Specifications
Power supply max. 230VAC/50Hz
Microphone input 1.5mV / 2k / balanced Ω
Phono inputs 3mV / 47k Ω
Line inputs 150mV / 27 Ω
Master output 0dB / 1V / 600 Ω
Record output 0dB / 1V / 600 Ω
Frequency response 20Hz~20kHz +/-2dB
Distortion 0.02%
S/N ratio >80dB
Headphones impedance 160 Ω
Dimensions 240 x 166 x 112mm
Total Weight 2.2kg
Fuse F 0.5A, 250VAC (5 x 20mm) (order code ) FF0.5N
The information in this manual is subject to change without prior notice.
PROMIX20 – 2-KANAALS MENGPANEEL
1. Inleiding en kenmerken
Aan alle ingezetenen van de Europese Unie
Belangrijke milieu-informatie betreffende dit product
Dit symbool op het toestel of de verpakking geeft aan dat, als het na zijn levenscyclus wordt weggeworpen, dit toestel schade kan
toebrengen aan het milieu.
Gooi dit toestel (en eventuele batterijen) niet bij het gewone huishoudelijke afval; het moet bij een gespecialiseerd bedrijf
terechtkomen voor recyclage.
U moet dit toestel naar uw verdeler of naar een lokaal recyclagepunt brengen.
Respecteer de plaatselijke milieuwetgeving.
Heeft u vragen, contacteer dan de plaatselijke autoriteiten inzake verwijdering.
Dank u voor uw aankoop! Lees deze handleiding grondig voor u het toestel in gebruik neemt. Ga na of het toestel
niet werd beschadigd tijdens het transport. Zo ja, stel dan de installatie van het toestel uit en raadpleeg uw dealer.
2. Veiligheidsinstructies
Wees voorzichtig bij de installatie: raak geen kabels aan die onder stroom staan om
dodelijke elektroshocks te vermijden.
Bescherm dit toestel tegen regen en vochtigheid.
Verzeker u ervan dat het toestel niet aangesloten is op een stroombron alvorens het te openen.
• De garantie geldt niet voor schade door het negeren van bepaalde richtlijnen in deze handleiding en uw dealer zal
de verantwoordelijkheid afwijzen voor defecten of problemen die hier rechtstreeks verband mee houden.
• Om beschadiging te vermijden, zet u het toestel best niet aan onmiddellijk nadat het werd blootgesteld aan
temperatuurschommelingen. Wacht tot het toestel op kamertemperatuur gekomen is.
• De beschikbare netspanning mag niet hoger zijn dan de spanning in de specificaties achteraan de handleiding.
• De voedingskabel mag niet omgeplooid of beschadigd zijn. Laat uw dealer zo nodig een nieuwe kabel plaatsen.
• Trek de stekker uit het stopcontact (trek nooit aan de kabel!) voordat u het toestel reinigt en als u het niet
gebruikt.
• Schade door wijzigingen die de gebruiker heeft aangebracht aan het toestel vallen niet onder de garantie.
• Hou dit toestel uit de buurt van kinderen en onbevoegden.
