Thank you for purchasing a GE cooking product! The broiler pan
referred to in the enclosed literature is not included and is
available as an optional accessory. You can order your broiler pan
(a $25 value) at a discount using the redemption coupon below or
by calling 1-800-626-2002 toll free.
Limited Time Offer!
Free Shipping
When you order your broiler pan within 30 da
of purchasing your GE cooking product.
Get the Most out of your Broiler Pan
Use your pan and grid cover to:
Broil hamburgers, seafood, steaks, vegetables, bacon
chops, and so much more! The pan below catches th
excess fat and oils!
• Genuine GE Part
• Easy to Clean
• One Year Warranty
Small Large* XL**
Part # WB48X10055 WB48X10056 WB48X100
8-3/4” W 12-3/4” W 17” W
Dimensions 1-1/4” H 1-1/4” H 1-1/4” H
13-1/2” D 16-1/2” D 19-1/4”
Price $10.50 $14.50 $16.75
Broiler Pan Order Form
Customer Information
First
Name________________________
_
Last
Name________________________
_
Address
___________________________
City
_____________________________
_
State _______
Zip_______________
Phone __________________________
E-mail
_____________________________
I would like to order:
Quantity Part #
________
_____________
________
_____________
________
_____________
Product Information
Model#
____________________________
Serial#
____________________________
Brand
_____________________________
Date of Purchase
FREE SHIPPING!!
*The large (standard) broil pan does not fit in compact ranges.
**The XL pan does not fit in 24 inch wall ovens, 27 inch drop-ins, or compact ranges.
Call 1-800-626-2002 or
Use this mail-in form to place your order
Experience these other great products to keep your kitchen looking great!
PM10X311
$6.00
Ceramic Cooktop
Cleaning Kit:
Includes cleaner,
scraper and pad
Stainless Steel
Appliance Cleaner
Ceramic Cooktop
Cleaning Wipes
Stainless Steel
Appliance Polish Wipes
WX10X117GCS
$12.75
WX10X305
$4.25
WX10X10001
$5.25
Coil Top and
Radiant Top Models
Standard
Clean Models
JBS03
JBS07
JBS15
JBS27
RB525
RB526
RB536
RB540
Self-Clean
Models
JB600
JBP15
JBP21
JBP22
JBP60
RB740
RB757
RB787
RB790
RB800
183D6379P028 49-88022 08-05 JR
Safety Information . . . . . . . . . . 2–6
Operating Instructions
Adjust the Oven
Thermostat . . . . . . . . . . . . . . . . . . .21
Clock and Timer . . . . . . . . . . .15, 16
Oven . . . . . . . . . . . . . . . . . . . . .12–14
Oven Controls . . . . . . . . . . . . .10, 11
Sabbath Feature . . . . . . . . . . . .19, 20
Selecting Types of Cookware . . . . .9
Self-Cleaning . . . . . . . . . . . . . .24, 25
Special Features . . . . . . . . . . . . . . .18
Surface Units . . . . . . . . . . . . . . . . 7, 8
Timed Baking and Roasting . . . . .17
Warming Drawer . . . . . . . . . . . 22, 23
Care and Cleaning . . . . . . . . 24–33
Glass Cooktop . . . . . . . . . . . . .32, 33
Self-Cleaning Oven . . . . . . . . .24, 25
Installation Instructions
Anti-Tip Device . . . . . . . . . . . .34, 40
Before You Begin . . . . . . . . . . . . . 34
Electrical Connections . . . . . . .36–39
Leveling . . . . . . . . . . . . . . . . . .40, 41
Troubleshooting Tips . . . . . . 42–46
Accessories . . . . . . . . . . . . . . . . . . 47
Consumer Support
Consumer Support . . . . .Back Cover
Product Registration . . . . . . . . 49, 50
Warranty . . . . . . . . . . . . . . . . . . . . 51
ge.com
Write the model and serial
numbers here:
Model # __________________
Serial #____________________
You can find them on a label,
behind the storage drawer or
warming drawer on the oven
frame.
Owner’s Manual and
Installation Instructions
Ranges
Electric Coil & Radiant
IMPORTANT SAFETY INFORMATION.
READ ALL INSTRUCTIONS BEFORE USING.
WARNING!
For your safety, the information in this manual must be followed to minimize the risk of fire or explosion,
electric shock, or to prevent property damage, personal injury, or loss of life.
All ranges can tip and injury could result.
To prevent accidental tipping of the range, attach
it to the wall by installing the Anti-Tip device
supplied.
If the Anti-Tip device supplied with the range does
not fit this application, use the universal Anti-Tip
device WB2X7909.
To check if the device is installed and engaged
properly, carefully tip the range forward. The
Anti-Tip device should engage and prevent
the range from tipping over.
If you pull the range out from the wall for
any reason, make sure the device is properly
engaged when you push the range back against
the wall. If it is not, there is a possible risk of the
range tipping over and causing injury if you or
a child stand, sit or lean on an open door.
Please refer to the Anti-Tip device information
in this manual. Failure to take this precaution
could result in tipping of the range and injury.
WARNING ANTI-TIP DEVICE
IMPORTANT SAFETY NOTICE
The California Safe Drinking Water and Toxic
Enforcement Act requires the Governor of
California to publish a list of substances known
to the state to cause cancer, birth defects or other
reproductive harm, and requires businesses to
warn customers of potential exposure to such
substances.
The fiberglass insulation in self-clean ovens gives
off a very small amount of carbon monoxide during
the cleaning cycle. Exposure can be minimized by
venting with an open window or using a ventilation
fan or hood.
When using electrical appliances, basic safety precautions should be followed, including the following:
■Use this appliance only for its intended
purpose as described in this Owner’s Manual.
■Be sure your appliance is properly installed
and grounded by a qualified technician in
accordance with the provided installation
instructions.
■ Do not attempt to repair or replace any
part of your range unless it is specifically
recommended in this manual. All other
servicing should be referred to a qualified
technician.
■ Before performing any service, disconnect
the range power supply at the household
distribution panel by removing the fuse or
switching off the circuit breaker.
■ Do not leave children alone—children
should not be left alone or unattended in
an area where an appliance is in use. They
should never be allowed to sit or stand on
any part of the appliance.
■ Do not allow anyone to climb, stand or
hang on the door, storage drawer, warming
drawer, or cooktop. They could damage the
range and even tip it over, causing severe
personal injury.
■ Do not store flammable materials in an oven
or near the cooktop.
■ CAUTION: Items of interest to
children should not be stored in cabinets
above a range or on the backsplash of a
range—children climbing on the range to
reach items could be seriously injured.
SAFETY PRECAUTIONS
2
Operating
Instructions Safety InstructionsCare and Cleaning
Installation
Instructions
Troubleshooting TipsConsumer Support
3
Operating
Instructions Care and Cleaning Installation
Instructions Troubleshooting Tips
Safety Instructions
Consumer Support
ge.com
COOK MEAT AND POULTRY THOROUGHLY…
Cook meat and poultry thoroughly—meat to at least an INTERNAL temperature of 160°F and poultry to at least an
INTERNAL temperature of 180°F. Cooking to these temperatures usually protects against foodborne illness.
■ Never wear loose-fitting or hanging garments
while using the appliance. Be careful when
reaching for items stored over the range.
Flammable material could be ignited if
brought in contact with hot surface units
or heating elements and may cause severe
burns.
■ Use only dry pot holders—moist or damp
pot holders on hot surfaces may result in
burns from steam. Do not let pot holders
touch hot surface units or heating elements.
Do not use a towel or other bulky cloth.
■ For your safety, never use your appliance
for warming or heating the room.
■ Do not let cooking grease or other flammable
materials accumulate in or near the range.
■ Do not use water on grease fires. Never pick
up a flaming pan. Turn the controls off.
Smother a flaming pan on a surface unit by
covering the pan completely with a well-
fitting lid, cookie sheet or flat tray. Use a
multi-purpose dry chemical or foam-type
fire extinguisher.
■Flaming grease outside a pan can be put
out by covering it with baking soda or,
if available, by using a multi-purpose dry
chemical or foam-type fire extinguisher.
■Flame in the oven or warming drawer
can be smothered completely by closing the
door and turning the oven off or by using a
multi-purpose dry chemical or foam-type fire
extinguisher.
■ Do not touch the surface units, the heating
elements or the interior surface of the oven.
These surfaces may be hot enough to burn
even though they are dark in color. During
and after use, do not touch, or let clothing
or other flammable materials contact, the
surface units, areas nearby the surface units
or any interior area of the oven; allow
sufficient time for cooling first.
■Potentially hot surfaces include the cooktop,
areas facing the cooktop, oven vent opening,
surfaces near the opening, crevices around
the oven door and metal trim parts above
the door.
■REMEMBER: The inside surface of the oven
may be hot when the door is opened.
■ Do not store or use combustible materials,
gasoline or other flammable vapors and
liquids in the vicinity of this or any other
appliance.
■ Keep the hood and grease filters clean
to maintain good venting and to avoid
grease fires.
■ Never block the vents (air openings) of the
range. They provide the air inlet and outlet
that are necessary for the range to operate
properly with correct combustion. Air
openings are located at the rear of the
cooktop, at the top and bottom of the oven
door, and at the bottom of the range under
the warming drawer or storage drawer.
WARNING!
SAFETY PRECAUTIONS
■Do not clean the door gasket. The door
gasket is essential for a good seal. Care
should be taken not to rub, damage or
move the gasket.
■Clean only parts listed in this Owner’s
Manual.
■Do not use oven cleaners on self-clean
models. No commercial oven cleaner or
oven liner protective coating of any kind
should be used in or around any part of
the oven. Residue from oven cleaners will
damage the inside of the oven when the
self-clean cycle is used.
■Before self-cleaning the oven, remove the
broiler pan, grid and other cookware.
■Be sure to wipe up excess spillage before
starting the self-cleaning operation.
■If the self-cleaning mode malfunctions,
turn the oven off and disconnect the power
supply. Have it serviced by a qualified
technician.
■Take the shelves out of the oven before
you begin the self-clean cycle or they
may discolor.
SELF-CLEANING OVEN (on some models)
IMPORTANT SAFETY INFORMATION.
READ ALL INSTRUCTIONS BEFORE USING.
4
■ Stand away from the range when opening
the oven door. Hot air or steam which
escapes can cause burns to hands, face
and/or eyes.
■ Do not heat unopened food containers.
Pressure could build up and the container
could burst, causing an injury.
■ Keep the oven vent unobstructed.
■ Keep the oven free from grease buildup.
■ Place the oven shelf in the desired position
while the oven is cool. If shelves must be
handled when hot, do not let pot holder
contact the heating elements.
■ Pulling out the shelf to the stop-lock is a
convenience in lifting heavy foods. It is also
a precaution against burns from touching
hot surfaces of the door or oven walls.
■ When using cooking or roasting bags in the
oven, follow the manufacturer’s directions.
■ Do not use the oven to dry newspapers.
If overheated, they can catch on fire.
■ Do not use the oven for a storage area.
Items stored in an oven can ignite.
■ Do not leave paper products, cooking
utensils or food in the oven when not in use.
OVEN
Operating
Instructions Safety InstructionsCare and Cleaning
Installation
Instructions
Troubleshooting TipsConsumer Support
5
Use proper pan size–select cookware having flat bottoms large enough to cover the surface unit
heating element. The use of undersized cookware will expose a portion of the surface unit to direct
contact and may result in ignition of clothing. Proper relationship of cookware to surface unit will also
improve efficiency.
■Never leave the surface units unattended at
high heat settings. Boilovers cause smoking
and greasy spillovers that may catch on fire.
■Only certain types of glass, glass ⁄ceramic,
earthenware or other glazed containers are
suitable for cooktop service; others may
break because of the sudden change in
temperature.
■To minimize the possibility of burns,
ignition of flammable materials and spillage,
the handle of a container should be turned
toward the center of the range without
extending over nearby surface units.
■Always turn the surface units off before
removing cookware.
■Do not flame foods on the cooktop. If you
do flame foods under the hood, turn the
fan on.
■Keep an eye on foods being fried at high or
medium high heat settings.
■Foods for frying should be as dry as possible.
Frost on frozen foods or moisture on fresh
foods can cause hot fat to bubble up and
over the sides of the pan.
■Use little fat for effective shallow or deep fat
frying. Filling the pan too full of fat can
cause spillovers when food is added.
■If a combination of oils or fats will be used in
frying, stir together before heating, or as fats
melt slowly.
■Always heat fat slowly, and watch as it heats.
■Use a deep fat thermometer whenever
possible to prevent overheating fat beyond
the smoking point.
SURFACE UNITS—ALL MODELS
Operating
Instructions Care and Cleaning Installation
Instructions Troubleshooting Tips
Safety Instructions
Consumer Support
ge.com
■The purpose of the warming drawer is
to hold hot cooked foods at serving
temperature. Always start with hot food;
cold food cannot be heated or cooked
in the warming drawer.
■Do not use the warming drawer to dry
newspapers. If overheated, they can catch
on fire.
■Do not leave paper products, cooking
utensils or food in the warming drawer
when not in use.
■Never leave jars or cans of fat drippings in
or near your warming drawer.
■Always keep wooden and plastic utensils
and canned food a safe distance away from
your warming drawer.
■Do not warm food in the warming drawer
for more than two hours.
■Do not touch the heating element or the interior
surface of the warming drawer. These surfaces
may be hot enough to burn.
REMEMBER: The inside surface of the
warming drawer may be hot when the
drawer is opened.
■Use care when opening the drawer. Open
the drawer a crack and let hot air or steam
escape before removing or replacing food.
Hot air or steam which escapes can cause
burns to hands, face and/or eyes.
■Do not use aluminum foil to line the drawer.
Foil is an excellent heat insulator and will
trap heat beneath it. This will upset the
performance of the drawer and it could
damage the interior finish.
WARMING DRAWER (on some models)
IMPORTANT SAFETY INFORMATION.
READ ALL INSTRUCTIONS BEFORE USING.
6
■Avoid scratching the glass cooktop. The
cooktop can be scratched with items such as
sharp instruments, rings or other jewelry and
rivets on clothing.
■Large scratches or impacts to glass doors
or cooktops can lead to broken or shattered
glass.
■Do not operate the radiant surface units if
the glass is broken. Spillovers or cleaning
solution may penetrate a broken cooktop
and create a risk of electrical shock. Contact
a qualified technician immediately should
your glass cooktop become broken.
■Never use the glass cooktop surface as a
cutting board.
■Do not place or store items that can melt or
catch fire on the glass cooktop, even when it
is not being used.
■Be careful when placing spoons or other
stirring utensils on the glass cooktop surface
when it is in use. They may become hot and
could cause burns.
■Clean the cooktop with caution. If a wet
sponge or cloth is used to wipe spills on a
hot surface unit, be careful to avoid steam
burns. Some cleaners can produce noxious
fumes if applied to a hot surface.
NOTE: We recommend that you avoid wiping
any surface unit areas until they have cooled
and the indicator light has gone off. Sugar
spills are the exception to this. Please see
Cleaning the glass cooktop section.
■When the cooktop is cool, use only the
recommended cleaning cream to clean
the cooktop.
■To avoid possible damage to the cooking
surface, do not apply cleaning cream to the
glass surface when it is hot.
■After cleaning, use a dry cloth or paper towel
to remove all cleaning cream residue.
■Read and follow all instructions and
warnings on the cleaning cream labels.
■Do not lift the cooktop. Lifting the cooktop
can lead to damage and improper operation
of the range.
Use care when touching the cooktop. The glass surface of the cooktop will retain heat after the controls
have been turned off.
WARNING!
RADIANT SURFACE UNITS (on some models)
READ AND FOLLOW THIS SAFETY INFORMATION CAREFULLY.
SAVE THESE INSTRUCTIONS
Operating
Instructions Safety InstructionsCare and Cleaning
Installation
Instructions
Troubleshooting TipsConsumer Support
■ Clean the cooktop with caution. If a
wet sponge is used to wipe spills on a hot
cooktop, be careful to avoid steam burns.
■ To avoid the possibility of a burn or electric
shock, always be certain that the controls for
all surface units are at the OFF position and
all coils are cool before attempting to lift or
remove a unit.
■ Do not immerse or soak the removable
surface units. Do not put them in a
dishwasher.
■ Be sure the drip pans and the vent duct are
not covered and are in place. Their absence
during cooking could damage range parts
and wiring.
■ Do not use aluminum foil to line the drip
pans or anywhere in the oven except as
described in this manual. Misuse could
result in a shock, fire hazard or damage
to the range.
WARNING!
COIL SURFACE UNITS (on some models)
7
Using the surface units. ge.com
Throughout this manual, features and appearance may vary from your model.
Push the knob in and turn in either
direction to the setting you want.
At both OFF and HI the control clicks
into position. You may hear slight clicking
sounds during cooking, indicating the
control is keeping the power level you set.
A HOT SURFACE or HOT COOKTOP
(depending on model) indicator light will
glow when any radiant element is turned
on and will remain on until the surface is
cool enough to touch.
A SURFACE UNIT on or BURNER ON
(depending on model) indicator light will
glow when any surface unit is on.
NOTE: The SURFACE UNIT on indicator light may
glow between the surface control settings of LO
and OFF, but there is no power to the surface units.
Operating
Instructions Care and Cleaning Installation
Instructions Troubleshooting Tips
Safety Instructions
Consumer Support
Be sure you turn the control knob
to OFF when you finish cooking.
How to Set Indicator Lights (on radiant glass models only)
About the radiant surface units…
The radiant cooktop features heating units
beneath a smooth glass surface.
NOTE: A slight odor is normal when a new cooktop
is used for the first time. It is caused by the heating
of new parts and insulating materials and will
disappear in a short time.
The surface unit will cycle on and off to
maintain your selected control setting.
It is safe to place hot cookware from the
oven or surface on the glass surface when
the surface is cool.
Even after the surface units are turned off,
the glass cooktop retains enough heat to
continue cooking. To avoid over-cooking,
remove pans from the surface units when
the food is cooked. Avoid placing anything
on the surface unit until it has cooled
completely.
Do not slide cookware across the cooktop
because it can scratch the glass—the glass
is scratch resistant, not scratch proof.
■Water stains (mineral deposits) are removable
using the cleaning cream or full-strength white
vinegar.
■Use of window cleaner may leave an iridescent
film on the cooktop. The cleaning cream will
remove this discoloration.
■Don’t store heavy items above the cooktop. If they
drop onto the cooktop, they can cause damage.
■Do not use the surface as a cutting board.
Using the radiant surface units. (on some models)
8
SURFACE
COOKING
Never cook directly on the glass.
Always use cookware.
OFF CENTER
Always place the pan in the center of
the surface unit you are cooking on.
Every radiant surface unit has a
temperature limiter.
The temperature limiter protects the glass
cooktop from getting too hot.
The temperature limiter may cycle the
units off for a time if:
■The pan boils dry.
■The pan bottom is not flat.
■The pan is off center.
■There is no pan on the unit.
Temperature Limiter
Operating
Instructions Safety InstructionsCare and Cleaning
Installation
Instructions
Troubleshooting TipsConsumer Support
DRAGGING
9
Selecting types of cookware. ge.com
The following information will help you choose cookware which will give good performance on glass cooktops.
Stainless Steel:
recommended
Aluminum:
heavy weight recommended
Good conductivity. Aluminum residues
sometimes appear as scratches on the
cooktop, but can be removed if cleaned
immediately. Because of its low melting
point, thin-weight aluminum should not
be used.
Copper Bottom:
recommended
Copper may leave residues which can
appear as scratches. The residues can be
removed, as long as the cooktop is cleaned
immediately. However, do not let these pots
boil dry. Overheated metal can bond to
glass cooktops. An overheated copper
bottom pot will leave a residue that will
permanently stain the cooktop if not
removed immediately.
Porcelain Enamel Covered Cast Iron:
recommended
As long as the cookware is covered
completely with porcelain enamel, this
cookware is recommended. Caution is
recommended for cast-iron cookware
that is not completely covered with smooth
porcelain enamel, as it may scratch the
glass-ceramic cooktop.
Glass-ceramic:
usable, but not recommended
Poor performance. May scratch the surface.
Stoneware:
usable, but not recommended
Poor performance. May scratch the surface.
Home Canning Tips:
Be sure the canner is centered over the
surface unit.
Make sure the canner is flat on the bottom.
Use recipes and procedures from
reputable sources. These are available
from manufacturers such as Ball®and
Kerr®and the Department of Agriculture
Extension Service.
To prevent burns from steam or heat, use
caution when canning.
Check pans for flat bottoms by using
a straight edge.
Pans with rounded, curved,
ridged or warped bottoms are
not recommended.
Wok Cooking
We recommend that you use only a flat-bottomed
wok. They are available at your local retail store.
Do not use woks that have support rings.
Use of these types of woks, with or without
the ring in place, can be dangerous.
Placing the ring over the surface unit will
cause a buildup of heat that will damage
the porcelain cooktop. Do not try to use
such woks without the ring. You could be
seriously burned if the wok tips over.
Use only flat-bottomed woks.
Operating
Instructions Care and Cleaning Installation
Instructions Troubleshooting Tips
Safety Instructions
Consumer Support
Use medium- or heavy-weight cookware.
Aluminum cookware conducts heat faster
than other metals. Cast-iron and coated
cast-iron cookware are slow to absorb heat,
but generally cook evenly at low to medium
heat settings. Steel pans may cook unevenly
if not combined with other metals.
For best cooking results, pans should be
flat on the bottom. Match the size of the
saucepan to the size of the surface unit.
The pan should not extend over the edge
of the surface unit more than 1 inch.
Not over 1 inch
1″
The following information will help you choose cookware which will give good performance on coil cooktops.
Surface Cookware Tips
Operating
Instructions Safety InstructionsCare and Cleaning
Installation
Instructions
Troubleshooting TipsConsumer Support
or
or
Oven Control, Clock and Timer Features and Settings
BAKE/TEMP RECALL Pad
Touch this pad to select the bake function.
BAKE Light
Flashes while in edit mode—you can change
the oven temperature at this point. Glows when
the oven is in bake mode.
START/ON Pad
Must be touched to start any cooking or
cleaning function.
Display
Shows the time of day, oven temperature,
whether the oven is in the bake, broil or
self-cleaning mode and the times set for
the timer or automatic oven operations.
The display will show PRE while preheating.
When the oven reaches the selected
temperature, the oven control will beep and
the display will show the oven temperature.
If “F– and a number or letter” flash in the display and the
oven control signals, this indicates a function error code.
If your oven was set for a timed oven operation and
a power outage occurred, the clock and all programmed
functions must be reset.
The time of day will flash in the display when there has been
a power outage. Reset the clock.
If the function error code appears during the self-cleaning
cycle, check the oven door latch. The latch handle may have
been moved, even if only slightly, from the latched position.
Make sure the latch is moved to the right as far as it will go.
Touch the CLEAR/OFF pad. Allow the oven to cool for
one hour. Put the oven back into operation. If the function
error code repeats, disconnect the power to the range and
call for service.
KITCHEN TIMER ON/OFF
or TIMER ON/OFF Pad
Touch this pad to select the timer feature.
Then touch the pads to adjust the+ –and
timer.
TIMER Light
Flashes while in edit mode—you can change
the set time at this point. Glows when the timer
has been activated. Flashes again when the time
has run out until the control is reset.
CLOCK Pad
To set the clock, press this pad twice and then
press the pads. The time of day will+ –and
flash in the display when the oven is first
turned on.
START TIME Pad (on some models)
Use along with the COOKING TIME or
SELF CLEAN pads to set the oven to start
and stop automatically at a time you set.
START TIME Light
Flashes while in edit mode—you can change
the start time at this point. Glows when the
function has been activated.
COOKING TIME Pad (on some models)
Touch this pad and then touch the + –or
pads to set the amount of time you want your
food to cook. The oven will shut off when the
cooking time has run out.
COOKING TIME Light
Flashes while in edit mode—you can change
the set time at this point. Glows when the
function has been activated. Flashes again when
the time has run out until the control is reset.
Throughout this manual, features and appearance may vary from your model.
Using the oven controls. (on some models)
10
11
Operating
Instructions Care and Cleaning Installation
Instructions Troubleshooting Tips
Safety Instructions
Consumer Support
ge.com
Oven Control, Clock and Timer Features and Settings
AUTOMATIC OVEN Light (on some models)
This lights anytime the oven has been
programmed using the COOKING TIME or
START TIME functions.
OVEN LIGHT or Pad
Touch this pad to turn the oven light on or off.
– Pad
Short taps to this pad will decrease the time
or temperature by small amounts. Touch
and hold the pad to decrease the time or
temperature by larger amounts.
+ Pad
Short taps to this pad will increase the time
or temperature by small amounts. Touch
and hold the pad to increase the time or
temperature by larger amounts.
SELF CLEAN Pad
Touch this pad to select the self-cleaning
function. See the Using the self-cleaning oven
section.
CLEAN Light
Flashes while in edit mode—you can change
the length of time for the self-clean cycle at this
point. Glows when the oven is in the self-clean
cycle. After the self-clean cycle, the light will
turn off. Unlatch the door.
CLEAR/OFF Pad
Touch this pad to cancel oven operationsALL
except the clock and timer.
BROIL HI/LO Pad
Touch this pad to select the broil function.
BROIL Light
Flashes while in edit mode—you can switch
from HI to LO BROIL at this point. Glows when
the oven is in broil mode.
Indicator Lights (on some pads)
EDIT mode lasts several seconds after the last
pad press. START TIME ON/OFF COOKINGand
TIME ON/OFF will be the only pads lit if either
of these options is selected. (Example: START
TIME BAKE START TIMEis selected with —the
pad will remain lit until the clock reaches the
programmed time, at which point it will turn
off and the BAKE/TEMP RECALL pad light will
light up).
12
Operating
Instructions Safety InstructionsCare and Cleaning
Installation
Instructions
Troubleshooting TipsConsumer Support
To avoid possible burns, place the shelves in the
desired position before you turn the oven on.
The shelves have stop-locks, so that when
placed correctly on the shelf supports (A
through E), they will stop before coming
completely out, and will not tilt.
When placing and removing cookware,
pull the shelf out to the bump on the
shelf support.
To remove a shelf, pull it toward you, tilt the
front end up and pull it out.
To replace, place the end of the shelf (stop-
locks) on the support, tilt up the front and
push the shelf in.
NOTE: The shelf is not designed to slide out
at the special low shelf (R) position.
Before you begin…
Using the oven.
KITCHEN TIMER ON/OFF Pad
Touch this pad to select the timer feature.
CLOCK Pad
Touch this pad before setting the clock.
Display
Shows the time of day and the time set for the timer, cook time or start time.
SET +/- Pads
These pads allow you to set the clock and timer.
Clock and Kitchen Timer (on some models)
Appearance may vary.
The oven has 5 shelf positions.
It also has a special low shelf
position (R) for extra large items,
such as a large turkey.
(On some models—
appearance will vary)
(On some models—
appearance will vary)
How to Set the Oven for Baking or Roasting (on models without an oven temperature knob)
Touch the BAKE pad.
Touch the pads until the +or –
desired temperature is displayed.
Touch the START/ON pad.
The oven will start automatically. The
display will show PRE while preheating.
When the oven reaches the selected
temperature, the oven control will beep and
the display will show the oven temperature.
To change the oven temperature during BAKE cycle,
touch the pad and then the pads to BAKE + –or
get the new temperature.
Check food for doneness at minimum
time on recipe. Cook longer if
necessary.
Touch the pad whenCLEAR/OFF
baking is finished and then remove
the food from the oven.
Type of Food Shelf Position
Frozen pies (on cookie sheet) C
Angel food cake, B
bundt or pound cakes
Biscuits, muffins, brownies, B or C
cookies, cupcakes,
layer cakes, pies
Casseroles B or C
Turkey R or A
Roasting R, A or B
The oven has a special low shelf (R)
position just above the oven bottom.
Use it when extra cooking space is
needed, for example, when cooking
a large turkey. The shelf is not
designed to slide out at this position.
OVEN TEMP
2
0
0
2
5
0
3
0
0
3
5
0
4
0
0
4
5
0
5
0
0
B
R
O
I
L
C
L
E
A
N
O
F
F
Oven Temperature Knob (on some models)
Turn this knob to the setting you want.
■The oven cycling light comes on during cooking.
Preheat the oven if the recipe calls for it.
To preheat, set the oven at the correct
temperature. Preheating is necessary for
good results when baking cakes, cookies,
pastry and breads.
For ovens without a preheat indicator light or tone,
preheat 10 minutes.
On some models, the display will show “PRE”
while preheating. When the oven reaches the
selected temperature, the oven control will beep
and the display will show the oven temperature.
Baking results will be better if baking pans
are centered in the oven as much as
possible. Pans should not touch each other
or the walls of the oven. If you need to use
two shelves, stagger the pans so one is not
directly above the other, and leave
approximately 11⁄2″from the front of the
pan to the front of the shelf.
Place the meat or fish on the broiler
grid in the broiler pan.
Follow suggested shelf positions in the
Broiling Guide.
If your range is connected to 208 volts, rare steaks
may be broiled by preheating the broiler and
positioning the oven shelf one position higher.
Use LO Broil to cook foods such as poultry
or thick cuts of meat thoroughly without
over-browning them.
Touch the BROIL HI/LO pad once for
HI Broil.
To change to LO Broil, touch the
BROIL HI/LO pad again.
Touch the START/ON pad.
When broiling is finished, touch the
CLEAR/OFF pad.
Operating
Instructions Care and Cleaning Installation
Instructions Troubleshooting Tips
Safety Instructions
Consumer Support
Never cover the oven bottom with
aluminum foil.
You can use aluminum foil to line the
broiler pan and broiler grid. However,
you must mold the foil tightly to the
grid and cut slits in it just like the grid.
Aluminum foil may also be used to catch
a spillover. To do so, place a small sheet of
foil on a lower shelf several inches below
the food.
Never entirely cover a shelf with aluminum
foil. This will disturb the heat circulation
and result in poor baking.
Leave the door open to the broil stop
position. The door stays open by itself,
yet the proper temperature is
maintained in the oven.
Preheating and Pan Placement
Type of Margarine Will Affect Baking Performance!
Aluminum Foil
How to Set the Oven for Broiling (on models without an oven temperature knob)
ge.com
Cut slits in the foil just like the grid.
Most recipes for baking have been
developed using high fat products such
as butter or margarine (80% fat). If you
decrease the fat, the recipe may not
give the same results as with a higher
fat product.
Recipe failure can result if cakes, pies, pastries,
cookies or candies are made with low fat spreads.
The lower the fat content of a spread product, the
more noticeable these differences become.
Federal standards require products labeled
“margarine” to contain at least 80% fat by
weight. Low-fat spreads, on the other hand,
contain less fat and more water. The high
moisture content of these spreads affects
the texture and flavor of baked goods. For
best results with your old favorite recipes,
use margarine, butter or stick spreads
containing at least 70% vegetable oil.
13
or
Not all features are on all models.
To Set the Timer
The timer does not control oven operations.
The maximum setting on the timer is 9 hours
and 59 minutes.
Touch the KITCHEN TIMER ON/OFF or
TIMER ON/OFF pad.
Touch the +or –pads until the
amount of time you want shows in
the display. The maximum time that
can be entered in minutes is 59.
Times more than 59 minutes should
be changed to hours and minutes.
If you make a mistake, touch the KITCHEN TIMER
ON/OFF TIMER ON/OFFor pad and begin again.
Touch the START/ON pad. The time
will start counting down, although
the display does not change until one
minute has passed.
When the timer reaches :00, the
control will beep 3 times followed by
one beep every 6 seconds until the
KITCHEN TIMER ON/OFF or TIMER
ON/OFF pad is touched.
The timer is a minute timer only.
The CLEAR/OFF pad does not affect
the timer.
Using the clock and timer. (on some models) ge.com
To Set the Clock
The clock must be set to the correct time
of day for the automatic oven timing
functions to work properly. The time of day
cannot be changed during a timed baking
or self-cleaning cycle.
Touch the pad twice.CLOCK
Touch the + –or pads.
If the +or –pads are not touched within
one minute after you touch the CLOCK pad,
the display reverts to the original setting.
If this happens, touch the CLOCK pad and
reenter the time of day.
Touch the START/ON pad until the
time of day shows in the display. This
enters the time and starts the clock.
To check the time of day when the display is
showing other information, simply touch the
CLOCK pad. The time of day shows until another
pad is touched.
Make sure the clock is set to the
correct time of day.
15
To Turn Off the Clock Display
If you have several clocks in your kitchen,
you may wish to turn off the time of day
clock display on your range.
Touch the pad once to turn CLOCK
off the time of day display. Although
you will not be able to see it, the clock
maintains the correct time of day.
Touch the pad again to recallCLOCK
the clock display.
Operating
Instructions Care and Cleaning Installation
Instructions Troubleshooting Tips
Safety Instructions
Consumer Support
Operating
Instructions Safety InstructionsCare and Cleaning
Installation
Instructions
Troubleshooting TipsConsumer Support
16
Not all features are on all models.
Using the clock and timer. (on some models)
To Reset the Timer
If the display is still showing the time
remaining, you may change it by touching
the KITCHEN TIMER ON/OFF or TIMER
ON/OFF pad, then touch the + –or pads
until the time you want appears in the
display.
If the remaining time is not in the display
(clock, delay start or cooking time are in
the display), recall the remaining time by
touching the KITCHEN TIMER ON/OFF or
TIMER ON/OFF pad and then touching the
+ –or pads to enter the new time you want.
To Cancel the Timer
Touch the KITCHEN TIMER ON/OFF
or TIMER ON/OFF pad twice.
End of Cycle Tones (on some models)
Clear the tones by pressing the pad of the
function you are using.
Power Outage
If a flashing time is in the display, you have
experienced a power failure. Reset the clock.
To reset the clock, touch the CLOCK pad
twice. Enter the correct time of day by
touching the pads. Touch the+ –or
START/ON pad.
or
or
Do not lock the oven door with the latch during timed cooking. The latch is used for self-cleaning only.
NOTE: Foods that spoil easily—such as milk, eggs, fish, stuffings, poultry and pork—should not be allowed to sit for
more than 1 hour before or after cooking. Room temperature promotes the growth of harmful bacteria. Be sure that
the oven light is off because heat from the bulb will speed harmful bacteria growth.
Using the timed baking and roasting features. (on some models) ge.com
How to Set an Immediate Start and Automatic Stop
The oven will turn on immediately and cook for a
selected length of time. At the end of the cooking
time, the oven will turn off automatically.
Touch the BAKE pad.
Touch the +or –pads to set the
oven temperature.
Touch the COOKING TIME pad.
NOTE: If your recipe requires preheating, you may
need to add additional time to the length of the
cooking time.
Touch the pads to set the + –or
baking time.
The cooking time that you entered will be
displayed. (If you select Cooking Time first
and then adjust the Bake Temperature, the
oven temperature will be displayed instead).
Touch the START/ON pad.
The display shows either the oven
temperature that you set or the cooking
time countdown. (The display starts with
PRE if showing the oven temperature.)
The oven will continue to cook for the
programmed amount of time, then turn
off automatically.
Touch the pad to clear CLEAR/OFF
the display if necessary.
Remove the food from the oven. Remember, even
though the oven shuts off automatically, foods
continue cooking after controls are off.
How to Set a Delayed Start and Automatic Stop
The oven will turn on at the time of day you set,
cook for a specific length of time and then turn off
automatically.
Make sure the clock shows the correct
time of day.
Touch the BAKE pad.
Touch the +or –pads to set the
oven temperature.
Touch the COOKING TIME pad.
Touch the +or –pads to set the
desired length of cooking time.
Touch the START TIME pad.
Touch the +or –pads to set the time
of day you want the oven to turn on
and start cooking.
Touch the START/ON pad.
NOTE: An attention tone will sound if you are using
timed baking and do not touch the START/ON pad.
NOTE: If you would like to check the times
you have set, touch the START TIME pad to
check the start time you have set or touch
the COOKING TIME pad to check the length
of cooking time you have set.
When the oven turns on at the time of day
you have set, the display will show PRE until
it reaches the selected temperature, then it
will display the oven temperature.
At the end of cooking time, the oven
will turn off and the end of cycle tone
will sound.
Touch the CLEAR/OFF pad to clear
the display if necessary.
Remove the food from the oven. Remember, even
though the oven shuts off automatically, foods
continue cooking after controls are off.
17
Operating
Instructions Care and Cleaning Installation
Instructions Troubleshooting Tips
Safety Instructions
Consumer Support
Operating
Instructions Safety InstructionsCare and Cleaning
Installation
Instructions
Troubleshooting TipsConsumer Support
18
Your new touch pad control has additional features that you may choose to use. The following are the features and
how you may activate them.
The special feature modes can only be activated while the display is showing the time of day. They remain in the
control’s memory until the steps are repeated.
When the display shows your choice, touch the START/ON pad. The special features will remain in memory after a
power failure.
NOTE: The Sabbath feature and the Thermostat Adjustment feature are also Special Features, but they are addressed
separately in the following sections.
Special features of your oven control.
12 Hour Shut-Off
With this feature, should you forget and leave the
oven on, the control will automatically turn off the
oven after 12 hours during baking functions or after
3 hours during a broil function.
If you wish to turn OFF this feature, follow
the steps below.
Touch the BAKE and BROIL HI/LO pads
at the same time for 3 seconds until
the display shows SF.
Touch the pad. The display willCLOCK
show ON (12 hour shut-off). Touch the
CLOCK pad repeatedly until the display
shows OFF (no shut-off).
Touch the START/ON pad to activate
the no shut-off and leave the control
set in this special features mode.
19
The Sabbath feature can be used for baking/roasting only. It cannot be used for broiling, self-cleaning or
Delay Start cooking.
NOTE: The oven light comes on automatically (on some models) when the door is opened and goes off when the
door is closed. The bulb may be removed. See the Oven Light Replacement section. On models with a light switch
on the control panel, the oven light may be turned on and left on.
How to Set for Timed Baking/Roasting—Immediate Start and Automatic Stop
NOTE: To understand how the oven control works,
practice using regular (non-Sabbath) Immediate Start and
Automatic Stop before entering the Sabbath mode.
Make sure the clock shows the correct time of day
and the oven is off.
Touch and hold both the and BAKE
BROIL HI/LO pads, at the same time,
until the display shows SF.
Tap the CLOCK pad until SAb appears
in the display.
Touch the START/ON pad and ⊃ will
appear in the display.
Touch the COOKING TIME pad.
Touch the +or –pads to set the desired
length of cooking time between 1 minute
and 9 hours and 59 minutes. The cooking
time that you entered will be displayed.
Touch the START/ON pad.
Touch the BAKE pad. No signal will
be given.
The preset starting temperature will
automatically be set to 350.° Tap the +
or –pads to increase or decrease the
temperature in 25° increments. The
temperature can be set between 170°
and 550.° No signal or temperature
will be given.
Touch the START/ON pad.
After a random delay period of
approximately 30 seconds to 1 minute,
⊃will appear in the display indicating
that the oven is
baking/roasting.
If ⊃
doesn’t appear in the display, start again
at Step 7.
To adjust the oven temperature, touch the
BAKE pad and tap the + –or pads to increase
or decrease the temperature in 25° increments.
Touch the START/ON pad.
When cooking is finished, the display will change
from ⊃to ⊃, indicating that the oven has
turned OFF but is still set in Sabbath. Remove
the cooked food.
⊃
⊃
⊃
Using the Sabbath Feature.(on some models)
(Designed for use on the Jewish Sabbath and Holidays) ge.com
How to Set for Regular Baking/Roasting
NOTE: To understand how the oven control works,
practice using regular baking (non-Sabbath) before
entering Sabbath mode.
Make sure the clock shows the correct time of day
and the oven is off.
Touch and hold both the and BAKE
BROIL HI/LO pads, at the same time,
until the display shows SF.
Tap the CLOCK pad until SAb appears
in the display.
Touch the START/ON pad and ⊃ will
appear in the display.
Touch the pad. No signal will BAKE
be given.
The preset starting temperature will
automatically be set to 350.° Tap the +
or –pads to increase or decrease the
temperature in 25° increments. The
temperature can be set between 170°
and 550.° No signal or temperature
will be given.
Touch the START/ON pad.
After a random delay period of
approximately 30 seconds to 1 minute,
⊃will appear in the display indicating
that the oven is
baking/roasting.
If ⊃
doesn’t appear in the display, start again
at Step 4.
To adjust the oven temperature, touch the
BAKE pad and tap the + –or pads to increase
or decrease the temperature in 25° increments.
Touch the START/ON pad.
NOTE: The CLEAR/OFF COOKING TIME and pads
are active during the Sabbath feature.
⊃
⊃
When the display shows ⊃ the
oven is set in Sabbath. When the
display shows the oven is⊃
baking/roasting.
⊃
When the display shows ⊃ the
oven is set in Sabbath. When the
display shows the oven is⊃
baking/roasting.
⊃
Operating
Instructions Care and Cleaning Installation
Instructions Troubleshooting Tips
Safety Instructions
Consumer Support
You may find that your new oven cooks differently than the one it replaced. Use your new oven for a few weeks to
become more familiar with it. If you still think your new oven is too hot or too cold, you can adjust the thermostat yourself.
Do not use thermometers, such as those found in grocery stores, to check the temperature setting of your oven. These
thermometers may vary 20–40°F.
NOTE: This adjustment will not affect the broiling or the self-cleaning temperatures (on some models). The adjustment
will be retained in memory after a power failure.
Adjust the oven thermostat—Easy to do yourself! ge.com
Pull the OVEN TEMP knob off the range
and look at the back side.
To make an adjustment, loosen
(approximately one turn), but do not
completely remove, the two screws on
the back of the knob.
To increase the oven temperature,
move the pointer toward the words
“MAKE HOTTER.”
To decrease the oven temperature,
turn the pointer toward the words
“MAKE COOLER.”
Each click will change the oven
temperature approximately 10°F.
(Range is plus or minus 60°F from the
arrow.) We suggest that you make the
adjustment one click from the original
setting and check oven performance
before making any additional
adjustments.
After the adjustment is made, retighten
screws so they are snug, but be careful
not to overtighten.
Replace the knob, matching the flat
area of the knob to the shaft, and
check performance.
To Adjust the Thermostat with this Type of Knob
Back of OVEN TEMP knob
(knob appearance may vary)
Pointer
Front of OVEN TEMP knob
(knob appearance may vary)
OVEN TEMP
2
0
0
2
5
0
3
0
0
3
5
0
4
0
0
4
5
0
5
0
0
B
R
O
I
L
C
L
E
A
N
O
F
F
Front of OVEN TEMP knob
(knob appearance may vary)
To Adjust the Thermostat on Other Models
Touch the BAKE and BROIL HI/LO pads
at the same time for 2 seconds until
the display shows SF.
Touch the BAKE pad. A two digit
number shows in the display.
The oven temperature can be adjusted
up to (+) 35°F hotter or (–) 35°F
cooler. Touch the +pad to increase the
temperature in 1 degree increments.
Touch the pad to decrease the–
temperature in 1 degree increments.
When you have made the adjustment,
touch the START/ON pad to go back to
the time of day display. Use your oven
as you would normally.
NOTE: This adjustment will not affect the broiling
or self-cleaning temperatures. It will be retained
in memory after a power failure.
Operating
Instructions Care and Cleaning Installation
Instructions Troubleshooting Tips
Safety Instructions
Consumer Support
21
To Adjust the Thermostat with this Type of Knob
Pull the OVEN TEMP knob off the range
and look at the back side.
To make an adjustment, loosen
(approximately one turn), but do not
completely remove, the two screws on
the back of the knob.
With the back of the knob facing you,
hold the outer edge of the knob with
one hand and turn the front of the
knob with the other hand.
To increase the oven temperature,
move the top screw toward the right.
You’ll hear a click for each notch you
move the knob.
To decrease the oven temperature,
move the top screw toward the left.
Each click will change the oven
temperature approximately 10°F.
(Range is plus or minus 60°F from the
arrow.) We suggest that you make the
adjustment one click from the original
setting and check oven performance
before making any additional
adjustments.
After the adjustment is made, retighten
screws so they are snug, but be careful
not to overtighten.
Replace the knob, matching the flat
area of the knob to the shaft, and
check performance.
L
O
O
S
E
N
S
C
R
E
W
S
T
O
R
O
T
A
T
E
M
A
K
E
C
O
O
L
E
R
M
A
K
E
H
O
T
T
E
R
Back of OVEN TEMP knob
(knob appearance may vary)
22
Operating
Instructions Safety InstructionsCare and Cleaning
Installation
Instructions
Troubleshooting TipsConsumer Support
Using the warming drawer. (on some models)
When Using the Warming Drawer
The warming drawer will keep hot, cooked
foods at serving temperature. Always start
with hot food. Do not use to heat cold
food other than crisping crackers, chips
or dry cereal.
Do not line the warming drawer or pan with
aluminum foil. Foil is an excellent heat
insulator and will trap heat beneath it. This
will upset the performance of the drawer
and could damage the interior finish.
■Preheat prior to use according to these
recommended times:
Setting LO . . . . . . . . . . . . . .15 minutes
Setting MED . . . . . . . . . . . . .25 minutes
Setting HI . . . . . . . . . . . . . . .35 minutes
■Do not put liquid or water in the
warming drawer.
■For moist foods, cover them with a lid
or aluminum foil.
■For crisp foods, leave them uncovered.
■Food should be kept hot in its cooking
container or transferred to a heat-safe
serving dish.
CAUTION: Plastic containers or
plastic wrap will melt if in direct contact with the
drawer, pan or a hot utensil. Melted plastic may not
be removable and is not covered under your warranty.
■Remove serving spoons, etc., before
placing containers in warming drawer.
Control Knob (on models equipped with a knob)
Push and turn the control knob to any
desired setting.
NOTE: The warming drawer should not
be used during a self-clean cycle.
ON Signal Light
The ON signal light is located above the
control knob and glows when the knob is in
the on position. It stays on until the knob is
moved to the OFF position.
Warming Drawer
LO HI
MED
OFF
LO . . . . . . . . . . . . . . . . . . . . . . . . .Pies
MED . . . . . . . . . . . . . . . . . . .Casseroles
HI . . . . . . . . . . . . . . . . . . . . . . . .Meats
23
Operating
Instructions Care and Cleaning Installation
Instructions Troubleshooting Tips
Safety Instructions
Consumer Support
ge.com
Temperature Selection Chart
■The temperature, type and amount of
food, and the time held will affect the
quality of the food.
■Food in heat-safe glass and glass-ceramic
utensils may need a higher control setting
as compared to food in metal utensils.
■Repeated opening of the drawer allows
hot air to escape and food to cool.
■ Allow extra time for the temperature
inside the drawer to stabilize after
adding items.
■With large loads it may be necessary to
use a higher thermostat setting and
cover some of the cooked food items.
■Do not use plastic containers or
plastic wrap.
CAUTION: Do not keep food in the
warming drawer for more than two hours.
To Crisp Stale Items
■Place food in low-sided dishes or pans.
■Preheat on LO setting.
■Check crispness after 45 minutes.
Add time as needed.
To Warm Serving Bowls and Plates
To warm serving bowls and plates, set the
control on LO.
■Use only heat-safe dishes.
■Place empty dishes on the rack to raise
them off the bottom of the drawer.
Placing dishes on the warming drawer
bottom may cause them to become
extremely hot and could damage them.
■If you want to heat fine china, please
check with the manufacturer of the
dishes for their maximum heat tolerance.
■You may warm empty serving dishes while
preheating the drawer.
■When holding hot, cooked foods and
warming empty serving dishes at the
same time, place the serving dishes on
the rack and the food on the bottom of
the drawer.
CAUTION: Dishes will be hot. Use
pot holders or mitts when removing hot dishes.
Food Type Control Setting
Bacon HI
Breads MED
Casserole MED
Chicken, fried HI
Eggs, scrambled MED
Fish HI
Gravy, sauces HI
Ham HI
Muffins MED
Onion rings HI
Pies LO
Pizza HI
Potatoes, baked HI
Potatoes, mashed LO
Tortilla Chips LO
To keep several different foods hot, set the control to the food needing the highest setting.
Place the items needing the highest setting on the bottom of the drawer and items
needing less heat on the rack.
Rack (on some models)
■For use in the warming drawer only.
Do not use in the oven.
■Preheat with the rack in place.
■Using the rack allows for double stacking
of items.
Operating
Instructions Safety InstructionsCare and Cleaning
Installation
Instructions
Troubleshooting TipsConsumer Support
For the first self-clean cycle, we recommend
venting your kitchen with an open window
or using a ventilation fan or hood.
Remove the shelves, broiler pan, broiler
grid, all cookware and any aluminum foil
from the oven.
The oven shelves can be self-cleaned,
but they will darken, lose their luster
and become hard to slide.
Do not use commercial oven cleaners or
oven protectors in or near the self-cleaning
oven. A combination of any of these
products plus the high clean cycle
temperatures may damage the porcelain
finish of the oven.
Soil on the front frame of the range and
outside the gasket on the door will need
to be cleaned by hand. Clean these areas
with hot water, soap-filled steel-wool pads
or cleansers such as Soft Scrub®
.
Rinse well with clean water and dry.
Do not clean the gasket. The fiberglass
material of the oven door gasket cannot
withstand abrasion. It is essential for the
gasket to remain intact. If you notice it
becoming worn or frayed, replace it.
Wipe up any heavy spillovers on the oven
bottom.
Make sure the oven light bulb cover is in
place and the oven light is off.
CAUTION: The grates and drip pans
(on some models) should never be cleaned in
the self-cleaning oven.
Do not use commercial oven cleaners or oven
protectors in or near the self-cleaning oven.
A combination of any of these products
plus the high clean cycle temperatures may
damage the porcelain finish of the oven.
IMPORTANT: The health of some birds is
extremely sensitive to the fumes given off
during the self-cleaning cycle of any range.
Move birds to another well ventilated room.
Never force the latch handle. Forcing the handle will damage the door lock mechanism.
The oven door must be closed and all controls set correctly for the cycle to work properly.
Using the self-cleaning oven. (on some models)
Before a Clean Cycle
Wipe up heavy soil on the oven
bottom.
How to Set the Oven for Cleaning (on models with press pads)
Follow the directions in the Before a Clean
Cycle section.
Latch the door.
Touch the SELF CLEAN pad.
Touch the +or –pads until the
desired Clean Time is displayed.
The Clean Time is normally 4 hours and 20 minutes.
You can change the Clean Time to any time between
3 and 5 hours, depending on the amount of soil in
your oven.
Touch the START/ON pad.
The self-clean cycle will automatically
begin after CLEAN is displayed and the time
countdown appears in the display.
While the oven is self-cleaning, you can
touch the pad to display the time CLOCK
of day. To return to the clean countdown,
touch the SELF CLEAN pad.
The oven shuts off automatically when the
clean cycle is complete, and 0:00 will flash
in the display.
Slide the latch handle to the left as far
as it will go and open the door.
NOTE: Never force the latch. If the oven
is too hot, you will not be able to slide the
latch. Allow the oven to cool.
How to Set the Oven for Cleaning (on models with knobs)
Follow the directions in the Before a Clean
Cycle section.
Latch the door.
Turn the OVEN TEMP knob to CLEAN.
The Clean Time is 4 hours and 20 minutes. The self
clean light will come on and stay on until the self
clean cycle is complete.
The oven shuts off automatically when the clean
cycle is complete.
After a clean cycle, turn the OVEN
TEMP knob to OFF and slide the latch
handle to the left as far as it will go.
To cancel self clean cycle, turn OVEN TEMP
knob to off and slide latch to left as far as
it will go. Wait until self clean light stops
blinking. Use oven as desired.
NOTE: Never force the latch. If the oven
is too hot, you will not be able to slide the
latch. Allow the oven to cool.
OVEN TEMP
2
0
0
2
5
0
3
0
0
3
5
0
4
0
0
4
5
0
5
0
0
B
R
O
I
L
C
L
E
A
N
O
F
F
24
25
The oven door must be closed and all controls set correctly for the cycle to work properly.
After a Clean Cycle
You cannot set the oven for cooking until
the oven is cool enough for the door to be
unlatched.
You may notice some white ash in the oven.
Wipe it up with a damp cloth after the
oven cools.
If white spots remain, remove them with a soap-
filled steel-wool pad and rinse thoroughly with
a vinegar and water mixture.
These deposits are usually a salt residue
that cannot be removed by the clean cycle.
If the oven is not clean after one clean
cycle, repeat the cycle.
■You cannot set the oven for cooking until
the oven is cool enough for the door
to unlock.
■ While the oven is self-cleaning, you can
touch the pad to display the time CLOCK
of day. To return to the clean countdown,
touch the COOKING TIME pad.
■If the shelves become hard to slide,
apply a small amount of vegetable oil or
cooking oil to a paper towel and wipe
the edges of the oven shelves with the
paper towel.
ge.com
How to Delay the Start of Cleaning
You can set the oven control to delay-start the oven,
clean for a specific length of time and then turn off
automatically.
Make sure the clock shows the correct time
of day.
Follow the directions in the Before a Clean
Cycle section.
Latch the door.
NOTE: Never force the latch. If the oven is
too hot, you will not be able to slide the
latch. Allow the oven to cool.
Touch the SELF CLEAN pad.
Touch the +or –pads to set the
Clean Time.
The Clean Time is preset for 4 hours and 20 minutes.
You can change the Clean Time to any time between
3 and 5 hours, depending on the amount of soil in
your oven. If a different Clean Time is desired, touch
the + or – pads until the desired Clean Time is
displayed.
Touch the START TIME pad.
Change the Start Time by touching the + or – pads.
The start time will appear in the display.
Touch the START/ON pad.
The self-clean cycle will automatically begin
at the time set.
While the oven is self-cleaning, you can
touch the CLOCK pad to display the time
of day. To return to the clean countdown,
touch the SELF CLEAN pad.
The oven shuts off automatically when the
clean cycle is complete, and 0:00 will flash
in the display.
Slide the latch handle to the left as far
as it will go and open the door.
To Stop a Clean Cycle
Touch the CLEAR/OFF pad.
Wait until the oven has cooled below the
locking temperature to unlatch the door.
You will not be able to open the door right
away unless the oven has cooled below the
locking temperature.
Operating
Instructions Care and Cleaning Installation
Instructions Troubleshooting Tips
Safety Instructions
Consumer Support
CAUTION: Before replacing your oven light
bulb, turn the oven light off and disconnect the
electrical power to the range at the main fuse
or circuit breaker panel.
Be sure to let the light cover and bulb cool
completely.
To remove the cover:
Hold a hand under the cover so it
doesn’t fall when released. With fingers
of the same hand, firmly push back the
wire cover holder. Lift off the cover.
Do not remove any screws to remove the cover.
Replace bulb with a 40-watt household
appliance bulb.
To replace the cover:
Place it into groove of the light
receptacle. Pull wire forward to the
center of the cover until it snaps
into place.
Connect electrical power to the range.
ge.com
27
Do not clean the bake element or the broil element.
Any soil will burn off when the elements are heated.
To clean the oven floor, gently lift the bake
element. Clean with warm soapy water.
Clean the oven shelves with an abrasive
cleanser or scouring pad. After cleaning,
rinse the shelves with clean water and dry
with a clean cloth.
NOTE: Take the shelves out of the oven
before you begin the self-clean cycle or
they may discolor.
To make the shelves slide more easily, apply
a small amount of vegetable oil or cooking
oil to a paper towel and wipe the edges of
the oven shelves with the paper towel.
Wire cover holder
Oven Heating Elements
Oven Shelves
Oven Light Replacement (on some models)
Operating
Instructions Care and Cleaning Installation
Instructions Troubleshooting Tips
Safety Instructions
Consumer Support
Operating
Instructions Safety InstructionsCare and Cleaning
Installation
Instructions
Troubleshooting TipsConsumer Support
28
Do not clean the broiler pan or grid in a
self-cleaning oven.
After broiling, remove the broiler pan from
the oven. Remove the grid from the pan.
Carefully pour out the grease from the pan
into a proper container.
Wash and rinse the broiler pan and grid
in hot water with a soap-filled or plastic
scouring pad.
If food has burned on, sprinkle the grid
with detergent while hot and cover with wet
paper towels or a dishcloth. Soaking the
pan will remove burned-on foods.
The broiler pan may be cleaned with a
commercial oven cleaner. If the grid is grey
enamel, it can also be cleaned with an oven
cleaner.
Both the broiler pan and grid can also be
cleaned in the dishwasher.
Do not store a soiled broiler pan and grid anywhere
in the range.
CAUTION: Do not clean the broiler
pan or grid in a self-cleaning oven.
After broiling, remove the broiler pan
from the oven.
To remove the storage drawer:
Pull the drawer out all the way.
Tilt up the front and remove it.
To replace the storage drawer:
Insert glides at the back of the drawer
beyond the stop on range glides.
Lift the drawer if necessary to insert
easily.
Let the front of the drawer down, then
push in to close.
Clean under the range.
Broiler Pan & Grid
Storage Drawer Removal (on some models)
Care and cleaning of the range.
It’s a good idea to wipe the control panel
after each use of the oven. Use a damp
cloth to clean or rinse. For cleaning, use
mild soap and water or a 50/50 solution of
vinegar and water. For rinsing, use clean
water. Polish dry with a soft cloth.
Do not use abrasive cleansers, strong liquid
cleaners, plastic scouring pads or oven
cleaners on the control panel—they will
damage the finish.
The control knobs may be removed for
easier cleaning.
To remove a knob, pull it straight off the
stem. If a knob is difficult to remove, place
a towel or dishcloth between the knob and
control panel and pull gently. Wash the
knobs in soap and water or a vinegar and
hot water solution.
Before removing the knobs for cleaning,
please note that the knobs are in the OFF
position. When replacing the knobs, check
the OFF position to ensure proper placement.
Do not bend knobs by pulling them up or
down or by hanging a towel or other such
loads. This can damage the shaft.
Pull the knob straight off the stem.
Control Panel and Knobs
Operating
Instructions Safety InstructionsCare and Cleaning
Installation
Instructions
Troubleshooting TipsConsumer Support
30
Care and cleaning of the range.
Be sure all the controls are turned to OFF and the
surface units are cool before attempting to remove
them.
To clean the surface units, turn the control
to the highest setting for a minute. The coils
will burn off any soil.
To remove a surface unit:
To remove the drip pans for cleaning, the
surface units must be removed first.
Lift the surface unit about 1 inch above the
drip pan and pull it out.
Do not lift the surface unit more than 1″. If you do,
it may not lie flat on the drip pan when you plug it
back in.
Repeated lifting of the surface unit more than
1 inch above the drip pan can permanently
damage the receptacle.
To replace a surface unit:
Replace the drip pan into the recess in the
cooktop. Make sure the opening in the pan
lines up with the receptacle.
Insert the terminals of the surface unit
through the opening in the drip pan and
into the receptacle.
Guide the surface unit into place so it rests
evenly.
Do not immerse the surface units in
liquids of any kind.
Do not clean the surface units in a
dishwasher.
Do not bend the surface unit plug
terminals.
Do not attempt to clean, adjust or in any
way repair the plug-in receptacle.
Be sure all surface units are turned
off before raising the cooktop.
Some models have a cooktop that can be
lifted up for easier cleaning. The entire
cooktop may be lifted up and supported
in the up position.
The surface units do not need to be
removed; however, you may remove one to
make raising the cooktop easier. There are
two side supports that lock into position
when the cooktop is lifted up.
After cleaning under the cooktop with hot,
mild soapy water and a clean cloth, lower
the cooktop. Be careful not to pinch your
fingers.
To lower the cooktop, push the rods back
and gently lower the cooktop until it rests
in place.
NOTE: Do not lift the cooktop on radiant top models.
Lifting the cooktop can lead to damage and improper
operation of the range.
The porcelain enamel finish is sturdy
but breakable if misused. This finish is
acid-resistant. However, any acidic foods
spilled (such as fruit juices, tomato or
vinegar) should not be permitted to remain
on the finish.
If acids spill on the cooktop while it is hot,
use a dry paper towel or cloth to wipe it up
right away. When the surface has cooled,
wash with soap and water. Rinse well.
For other spills such as fat spatterings, wash
with soap and water or cleansing powders
after the surface has cooled. Rinse well.
Polish with a dry cloth.
Porcelain Enamel Cooktop (on some models)
Surface unit
Drip pan
Receptacle
Remove the surface units. Then lift out the
drip pans.
Place them in a covered container. Add
1/4 cup ammonia and let soak several
hours or overnight. Wash, rinse well
and dry.
The drip pans may also be cleaned in the
dishwasher.
Clean the area under the drip pans often.
Built-up soil, especially grease, may catch fire.
Do not cover the drip pans with foil. Using foil so
close to the receptacle could cause shock, fire or
damage to the range.
NOTE: Do not clean the drip pans in a
self-cleaning oven.
Drip Pans (on some models)
Surface Units (on some models)
Lift-Up Cooktop (on some models)
31
ge.com
Operating
Instructions Care and Cleaning Installation
Instructions Troubleshooting Tips
Safety Instructions
Consumer Support
Painted surfaces include the sides of the
range and the sides of the door trim.
To clean the painted surfaces, use a hot,
damp cloth with a mild detergent suitable
for these surfaces. Use a clean, hot, damp
cloth to remove soap. Dry with a dry, clean
cloth.
Do not use steel-wood pads, commercial
oven cleaners, cleaning powders or other
abrasive cleaners. They will damage the
surface.
Painted Surfaces (on some models)
On glass cooktop models, the oven is vented
through an opening at the rear of the
cooktop.
On coil cooktop models, the oven is vented
through an opening under the right rear
surface unit.
Never cover the opening with aluminum foil or
any other material.
Oven Vent
To clean the outside glass finish, use a glass
cleaner. Rinse and polish with a dry cloth.
Glass Window (on some models)
Stainless Steel Surfaces (on some models)
Do not use a steel-wool pad; it will scratch
the surface.
Shake bottle well.
Place a small amount of CERAMA
BRYTE
®Stainless Steel Appliance
Cleaner on a damp cloth or damp
paper towel.
Clean a small area (approximately
8″ ″x 8 ), rubbing with the grain of the
stainless steel if applicable.
Dry and buff with a clean, dry paper
towel or soft cloth.
Repeat as necessary.
NOTE: If a mineral oil-based stainless steel
appliance cleaner has been used before
to clean the appliance, wash the surface
with dishwashing liquid and water prior
to using the CERAMA BRYTE ®Stainless
Steel Appliance Cleaner. After washing
the surface with dishwashing liquid
and water, use a generous amount
of CERAMA BRYTE®Stainless Steel
Appliance Cleaner to clean the appliance.
To Order
To order CERAMA BRYTE ®Stainless
Steel Appliance Cleaner, please call our
toll-free number:
National Parts Center 800.626.2002
ge.com
CERAMA BRYTE
®
Stainless Steel Appliance
Cleaner . . . . . . . . . . . . . . . . . . . . .# PM10X311
32
Cleaning the glass cooktop. (on some models)
Operating
Instructions Safety InstructionsCare and Cleaning
Installation
Instructions
Troubleshooting TipsConsumer Support
Allow the cooktop to cool.
Use a single-edge razor blade
scraper at approximately a 45° angle
against the glass surface and scrape
the soil. It will be necessary to apply
pressure to the razor scraper in
order to remove the residue.
After scraping with the razor
scraper, spread a few drops of
CERAMA BRYTE
®Ceramic Cooktop
Cleaner on the entire burned residue
area. Use the CERAMA BRYTE ®
Cleaning Pad to remove any
remaining residue.
For additional protection,
after all residue has been removed,
polish the entire surface with
CERAMA BRYTE
®Ceramic Cooktop
Cleaner and a paper towel.
Burned-On Residue
WARNING: DAMAGE to your glass surface may
occur if you use scrub pads other than those
recommended.
Allow the cooktop to cool.
Spread a few drops of CERAMA
BRYTE
®Ceramic Cooktop Cleaner
on the entire burned residue area.
Using the included CERAMA
BRYTE
®Cleaning Pad for Ceramic
Cooktops, rub the residue area,
applying pressure as needed.
If any residue remains, repeat the
steps listed above as needed.
For additional protection, after
all residue has been removed, polish
the entire surface with CERAMA
BRYTE
®Ceramic Cooktop Cleaner
and a paper towel.
The CERAMA BRYTE
®Ceramic
Cooktop Scraper and all
recommended supplies are
available through our Parts Center.
See instructions under “To Order
Parts” section on next page.
NOTE: Do not use a dull or
nicked blade.
Heavy, Burned-On Residue
Use a CERAMA BRYTE
®Cleaning
Pad for Ceramic Cooktops.
Normal Daily Use Cleaning
ONLY use CERAMA BRYTE®Ceramic
Cooktop Cleaner on the glass cooktop.
Other creams may not be as effective.
To maintain and protect the surface of your
glass cooktop, follow these steps:
Before using the cooktop for the
first time, clean it with CERAMA
BRYTE
®Ceramic Cooktop Cleaner.
This helps protect the top and makes
cleanup easier.
Daily use of CERAMA BRYTE®
Ceramic Cooktop Cleaner will help
keep the cooktop looking new.
Shake the cleaning cream well. Apply
a few drops of CERAMA BRYTE ®
Ceramic Cooktop Cleaner directly to
the cooktop.
Use a paper towel or CERAMA
BRYTE
®Cleaning Pad for Ceramic
Cooktops to clean the entire cooktop
surface.
Use a dry cloth or paper towel
to remove all cleaning residue.
No need to rinse.
NOTE: It is very important that you DO NOT heat
the cooktop until it has been cleaned thoroughly.
Clean your cooktop after
each spill. Use CERAMA
BRYTE
®Ceramic Cooktop
Cleaner.
35
Installation Instructions
PREPARE TO INSTALL THE RANGE
TOOLS YOU WILL NEED
MATERIALS YOU MAY NEED
Anchor SleevesLag BoltsTin Snips
(For Anti-Tip Bracket Mounted on Concrete Floors Only)
3-Wire Cord
4‘ Long
4-Wire Cord OR
4‘ Long
(UL Approved 40 AMP)
Adjustable Wrench
Level1/4” Nut Driver
Phillips Screwdriver
Drill with 1/8” Bit
Pencil
Safety Glasses
Tape Measure
Pliers
Flat-blade
Screwdriver
PARTS INCLUDED
Anti-Tip Bracket Kit
REMOVE SHIPPING MATERIALS
Remove packaging materials. Failure to
remove packaging materials could result
in damage to the appliance.
1
PREPARE THE OPENING
Allow 1 1⁄2″ spacing from the range to adjacent
vertical walls above the cooktop surface.
Allow 30″ minimum clearance between
the surface units and the bottom of
unprotected wood or metal top cabinet,
and 15″ minimum between the
countertop and adjacent cabinet bottom.
EXCEPTION: Installation of a listed
microwave oven or cooking appliance over
the cooktop shall conform to the installation
instructions packed with that appliance.
If cabinet storage is installed, reduce the
risk by installing a range hood that projects
horizontally a min. of 5 beyond the″
bottom of the cabinets. Make sure the wall
covering, countertops and cabinets around
the range can withstand heat generated
by the range, oven or cooktop up to 200°F.
Flooring under the range
Your range, like many other household items,
is heavy and can settle into soft floor coverings
such as cushioned vinyl or carpeting.
When moving the range on this type of
flooring, it should be installed on a 1/4″
thick sheet of plywood (or similar material)
as follows:
When the floor covering ends at the front
of the range, the area that the range will
rest on should be built up with plywood
to the same level or higher than the floor
covering. This will allow the range to be
moved for cleaning or servicing.
2
Cord
Wall
Floor
7″
5″
C of range
L
Outlet
box
Hood
Wall
Not less than
the width of
the range
5″ Min.
30″
Min. 15″
Min.
11⁄2″
Min.
Locate the outlet box
within either shaded area.
21⁄4″
71⁄2″
71⁄2″
31⁄2″
Install the
outlet box
on either
side of the
C
L
Squeeze Connector
(For Conduit
Installations Only)
36
Installation Instructions
ELECTRICAL CONNECTIONS
ALL NEW CONSTRUCTIONS,
MOBILE HOMES AND
INSTALLATIONS WHERE
LOCAL CODES DO NOT
ALLOW GROUNDING
THROUGH NEUTRAL
Use only a 3-conductor or a 4-conductor
UL-listed range cord. These cords may be
provided with ring terminals on wire and
a strain relief device.
A range cord rated at 40 amps with 125/250
minimum volt range is required. A 50 amp
range cord is not recommended but if used, it
should be marked for use with nominal 1 3⁄8″
diameter connection openings. Care should
be taken to center the cable and strain relief
within the knockout hole to keep the edge
from damaging the cable.
• Because range terminals are not accessible
after range is in position, flexible service
conduit or cord must be used.
NOTE: If conduit is being used, go to Step 3D
and then to Step 6 or 7.
• On some models, a filter capacitor may be
connected between the black and white
leads on the junction block.
ELECTRICAL REQUIREMENTS
CAUTION: For personal safety,
do not use an extension cord with this
appliance. Remove house fuse or open circuit
breaker before beginning installation.
This appliance must be supplied with the
proper voltage and frequency, and connected
to an individual properly grounded branch
circuit, protected by a circuit breaker or fuse
having amperage as specified on the rating
plate. The rating plate is located behind the
storage drawer or warming drawer on the
oven frame.
We recommend you have the electrical wiring
and hookup of your range connected by a
qualified electrician. After installation, have
the electrician show you where your main
range disconnect is located.
Check with your local utilities for electrical
codes which apply in your area. Failure to
wire your oven according to governing codes
could result in a hazardous condition. If there
are no local codes, your range must be wired
and fused to meet the requirements of the
National Electrical Code, ANSI/NFPA No. 70—
Latest Edition. You can get a copy by writing:
National Fire Protection Association
Batterymarch Park
Quincy, MA 02269
Effective January 1, 1996, the National
Electrical Code requires that new construction
(not existing) utilize a 4-conductor connection
to an electric range.
When installing an electric range in new
construction, follow Steps 3 and 5 for 4-wire
connection.
You must use a 3-wire, single-phase A.C.
208Y/120 Volt or 240/120 Volt, 60 hertz
electrical system. If you connect to aluminum
wiring, properly installed connectors
approved for use with aluminum wiring
must be used.
If the electrical service provided does not
meet the above specifications, have a
licensed electrician install an approved outlet.
Location of
model rating
plate
37
Installation Instructions
POWER CORD AND STRAIN
RELIEF INSTALLATION
Remove the wire cover (on the lower
back of the range) by removing two (2)
screws using a 1/4” nut driver.
Do not discard these screws.
Remove the knockout ring (1 3⁄8″) located
on bracket directly below the terminal
block. To remove the knockout, use a
pair of pliers to bend the knockout ring
away from the bracket and twist until
ring is removed.
B
A
3For power cord installations only (see
the next step if using conduit), assemble
the strain relief in the hole. Insert the
power cord through the strain relief and
tighten. Allow enough slack to easily
attach the cord terminals to the terminal
block. If tabs are present at the end of
the winged strain relief, they can be
removed for better fit.
NOTE: Do not install the power cord
without a strain relief. The strain relief
bracket should be installed before
reinstalling the rear range wiring cover.
Skip to Step 4 or 5.
C
Wire cover
2 screws
to remove
wire cover
Knockout ring
in bracket
Knockout
ring removed
Power cord
Strain relief
Terminal
block
Bracket
Retaining
tab
Back of range
Terminal block
(appearance
may vary)
For conduit installations only, purchase a
squeeze connector matching the diameter
of your conduit and assemble it in the hole.
Insert the conduit through the squeeze
connector and tighten. Allow enough slack to
easily attach the wires to the terminal block.
NOTE: Do not install the conduit without a
squeeze connector. The squeeze connector
should be installed before reinstalling the
rear range wiring cover.
Skip to Step 6 or 7.
D
Squeeze
connector
Terminal
block
Conduit Bracket
ELECTRICAL CONNECTIONS (CONT.)
38
Installation Instructions
4-WIRE POWER CORD
INSTALLATION
WARNING: The neutral wire of
the supply circuit must be connected to the
neutral terminal located in the lower center
of the terminal block. The power leads must
be connected to the lower left and the lower
right terminals of the terminal block. The 4th
grounding lead must be connected to the
frame of the range with the ground plate
and the ground screw.
Remove the 3 lower terminal screws from
the terminal block. Remove the ground
screw and ground plate and retain them.
Cut and discard the ground strap. DO NOT
DISCARD ANY SCREWS.
Insert the one ground screw into the power
cord ground wire terminal ring, through the
ground plate and into the frame of the range.
Insert the 3 terminal screws (removed earlier)
through each power cord terminal ring and
into the lower terminals of the terminal block.
Be certain that the center wire (white/neutral)
is connected to the center lower position of
the terminal block. Tighten screws securely
into the terminal block.
Skip to Step 8 and proceed with the installation.
E
D
C
B
A
5
3-WIRE POWER CORD
INSTALLATION
WARNING: The neutral or ground
wire of the power cord must be connected
to the neutral terminal located in the
center of the terminal block. The power
leads must be connected to the lower left
and the lower right terminals of the
terminal block.
Remove the 3 lower terminal screws
from the terminal block. Insert the 3
terminal screws through each power cord
terminal ring and into the lower terminals
of the terminal block. Be certain that the
center wire (white/neutral) is connected
to the center lower position of the
terminal block. Tighten screws securely
into the terminal block.
DO NOT remove the ground strap
connection.
Skip to Step 8 and proceed with the
installation.
B
A
4
Ground
strap
Terminal
block
(appearance
may vary)
Neutral
terminal Before
After
Terminal
block
Terminal
block
Neutral
terminal
Neutral
terminal
Ground strap
Ground
plate
(grounding
to range)
Ground
screw
Power cord
Ground plate
Ground strap
or
39
Installation Instructions
3-WIRE CONDUIT INSTALLATION
Loosen the 3 lower terminal screws from
the terminal block. Insert the center bare
wire (white/neutral) tip through the bottom
center terminal block opening. On certain
models, the wire will need to be inserted
through the ground strap opening and then
into the bottom center block opening. Insert
the two side bare wire tips into the lower
left and the lower right terminal block
openings. Tighten the screws until the wire
is firmly secure (approximately 20 inch-lbs.).
NOTE: ALUMINUM WIRING:
Aluminum building wire may be used
but it must be rated for the correct
amperage and voltage to make
connection. Connect wires according
to this Step 6 or Step 7 depending on
number of wires.
Wire used, location and enclosure
of splices, etc., must conform to good
wiring practices and local codes.
Skip to Step 8 and proceed with the
installation.
B
A
6
4-WIRE CONDUIT INSTALLATION
Loosen the three lower terminal screws
from the terminal block. Remove the ground
screw and ground plate and retain them.
Cut and discard the ground strap. DO NOT
DISCARD ANY SCREWS.
Insert the ground bare wire tip between the
range frame and the ground plate (removed
earlier) and secure it in place with the ground
screw (removed earlier). Insert the bare wire
(white/neutral) tip through the bottom center
of the terminal block opening. Insert the two
side bare wire tips into the lower left and the
lower right terminal block openings. Tighten
the screws until the wire is firmly secure
(approximately 20 inch-lbs.).
Wire used, location and enclosure
of splices, etc., must conform to good
wiring practices and local codes.
Proceed to Step 8.
C
B
A
7
Before
Terminal
block
Ground strap
After
Terminal
block Ground
plate
(grounding
to range)
Bracket
Neutral
terminal
Wire tips
Wire tips
Terminal
block
Conduit
Bracket
Ground
screw
Ground strap
or
40
Installation Instructions
INSTALL THE RANGE
ANTI-TIP DEVICE INSTALLATION
An Anti-Tip bracket is supplied with
instructions for installation in a variety of
locations. The instructions include all
necessary information to complete the
installation. Read the Safety Instructions
and the instructions that fit your situation
before beginning installation.
WARNING:
• Range must be secured by Anti-Tip bracket
supplied.
• If the Anti-Tip device supplied with the
range does not fit this application, use the
universal Anti-Tip device WB2X7909.
• See instructions to install (supplied with bracket).
• Unless properly installed, the range could
be tipped by stepping or sitting on the door.
Injury may result from spilled hot liquids
or from the range itself.
9
Typical installation of anti-tip bracket attachment to wall
Bracket
Screw must
enter wood
or metal
Wall plate
REPLACE THE WIRE COVER
Replace the wire cover on the range back
by sliding its right edge under the retaining
tab and replacing the two screws removed
earlier. Make sure that no wires are pinched
between the cover and the range back.
8
LEVEL THE RANGE
Install the oven shelves in the oven and
position the range where it will be installed.
Check for levelness by
placing a spirit level or a
cup, partially filled with
water, on one of the
oven shelves. If using a
spirit level, take two
readings—with the level
placed diagonally first in one direction
and then the other.
On all models except warming drawer
models, remove the storage drawer,
broiler drawer or kick panel. The front
leveling legs can be adjusted from the
bottom and the rear legs can be adjusted
from the top. (For warming drawer
models, see Step D.)
C
B
A
10
Leg
leveler
Lower
range
Raise
range
Front leveling legs
(on some models)
Rear leveling legs
(on some models)
Lower
range
Raise
range
Spirit level
Wire
cover
2 screws
to replace
wire cover
Retaining
tab
Back of range
Adjust from
the top
Adjust from
the bottom
Front of range
LEVEL THE RANGE (CONT.)
On all warming drawer models, the rear
leveling legs must be adjusted prior to
moving the range into position. They can
be adjusted from the bottom at the back
of the range.
Use an open-end or adjustable wrench
to adjust the leveling legs until the range
is level.
Replace the drawer or panel.
F
E
D
10
Installation Instructions
FINAL INSTALLATION
CHECKLIST
• Check to make sure the circuit breaker is
closed (RESET) or the circuit fuses are
replaced.
• Be sure power is in service to the building.
• Note (on some models): If the clock flashes
“bAd” and then “LinE” with a loud tone,
the neutral connection to the range is
miswired. Check the terminal block
connections and/or house wiring to correct.
• Check to be sure that all packing materials
and tape have been removed. This will
include tape on metal panel under control
knobs (if applicable), adhesive tape, wire
ties, cardboard and protective plastic.
Failure to remove these materials could
result in damage to the appliance once the
appliance has been turned on and surfaces
have heated.
• Check to make sure that the rear leveling
leg is fully inserted into the Anti-Tip bracket
and that the bracket is securely installed.
11
OPERATION CHECKLIST
• Turn on one of the surface units to observe
that the element glows within 60 seconds.
Turn the unit off when glow is detected. If
the glow is not detected within the time
limit, recheck the range wiring connections.
If change is required, retest again. If no
change is required, have building wiring
checked for proper connections and voltage.
• Check to make sure the Clock (on models
so equipped) display is energized. If a series
of horizontal red lines appear in the display,
disconnect power immediately. Recheck the
range wiring connections. If change is
made to connections, retest again. If no
change is required, have building wiring
checked for proper connections and
voltage. It is recommended that the clock
be changed if the red lines appear.
• Be sure all range controls are in the OFF
position before leaving the range.
12
41
Adjust from
the bottom
back of range
(warming
drawer models)
Back of range
Leg
leveler
Lower
range
Raise
range
Operating
Instructions Safety InstructionsCare and Cleaning
Installation
Instructions
Troubleshooting TipsConsumer Support
42
Before you call for service…
Troubleshooting Tips
Save time and money! Review the charts on the following
pages first and you may not need to call for service.
Problem Possible Causes What To Do
Radiant Cooktops
Surface units will not Improper cookware •Use pans which are flat and match the diameter
maintain a rolling boil being used. of the surface unit selected.
or cooking is not
fast enough
Surface units do A fuse in your home may be • Replace the fuse or reset the circuit breaker.
not work properly blown or the circuit breaker
tripped.
Cooktop controls • Check to see the correct control is set for the surface
improperly set. unit you are using.
Scratches (may appear Incorrect cleaning • Scratches are not removable. Tiny scratches will become
as cracks) on cooktop methods being used. less visible in time as a result of cleaning.
glass surface Cookware with rough bottoms • To avoid scratches, use the recommended cleaning
being used or coarse particles procedures. Make sure bottoms of cookware are clean
(salt or sand) were between before use, and use cookware with smooth bottoms.
the cookware and the surface
of the cooktop.
Cookware has been slid
across the cooktop surface.
Areas of discoloration Food spillovers not cleaned • See the Cleaning the glass cooktop section.
on the cooktop before next use.
Hot surface on a model • This is normal. The surface may appear discolored
with a light-colored glass when it is hot. This is temporary and will disappear
cooktop. as the glass cools.
Plastic melted to Hot cooktop came into • See the Glass surface—potential for permanent damage
the surface contact with plastic placed section in the Cleaning the glass cooktop section.
on the hot cooktop.
Pitting (or indentation) Hot sugar mixture spilled • Call a qualified technician for replacement.
of the cooktop on the cooktop.
Frequent cycling Improper cookware • Use only flat cookware to minimize cycling.
off and on of being used.
surface units
43
ge.com
Operating
Instructions Care and Cleaning Installation
Instructions Troubleshooting Tips
Safety Instructions
Consumer Support
Problem Possible Causes What To Do
Coil Cooktops
Surface units The surface units are not •With the controls off, check to make sure the surface
not functioning plugged in solidly. unit is plugged completely into the receptacle.
properly
The surface unit controls •Check to see the correct control is set for the surface
improperly set. unit you are using.
The drip pans are not set securely •With the controls off, check to make sure the drip pan is
in the cooktop. in the recess in the cooktop and that the opening in the
pan lines up with the receptacle.
Oven—All Models
Oven light does not work Light bulb is loose or defective. •Tighten or replace the bulb.
Switch operating light is broken. •Call for service.
Oven will not work Plug on range is not completely • Make sure electrical plug is plugged into a live, properly
inserted in the electrical outlet. grounded outlet.
A fuse in your home may • Replace fuse or reset circuit breaker.
be blown or the circuit
breaker tripped.
Oven controls improperly set. • See the Using the oven section.
On self-cleaning models, door • If necessary, allow the oven to cool then unlock the door.
left in the locked position.
Food does not bake Oven controls improperly set. •See the Using the oven section.
or roast properly Shelf position is incorrect or the • See the Using the oven section.
shelf is not level.
Incorrect cookware or cookware • See the Using the oven section.
of improper size being used.
Oven thermostat needs •See the Adjust the oven thermostat–Easy to do yourself!
adjustment. section.
Troubleshooting Tips
Operating
Instructions Safety InstructionsCare and Cleaning
Installation
Instructions
Troubleshooting TipsConsumer Support
44
Before you call for service…
Problem Possible Causes What To Do
Food does not Oven is not set to BROIL. •On models with a temperature knob, make sure you turn
broil properly it all the way to the BROIL position. On models with a
BROIL HI/LO pad, make sure it is turned on.
Door not open to the broil stop •See the Using the oven section.
position as recommended.
Improper shelf position • See the Broiling guide.
being used.
Food being cooked in a hot pan. •Use the broiling pan and grid that came with your
range. Make sure it is cool.
Cookware not suited for broiling. • Use the broiling pan and grid that came with your
range.
Aluminum foil used on the • See the Using the oven section.
broiling pan and grid has
not been fitted properly and
slit as recommended.
In some areas the power • Preheat the broil element for 10 minutes.
(voltage) may be low. • Broil for the longest period of time recommended in
the Broiling guide.
Control signals after You forgot to enter a bake •Press the BAKE pad and desired temperature or the
entering cooking time temperature or cleaning time. SELF CLEAN pad and desired clean time.
or delay start
Display flashes "bAd" The installed connection •Contact installer or electrician to correct miswire.
then "linE" with a from the house to the unit
loud tone is miswired.
Warming drawer will A fuse in your home may be • Replace the fuse or reset the circuit breaker.
not work blown or the circuit breaker
tripped.
The oven is self-cleaning. • Wait for the self-clean cycle to finish and the oven
to cool.
Controls improperly set. • See the Using the warming drawer section.
Excessive condensation Liquid in warming drawer. • Remove liquid.
in the warming drawer Uncovered foods. • Cover food with lid or aluminum foil.
Temperature setting too high. • Reduce temperature setting.
Food dries out in the Moisture escaping. • Cover food with lid or aluminum foil.
warming drawer
45
ge.com
Operating
Instructions Care and Cleaning Installation
Instructions Troubleshooting Tips
Safety Instructions
Consumer Support
Problem Possible Causes What To Do
Oven temperature too Oven thermostat •See the Adjust the oven thermostat–Easy to do
hot or too cold needs adjustment. yourself! section.
Clock and timer do Plug on range is not completely • Make sure electrical plug is plugged into a live, properly
not work inserted in the electrical outlet. grounded outlet.
A fuse in your home may be • Replace fuse or reset circuit breaker.
blown or the circuit breaker
tripped.
Oven controls improperly set. •See the Using the clock and timer section.
Display goes blank A fuse in your home may be •Replace the fuse or reset the circuit breaker.
blown or the circuit breaker
tripped.
The clock is turned off from • See the Using the clock and timer section.
showing in the display.
Oven door is crooked The door is out of position. • Because the oven door is removable, it sometimes gets
out of position during installation. To straighten the
door, push down on the high corner.
Oven makes This is the sound of the •This is normal.
clicking noise heating element turning
off and on during
cooking functions.
“F—and a number You have a function error code. •Press the CLEAR/OFF pad. Put the oven back
or letter” flash in into operation.
the display If the function code repeats: • Disconnect all power to the range for at least 30
seconds and then reconnect power. If the function
error code repeats, call for service.
• On self-cleaning models, if a function error code
appears during the self-cleaning cycle, check the oven
door latch. The latch may have been moved, if only
slightly, from the locked position. Make sure the latch
is moved to the right as far as it will go. Press the
CLEAR/OFF pad. Allow the oven to cool for one hour.
Put the oven back into operation.
Power outage Power outage or surge. •Some models will automatically resume their setting once
the power is restored. On models with a clock, you must
reset the clock. If the oven was in use, you must reset it by
pressing the pad, setting the clock and CLEAR/OFF
resetting any cooking function.
Display flashes Power failure. •Reset the clock.
Unable to get the display Oven control pads were not •The BAKE and BROIL HI/LO pads must be pressed at the
to show “SF” pressed properly. same time and held for 3 seconds.
Specyfikacje produktu
| Marka: | Hotpoint |
| Kategoria: | piekarnik |
| Model: | RB787WHWW |
Potrzebujesz pomocy?
Jeśli potrzebujesz pomocy z Hotpoint RB787WHWW, zadaj pytanie poniżej, a inni użytkownicy Ci odpowiedzą
Instrukcje piekarnik Hotpoint
9 Kwietnia 2025
13 Stycznia 2025
4 Stycznia 2025
29 Grudnia 2024
29 Grudnia 2024
29 Grudnia 2024
29 Grudnia 2024
12 Grudnia 2024
12 Grudnia 2024
12 Grudnia 2024
Instrukcje piekarnik
- piekarnik Bauknecht
- piekarnik Ikea
- piekarnik Samsung
- piekarnik Bertazzoni
- piekarnik Electrolux
- piekarnik DeLonghi
- piekarnik AEG
- piekarnik Balay
- piekarnik Beko
- piekarnik Teka
- piekarnik LG
- piekarnik Küppersbusch
- piekarnik Smeg
- piekarnik Götze & Jensen
- piekarnik Gram
- piekarnik Caso
- piekarnik Amica
- piekarnik Gorenje
- piekarnik Etna
- piekarnik LERAN
- piekarnik Sharp
- piekarnik Cookology
- piekarnik Russell Hobbs
- piekarnik Sage
- piekarnik Tefal
- piekarnik Philips
- piekarnik Livoo
- piekarnik SilverCrest
- piekarnik Dometic
- piekarnik Bosch
- piekarnik Xblitz
- piekarnik Dash
- piekarnik Candy
- piekarnik Whirlpool
- piekarnik Ferroli
- piekarnik Cramer
- piekarnik Miele
- piekarnik Brentwood
- piekarnik Midea
- piekarnik Lamona
- piekarnik Severin
- piekarnik Hisense
- piekarnik Berg
- piekarnik Infiniton
- piekarnik Panasonic
- piekarnik Liebherr
- piekarnik Nedis
- piekarnik Medion
- piekarnik Baumatic
- piekarnik Black & Decker
- piekarnik OK
- piekarnik Adler
- piekarnik Hoover
- piekarnik Toshiba
- piekarnik Tesla
- piekarnik Ribimex
- piekarnik Westinghouse
- piekarnik Rinnai
- piekarnik Hendi
- piekarnik Quigg
- piekarnik Romo
- piekarnik Maytag
- piekarnik Domo
- piekarnik GE
- piekarnik Ardes
- piekarnik Taurus
- piekarnik Orbegozo
- piekarnik Blaupunkt
- piekarnik Brandt
- piekarnik Vivax
- piekarnik Siemens
- piekarnik Ambiano
- piekarnik Danby
- piekarnik Grundig
- piekarnik Haier
- piekarnik KKT Kolbe
- piekarnik Cylinda
- piekarnik Jocel
- piekarnik Hyundai
- piekarnik Silverline
- piekarnik Blomberg
- piekarnik Bimar
- piekarnik Rowenta
- piekarnik Brother
- piekarnik Mesko
- piekarnik Husqvarna
- piekarnik BLOW
- piekarnik Concept
- piekarnik Fisher & Paykel
- piekarnik Tripp Lite
- piekarnik ECG
- piekarnik Indesit
- piekarnik Ilve
- piekarnik Unold
- piekarnik Viking
- piekarnik Nodor
- piekarnik CATA
- piekarnik Cambridge
- piekarnik Fiap
- piekarnik Kenwood
- piekarnik V-Zug
- piekarnik Trisa
- piekarnik Ariston Thermo
- piekarnik Zelmer
- piekarnik Mestic
- piekarnik PKM
- piekarnik Ninja
- piekarnik Cuisinart
- piekarnik Unox
- piekarnik Wilfa
- piekarnik Thor
- piekarnik Amana
- piekarnik Dacor
- piekarnik Hotpoint Ariston
- piekarnik Krups
- piekarnik Furrion
- piekarnik Bomann
- piekarnik Moulinex
- piekarnik Ursus Trotter
- piekarnik PowerXL
- piekarnik Emerio
- piekarnik Create
- piekarnik Biltema
- piekarnik H.Koenig
- piekarnik InAlto
- piekarnik Meireles
- piekarnik Melissa
- piekarnik Schneider
- piekarnik Enders
- piekarnik Thetford
- piekarnik Stirling
- piekarnik MPM
- piekarnik OneConcept
- piekarnik CDA
- piekarnik Sam Cook
- piekarnik Philco
- piekarnik Neff
- piekarnik Qilive
- piekarnik Corbero
- piekarnik Morphy Richards
- piekarnik Zanussi
- piekarnik Bourgini
- piekarnik Instant
- piekarnik Ravanson
- piekarnik Thermex
- piekarnik Fagor
- piekarnik Redmond
- piekarnik Koenic
- piekarnik Everdure
- piekarnik Thomson
- piekarnik Bröhn
- piekarnik Izzy
- piekarnik Ardo
- piekarnik WMF
- piekarnik ProfiCook
- piekarnik Klarstein
- piekarnik BEEM
- piekarnik Coyote
- piekarnik Güde
- piekarnik Arendo
- piekarnik Witt
- piekarnik Manta
- piekarnik Wolkenstein
- piekarnik Cecotec
- piekarnik Artusi
- piekarnik KitchenAid
- piekarnik AFK
- piekarnik Eta
- piekarnik Camry
- piekarnik Steba
- piekarnik Germanica
- piekarnik Weber
- piekarnik Lenoxx
- piekarnik Qlima
- piekarnik Imperial
- piekarnik Scarlett
- piekarnik Sôlt
- piekarnik Nevir
- piekarnik Navitel
- piekarnik TriStar
- piekarnik Landmann
- piekarnik Exquisit
- piekarnik Bartscher
- piekarnik First Austria
- piekarnik Hestan
- piekarnik Gastroback
- piekarnik GYS
- piekarnik Mitsubishi
- piekarnik Privileg
- piekarnik Dimplex
- piekarnik Aurora
- piekarnik Falmec
- piekarnik Arçelik
- piekarnik Hanseatic
- piekarnik Continental Edison
- piekarnik Delta
- piekarnik Bifinett
- piekarnik Linarie
- piekarnik Maginon
- piekarnik Atag
- piekarnik Rosieres
- piekarnik Franke
- piekarnik DCG
- piekarnik Beautiful
- piekarnik G3 Ferrari
- piekarnik Axis
- piekarnik Sanyo
- piekarnik Westfalia
- piekarnik Hamilton Beach
- piekarnik Gourmetmaxx
- piekarnik Novy
- piekarnik Clatronic
- piekarnik Telefunken
- piekarnik Ferrari
- piekarnik Rommer
- piekarnik Inventum
- piekarnik SVAN
- piekarnik Ariete
- piekarnik IFB
- piekarnik Tepro
- piekarnik TurboTronic
- piekarnik Napoleon
- piekarnik Princess
- piekarnik Innoliving
- piekarnik Sunbeam
- piekarnik Solac
- piekarnik Heller
- piekarnik Euro Appliances
- piekarnik Waring Commercial
- piekarnik Mora
- piekarnik Caple
- piekarnik Duronic
- piekarnik Omega
- piekarnik Comfee
- piekarnik Classique
- piekarnik Bush
- piekarnik New Pol
- piekarnik Kenmore
- piekarnik Kaiser
- piekarnik Breville
- piekarnik BORA
- piekarnik VOX
- piekarnik Insignia
- piekarnik Hiberg
- piekarnik AYA
- piekarnik Pelgrim
- piekarnik Veripart
- piekarnik Esperanza
- piekarnik Chefman
- piekarnik Frilec
- piekarnik Benavent
- piekarnik Element
- piekarnik Tower
- piekarnik Orima
- piekarnik Rex
- piekarnik Kernau
- piekarnik Aspes
- piekarnik Hitachi
- piekarnik Zerowatt
- piekarnik Tracer
- piekarnik Salton
- piekarnik Respekta
- piekarnik Technika
- piekarnik Vedette
- piekarnik Seiki
- piekarnik JennAir
- piekarnik Frigidaire
- piekarnik Galanz
- piekarnik Matrix
- piekarnik Barazza
- piekarnik RCA
- piekarnik Summit
- piekarnik Gemini
- piekarnik Sirius
- piekarnik Foster
- piekarnik Chef
- piekarnik Rommelsbacher
- piekarnik Fulgor Milano
- piekarnik Electroline
- piekarnik Kelvinator
- piekarnik Gaggenau
- piekarnik Sencor
- piekarnik Hobart
- piekarnik Mistral
- piekarnik Elica
- piekarnik Nabo
- piekarnik Avanti
- piekarnik Asko
- piekarnik Kalorik
- piekarnik Binatone
- piekarnik Suntec
- piekarnik Nextbase
- piekarnik Zenith
- piekarnik Flavel
- piekarnik Altus
- piekarnik Esatto
- piekarnik Signature
- piekarnik Daewoo
- piekarnik Capital
- piekarnik Cosori
- piekarnik BlueStar
- piekarnik Consul
- piekarnik BioChef
- piekarnik Porter & Charles
- piekarnik Kunft
- piekarnik Robinhood
- piekarnik Grunkel
- piekarnik Becken
- piekarnik Haeger
- piekarnik Scandomestic
- piekarnik Bizerba
- piekarnik Traeger
- piekarnik Ignis
- piekarnik Guzzanti
- piekarnik Mach
- piekarnik Emilia
- piekarnik Aroma
- piekarnik Edilkamin
- piekarnik Dualit
- piekarnik Comelec
- piekarnik Campart
- piekarnik Belling
- piekarnik De Dietrich
- piekarnik ZLine
- piekarnik Campingaz
- piekarnik Magic Chef
- piekarnik Eurom
- piekarnik Clas Ohlson
- piekarnik Arctic Cooling
- piekarnik Sauber
- piekarnik Smith&Brown
- piekarnik Sogo
- piekarnik George Foreman
- piekarnik Crosley
- piekarnik Nutrichef
- piekarnik Constructa
- piekarnik Proline
- piekarnik Euromaid
- piekarnik Char-Broil
- piekarnik Flama
- piekarnik BLANCO
- piekarnik Emax
- piekarnik Ideal
- piekarnik Scancool
- piekarnik AENO
- piekarnik Thermador
- piekarnik Bass Polska
- piekarnik Finlux
- piekarnik Bestron
- piekarnik Optimum
- piekarnik Atosa
- piekarnik Swan
- piekarnik Zanker
- piekarnik Kluge
- piekarnik Acec
- piekarnik Alpina
- piekarnik Airlux
- piekarnik Aga
- piekarnik Ariston
- piekarnik Techwood
- piekarnik Arthur Martin
- piekarnik Korona
- piekarnik Saturn
- piekarnik Tiger
- piekarnik Progress
- piekarnik Zanussi-electrolux
- piekarnik Tomado
- piekarnik Bellini
- piekarnik Oster
- piekarnik Vestel
- piekarnik Sinbo
- piekarnik Jata
- piekarnik Fritel
- piekarnik Prima
- piekarnik Junker
- piekarnik Outwell
- piekarnik Mabe
- piekarnik Monogram
- piekarnik Iberna
- piekarnik Logik
- piekarnik Valberg
- piekarnik Scholtes
- piekarnik Profilo
- piekarnik Ernesto
- piekarnik Mellerware
- piekarnik Castor
- piekarnik Heinner
- piekarnik Lakeland
- piekarnik Termozeta
- piekarnik Bella
- piekarnik Palson
- piekarnik Eldom
- piekarnik Jocca
- piekarnik Maxxmee
- piekarnik Hoover-Helkama
- piekarnik Juno
- piekarnik Defy
- piekarnik Premium
- piekarnik Blokker
- piekarnik Trebs
- piekarnik Luxor
- piekarnik Nordmende
- piekarnik Rangemaster
- piekarnik Friac
- piekarnik Boretti
- piekarnik Eico
- piekarnik Hansa
- piekarnik Drew & Cole
- piekarnik Kubo
- piekarnik Elba
- piekarnik WLA
- piekarnik SEB
- piekarnik Champion
- piekarnik Everglades
- piekarnik Steel Cucine
- piekarnik Buffalo
- piekarnik Jenn-Air
- piekarnik Limit
- piekarnik Freggia
- piekarnik Listo
- piekarnik Edesa
- piekarnik Ufesa
- piekarnik Milectric
- piekarnik Leonard
- piekarnik Presto
- piekarnik Lofra
- piekarnik Zavor
- piekarnik Laica
- piekarnik New World
- piekarnik Leisure
- piekarnik Kayoba
- piekarnik Bompani
- piekarnik Glem Gas
- piekarnik FriFri
- piekarnik Viva
- piekarnik Nova
- piekarnik M-System
- piekarnik Koblenz
- piekarnik Proctor Silex
- piekarnik Primo
- piekarnik Barbecook
- piekarnik German Pool
- piekarnik Creda
- piekarnik Atlantic
- piekarnik Falcon
- piekarnik Saro
- piekarnik Airforce
- piekarnik Godrej
- piekarnik Konig
- piekarnik Ices
- piekarnik Conrad
- piekarnik Mx Onda
- piekarnik Igenix
- piekarnik Kleenmaid
- piekarnik Essentiel B
- piekarnik RGV
- piekarnik Montiss
- piekarnik Team
- piekarnik Schock
- piekarnik Stoves
- piekarnik Faber
- piekarnik Edy
- piekarnik CaterChef
- piekarnik Kambrook
- piekarnik Parmco
- piekarnik Roadstar
- piekarnik Zephir
- piekarnik Eurotech
- piekarnik Efbe-schott
- piekarnik Cadac
- piekarnik Wolf
- piekarnik Carrefour Home
- piekarnik Equator
- piekarnik Brixton
- piekarnik Vestfrost
- piekarnik Superior
- piekarnik Day
- piekarnik Koenig
- piekarnik Outdoorchef
- piekarnik Smev
- piekarnik Upo
- piekarnik Belion
- piekarnik Nesco
- piekarnik Waves
- piekarnik SIBIR
- piekarnik Coline
- piekarnik White And Brown
- piekarnik Eccotemp
- piekarnik Home Electric
- piekarnik Sauter
- piekarnik Café
- piekarnik ARC
- piekarnik Ellrona
- piekarnik Lynx
- piekarnik Bluesky
- piekarnik Burco
- piekarnik Khind
- piekarnik Tecnolux
- piekarnik Tisira
- piekarnik Micromaxx
- piekarnik Fratelli Onofri
- piekarnik Ronco
- piekarnik Eurochef
- piekarnik Premier
- piekarnik Weasy
- piekarnik Marynen
- piekarnik Opera
- piekarnik Therma
- piekarnik La Germania
- piekarnik Luxell
- piekarnik Krefft
- piekarnik Solitaire
- piekarnik Oranier
- piekarnik Leventi
- piekarnik Orava
- piekarnik Rösle
- piekarnik James
- piekarnik Roadeyes
- piekarnik Jamie Oliver
- piekarnik Globe
- piekarnik Esmaltec
- piekarnik Riviera And Bar
- piekarnik Apelson
- piekarnik Dominox
- piekarnik Thermomate
- piekarnik Melchioni
- piekarnik Fine Dine
- piekarnik Venga
- piekarnik OBU
- piekarnik Rival
- piekarnik Eudora
- piekarnik Thomas
- piekarnik Steelmatic
- piekarnik Supra
- piekarnik Wells
- piekarnik Kucht
- piekarnik Avantco
- piekarnik Kogan
- piekarnik Mibrasa
- piekarnik Vulcan
- piekarnik Lacanche
- piekarnik Emeril Lagasse
- piekarnik Verona
- piekarnik Riviera Bar
- piekarnik Thane
- piekarnik LotusGrill
- piekarnik APW Wyott
- piekarnik Cuckoo
- piekarnik General Electric
- piekarnik MSR
- piekarnik SPT
- piekarnik Pit Boss
- piekarnik Hatco
- piekarnik Elin
- piekarnik High One
- piekarnik Ciarra
- piekarnik WestBend
- piekarnik Companion
- piekarnik XO
- piekarnik NU-VU
- piekarnik Curtiss
- piekarnik Blodgett
- piekarnik Nemco
- piekarnik K&H
- piekarnik Winia
- piekarnik Bakers Pride
- piekarnik Alto-Shaam
- piekarnik TurboChef
- piekarnik Simfer
- piekarnik Firefriend
- piekarnik Merrychef
- piekarnik LAFE
- piekarnik Promis
- piekarnik Inno-Hit
- piekarnik Fisher Paykel
- piekarnik Brock
- piekarnik Arda
- piekarnik Casselin
- piekarnik Girmi
- piekarnik Americana
- piekarnik Petromax
- piekarnik YUNA
- piekarnik Spring USA
- piekarnik Cosmo
- piekarnik Elements
- piekarnik Forge Adour
- piekarnik Chef-Master
- piekarnik UGo
- piekarnik Eltac
- piekarnik Kitchenware
- piekarnik FAURE
- piekarnik Novamatic
- piekarnik VENINI
- piekarnik Buschbeck
- piekarnik Blackstone
- piekarnik BSK
- piekarnik New.Up!
- piekarnik Roller Grill
- piekarnik DPM
- piekarnik Studio
- piekarnik Adora
- piekarnik Sunpentown
- piekarnik Backyard Pro
- piekarnik Brastemp
- piekarnik Royal Catering
- piekarnik BAXTER
- piekarnik Vitrokitchen
- piekarnik Longvie
- piekarnik Gasmate
- piekarnik Arthur Martin-Electrolux
- piekarnik Triomph
- piekarnik PITT
- piekarnik Elektra Bregenz
- piekarnik KB Elements
- piekarnik TZS First Austria
- piekarnik Pyramis
- piekarnik Pando
- piekarnik Wiggo
- piekarnik Nestor Martin-Electrolux
- piekarnik Imarflex
- piekarnik Mayer
- piekarnik Acros
- piekarnik Thermarest
- piekarnik HomeCraft
- piekarnik La Cornue
- piekarnik Master Kitchen
- piekarnik Goldbrunn
- piekarnik Platypus
- piekarnik Yamazen
- piekarnik Masterpro
- piekarnik Fratelli
- piekarnik St George
- piekarnik Helkama
- piekarnik Pitsos
- piekarnik Sheffield
- piekarnik Lacunza
- piekarnik Globe Fire
- piekarnik Radiola
Najnowsze instrukcje dla piekarnik
9 Kwietnia 2025
9 Kwietnia 2025
9 Kwietnia 2025
9 Kwietnia 2025
9 Kwietnia 2025
9 Kwietnia 2025
9 Kwietnia 2025
9 Kwietnia 2025
9 Kwietnia 2025
9 Kwietnia 2025
