Instrukcja obsługi Hotpoint HAFC9 TA44SX H

Hotpoint lodówka HAFC9 TA44SX H

Przeczytaj poniżej 📖 instrukcję obsługi w języku polskim dla Hotpoint HAFC9 TA44SX H (36 stron) w kategorii lodówka. Ta instrukcja była pomocna dla 4 osób i została oceniona przez 2 użytkowników na średnio 4.5 gwiazdek

Pobierz PDF
Strona 1/36
EN
Quick guide
* Available only on certain models
THANK YOU FOR BUYING A
HOTPOINT-ARISTON PRODUCT
In order to receive a more complete assistance, please
register your product on www . hotpoint . eu/ register
Before using the appliance carefully read the Safety
Instruction.
FIRST TIME USE
After installation, wait at least two hours before connecting the
appliance to the power supply. Once connected, it will start working
automatically. The ideal temperature settings are preset from the
factory.
After turning the appliance on, wait 4-6 hours for it to reach the correct
food storage temperature.
CONTROL PANEL
ON/OFF
To switch on/switch o the product press both Freezer operation
button and Super Freeze button by 3 seconds.
FREEZER TEMPERATURE SETTING
To regulate the temperature in the freezer compartment use Freezer
operation button. The temperature of the freezer is consisted with 4
levels as indicated on serigraphy (signaled by led light).
Recommended setting for the freezer is -18°C.
SUPER FREEZE FUNCTION
This function is recommended for freezing fresh food. Fresh food
should be frozen as quickly as possible, for the best possible
preservation and for keeping its nutritional value. Press the Super
Freeze button when you need to freeze fresh food; the Super Freeze
indicator will come on.
We recommend you press the Super Freeze button 24 hours before
putting the food in, in order to prepare the freezer compartment for
the best possible freezing conditions. We recommend you use the
bottom drawer to maximize the freezing capacity.
The Super Freeze function is automatically deactivated after 48 hours,
or you can disable it manually by pressing the Fast Freeze button.
FRIDGE TEMPERATURE SETTING
The temperature of the fridge is consisted with 4 levels as indicated on
serigraphy (signaled by led light). To regulate the temperature of the
refrigerator compartment use Refrigerator operation button.
Recommended setting for the refrigerator compartment is +4°C.
SUPER COOL FUNCTION
You can enable or disable the Super Cool feature (quick cooling of
both fresh and just cooked food) by pressing the Super Cool key on the
display. The Super Cool led turns on when activated. The function is
automatically disabled after 12 hours, or can be manually disabled by
pressing the Super Cool button.
LED LIGHT
This product contains a light source of energy eciency class F.
If the LED light system does not work, please contact the Service to
replace it.
Important: The refrigerator compartment light switches on when
the refrigerator door is opened. If the door is kept open for more than
8 minutes the light will be automatically switched o.
1. Freezer operation button
2. Super freeze button
3. Super freeze indicator light
4. Freezer temperature indicator light
5. Fridge temperature indicator light
6. Super cool indicator light
7. Super cool button
8. Refrigerator operation button
4 53 6
2
1
7 8
HOW TO STORE FRESH FOOD AND BEVERAGES
*
a) b)
* The number and type of door balconies depends on the model
Legend
TEMPERATE ZONE
Suggested for storage of tropical fruit, cans, drinks,
eggs, sauces, pickles, butter, jam
COOL ZONE
Suggested for the storage of cheese, milk, daily
food, delicatessen, yogurt
COOLEST AREA
a) Suggested for storage of cold cuts, desserts, meat
and sh
b) Suggested for storage of sh, meat, cheese, dairy
products, fruits, vegetables.
The drawer available only on certain models
FRUIT & VEGETABLE DRAWER
FREEZER DRAWERS
(One drawer in models lower than 1,7m)
FREEZING ZONE DRAWER
(Max cool zone)
Suggested to freeze fresh / cooked food
REFRIGERATION COMPARTMENT
Refrigerator compartment defrosting is completely automatic.
Droplets of water on the rear wall inside the refrigerator compartment
indicate that the automatic defrost phase is in progress.
The defrost water is automatically run into a drain hole and collected in
a container, where it evaporates.
Multi-fresh Zone (drawer)*
You can customize the temperature in the Multi-fresh Zone (b) to
preserve the type of food you place inside as best possible.
Turn the knob on the drawer to set the food type:
• Fish and meat*
• Cheese and dairy products
• Fruit and vegetables
Note: we recommend you do not put sh and meat inside the drawer at
the same time unless they are properly packed, to avoid cross
contamination.
Humidity Control*
Turn the knob to the left if you are storing vegetables (for which a
more humid environment is recommended), rotate the knob to the
right if you are storing fruit (for which a less humid environment
is recommended), turn the knob to the middle if you are storing a
mixture of fruit and vegetables.
Foldable shelf*
This shelf can be used in three dierent ways:
1. Full-depth, to use the entire surface.
2. Half-depth, to use the rear part and at the same time create space
for taller items (like bottles and jugs) on the shelf below. To adjust
the shelf to half-depth, slightly raise the front part then pull it in.
3. Flipped up if you need to make space for tall or bulky items on
the shelf below. To ip the shelf up, rst adjust it to the halfway
position from half-depth. Flip the shelf down to go back to using it
in half-depth and full-depth.
* Available only on certain models
FREEZER COMPARTMENT
Total No Frost freezers provide chilled air circulation around the
storage areas, and prevent the formation of ice, thereby completely
eliminating the need for defrosting.
Frozen items don’t stick to the walls, labeling stays legible and storage
space remains neat and clear.
The freezer compartment allows for the storage of frozen food and the
freezing of fresh food. The quantity of fresh food that can be frozen
in a specic time period is indicated on the rating plate. Arrange the
fresh food in the freezing area inside the freezer compartment, leaving
enough space around it to allow air to circulate freely. Avoid allowing
fresh food to come into direct contact with frozen food. Load limits are
determined by baskets, aps, drawers, shelves etc..
Make sure that these components can still close easily after loading.
The freezing zone's drawer/compartment is shown in the picture
above. To optimize freezing speed and get more storage space, the
freezer compartment can be used without the freezer drawers and
the food can be placed directly on the bottom of the compartment.
To avoid food waste, please refer to the recommended setting and
storage found in the online user manual.
Ice cubes
Fill 2/3 of the ice tray with water and place it back in the freezer
compartment. Do not use sharp or pointed objects to remove the ice.
ACCESSORIES*
EGG TRAY ICE TRAY BOTTLE RACK FOLDABLE SHELF
GENERAL INFORMATION
The drawers, baskets, and shelves should be kept in their current
position unless otherwise specied in this quick guide.
The light system inside the refrigerator compartment uses LED lights,
which provide better lighting and use less energy than traditional
bulbs.
Doors and lids of the refrigerator should be removed before disposal,
to avoid children or animals getting trapped inside.
TROUBLESHOOTING
What to do if... Possible reasons Solutions
The appliance is not
working.
There may be an appliance power supply
problem.
• Check if power cable plugged into a live socket with the proper
voltage.
• Check if the protection devices and fuses of the electrical system in
your home
There is water in the defrost
pan.
This is normal in hot, damp weather. The
pan can even be half full.
• Make sure the appliance is level so that the water does not
overow.
The edges of the appliance
cabinet, which come in
contact with the door seal,
are warm to the touch.
This is not a defect. This is normal in hot
weather and when the compressor is
running.
The light does not work. The light may need replacing.
The appliance may be in On/ Stand-by
model.
• Make sure if the protection devices and fuses of the electrical
system in your home work well.
• Check if the power cable is plugged into a live socket with the
proper voltage
• In case the LEDs are broken the user must call the Service for
exchange of the same type available only at our Aftersales Service
Centers or authorized dealers.
The motor seems to run too
much.
Motor running time depends on dierent
things: number of door openings,
amount of food stored, temperature of
the room, setting of the temperature
controls.
• Make sure that the appliance controls are correctly set.
• Check if there is not a large amount of food been added to the
appliance.
• Check that the door is not opened too often.
• Check that the door close properly.
* Available only on certain models
