ENGLISH 1
INTRODUCTION
Thank you for purchasing a Honda lawnmower!
This manual covers the operation and maintenance of the Honda
HRS536C5 VKEA lawnmower.
We want to help you get the best results from your new lawnmower
and to operate it safely. This manual contains the information on how
to do that; please read it carefully.
This manual should be considered a permanent part of the
lawnmower and should remain with it if it is resold.
If you have a problem or questions concerning the lawnmower,
contact your supplying dealer.
We recommend that you read the warranty policy to fully understand
its coverage and your responsibilities of ownership.
Honda Power Equipment Mfg., Inc. reserves the right to make
changes at any time without notice and without incurring any
obligation.
No part of this publication may be reproduced without written
permission.
SAFETY MESSAGES
Pay special attention to statements preceded by the following words:
Each message tells you what the hazard is, what can happen, and
what you can do to avoid or reduce injury.
DAMAGE PREVENTION MESSAGES
You will also see other important messages that are preceded by the
following word:
The purpose of these messages is to help prevent damage to your
lawnmower, other property, or the environment.
CONTENTS
DANGER You WILL be KILLED or SERIOUSLY
HURT if you don’t follow instructions.
WARNING You CAN be KILLED or SERIOUSLY
HURT if you don't follow instructions.
CAUTION You CAN be HURT if you don't follow
instructions.
NOTICE
Your lawnmower, other property, or the
environment can be damaged if you don’t
follow instructions.
INTRODUCTION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
SAFETY MESSAGES . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
SAFETY INSTRUCTIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
COMPONENT IDENTIFICATION . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
SET-UP . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
CONTROLS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
PRE-OPERATION CHECKS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
OPERATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
MAINTENANCE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
TRANSPORTING. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
STORAGE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
TROUBLESHOOTING . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
SPECIFICATIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Honda Warranty Conditions,
“EC Declaration of Conformity” CONTENT OUTLINE,
Major Honda Distributor Locations . . . . . . . . . . . . . . . . . . . .Last pages
OWNER’S MANUAL
(Original instructions)
HRS536C5VKEA
PEDESTRIAN CONTROLLED
LAWNMOWER
© 2017 American Honda Motor Co., Inc.—All Rights Reserved
ENGLISHFRANÇAISESPAÑOL
C5
ITALIANONEDERLANDS DEUTSCH
00X39VG3 6561
HPE.2017.09
PRINTED IN U.S.A.
2ENGLISH
SAFETY INSTRUCTIONS
To ensure safe operation –
• Read instructions carefully, become familiar with controls and
proper use of equipment.
• Never allow children or people unfamiliar with these
instructions to use the lawnmower. Local regulations may
restrict the age of the operator.
• Never mow when:
– People, especially children, or pets are nearby.
– There is a risk of adverse weather such as lightning or a
storm.
• Keep in mind that the operator or user is responsible for
injuries, property damage, or hazards occurring to other
people or their property.
• While mowing, always wear substantial footwear and long
trousers. Do not operate the equipment when barefoot or
wearing open sandals.
• Thoroughly inspect the area where the equipment is to be
used, and remove all objects which may be thrown by the
machine.
• WARNING - Petrol is highly flammable:
– Store fuel in containers specifically designed for this
purpose.
– Refuel outdoors only and do not smoke while refueling.
– Add fuel before starting the engine. Never remove the cap of
the fuel tank or add petrol while the engine is running or
when the engine is hot.
– If petrol is spilled, do not attempt to start the engine, but
move the machine away from the area of spillage, and avoid
creating any source of ignition until the petrol vapors have
dissipated.
– Install fuel caps securely.
• Replace faulty mufflers.
• Before using, always visually inspect to see that the cutting
means, cutting means bolts, and cutting-means enclosure are
not worn or damaged. Replace a worn or damaged cutting
means and cutting-means bolts in sets to preserve balance.
• Check grass catchers frequently for wear or deterioration.
• Do not operate the engine in a confined space where
dangerous carbon monoxide fumes can collect.
• Mow only in daylight or good artificial light.
• Avoid operating the equipment in wet grass, where feasible.
• Mowing stability:
– Always be sure of your footing on slopes.
– Mow across slopes, never up and down.
– Walk, never run.
– Exercise extreme caution when changing direction on
slopes.
– Do not mow excessively steep slopes.
• Use extreme caution when pulling the lawnmower toward you.
• Stop the cutting means if the lawnmower has to be tilted for
transporting, when crossing surfaces other than grass, and
when transporting the lawnmower to and from the area to be
mowed.
• Never operate the lawnmower with defective guards or
shields, or without safety devices (for example, discharge
guards and/or grass catchers in place).
• Do not attempt to make wheel height adjustments while the
machine is running.
• Do not change the engine governor setting or over-speed the
engine.
• Disengage the Smart Drive control before starting the
machine.
• Start the engine carefully according to the instructions and
with feet well away from the cutting means.
• Do not start the engine when standing in front of the discharge
chute.
• Do not tilt the lawnmower when starting the engine.
• Do not put hands or feet near or under rotating parts. Keep
clear of the discharge opening at all times.
• Never pick up or carry a lawnmower while the engine is
running.
• Stop the engine and disconnect the spark plug wire:
– Before clearing a blockage or unclogging the lawnmower.
– Before checking, cleaning, or working on the lawnmower.
– After striking a foreign object. Inspect the lawnmower for
damage and make repairs before restarting and operating
the lawnmower.
– If lawnmower starts to vibrate abnormally, stop the engine
immediately.
• Stop the engine:
– Whenever you leave the lawnmower.
– Before refueling the lawnmower.
– Before removing the side discharge guard.
• Turn the fuel valve off at the conclusion of mowing.
• Keep all nuts, bolts, and screws tight to be sure the equipment
is in safe working condition.
• Never store the equipment with petrol in the tank inside a
building where fumes may reach an open flame or spark.
• Allow the engine to cool before storing in any enclosure.
• To reduce the fire hazard, keep the petrol storage area, engine,
muffler, and battery compartment (if applicable) free of grass,
leaves, or excessive grease.
• Replace worn or damaged parts for safety.
• If the fuel tank has to be drained, this should be done
outdoors.
• Wear eye protection.
WARNING
• Honda lawnmowers are designed
to give safe and dependable service if
operated according to instructions.
Read and understand the Owner’s
Manual before operating the mower.
Failure to do so could result in
personal injury or equipment damage.
Disposal
To protect the environment, do not dispose of this product,
battery, engine oil, etc. carelessly by leaving them in the
waste. Observe the local laws and regulations or consult
your authorized Honda dealer for disposal.
ENGLISH 3
SAFETY LABEL LOCATION
The labels shown here contain important safety information. Carefully
read their meaning. These labels are considered permanent parts of
your Honda mower. If a label comes off or becomes hard to read,
contact your Honda dealer for a replacement.
PRODUCT IDENTIFICATION PLATE
COMPONENT IDENTIFICATION
Record the frame and engine serial numbers in the space below. You
will need these numbers when ordering parts and when making
technical or warranty inquires.
Frame serial number:___________________________
Engine serial number:___________________________
Date of purchase:______/______/______
Letter Meaning
A
1. Read the owner’s manual before using the mower.
2. Risk of projections: Keep third persons away from the area
during use.
3. Risk of cuts. Rotating cutting means: Do not put hands or feet
inside the cutting-means enclosure. Disconnect the spark plug
cap before performing any operation of maintenance or repairs.
4. Do not operate without either discharge guard or grass
catcher in place.
B
5. Read the owner’s manual before using the mower.
6. The engine emits toxic carbon monoxide. Do not run in an
enclosed area.
7. Petrol is highly flammable. Stop the engine before refueling.
C
8. Risk of projections: Keep third persons away from the area
during use.
9. Do not operate without either discharge guard or grass
catcher in place.
Letter Meaning
D
1. Sound power level
guaranteed according to
directive 2000/14/EC
2. Conformity mark according to
EC directive
3. Conformity mark optional
4. Nominal power in kilowatts
5. Maximum operating engine
speed
6. Year of manufacture
7. Weight in kilograms
8. Serial number
9. Model
10.Name and address of
authorized representative
11.Name and address of
Manufacturer
Name and address of manufacturer and authorized representative are
written in the “EC Declaration of Conformity” CONTENT OUTLINE in this
Owner’s Manual.
1
23
4
567
8 9
7
8
9
10
6
11
1
Smart Drive control
(Transmission control which
drives the rear wheels)
8 Engine serial number
2 Handlebar 9 Recoil starter grip
3Cutting-means control (Starts and
stops the cutting means)10 Handlebar adjust knob (2)
4Cutting height adjustment
levers (4)
11 Fuel tank cap
12 Fuel valve
5 Muffler 13 Air cleaner
6 Discharge guard 14 Carburetor
7 Oil filler cap 15 Spark plug cap
[2]
D [LABEL]
[4] (2)
[5]
[7]
[4]
[10] (2)
[9]
[13]
B [LABEL]
[15]
[14]
[6]
[1]
[12]
[3]
[11]
A [LABEL]
C [LABEL]
[8]

Specyfikacje produktu

Marka: Honda
Kategoria: kosiarka
Model: HRS 536 C5 VK

Potrzebujesz pomocy?

Jeśli potrzebujesz pomocy z Honda HRS 536 C5 VK, zadaj pytanie poniżej, a inni użytkownicy Ci odpowiedzą


Instrukcje kosiarka Honda

Honda

Honda HRS 536 C5 VK Instrukcja

2 Października 2024
Honda

Honda HRG466C1 Instrukcja

2 Października 2024
Honda

Honda IZY HRG 466C1 PKEH Instrukcja

2 Października 2024
Honda

Honda IZY HRG-416SK Instrukcja

2 Października 2024
Honda

Honda IZY HRG 466C1 Instrukcja

2 Października 2024
Honda

Honda IZY HRG-416PK Instrukcja

2 Października 2024
Honda

Honda UM2460 Instrukcja

14 Września 2024
Honda

Honda Buffalo Buck HRU19R1 Instrukcja

13 Września 2024
Honda

Honda HRX217HXA Instrukcja

12 Września 2024
Honda

Honda izy Instrukcja

8 Września 2024

Instrukcje kosiarka

Najnowsze instrukcje dla kosiarka

Hecht

Hecht 5564 SX Instrukcja

15 Października 2024
Craftsman

Craftsman 25365 Instrukcja

15 Października 2024
AL-KO

AL-KO Solo 4758 VSI Instrukcja

15 Października 2024
AL-KO

AL-KO Classic 4.64 SP-S Instrukcja

15 Października 2024
Gardena

Gardena PowerMax 36 A Li Instrukcja

15 Października 2024
Einhell

Einhell BG-PM 46 Instrukcja

14 Października 2024
Stihl

Stihl RMA 235 Instrukcja

13 Października 2024
Einhell

Einhell GC-PM 46 S Instrukcja

11 Października 2024
BaByliss

BaByliss Pro FX660E Instrukcja

11 Października 2024
Conair

Conair HC108RGB Instrukcja

9 Października 2024
