Instruction Manual • Bedienungsanleitung • Manuel d’utilisation • Manuale di Istruzioni
®
StratocamTM
Stratocam
®
EN
All instructions, warranties and other collateral documents are subject to change at the sole discretion of Horizon Hobby, LLC. For up-to-date product litera-
ture, visit www.horizonhobby.com and click on the support tab for this product.
NOTICE
The following terms are used throughout the product literature to indicate various levels of potential harm when operating this product:
NOTICE: Procedures, which if not properly followed, create a possibility of physical property damage AND little or no possibility of injury.
CAUTION: Procedures, which if not properly followed, create the probability of physical property damage AND a possibility of serious injury.
WARNING: Procedures, which if not properly followed, create the probability of property damage, collateral damage, and serious injury OR create a high
probability of superficial injury.
Meaning of Special Language:
Read the ENTIRE instruction manual to become familiar with the features of the product before operating. Failure to operate the product WARNING:
correctly can result in damage to the product, personal property and cause serious injury.
This is a sophisticated hobby product. It must be operated with caution and common sense and requires some basic mechanical ability. Failure to operate
this Product in a safe and responsible manner could result in injury or damage to the product or other property. This product is not intended for use by
children without direct adult supervision. Do not use with incompatible components or alter this product in any way outside of the instructions provided
by Horizon Hobby, LLC. This manual contains instructions for safety, operation and maintenance. It is essential to read and follow all the instructions and
warnings in the manual, prior to assembly, setup or use, in order to operate correctly and avoid damage or serious injury.
Safety Precautions and Warnings
As the user of this product, you are solely responsible for operating in a manner
that does not endanger yourself and others or result in damage to the product
or the property of others.
• Always keep a safe distance in all directions around your model to avoid
collisions or injury. This model is controlled by a radio signal subject to
interference from many sources outside your control. Interference can cause
momentary loss of control.
• Alwaysoperateyourmodelinopenspacesawayfromfull-sizevehicles,traf-
fic and people.
• Alwayscarefullyfollowthedirectionsandwarningsforthisandanyoptional
support equipment (chargers, rechargeable battery packs, etc.).
• Alwayskeepallchemicals,smallpartsandanythingelectricaloutofthe
reach of children.
• Alwaysavoidwaterexposuretoallequipmentnotspecicallydesignedand
protected for this purpose. Moisture causes damage to electronics.
• Neverplaceanyportionofthemodelinyourmouthasitcouldcauseserious
injury or even death.
• Neveroperateyourmodelwithlowtransmitterbatteries.
•Alwayskeepaircraftinsightandundercontrol.
•Alwaysusefullychargedbatteries.
•Alwayskeeptransmitterpoweredonwhileaircraftispowered.
•Alwaysremovebatteriesbeforedisassembly.
•Alwayskeepmovingpartsclean.
•Alwayskeeppartsdry.
•Alwaysletpartscoolafterusebeforetouching.
•Alwaysremovebatteriesafteruse.
•Alwaysensurefailsafeisproperlysetbeforeying.
•Neveroperateaircraftwithdamagedwiring.
•Nevertouchmovingparts.
Charging Warnings
CAUTION:Allinstructionsandwarningsmustbefollowedexactly.
Mishandling of Li-Po batteries can result in a fire, personal injury,
and/or property damage.
• Never leave charging batteries unattended.
• Never charge batteries overnight.
• By handling, charging or using the included Li-Po battery, you assume all
risks associated with lithium batteries.
• If at any time the battery begins to balloon or swell, discontinue use im-
mediately. If charging or discharging, discontinue and disconnect. Continuing
to use, charge or discharge a battery that is ballooning or swelling can result
in fire.
• Always store the battery at room temperature in a dry area for best results.
• Always transport or temporarily store the battery in a temperature range of
40–120º F (5–49º C). Do not store battery or aircraft in a car or direct sun-
light. If stored in a hot car, the battery can be damaged or even catch fire.
• Alwayschargebatteriesawayfromammablematerials.
• Always inspect the battery before charging and never charge dead or dam-
aged batteries.
• Always disconnect the battery after charging, and let the charger cool
between charges.
• Always constantly monitor the temperature of the battery pack while
charging.
• ONLY USE A CHARGER SPECIFICALLY DESIGNED TO CHARGE LI-PO BATTER-
IES. Failure to charge the battery with a compatible charger may cause fire
resulting in personal injury and/or property damage.
• Never discharge Li-Po cells to below 3V under load.
• Never cover warning labels with hook and loop strips.
• Never charge batteries outside recommended levels.
• Never attempt to dismantle or alter the charger.
• Never allow minors under the age of 14 to charge battery packs.
• Neverchargebatteriesinextremelyhotorcoldplaces(recommended
between 40–120° F or 5–49° C) or place in direct sunlight.
14+AGE RECOMMENDATION:
Not for children under 14
years. This is not a toy.
2
RTF
For more information and to register your product online, visit www.hobbyzonerc.com
Specifications and Features
Preflight Checklist
1. Find a safe and open area.
2. Chargeight&camera
battery
3. Installightbatteryin
aircraft.
4. Perform Control Direction
Test.
5. Planightforyingeld
conditions.
6. Have fun!
Included in the Box
Includes
Transmitter
Motor: (2) 180 brushed
Battery: 2S 1300mAh Li-Po
Battery Charger: 1.5A 2-cell Li-Po Battery
charger
Power Supply: 2.0A AC Power Supply
Transmitter:
2.4GHz Transmitter
Camera: Wide angle lens with integrated
battery&8GBClass10SDcard(Included).
• SAFE® technology (Sensor Assisted Flight Envelope)
isdesignedasightassistance,notanautopilot.
Thepilotisalwaysincontrolandrequiredtoythe
aircraft at all times.
• Landing skids, designed to protect propellers during
landing.
• Break-away wing, designed to snap free from
fuselage during a crash to minimize damage.
17.5 oz (496 g)
41.3 inch (1050 mm)
30.5 inch (775mm)
Table of Contents
Charging the Flight Battery 4 ....................................
Transmitter 4 ............................................................
Camera 5 ..................................................................
SAFE® Technology Flight Modes 7 .............................
Tail Installation 8 .......................................................
Wing Installation 9 ....................................................
Flight Battery Installation 10 .....................................
Arming the Electronic Speed Control (ESC) 10 ...........
Control Direction Test ...........................................11
Choose a Flying Field 12 ...........................................
Range Test ...........................................................12
Flight Control 13 .......................................................
Trimming 13 .............................................................
Flying Tips ...........................................................14
Landing Gear Installation 16 .....................................
Runway Takeoff ...................................................16
Contol Horn Settings 16 ............................................
Binding 17 ...............................................................
Motor Service 17 ......................................................
Trouble Shooting Guide 18 ........................................
AMA National Model aircraft Safety Code 19 .............
Limited Warranty .................................................20
Contact Information 21 .............................................
FCC Information 21 ...................................................
IC Information 21 ......................................................
EU Compliance Statement 21 ....................................
Replacement Parts 79 ...............................................
Stratocam EN
