Hegel H80
High End Integrated Amplifier
User manual
USER GUIDE
Congratulations on your new HEGEL H80!
All Hegel products are based on a simple philosophy:
The audio reproduction instrument shall reproduce the original musical sound, purely and naturally.
It shall use Scandinavian design reflecting natural music reproduction and styling to fit in with any interior.
The products shall be easy to operate and shall be manufactured according to the best quality principles.
All HEGEL products are designed with acoustical instruments in a concert situation as the point of refer-
ence. The music is reproduced exactly like the original and is limited only by the quality of the recording.
Our aim is to give you the best possible music experience!
SOUND ADVICE
The Hegel H80 Integrated Amplifier is easy to connect and operate and requires no prior technical
knowledge. However, to get the most out of the amplifier’s superior sound and music quality, we have
provided a brief description of the connections and use of the amplifier in order to provide a total music
experience.
We recommend keeping this user guide for future reference.
USE & PLACEMENT
The HEGEL H80 should be placed on a hard, flat surface to ensure proper cooling. Air circulation is required
above and below the amplifier, so be certain there is space above and below it. The amplifier performs
best after being powered on for 1 hour, to warm up the electronics. The amplifier must never be placed
on a carpet or similar surface that obstructs air circulation through the unit. The amplifier should never be
covered while in use or placed on a narrow shelf or in a confined space.
The amplifier automatically switches itself off if overheated.
The amplifier needs some break-in time before maximum sound quality can be experienced.
Never lift the H80 by holding the volume knob or source knob. The H80 is heavy, and applying pressure
may damage the knobs.
GENERAL USE
On/Off
The H80 amplifier is switched on and off with the power button, located on the bottom of the amplifier, on
the left side, close to the front panel. When powered up, the H80 takes a few seconds to calibrate. During
this time, the outputs are muted.
NOTE: When powered up the outputs are muted and the right hand part of the display flashes for a few
seconds, indicating mute. This is normal, and is part of the start-up procedure.
NOTE: When the H80 has been switched off, wait 30 seconds before powering on again.
Display
The left side of the display shows the selected source input, while the volume value is shown on the right
side of the display. A flashing volume value indicates the amplifier is in mute mode.
Source Selector
The input source selector knob is on the left side of the front panel. The three letters indicate the selected
source input.
Volume
The volume control knob is on the right side of the front panel. The volume level is indicated by a number
between 0 and 99 in the right side of the display. The H80 powers up with a preset volume value. The
volume level is adjusted by turning the volume knob clockwise or counter clockwise, or by using the Hegel
remote control.
Mute
Pressing the mute button on the Hegel remote control mutes the speaker outputs and the Pre Out output.
The volume number flashes to indicate that mute is on. Press the mute button again to switch mute off.
Display On/Off
The DISP button on the Hegel remote control turns the display of the H80 on or off.
To turn the display off, hold the DISP button for more than 1 second. To turn the display on, hold the DISP
button for less than one second.
(Optional features)
Extra fetaures become available if using the HEGEL RC8 master remote control (optional). These include
setting of start-up volume, max volume, factory reset, etc.
