Strona 1/24
I&W #07.05.209.00
Do not operate this equipment unless
you have read and understood the
contents of this manual! Failure to follow
the instructions contained in this manual
may result in serious injury or death.
This manual contains important safety
information concerning the
maintenance, use, and operation of this
product. If you’re unable to understand
the contents of this manual, please bring
it to the attention of your supervisor.
Keep this manual in a safe location for
future reference.
ULTRA-GLO®
Ceramic Infrared Strip Heaters
UGA, UGAL, UGAH, and UGAHL Series
Installation and Operating Manual
© 2008 Hatco Corporation
No opere este equipo al menos que haya
leído y comprendido el contenido de este
manual! Cualquier falla en el
seguimiento de las instrucciones
contenidas en este manual puede
resultar en un serio lesión o muerte. Este
manual contiene importante información
sobre seguridad concerniente al
mantenimiento, uso y operación de este
producto. Si usted no puede entender el
contenido de este manual por favor
pregunte a su supervisor. Almacenar
este manual en una localización segura
para la referencia futura.
CONTENTS
Form No. UGAM-0908
i
INTRODUCTION
Hatco Ultra-Glo®Ceramic Strip Heaters ensure
maximum food holding and minimize the risk of food-
borne illness. Optimum safety and quality is the result of
food held at the proper serving temperatures using Ultra
Glo’s pre-focused heat patterns. The pre-focused heat
pattern prevents foods from being over-cooked in the
middle and cooling off around the edges by
concentrating higher temperatures to the outer edges of
holding surfaces where heat loss is the greatest. Utilizing
specially designed reflectors to direct the heat from the
element, Ultra-Glo Ceramic Strip Heaters safely maintain
peak serving temperatures longer without cooking the
food beyond the point of excellence. The ceramic
element heat output allows the units to be mounted at
increased heights for improved working clearances.
Ultra-Glo Ceramic Strip Heaters are available from the
factory with or without shatter-resistant display lights to
illuminate the warming area. These bulbs have a special
coating that guards against injury and food
contamination in the event of breakage.
Ultra-Glo Ceramic Strip Heaters are a product of
extensive research and field testing. The materials used
were selected for maximum durability, attractive
appearance, and optimum performance. Every unit is
inspected and tested thoroughly prior to shipment.
This manual provides the installation, safety, and
operating instructions for Ultra-Glo Ceramic Strip
Heaters. Hatco recommends all installation, operating,
and safety instructions appearing in this manual be read
prior to installation or operation of the strip heaters.
Safety information that appears in this manual is
identified by the following signal word panels:
WARNING indicates a hazardous situation which,
if not avoided, could result in death or serious
injury.
CAUTION indicates a hazardous situation which,
if not avoided, could result in minor or moderate
injury.
NOTICE is used to address practices not related
to personal injury.
NOTICE
CAUTION
WARNING
Important Owner Information...............................i
Introduction ...........................................................i
Important Safety Information ..............................1
Model Designation ...............................................2
Model Descriptions..............................................2
Specifications.......................................................3
Electrical Rating Charts...................................3
Dimensions ....................................................11
Installation ..........................................................12
General ..........................................................12
Minimum Clearance Requirements ...............13
Recommended Mounting Heights .................13
Assembly.......................................................14
Undershelf Mounting .....................................14
Permanent Surface Mount.............................15
Overhead Mounting .......................................16
Electrical Wiring Hook-Up..............................16
Operation ............................................................17
Maintenance .......................................................18
General ..........................................................18
Replacing Display Light Bulbs.......................18
Troubleshooting Guide......................................19
Options................................................................20
Hatco Limited Warranty.....................................21
Authorized Parts Distributors ...........Back Cover
IMPORTANT OWNER INFORMATION
Record the model number, serial number
(identification decal located on the underside of the
unit), voltage, and purchase date of your strip heater
in the spaces below. Please have this information
available when calling Hatco for service assistance.
Model No. ________________________________
Serial No. ________________________________
Voltage __________________________________
Date of Purchase __________________________
Business 8:00 a.m. to 5:00 p.m.
Hours: Central Standard Time
(Summer Hours: June to September –
8:00 a.m. to 5:00 p.m. C.S.T.
Monday through Thursday
8:00 a.m. to 2:30 p.m. C.S.T. Friday)
Telephone: (800) 558-0607; (414) 671-6350
Fax: (800) 690-2966 (Parts and Service)
(414) 671-3976 (International)
24 Hour 7 Day Parts and Service
Assistance available in the
United States and Canada
by calling (800) 558-0607.
Additional information can be found by visiting our web
site at www.hatcocorp.com.
IMPORTANT SAFETY INFORMATION
Form No. UGAM-0908 1
ELECTRIC SHOCK HAZARD:
• For hard-wired units, all electrical
connections must be in accordance with
local electrical codes and any other
applicable codes. Connections should be
made by a qualified, licensed electrician.
• Turn the power OFF at the fused disconnect
switch/circuit breaker and allow the unit to
cool before performing any maintenance or
cleaning.
• DO NOT submerge or saturate with water.
Unit is not waterproof. Do not operate if unit
has been submerged or saturated with water.
• This unit is not “jet-proof” construction. Do
not use jet-clean spray to clean this unit.
• Use only Genuine Hatco Replacement Parts
when service is required. Failure to use
Genuine Hatco Replacement Parts will void
all warranties and may subject operators of
the equipment to hazardous electrical
voltage, resulting in electrical shock or burn.
Genuine Hatco Replacement Parts are
specified to operate safely in the
environments in which they are used. Some
aftermarket or generic replacement parts do
not have the characteristics that will allow
them to operate safely in Hatco equipment.
FIRE HAZARD:
• Do not install Ultra-Glo ceramic strip heaters
above or around combustible surfaces.
Discoloration or combustion could occur.
Ultra-Glo ceramic strip heaters must be
installed in non-combustible surroundings
only.
• Do not store or use gasoline or other
flammable vapors or liquids in the vicinity of
this or any other appliance.
Use only light bulbs that meet or exceed
National Sanitation Foundation (NSF) standards
and are specifically designed for food holding
areas. Breakage of light bulbs not specially
coated could result in personal injury and/or
food contamination.
This unit has no “user-serviceable” parts. If
service is required on this unit, contact an
Authorized Hatco Service Agent or contact the
Hatco Service Department at 800-558-0607 or
414-671-6350; fax 800-690-2966; or International
fax 414-671-3976.
WARNING
BURN HAZARD: Some exterior surfaces on the
unit will get hot. Use caution when touching
these areas.
Standard and approved manufacturing oils may
smoke up to 30 minutes during initial startup.
This is a temporary condition. Operate unit
without food product until smoke dissipates.
To ensure safe and proper operation, refer to the
“Minimum Clearance Requirements” listed in
the INSTALLATION section of this manual.
Installation of two or more separate units with
less than 3″ (76 mm) between housings may
result in premature failure of component parts.
Failure to provide proper spacing may result in
heat damage to electrical components.
To prevent unit failure, do not add a decorative
soffit to hide a pass-through mounted strip
heater.
To prevent premature failure of components due
to excessive heat, remote control enclosures
must be installed outside the strip heater heat
zone.
Heat damage to countertop material such as
Corian®and similar products (other than
stainless steel) is not covered under the Hatco
warranty. Contact the manufacturer of the base
material for temperature limits and application
information before installing the unit.
Use non-abrasive cleaners only. Abrasive
cleaners could scratch the finish of the unit,
marring its appearance and making it
susceptible to dirt accumulation.
CAUTION
NOTICE
Read the following important safety information before using this equipment to avoid
serious injury or death and to avoid damage to equipment or property.
