GLO-RAY®
Pizza Warmer
GRPWS Series
Installation and Operating Manual
P/N 07.04.315.00
© 2012 Hatco Corporation
Register Online!
(see page 2)
www.hatcocorp.com
Do not operate this equipment unless you
have read and understood the contents of
this manual! Failure to follow the
instructions contained in this manual may
result in serious injury or death. This
manual contains important safety
information concerning the maintenance,
use, and operation of this product. If
you’re unable to understand the contents
of this manual, please bring it to the
attention of your supervisor. Keep this
manual in a safe location for future
reference.
No opere este equipo al menos que haya
leído y comprendido el contenido de este
manual! Cualquier falla en el seguimiento
de las instrucciones contenidas en este
manual puede resultar en un serio lesión
o muerte. Este manual contiene
importante información sobre seguridad
concerniente al mantenimiento, uso y
operación de este producto. Si usted no
puede entender el contenido de este
manual por favor pregunte a su
supervisor. Almacenar este manual en
una localización segura para la referencia
futura.
Ne pas utiliser cet équipement sans avoir
lu et compris le contenu de ce manuel !
Le non-respect des instructions
contenues dans ce manuel peut entraîner
de graves blessures ou la mort. Ce
manuel contient des informations
importantes concernant l'entretien,
l'utilisation et le fonctionnement de ce
produit. Si vous ne comprenez pas le
contenu de ce manuel, veuillez le signaler
à votre supérieur. Conservez ce manuel
dans un endroit sûr pour pouvoir vous y
référer plus tard.
WARNING
ADVERTENCIA
AVERTISSEMENT
2
CONTENTS
Form No. GRPWSM-1012
Safety information that appears in this manual is identified by
the following signal word panels:
WARNING indicates a hazardous situation which, if not
avoided, could result in death or serious injury.
CAUTION indicates a hazardous situation which, if not
avoided, could result in minor or moderate injury.
NOTICE is used to address practices not related to personal
injury.
CAUTION
WARNING
NOTICE
INTRODUCTION
Hatco Glo-Ray®Pizza Warmers are perfect for holding boxed or
bagged pizza and other wrapped food product on a buffet line
or at temporary serving areas. These warmers hold hot
wrapped food product and keep it at optimum serving
temperatures without affecting quality. The thermostatically-
controlled heated base in each heat zone extends the holding
times of most wrapped food product. These units also feature
incandescent lights along with a cord and plug set.
Hatco Glo-Ray Pizza Warmers are products of extensive
research and field testing. The materials used were selected
for maximum durability, attractive appearance, and optimum
performance. Every unit is inspected and tested thoroughly prior
to shipment.
This manual provides the installation, safety, and operating
instructions for Glo-Ray Pizza Warmers. Hatco recommends all
installation, operating, and safety instructions appearing in this
manual be read prior to installation or operation of the warmer.
Important Owner Information ..............................................2
Introduction...........................................................................2
Important Safety Information...............................................3
Model Description.................................................................4
Model Designation................................................................4
Specifications........................................................................5
Plug Configurations.............................................................5
Electrical Rating Chart — GRPWS-XXXX Models ............5
Electrical Rating Chart — GRPWS-XXXXD Models..........5
Electrical Rating Chart — GRPWS-XXXXT Models ..........6
Electrical Rating Chart — GRPWS-XXXXQ Models .........6
Dimensions — Box Stop with Sign Holder..........................6
Dimensions — GRPWS-XXXX and
GRWPS-XXXXD Models ..................................................7
Dimensions — GRPWS-XXXXT Models ............................8
Dimensions — GRPWS-XXXXQ Models............................9
Installation ...........................................................................10
General .............................................................................10
Operation .............................................................................11
General..............................................................................11
Maintenance ........................................................................12
General .............................................................................12
Daily Cleaning ...................................................................12
Replacing Display Light Bulbs ..........................................12
Troubleshooting Guide ......................................................13
Options and Accessories...................................................14
Limited Warranty.................................................................15
Authorized Parts Distributors............................Back Cover
IMPORTANT OWNER INFORMATION
Record the model number, serial number (specification label
located on the back of the unit), voltage, and purchase date of
the unit in the spaces below. Please have this information
available when calling Hatco for service assistance.
Model No. ____________________________________
Serial No. ____________________________________
Voltage ______________________________________
Date of Purchase ______________________________
Register your unit!
Completing online warranty registration will prevent delay in
obtaining warranty coverage. Access the Hatco website at
www.hatcocorp.com, select the Parts & Service pull-down
menu, and click on “Warranty Registration”.
Business
Hours: 8:00 AM PMto 5:00 CST
(Summer Hours: June to September —
8:00 AM to 5:00 CDT Monday through ThursdayPM
8:00 AM to 2:30 CDT Friday)PM
Telephone: (800) 558-0607; (414) 671-6350
E-mail: partsandservice@hatcocorp.com
Fax: (800) 690-2966 (Parts and Service)
(414) 671-3976 (International)
Additional information can be found by visiting our web site at
www.hatcocorp.com.
24 Hour 7 Day Parts and Service
Assistance available in the United States
and Canada by calling (800) 558-0607.
IMPORTANT SAFETY INFORMATION
Form No. GRPWSM-1012 3
Make sure food product has been heated to the proper
food-safe temperature before placing in unit. Failure to
heat food product properly may result in serious health
risks. This unit is for holding pre-heated food product only.
Hatco Corporation is not responsible for actual food
product serving temperature. It is the responsibility of the
user to ensure that food product is held and served at a
safe temperature.
Do not place food product directly onto hardcoat surface.
Food product must be wrapped, boxed, or on a food pan.
Make sure all operators have been instructed on the safe
and proper use of the unit.
This unit is not intended for use by children or persons
with reduced physical, sensory, or mental capabilities.
Ensure proper supervision of children and keep them away
from the unit.
This unit has no “user-serviceable” parts. If service is
required on this unit, contact an Authorized Hatco Service
Agent or contact the Hatco Service Department at
800-558-0607 or 414-671-6350; fax 800-690-2966; or
International fax 414-671-3976.
BURN HAZARD: Some exterior surfaces on unit will get
hot. Use caution when touching these areas.
Locate unit at proper counter height in an area that is
convenient for use. The location should be level to prevent
unit or its contents from falling accidentally and strong
enough to support the weight of the unit and contents.
The National Sanitation Foundation (NSF) requires that
units over 36″ (914 mm) in width or weighing more than 80
lbs. (36 kg) either be sealed to or raised above the
installation surface. If unit cannot be sealed at the point of
use, 4″ (102 mm) legs are included to allow for proper
cleaning access below unit.
Do not lay unit on the side with the control panel. Damage
to unit could occur.
Use non-abrasive cleaners and cloths only. Abrasive
cleaners and cloths could scratch finish of unit, marring
its appearance and making it susceptible to soil
accumulation.
Clean unit daily to avoid malfunctions and maintain
sanitary operation.
WARNING
CAUTION
NOTICE
ELECTRIC SHOCK HAZARD:
• Plug unit into a properly grounded electrical receptacle
of the correct voltage, size, and plug configuration. If
plug and receptacle do not match, contact a qualified
electrician to determine and install proper voltage and
size electrical receptacle.
• Turn OFF power switch, unplug power cord, and allow
unit to cool before performing any cleaning,
adjustments, or maintenance.
• Unit is not weatherproof. Locate unit indoors where
ambient air temperature is a minimum of 70°F (21°C).
• DO NOT submerge or saturate with water. Unit is not
waterproof. Do not operate if unit has been submerged
or saturated with water.
• Do not steam clean or use excessive water on unit.
• This unit is not “jet-proof” construction. Do not use jet-
clean spray to clean this unit.
• Do not pull unit by power cord.
• Discontinue use if power cord is frayed or worn.
• Do not attempt to repair or replace a damaged power
cord. The cord must be replaced by Hatco, an
Authorized Hatco Service Agent, or a person with
similar qualifications.
• Do not clean unit when it is energized or hot.
• This unit must be serviced by qualified personnel only.
Service by unqualified personnel may lead to electric
shock or burn.
• Use only Genuine Hatco Replacement Parts when
service is required. Failure to use Genuine Hatco
Replacement Parts will void all warranties and may
subject operators of the equipment to hazardous
electrical voltage, resulting in electrical shock or burn.
Genuine Hatco Replacement Parts are specified to
operate safely in the environments in which they are
used. Some aftermarket or generic replacement parts
do not have the characteristics that will allow them to
operate safely in Hatco equipment.
FIRE HAZARD: Locate unit a minimum of 1″ (25 mm) from
combustible walls and materials. If safe distances are not
maintained, discoloration or combustion could occur.
Use only light bulbs that meet or exceed National
Sanitation Foundation (NSF) standards and are specifically
designed for food holding areas. Breakage of light bulbs
not specially-coated could result in personal injury and/or
food contamination.
WARNING
Read the following important safety information before using this equipment to avoid serious
injury or death and to avoid damage to equipment or property.
Specyfikacje produktu
| Marka: | Hatco |
| Kategoria: | podgrzewacz do jedzenia |
| Model: | Glo-Ray GRPWS-4824T |
Potrzebujesz pomocy?
Jeśli potrzebujesz pomocy z Hatco Glo-Ray GRPWS-4824T, zadaj pytanie poniżej, a inni użytkownicy Ci odpowiedzą
Instrukcje podgrzewacz do jedzenia Hatco
21 Września 2024
21 Września 2024
18 Września 2024
18 Września 2024
Inne instrukcje Hatco
23 Września 2024
23 Września 2024
23 Września 2024
22 Września 2024
22 Września 2024
22 Września 2024
22 Września 2024
22 Września 2024
22 Września 2024
22 Września 2024
