Strona 1/6
PowerStacker™ Tower
with Modular Components
10-Bay (LTBB10)
and 20-Bay (LTCC20)
Charging Cabinets
Shown with optional casters (sold separately)
80 Little Falls Road
Fairfield, NJ 07004
1-800-631-0868
www.HamiltonBuhl.com
PowerStacker™ Tower — 09/2015
v.2d5
Overview...............................................
Unpacking the Charging Cabinet
Initial Set Up
Understanding the Two Compartments
Safety Information
Warnings...............................................
Caution
Types of Units that can be Charged
Power Connection
Installation of the shelf
Surge Protector
Connection Charging Cables
LTBB10 Specifications..........................
LTCC20 Specifications..........................
PowerStacker™ Tower............................
PowerStacker™ Accessories..................
Multiple Stacking Plates - LTFFST
Rubber Feet - LTGGRF
Casters - LTDDCS
Transport Handles - LTEEHD
Programmer Timer - LTHHPT
Table Anchor Option
Product Registration.............................
PowerStacker™ Charging Cabinet
Index
2
3
4
5
6
7
10
Our Mission:
Since our founding in 1933, HamiltonBuhl continues to evolve as a leader in
technology products for education and industry. Our products are embraced by
educators, corporate trainers, presenters, government agencies, and
hospitals for their daily presentation, from classroom to the boardroom,
HamiltonBuhl has the presentation product for you.
Product Registration Instructions
Visit: www.hamiltonbuhl.com
1. Click on Customer Support
2. Click on Product Registration Form
3. Please fill out all fields marked with * to register
W
A
R
R
A
N
T
Y
PowerStacker™ 10-Bay and 20-Bay Charging Cabinets
1 10
PowerStacker™ 10-Bay and 20-Bay Charging Cabinets
Overview
Introducing the PowerStacker™ Tower from HamiltonBuhl. Built from the
ground up, these new and unique products don’t require any cooling fans,
and feature a modular design with configurations ranging from as small as 10
charging units up to a maximum of 40 charging units.
Each cabinet can charge laptops, Chromebooks, iPads and other tablets
simultaneously in the same cabinet. The double-lock doors ensure that devices
are well-protected and tablets are secured, for round-the-clock protection while
charging. They may also be programmed for sequential charging, so as not to
exceed the 15 amp limit available in most classrooms.
Made in the USA!
Unpacking the Charging Cabinet for the First Time
New units are shipped in a custom-designed corrugated container. Accessories,
if purchased, will come in a separate corrugated container. Place the
PowerStacker™ on the floor with ample working space.
1. Open the top of the container and fold down the four flaps.
2. Remove any packaging materials located on the top of the container.
3. Invert the PowerStacker™ leaving it in the shipping container.
4. Lift the container off leaving the PowerStacker™ inverted on the floor.
5. If feet or casters have been purchased, attach them to the bottom of the unit.
Once feet or casters have been attached, turn the PowerStacker™ upright,
place it on a table and continue installation and set-up.
Initial Set-Up
The PowerStacker™ has two separate compartments. Looking at the front
of the unit the smaller power compartment is on the right and the housing
compartment is on the left. A door with locks secures both sections.
Understanding the Two Compartments
The purpose of having two compartments is for security and the safety of those
using the system. Both compartments are secured with locking mechanism.
There is NEVER a need to have children access the power compartment. The
larger housing compartment is for low voltage use only.
Safety Information
These units are designed for adult operation. Reviewing of safety information is
critical for proper operation prior to use.
Table Anchor Option
Two openings in the bottom plate of the unit are for the nut and bolt set for
securing the unit to a table. Drill holes accordingly and secure the unit to the table.
Note: Appropriate parts (nuts and bolts) must be purchased from any retail hardware
stores based on proper measurements of your table.
Programmer Timer - LTHHPT (sold separately)
Most classrooms provide 15-amp service. Occasions may occur where the unit will
overload the circuit and cause a disruption. For these applications a programmable
timer should be used. Follow the directions included in the programmable timer kit
and attach it to the 110 circuit located in the back of the unit.
PowerStacker™ 10-Bay and 20-Bay Charging Cabinets
29
PowerStacker™ 10-Bay and 20-Bay Charging Cabinets
