Strona 1/2
Plug the attached AC cord into a standard AC
power outlet to power the DVD player.
AUDIO OU T VIDEO OUT DIGI TALHDM I O UTPUT
COAXIAL
L R VIDEO
120V ~ 60Hz
USER’S GUIDE
V:548-01
Composite Video
Output
Coaxial Digital Audio
Output
DH300B DVD Player
Warning: Changes or modications to this unit not expressly approved by the party responsible
for compliance could void the user’s authority to operate the equipment.
NOTE: This equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable
protection against harmful interference in a residential installation. This equipment generates,
uses, and can radiate radio frequency energy and, if not installed and used in accordance with
the instructions, may cause harmful interference to radio communications. However, there is
no guarantee that interference will not occur in a particular installation. If this equipment does
cause harmful interference to radio or television reception, which can be determined by turning
the equipment off and on, the user is encouraged to try to correct the interference by one or
more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to which the receiver
is connected.
• Consult the dealer or an experienced radio/TV technician for help.
• The apparatus shall not be exposed to dripping or splashing and that no objects lled with
liquids, such as vases, shall be placed on apparatus.
 L’appareilnedoitpasêtreexposéauxécoulementsouauxéclaboussuresetaucunobjetne
contenantdeliquide,telqu’unvase,nedoitêtreplacésurl’objet.
• Main plug is used as disconnect device and it should remain readily operable during intended
use. In order to disconnect the apparatus from the mains completely, the mains plug should
be disconnected form the mains socket outlet completely.
Laprisedusecteurnedoitpasêtreobstruéeoudoitêtrefacilementaccessiblependantson
utilisation.Pourêtrecomplètementdéconnectédel’alimentationd’entrée,laprisedoitêtre
débranchéedusecteur.
• Battery shall not be exposed to excessive heat such as sunshine, re or the like.
Lespilesnedoiventpasêtreexposéesàdefortechaleur,telqu’àlalumièredusoleil,aufeu
ouautreschosesdesemblable.
• Caution marking is located at the rear or bottom of the apparatus.
 Attentionmarquageestsituésurlepaneauarrièreouinférieurdel’unité.
• The marking information is located at the rear or bottom of apparatus.
 Lemarquageestsituésurlepaneauarrièreouinférieurdel’unité.
1. Read these Instructions.
2. Keep these Instructions.
3. Heed all Warnings.
4. Follow all instructions.
5. Do not use this apparatus near water.
6. Clean only with a dry cloth.
7. Do not block any ventilation openings. Install in
accordance with the manufacturer’s instructions.
8. Do not install near any heat sources such as radiators,
heat registers, stoves, or other apparatus (including
ampliers) that produce heat.
9. Do not defeat the safety purpose of the polarized or
grounding - type plug. A polarized plug has two blades
with one wider than the other. A grounding type plug
has two blades and a third grounding prong. The
wide blade or the third prong are provided for your
safety. When the provided plug does not t into your
outlet, consult an electrician for replacement of the
obsolete outlet.
10. Protect the power cord from being walked on or
pinched particularly at plugs, convenience receptacles,
and the point where they exit from the apparatus.
11. Only use attachments/accessories specied by the
manufacturer.
12. Use only with a cart, stand, tripod, bracket, or table
specied by the manufacturer, or sold with the
apparatus. When a cart is used, use caution when
moving the cart/apparatus combination to avoid injury
from tip-over. Unplug this apparatus during lightning
storms or when unused for long periods of time.
13. Refer all servicing to qualied
service personnel. Servicing is
required when the apparatus has
been damaged in any way, such
as power-supply cord or plug is
damaged, liquid has been spilled
or objects have fallen into the
apparatus, the apparatus has
been exposed to rain or moisture,
does not operate normally, or has
been dropped.
• CAUTION: TO PREVENT ELECTRIC SHOCK, MATCH WIDE BLADE OF PLUG TO WIDE
SLOT, FULLY INSERT.
• WARNING:To reduce the risk of re or electric shock, do not expose this apparatus to rain or
moisture.
• AVERTISSEMENT: Pour réduire le risque d’incendie ou de choc électrique, ne pas exposer cet
appareil sous la pluie et l’humidité.
• CAUTION: Use of controls or adjustments or performance of procedures other than those specied
may result in hazardous radiation exposure.
• WARNING: Changes or modications to this unit not expressly approved by the party responsible
for compliance could void the user’s authority to operate the equipment.
• WARNING: Do not place the unit on top of any soft, porous, or sensitive surfaces to avoid
damaging the surface. Use a protective barrier between the unit and surface to protect the surface.
• WARNING: Use of this unit near uorescent lighting may cause interference regarding use of
the remote. If the unit is displaying erratic behavior move away from any uorescent lighting, as
it may be the cause.
• CAUTION:Danger of explosion if battery is incorrectly replaced. Replace only with the same
or equivalent type.
• WARNING: Shock hazard - Do Not Open.
• AVIS:RISQUEDECHOCÉLECTRIQUE-NEPASOUVRIR
Mains plug is used as disconnect device and it should remain readily operable during intended
use. In order to disconnect the apparatus from the mains completely, the mains plug should be
disconnected form the mains socket outlet completely.
Laprisedusecteurestutilisépourdéconnecterlesystème.
Laprisedusecteurnedoitpasêtreobstruéeoudoitêtrefacilementaccessiblependantson
utilisation.Pourêtrecomplètementdéconnectédel’alimentationd’entrée,laprisedoitêtre
débranchéedusecteur.
Do not mix old and new batteries.
Do not mix alkaline, standard (carbon-zinc), or rechargeable (ni-cad, ni-mh, etc) batteries.
Nomezclebateríasviejasynuevas.
Nomezclebateríasalcalinas,estándar(carbono-zinc)orecargables(ni-cad,ni-mh,etc.).
WARNING: TO REDUCE THE RISK OF
ELECTRIC SHOCK, DO NOT REMOVE
COVER (OR BACK). NO USER-
SERVICEABLE PARTS INSIDE. REFER
SERVICING TO QUALIFIED SERVICE
PERSONNEL.
ATTENTION
RISQUE D' ÉLECTROCUTION
NE PAS OUVRIR
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
The exclamation point within an equilateral
triangle is intended to alert the user to the
presence of important operating and maintenance
(servicing) instructions in the literature
accompanying the appliance.
This symbol indicates that this product
incorporates double insulation between hazardous
mains voltage and user accessible parts.
The lightning ash with arrowhead symbol,
within an equilateral triangle, is intended to alert
the user to the presence of uninsulated “dangerous
voltage” within the product’s enclosure that may
be of sufcient magnitude to constitute a risk of
electric shock to persons.
IMPORTANT SAFETY INSTRUCTIONS
Introduction and Setup
FCC Warnings
Power
Requires 2 AAA batteries (not included).
Do not mix old and new batteries.
Do not mix alkaline, standard (carbon-zinc), or
rechargeable (ni-cad, ni-mh, etc) batteries
Remote
Additional Warnings
WARNINGS AND PRECAUTIONS
POW ERPLAY/
PAUSE
STOPOPEN/
CLOS E
DVD / C D PL AYER
HDMI
AUDIO OUT VIDEO OUT DIGITALHDMI OUTPUT
COAXIAL
L R VIDEO
120V ~ 60Hz
OPEN/CLOSE
MUTE
AUDIOSTOPN/PSUBTITLE
TITLEOSD
VIDEOWIDEZOOMANGLE
SETUP
ENTER
MENU
VOLUME
GOTORANDOMCLEARPROG
STEPSLOWHDMIREPEAT
Open/Close
Number Keypad
Menu
Main DVD menu
Skip
Search
OSD
On screen
display
N/P
Switch between
NTSC and PAL
Subtitle
Zoom
Angle
HDMI
Repeat
Prog
Create a
program to
play chapters
or tracks in a
specied order
Volume
Mute
Setup
Setup menu
Arrows/Enter
Play/Pause
Stop
Title
Audio
Wide
Adjusts the
aspect ratio
Video
Switch between
CVBS or HD
Slow
Step
Goto
Random
Clear
Power
HDMI Output
Power
Press to turn the DVD
player off or on.
Play/Pause
Press to play or pause
the loaded disc.
Open/Close
Press to open or close
the Disc Drawer.
Disc Drawer
RCA Stereo Audio
Outputs
Stop
Press to stop the
loaded disc.
For Warranty Information and the most up-to-date version of this User’s Guide, go to www.gpx.com 1-888-999-4215Customer Service:
Email Support: Email Parts: prodinfo@dpiinc.com, partsinfo@dpiinc.com
Copyright © 2011 Digital Products International (DPI, Inc.) All other trademarks appearing herein are the property of their respective owners. Specications are subject to change without notice.
AUDIO OUT VIDEO OUT DIGITALHDMI OUT PUT
COAXIAL
L R VIDEO
120V ~ 60Hz
1. Press the button to open the Open/Close
Disc Drawer.
2. Load a disc into the DVD player, label side
facing up.
3. Press the button to close the Open/Close
Disc Drawer.
4. After a disc is loaded, it will begin playing
automatically.
1. Follow the instructions for Loading a Disc
and Playing a Loaded Disc.
2. While the loaded disc is playing, press the
PROG button on the remote.
3. Use the Arrows/Enter/Number Keypad
buttons to highlight and select a DVD title
and chapter, or CD track.
4. Highlight the PLAY button to play.
5. DVD Titles and chapters or CD tracks will
play in the order they are programmed.
6. Repeat step 3 until the desired DVD
titles and chapters or CD tracks are
programmed.
DVD and CD Connecting Video and Audio
Loading a Disc
1. Follow the instructions for Loading a Disc.
2. If the disc does not begin playing
automatically, press the Play/Pause
button.
Playing a Loaded Disc
Programming a Loaded Disc
1. Load a JPEG photo disc into the player
by following the instructions for Loading
a Disc.
2. A slide show of JPEG photos from the CD
will begin playing automatically.
3. Press the button to access a le Stop
view of the loaded JPEG disc.
4. Use the buttons on the Arrows/Enter
remote to select and view photos.
Playing a JPEG CD
Press the button on the remote twice.Stop
In order to access all of the features of the DVD
setup menu, the DVD player needs to be fully
stopped.
Press the button on the remote.Setup
Access the DVD Setup Menu
Press the button on the remote to Setup
access the Audio menu.
• OFF: There will be no digital audio signal
output. (Coaxial off)
• RAW: The digital audio signal output
will be in its raw format. This mode is
usually used for DTS & Dolby Digital 5.1
signals.
• PCM: The digital audio signal output will
be in PCM format. This mode is usually
used for audio CD signals.
Digital Output Settings
To download this User’s Guide in English, Spanish,
or French, or to get answers to frequently
asked questions, visit the support section at:
www.gpx.com
Para descargar este Manual del Usuario en
inglés, español y francés, o para obtener
respuestas a preguntas frecuentes,
visite la sección de apoyo en
www.gpx.com
Pour télécharger ce guide de l’utilisateur en
anglais, espagnol ou français, ou pour obtenir
des réponses à des questions fréquemment
posées, consultez la rubrique d’assistance sur
www.gpx.com
International Support
Television
Composite Video Input
Note: Before making or changing any connections, make sure that all the devices are
disconnected from the power outlet.
Note: Both video and audio connections must be made from the DVD player to your television.
1. Use the to Composite Video Output
send video from the DVD player to a
television.
2. Requires an RCA video cable (included).
3. Use the RCA video cable to connect the
Composite Video Output to a composite
video input on a television.
4. Adjust the connected televisions input
setting to match the input used in the
previous step.
Composite Video Output (Good)
AUDIO OUT VIDEO OUT DIGITALHDMI OUTPUT
COAXIAL
L R VIDEO
120V ~ 60Hz
HDMI
HDMI
Television
HDMI Input
1. Use the to send high quality HDMI Output
video from the DVD player to a television.
2. Requires a HDMI cable (not included).
3. Use a HDMI cable to connect the HDMI
Output to a HDMI input on a television.
4. Adjust the connected televisions input
setting to match the input used in the
previous step.
5. Press the button on the remote HDMI
to adjust the display resolution between
480p, 720p, 1080i, and 1080p.
Note: If the screen remains blank, press
the button repeatedly to enter HDMI Video
Mode.
HDMI Output (Better)
AUDIO OUT VIDEO OUT DIGITALHDMI OUT PUT
COAXIAL
L R VIDEO
120V ~ 60Hz
Television
RCA Stereo Audio Inputs
1. Use the to RCA Stereo Audio Output
send audio from the DVD player to a
television.
2. Requires an RCA audio cable (included).
3. Use the RCA audio cable to connect the
RCA Stereo Audio Output to an RCA
stereo audio input on a television.
4. Adjust the connected televisions input
setting to match the input used in the
previous step.
RCA Stereo Audio Output (Good)
AUD IO OU T VIDE O OUT DIG ITALH DMI OU TPU T
COAXIAL
L R V IDE O
120V ~ 60Hz
Audio System
Coaxial Digital Audio Input
1. Use the Coaxial Digital Audio Output
to send high quality audio from the DVD
player to an audio system.
2. Requires an RCA audio cable (included).
3. Use the RCA audio cable to connect
the to an Coaxial Digital Audio Output
coaxial digital audio input on an audio
system.
4. Adjust the connected audio system’s input
setting to match the input used in the
previous step.
5. In the portion of the Digital Out
setup menu, adjust to PCM, RAW or
OFF.
Coaxial Digital Audio Output
For Warranty Information and the most up-to-date version of this User’s Guide, go to www.gpx.com 1-888-999-4215Customer Service:
Email Support: Email Parts: prodinfo@dpiinc.com, partsinfo@dpiinc.com
Copyright © 2012 Digital Products International (DPI, Inc.) All other trademarks appearing herein are the property of their respective owners. Specications are subject to change without notice.

Specyfikacje produktu

Marka: GPX
Kategoria: odtwarzacz DVD
Model: DH300B

Potrzebujesz pomocy?

Jeśli potrzebujesz pomocy z GPX DH300B, zadaj pytanie poniżej, a inni użytkownicy Ci odpowiedzą


Instrukcje odtwarzacz DVD GPX

GPX

GPX DH300B Instrukcja

3 Października 2024
GPX

GPX D200B Instrukcja

24 Września 2024
GPX

GPX BD717BU Instrukcja

24 Września 2024

Instrukcje odtwarzacz DVD

Najnowsze instrukcje dla odtwarzacz DVD

Samsung

Samsung DVD-P366KD Instrukcja

8 Października 2024
Samsung

Samsung DVD-K305W Instrukcja

8 Października 2024
Samsung

Samsung DVD-K300S Instrukcja

8 Października 2024
Samsung

Samsung DVD-P465 Instrukcja

8 Października 2024
Mx Onda

Mx Onda MX-DVD8356 Instrukcja

7 Października 2024
Panasonic

Panasonic SC-HT860 Instrukcja

6 Października 2024
Philips

Philips DVDR3400 Instrukcja

4 Października 2024
Philips

Philips DVDR3570H Instrukcja

4 Października 2024
LG

LG RCT699H Instrukcja

4 Października 2024
Kenwood

Kenwood DVF-5500-S Instrukcja

4 Października 2024
