SFIGMOMANOMETRI

SPHYGMOMANOMETERS

TENSIOMETRES

BLUTDRUCKMESSGERÄTE

ESFIGMOMANOMETROS

ESFIGMOMANMETROS

ΣΦΥΓΜΟΜΑΝΟΜΕΤΡΑ

PROF E S S I ONAL M EDI CAL PRODU CT S

M32709-M-Rev.6-05.20

Gima S.p.A.

Via Marconi, 1 - 20060 Gessate (MI) Italy

gima@gimaitaly.com - export@gimaitaly.com

www.gimaitaly.com

Made in China

32709 - 32719 - 32720 - 32725 - 32726

32727 - 32728 - 32731 - 32734 - 32738 0476

FEATURES

We would like to thank you for having purchased a precision GIMA sphygmomanometer.

All GIMA sphygmomanometers are manufactured with high quality materials and, when

maintained at perfect operating efciency through regular calibration checks, ensure complete

reliability and precision, even after several years of use.

Our line of sphygmomanometers offers the same quality standards for both professional and

home models.

The sphygmomanometer you have purchased complies with EEC directive 93/42/CEE.

PRESCRIPTIONS

It must be noted that self-measuring instruments are not a substitute for regular

medical checkups, and that only your doctor can accurately analyze these

measurements.

Arterial pressure is highly inuenced by one’s nervous tension and physical fatigue. It is

therefore recommended that you perform the measurement under conditions of both

physical and mental relaxation, while in a sitting or supine position and, where possible,

always at the same time of day, far from meal times.

Remember: do not move while measuring your pressure and do not wear clothing that

covers your arm and could limit blood circulation.

Pressure varies during the day: it is lower in the morning and higher in the evening; it is also

lower in the summer and higher in the winter.

INSTALLATION

After opening the packages, rst of all it is necessary to check all pieces and parts composing

the product. Check that they are all present and in perfect conditions.

Apply the armband to your bare left arm, 2-3 cm. above your elbow joint, and then prop up

your forearm, keeping it at heart level.

Velcro armband: Close the armband using the Velcro strap.

If not specically indicated, all GIMA sphygmomanometers are equipped with armbands

for adults; upon request, we can provide armbands for the obese, for use on the thigh

and for children, ranging from premature babies up to 14-year-olds.

Position the earpiece of the stethoscope on the artery, under your arm.

FUNCTIONING

1) After applying the armband, use the bulb to pump up to approximately 20 mmHg beyond

the level of individual systolic pressure: in other words, until the brachial artery is blocked

(maximum level). It is essential that the person being measured remains seated and calm,

and that his/her , with the inside part facing up.forearm is resting at heart level

2) To measure blood pressure, turn the release/deation screw on the bulb, unscrewing it

slowly in a counter-clockwise direction. The ideal deation speed is around 2-3 mmHg/

sec.

Visually check deation speed: on the scale, the indicator must move at a speed of between

1 and 1.5 gradations per second.

The models featuring automatic deation of the gauge, which automatically regulates

deation speed at 2-3 mmHg/sec. Simply press the valve up to the rst pressure point.

3) Due to the gradual decompression, your blood starts to run through the brachial artery again,

which in turn causes an initial pulsation, that is clearly perceived by the phonendoscope:

the pressure indicated on the gauge needle at the exact moment this rst beat is recorded

is referred to as the “systolic or maximum pressure”.

Systole = maximum pressure level when the heart contracts and blood is pushed into the

ENGLISH

blood vessels.

As you proceed with decompression, the pulsations gradually decrease until they suddenly

disappear or become so low as to be imperceptible.

The pressure indicated by the gauge needle at the moment the pulsations disappear is

referred to as the “diastolic or minimum pressure”.

Diastole: minimum blood pressure level when the heart muscle is expanding and relling

with blood.

4) Now completely open the release valve until air begins to come out of the armband.

Bloodpressure measurement is now completed.

MAINTENANCE

1. Gauge and bulb

Cleaning: The gauge and bulb can be wiped with a damp cloth. Sterilization is not necessary,

as the parts do not come into direct contact with the patient’s body.

2. Armbands

Cleaning: After removing the plenum chamber, the liners can be wiped with a damp cloth, or

you can wash them with soap and cold water. If you use this second method, rinse the

armbands with clean water and leave them to air dry. Nylon armbands must not be ironed.

The plenum chamber and tubes can be wiped with a damp cotton cloth.

GIMA WARRANTY TERMS

The Gima 12-month standard B2B warranty applies.

5ENGLISH

Caution: read instructions

(warnings) carefully

Medical Device complies

with Directive 93/42/EEC

Keep in a cool, dry place Keep away from sunlight

Manufacturer Consult instructions for use

Product code Lot number
