KEEP THIS OPERATION MANUAL FOR FUTURE REFERENCE
FUJITSU GENERAL LIMITED
OPERATING MANUAL
Indoor Unit
ASTG18LF
ASTG24LF
ASTG30LF
ASTG34LF
AIR CONDITIONER
Wall Mounted Type
HEAT & COOL MODEL
(REVERSE CYCLE)
R410A
REFRIGERANT
This Air Conditioner contains
and operates with refrigerant R410A.
THIS PRODUCT MUST ONLY BE INSTALLED OR SERVICED
BY QUALIFIED PERSONNEL.
Refer to Commonwealth, State, Territory and local legislation,
regulations, codes, installation & operation manuals, before
the installation, maintenance and/or service of this product.
P/N9315345387
9315345387_OM_EN.indb 1
9315345387_OM_EN.indb 1
9315345387_OM_EN.indb 1
9315345387_OM_EN.indb 19315345387_OM_EN.indb 1 12/2/2010 8:44:25 AM
12/2/2010 8:44:25 AM
12/2/2010 8:44:25 AM
12/2/2010 8:44:25 AM12/2/2010 8:44:25 AM
En-1
CONTENTS
SAFETY PRECAUTIONS ......................................En-1
FEATURES AND FUNCTIONS .............................En-2
NAME OF PARTS .................................................En-3
PREPARATION .....................................................En-5
OPERATION ..........................................................En-6
TIMER OPERATION .............................................En-8
SLEEP TIMER OPERATION .................................En-9
ADJUSTING THE DIRECTION OF
AIR CIRCULATION ............................................ En-10
SWING OPERATION ..........................................En-11
ECONOMY OPERATION .................................... En-11
10 °C HEAT OPERATION ...................................En-12
MANUAL AUTO OPERATION .............................En-12
CLEANING AND CARE .......................................En-13
SELECTING THE REMOTE CONTROLLER
SIGNAL CODE ....................................................En-15
TROUBLESHOOTING ........................................En-16
OPERATING TIPS ...............................................En-17
SAFETY PRECAUTIONS
● Do not attempt to install this air conditioner by yourself.
●
This air conditioner contains no user-serviceable parts. Always consult authorized service personnel for repairs.
●
When moving, consult authorized service personnel for disconnection and installation of the air conditioner.
● Do not become excessively chilled by staying for many hours in the direct cooling airfl ow.
● Do not insert fi ngers or objects into the outlet port or intake grille.
● Do not start and stop air conditioner operation by disconnecting the power supply cord.
● Take care not to damage the power supply cord.
● In the event of a malfunction (burning smell, etc.), immediately stop operation, turn off the breaker, and
consult authorized service personnel.
● In the event of the refrigerant leakage, be sure to keep it away from fi re or any fl ammables. (consult an
authorized service personnel)
● If the power supply cord of this appliance is damaged, it should only be replaced by the authorized service
personal, since special purpose tools and specifi ed cord are required.
● Provide occasional ventilation during use.
● Do not direct airfl ow at fi replaces or heating apparatus.
● Do not climb on, or place objects on, the air conditioner.
● Do not hang objects from the indoor unit.
● Do not set fl ower vases or water containers on top of air conditioners.
● Do not expose the air conditioner directly to water.
● Do not operate the air conditioner with wet hands.
● Do not pull power supply cord.
● Turn off power supply when not using the indoor unit for extended periods.
● Check the condition of the installation stand for damage.
● Do not place animals or plants in the direct path of the airfl ow.
● Do not drink the water drained from the air conditioner.
● Do not use in applications involving the storage of foods, plants or animals, precision equipment, or art
works.
● Connection valves become hot during Heating; handle with care.
● Do not apply any heavy pressure to radiator fi ns.
● Operate only with air fi lters installed.
● Do not block or cover the intake grille and outlet port.
● Ensure that any electronic equipment is at least 1 m away from either the indoor or outdoor units.
● Avoid installing the air conditioner near a fi replace or other heating apparatus.
● When installing the indoor and outdoor unit, take precautions to prevent access to infants.
● Do not use infl ammable gases near the air conditioner.
● This appliance is not intended for use by persons (including children) with reduced physical, sensory or
mental capabilities, or lack of experience and knowledge, unless they have been given supervision or
instruction concerning use of the appliance by a person responsible for their safety. Children should be
supervised to ensure that they do not play with the appliance.
● Before using the appliance, read these “PRECAUTIONS” thoroughly and operate in the correct way.
● The instructions in this section all relate to safety; be sure to maintain safe operating conditions.
● “DANGER, “WARNING” and “CAUTION” have the following meanings in these instructions:
This mark indicates procedures which, if improperly performed, are most likely to
result in the death or serious injury to the user or service personnel.
This mark indicates procedures which, if improperly performed, might lead to the
death or serious injury of the user or service personnel.
This mark indicates procedures which, if improperly performed, might possibly result
in personal harm to the user, or damage to property.
DANGER!
WARNING!
CAUTION!
DANGER!
CAUTION!
9315345387_OM_EN.indb 1
9315345387_OM_EN.indb 1
9315345387_OM_EN.indb 1
9315345387_OM_EN.indb 19315345387_OM_EN.indb 1 12/2/2010 8:44:33 AM
12/2/2010 8:44:33 AM
12/2/2010 8:44:33 AM
12/2/2010 8:44:33 AM12/2/2010 8:44:33 AM
En-2
FEATURES AND FUNCTIONSFEATURES AND FUNCTIONS
■ Energy saving and Comfortable function
INVERTER
At the start of operation, large amount of power is used to
bring the room quickly to the desired temperature. Afterwards,
the unit automatically switches to a low power setting for eco-
nomic and comfortable operation.
ECONOMY OPERATION
When ECONOMY operation mode is operated, the room tem-
perature will be little higher than the set-temp under cooling
mode and lower than set-temp under heating mode. Therefore,
the ECONOMY mode is able to save more energy than other
normal mode.
HORIZONTAL AIRFLOW: COOLING/
DOWNWARD AIRFLOW: HEATING
For cooling, use horizontal airflow so the cool air does not
blow directly on the occupants in the room. For heating, use
downward airfl ow to send powerful, warm air to the fl oor and
create a comfortable environment.
OMNI-DIRECTIONAL AIR FLOW
(SWING OPERATION)
3-dimensional control over air direction swing is possible through
dual use of both an UP/DOWN air direction swing and RIGHT/
LEFT air direction swing. Since UP/DOWN air direction fl aps op-
erate automatically according to the operating mode of the unit,
it is possible to set air direction based on the operating mode.
SUPER QUIET OPERATION
When the FAN button is used to select QUIET, the indoor unit
begins super quiet operation; the indoor unit’s airflow is re-
duced to produce quieter operation.
AUTO CHANGEOVER
The operation mode (cooling, dry, heating) is switched auto-
matically to maintain the set temperature, and the temperature
is kept constant at all times.
10°C HEAT OPERATION
The room temperature can be maintained at 10°C so as to
prevent the room temperature from falling too far.
■ Convenient function
PROGRAM TIMER
The program timer allows you to integrate OFF timer and ON timer
operations in a single sequence. The sequence can involve 1 tran-
sition from OFF timer to ON timer, or from ON timer to OFF timer,
within a 24 hour period.
SLEEP TIMER
When the SLEEP timer button is pressed during heating mode,
the air conditioner’s thermostat setting is gradually lowered dur-
ing the period of operation; during cooling or dry mode, the ther-
mostat setting is gradually raised during the period of operation.
When the set time is reached, the unit automatically turns off.
■ Clean function
REMOVABLE INTAKE GRILLE
The indoor unit’s intake grille can be removed for easy clean-
ing and maintenance.
MILDEW-RESISTANT FILTER
The AIR FILTER has been treated to resist mildew growth,thus
allowing cleaner use and easier care.
POLYPHENOL CATECHIN AIR CLEANING FILTER
The polyphenol catechin air cleaning fi lter uses static electric-
ity to clean fi ne particles and dust in the air such as tobacco
smoke and plant pollen that are too small to see. The filter
contains catechin, which is highly effective against various
bacteria by suppressing the growth of the bacteria adsorbed to
the fi lter. Note that when the air cleaning fi lter is installed, the
amount of air produced decreases, causing a slight decrease
in the indoor unit’s performance.
NEGATIVE AIR IONS DEODORIZING FILTER
It comprises pottery super micro particles which can produce
negative air ions having the effect of deodorizing and can ab-
sorb and remit the peculiar smell at home.
■ Remote controller
WIRELESS REMOTE CONTROLLER
The wireless remote controller allows convenient control of air
conditioner operation.
WIRED REMOTE CONTROLLER (OPTION)
The optional wired remote controller can be used. When you
use remote controller, there are following different points as
compared with using wireless remote controller.
[The additional functions for wired ones]
• Weekly timer
• Temperature set back timer
And you can use both wired and wireless remote controller si-
multaneously. (But function is limited)
When the restricted functions on the remote controller are
used, beeping sound will be heard, OPERATION, TIMER and
the 3rd lamp of the indoor unit will fl ash.
[The restricted functions for wireless ones]
• 10°C HEAT OPERATION
• TIMER (ON timer, OFF timer and Program timer)
• SLEEP TIMER
9315345387_OM_EN.indb 2
9315345387_OM_EN.indb 2
9315345387_OM_EN.indb 2
9315345387_OM_EN.indb 29315345387_OM_EN.indb 2 12/2/2010 8:44:34 AM
12/2/2010 8:44:34 AM
12/2/2010 8:44:34 AM
12/2/2010 8:44:34 AM12/2/2010 8:44:34 AM
