Installation and Operation Manual
THE E XP ERTS IN RO OM AIR CONDI T IONIN G
Standard Chassis Models Using R-32 Refrigerant
Uni-fit®
COOL ONLY
115 VOLT UCT08B10A, UCT10B10A, UCT12B10A
230 VOLT UCT10B30A, UCT12B30A, UCT14B30A
Uni-fit® COOL WITH ELECTRIC HEAT 115 VOLT UET08B11A
230 VOLT UET10B33A, UET12B33A, UET14B33A
Uni-fit ® Series
Thru-the-Wall Air Conditioners
93011015_02
2
CAUTION: Do Not Operate Equipment During Active Stages Of Construction
To ensure proper operation, Friedrich requires that all equipment is not operated during active construction phases. This includes active
stages of completing framing, drywalling, spackling, sanding, painting, flooring, and molding in the equipment’s designated conditioning space.
The use of this equipment during construction could result in premature failure of the components and/or system and is in violation of our
standard warranty guidelines. The operation of newly installed equipment during construction will accelerate the commencement and/or
termination of the warranty period.
Register your Air Conditioner
Model information can be found on the name plate.
Please complete and mail the owner registration card furnished
with this product, or register online at www.friedrich.com.
For your future convenience, record the model information .
Model Number ________________________
Serial Number ________________________
A. IMPORTANT SAFETY AND GENERAL INFORMATION ..3
A.1 Introduction 3 ...................................................................
A.2 Safety Warnings 3 ...........................................................
A.3 Warning For Using R32 Refrigerant 5 ..........................
A.4 Importance of a Quality Installation 8 ...........................
A.5 Product Inspection / Packing List 8 ..............................
B. SPECIFICATIONS ..........................................................9
B.1 Dimensions 9 ....................................................................
C. INSTALLATION OF THE UNIT ......................................10
C.1 Pre-Installation Checkpoints.................................... 10
C.2 Tools Required 10 ..........................................................
C.3. Choosing a Location 10 .................................................
C.4 Sleeve Installation 11 ....................................................
C.5 Chassis Installation 13 ...................................................
E. ELECTRICAL ................................................................17
E.1 Electrical Safety Information 17 ...............................
J. STARTUP AND OPERATION......................................... 18
J.1 Control Panel Operation 18 ............................................
J.5 Start-up 21 .......................................................................
L. WIFI ............................................................................21
M. TROUBLESHOOTING ..................................................22
M.1. Troubleshooting Tips 22 ............................................
M. TROUBLESHOOTING ..................................................23
R . INFORMATION FOR THE OWNER ............................... 23
R.1 Routine Maintenance 23 ................................................
R.3 Warranty 24 .....................................................................
3
A. IMPORTANT SAFETY AND GENERAL INFORMATION
A.1 Introduction
This booklet contains the installation and operating instructions for your Air Conditioning unit. There are some precautions that should be taken
to ensure proper operation. Improper installation can result in unsatisfactory operation or dangerous conditions.
Read this booklet and any instructions packaged with separate equipment required to make up the system prior to installation. Give this booklet
to the owner and explain its provisions. The owner should retain this booklet for future reference.
A.2 Safety Warnings
WARNING: The manufacturer’s warranty does not cover
any damage or defect to the air conditioner caused by the attachment
or use of any components, accessories or devices (other than those
authorized by the manufacturer) into, onto or in conjunction with the
air conditioner. You should be aware that the use of
unauthorized components, accessories or devices may
adversely affect the operation of the air conditioner
and may also endanger life and property. The
manufacturer disclaims any responsibility for such loss
or injury resulting from the use of such unauthorized
components, accessories or devices.
WARNING: Electrical Shock Hazard
Disconnect all power to the unit before starting maintenance. All
electrical connections and wiring MUST be installed by a qualified
electrician and conform to the National Code and all local codes
which have jurisdiction. Failure to do so can result in property
damage, severe electrical shock or death.
WARNING: Read Installation Manual
Please read this manual thoroughly prior to
equipment installation or operation. It is the
installer’s responsibility to properly apply and
install the equipment. Installation must be in
conformance with the NFPA 70-2023 national
electric code or current edition, International
Mechanic code 2021 or current edition, and any
other local or national codes.
WARNING: Safety First
Do not remove, disable, or bypass this unit’s safety devices. Doing so
may cause fire, injuries, or death.
WARNING ADVERTENCIA ATTENTION
• RISK OF FIRE OR
EXPLOSION
• FLAMMABLE REFRIGERANT
USED
• REPAIRS MAY ONLY BE
PERFORMED BY TRAINED
PERSONNEL
• CONSULT SERVICE
MANUAL BEFORE
ATTEMPTING REPAIRS. ALL
SAFETY PRECAUTIONS MUST
BE FOLLOWED
• DO NOT PUNCTURE
TUBING
• DISPOSE OF UNIT
PROPERLY IN ACCORDANCE
WITH FEDERAL OR LOCAL
REGULATIONS
• ONLY USE A2L APPROVED
SERVICE EQUIPMENT
• RIESGO DE FUEGO
• REFIGERANTE INFLAMABLE
UTILZADO
• PARA SER REPARDO
UNICAMENTE POR PERSONAL
DE SERVICIO CAPACITADO
• CONSULTE EL MANUAL
DE REPARACION DEL
PROPIETARIO ANTES
DE INTENTAR REPARAR
ESTE PRODUCTO. SE
DEBEN SEGUIR TODAS
LAS PRECAUCCIONES DE
SEGURIDAD
• NO PERFORE LA TUBERIA
DE REFIGERANTE
• DESECHE
APROPIADAMENTE DE
ACUERDO CON LAS
REGULACIONES FEDERALES
O LOCALES
• RISQUE D’INCENDIE
• REFRIGERANT
INFLAMMABLE UTILISE
• A REPARER UNIQUEMENT
PAR DU PERSONNELDE
SERVICE QUALIFIE
• CONSULTAR LE MANUEL
DE REPARATION/GUIDE
DU PROPRIETARE AVANTE
DE TENTER DE REPARER
CE PRODUIT. TOUTES LES
PRECAUTIONS DE SECURITE
DOIVENT ETRE SUIVIES
• NE PAS PERFORER LE
TUYAU DE REFIGERANT
• ELIMINER CORRECTEMENT
CONFORMENT AUX
REGLEMENTS FEDERAUX OU
LOCAUX
