Installation, User
d Guide Servicing
N E TO INSTAOT LLER: LEAVE THE OWNER’ NUS GUIDE MA AL E.WITH THE APP IAL NC
(Kee ur Re erenp For Fut e f ce)
Model
Milano, Venezia & Moena
FEM
2
RECORD HERE FOR EASY REFERENCE
Model Colour
Serial Number Installation Date
Dealer's Name and Address
Getting to know your new cooker
WHEN YOU CALL FOR SERVICE
OVERALL DIMENSIONS
SECTION FOR THE QUALIFIED TECHNICIAN
PROVISION FOR VENTILATION
GENERAL INFORMATION
INSTALLATION
ENVIRONMENTAL WARNING
Waste packaging
Do not throw the packaging of your appliance into the dustbin,
but pick out the different materials (for instance foil, paperboard,
polystyrene) according to the local rules for rubbish elimination.
This appliance must only be used for the purpose of domestic
cooking.
Thank you for choosing one of our products.
Our cookers are of simple, rational design. They are
constructed to the best standards to ensure good
service and outstanding safety.
Please read this manual carefully; it will provide all the
advice needed to allow you to obtain the best results
from the very first day.
ATTENTION:
- Before using the appliance, do not forget to remove the
protecting parts of the appliance.
-WARNING
Accessible parts will become hot when in use. To avoid
burns and scalds children should be kept away.
- WARNING
In order to prevent accidental tipping of the appliance, for
example by a child climbing onto the open oven door, the
stabilizing means must be installed.
- WARNING
This appliance is not intended for use by persons (including
children) with reduced physical, sensory or mental capabili-
ties, or lack of experience and knowledge, unless they
have been given supervision or instruction concerning use
of the appliance by a person responsible for their safety.
Children should be supervised to ensure that they do not
play with the appliance.
Young children and infirm persons should not be left
unsupervised in the vicinity.
- WARNING
Before you use the appliance for the first time, check that
the plastic films protecting some parts (fascia panel, parts
in stainless steel, etc.) have been removed.
- WARNING
A steam cleaner is not to be used cleaning this appliances.
- WARMING
DO NOT place inflammable materials or plastic utensils in
the warming drawer.
DO NOT SPRAY AEROSOLS IN THE VICINITY OF THIS
APPLIANCE WHILE IT IS IN OPERATION.
Not for use in marine craft, caravans or mobile homes
unless each burner is fitted with a flame safeguard.
WHERE THIS APPLIANCE IS INSTALLED IN MARINE
CRAFT OR IN CARAVANS, IT SHALL NOT BE USED AS
A SPACE HEATER
DO NOT MODIFY THIS APPLIANCE.
The room where the Cooker is installed should have permanent
ventilation as follows:
“Ventilation must be in accordance with AS/NZS 5601 - Gas
Installations. In general, the appliance should have adequate
ventilation for complete combustion of gas, proper flueing and to
maintain temperature of immediate surroundings within safe limits.”
Do not install in a bed-sitting room, a bathroom or shower room. If
there is another fuel burning appliance in the same room, a higher
level of ventilation will be required, you should consults " the safety
requirements".
In addition to the above, during prolonged use, opening a window in
the same room is recommended.This will avoid the build up of
excessive moisture and condensation.
When you call for service or order parts for your unit, be
sure to give:
1..MODEL
2. SERIAL NUMBER
3. COLOUR
4. PART NAME and/or description of problem
5. YOUR FULL NAME, ADDRESS, and HOME TELEPHONE
NUMBER and BUSINESS TELEPHONE NUMBER IF
APPROPRIATE.
Servicing shall be carried out only by authorised personnel.
X
600
B A
725
60
X (mod. 296) = 895 mm A = 25 mm according to the models
X (mod. 206) = 1000 mm A = 30 mm according to the models
A = 40 mm according to the models
B = 95 mm
B = Adjustable height only for some models reg. (90/150mm - 95/130mm -
115/165mm - 145/230mm according to the models).
Warning:
This appliance is noi suitable lo be installed on a base.
POSITIONING
3
min 10. 0 mm
min. 650 mm
min. 400 mm
"0" mm "0" mm
min. 650 mm
"0" mm "0" mm
min "60" mmmin "60" mm min "60" mm
non- combustible materials
non- combustible materials
min.10 mm
OK NO
Fig. 1 A
Fig. B Fig. C
G
wall
wall
Fig. A
76 mm550 mm
G R Hole
55 mm
chain
Position
1
P
osition
2
55 mm
P
osition
3
P
osition
4
Important: Fix the chain located next to the gas connection
on both sides of the cooker to the wall to prevent the cooker
from tilting. Both chains must be securely fixed.
Make sure that the wall surface behind the Cooker is
noncombustable (will not catch fire).
Where a painted surface is adjacent, a fire retardent paint
surface is recommended. Wallpaper, wood, or fabric should
not be used behind or next to the cooker.
Clearances to combustible materials
“Any adjoining wall surface (side or rear) situated within
200mm of any hob burner must be a suitable non-combusti-
ble material from the edge for a height of 150mm for the
entire length of the cooker.
Any combustible construction above the cooker must be at
least 650mm above the maintop.” Ensure that a power and
gas supply are nearby. The Cooker should be located
carefully so that the heat produced by it has plenty of space
to escape. The diagram below shows an ideal configuration.
No part of any adjoining wall surface can be made of
combustible materials. The protection of combustible
materials required by Clause 5.12.1.1 of AS/NZS 5601 is the
fixing of 5 mm thick ceramic tiles to the surface or attaching
fire resistant material to the surface and covering with sheet
metal with a minimum thickness of 0.4 mm.
Clearances to non- combustible materials
“If the cooker is being fitted next to cupboards or adjoing wall
surfaces, which are within 200mm from the edge of the hob
burner and of a suitable non-combustible material as
specified n , then ensure that a distance of at AS/NZS 5601
least 6cm is left between the edge of the cooker and the
non-combustible material. This gap is to allow plenty of
space for the heat produced by the cooker to escape on
each side of the cooker.
Note:
The cooker is fitted with 4 legs for an eventual alignment in
height with the furniture ( fig. 1 A ).
If the cooker is placed on a base, measures have to be taken
to prevent it from slipping off the base.
TO FIX THE COOKER TO THE REAR WALL
WARNING - For safety reasons and to prevent tipping of the
appliance, hese stabilizing means must be installed.
The cooker is equipped with 2 chains fixed on each side at
the rear of the cooker near the top (see Fig. A). The chains
are fitted with “spring clips” which must be clipped to the
“screw eyes” provided with the cooker.
Install the “screw eyes” as follows :
1. Drill four 6mm holes (position 1 - 2 - 3 - 4) in the wall as in
Fig. A.
2. Insert part “R” into the holes then screw in the “screw
eyes” part “ ” see Fig. B.G
Note: If the part provided is not suitable for the wall
material please use an appropriate device to ensure
secure holding of the “screw eyes” to the wall.
3. Bring the cooker near the wall and clip the chains on the
“screw eyes” as in Fig. C.
IMPORTANT: If the cooker is moved for any reason
(e.g. maintenance) resulting in the cooker being
unclipped from the wall, the cooker must be re-clipped
to the wall at the completion of the task.
