Fenix PD32 Flashlight

Fenix PD32 is an outdoor flashlight in small size for versatile usage. It offers four levels of

brightness and two types of flashing mode to be adjusted by pressing the side switch in the head, it

perfectly meet the needs of different brightness and runtime in various conditions. PD32 is a

portable flashlight with light weight, with two frost-resistant CR123A Lithium batteries or one

high capacity 18650 Li-ion battery, the light performs wonderfully in freezing areas. Featuring the

advanced technology to keep constant brightness and waterproofing to IPX-8 Standard, PD32 is

the best solution for your outdoor illumination or emergency use.

Technical Parameters

General Mode

ANSI/FSC

Turbo

Low

Mid

High

Strobe

SOS

OUTPUT

315

LUMENS

130

LUMENS

315

LUMENS

130

LUMENS

RUNTIME

200h

16h

DISTANCE

141m

INTENSITY

5000cd

IMPACT

RESISTANT

WATERPRO

IPX-8 2m ，underwater

EXTRA

FUNCTION

ACCESSORI

H - ostler ,clip, lanyard, spare o ring and rubber switch boot

◎Cree XP-G (R5) LED with a lifespan of 50,000 hours

◎Uses two 3V CR123A batteries (Lithium) or one 18650 rechargeable (Li battery -ion)

◎127 25.4mm (Length) x mm (Diameter)

◎61-gram weight (excluding batteries and the battery tube)

◎Digitally regulated output - maintains constant brightness

◎Reverse polarity protection, to protect from improper battery installation

◎Over heat protection to avoid high-temperature of the surface

◎Anti- - roll, slip resistant body design

◎Tactical tail switch with momentary- on function

◎Side switch in the head

◎Made of durable aircraft- grade aluminum

◎Premium Type III hard- - anodized anti abrasive finish

◎Toughened ultra- - clear glass lens with anti reflective coating

Notice: The above-mentioned parameters (tested by high-quality CR123A Lithium battery in Lab)

are approximate and may vary between flashlights, batteries and environments.

*The flashlight will transfer into the High brightness level after working about 30

minutes in the Turbo. Therefore, the runtime of Turbo output is an accumulated time.

Operation Instruction

Light turning on/off:

Press the tail switch lightly to activate the flashlight momentarily. And press the switch

completely to turn on the flashlight and lock it. Another complete press on it can turn it off.

On/Off Operation:

Depress the tail switch gently to momentarily activate the light. Depress the tail switch completely

to turn on the light and lock it. Another complete press on it can turn it off.

Mode Selecting:

A single press on the side switch in the head to adjust the brightness levels from Turbo → Low

output Medium High circle. → → →

Depress the side switch and hold it for 1 second to enter into Strobe mode.

Depress the side switch and hold it for 3 seconds to enter into SOS mode.

When the flashlight is in Strobe mode or SOS mode, a single press on the side switch to return to

general lighting mode.

The flashlight memorizes the last output in general lighting mode. However, it does not memorize

the mode, so the flashlight works in general lighting mode when it is lighted every time.

Over-heat protection: PD32 will accumulate a lot of heat when it is working in Turbo output. To

avoid the influence of using experience due to the high temperature, the flashlight will

automatically transfer into the high brightness level by working in Turbo output for over 30

minutes. If the Turbo output is needed continually, just reset it again.

Notice: The video for PD32 operation can be watched and downloaded from Fenix official

website, please log onto the service channel ->light operation video.

Battery Specifications

Type

Dimensions

Nominal

voltage

Usability

Non- rechargeable Battery

(Lithium)

CR123A

Recommended

√

√√

Rechargeable Battery

(Li- ion)

16340

3.7V

Banned

××

Rechargeable Battery

(Li- ion)

18650

3.7V

Cautious

！

！！

Rechargeable Lithium

iron phosphate battery

16340

3.2V

Usable

√

√√

Rechargeable Lithium

iron phosphate battery

18650

3.2V

Banned

××

Caution: please do not mix batteries of different size or type, or it will ruin the

batteries or flashlight.

Battery Replacement

Unscrew the tail cap to insert the batteries with the anode side (+) toward the light's head, screw

the tail cap to test.

Usage and Maintenance

◎18650 Li-ion batteries are industrial batteries and not for domestic use. Using inferior batteries

or misusing batteries (short circuit or high temperature, etc) may cause combustion and explosion

which will damage people and their property. Therefore, when using such batteries, users will

agree to take the relevant responsibility voluntarily. Quality Li-ion batteries with protective circuit

can lower the risks to some degree.

◎Please don't disassemble the sealed head, doing so can cause damage to the flashlight and will

void the warranty.

◎Please use battery of high quality, and take out the battery if the flashlight will not be used for a

long time, or it may cause damage from electrolyte leakage or battery explosion.

◎The o- o-ring may be worn out after using for a long time. If it happens, please replace the ring

with a new one to keep the flashlight properly sealed against water.

◎Please clean the contacts of your light from time to time, especially if the light flickers or

doesn't light up. There may be several reasons for a flickering or not working light:

Reason A: The battery needs replacing.
