Strona 1/8
9
Fig. 1
INDEX
1. Identification of external components Pag. 9
2. Features Pag. 10
3. Accesories Pag. 10
4. Installation of coffee machine Pag. 10
5. Water filling in the boiler Pag. 11
6. Main power switch Pag. 11
7. Pressure gauge Pag. 11
8. Machine start-up Pag. 12
9. Portafilter locking into the group Pag. 12
10. Coffee brewing Pag. 12
11. Control panel Pag. 13
11.1 Electronic control panel features
11.2 Programmation dosage of the electronic control panel
11.3 Electronic control panel alarms
12. Heating-up liquids Pag. 14
13. Hot water for infusions Pag. 14
14. Coffee machine with built-in grinder Pag. 14
15. Cleaning of coffee machine Pag. 15
16. Cleaning of group Pag. 15
17. Water softener device Pag. 16
18. Possible failures Pag. 16
19. Pieces of advice Pag. 16
20. Cautions Pag. 16
1. Identification of external components
PLEASE READ CAREFULLY THIS INSTRUCTIONS MANUAL BEFORE INSTALLING
OR USING THE COFFEE MACHINE
1. Steam knob
2. Boiler pressure gauge
3. Hot water knob 4. Coffee brewing button
5. Touchpad
6. Signal light
7. Adjustable leg
8. Main power switch
9. Portafilter
10. Grouphead
11. Manual boiler
refill
12. Water level indicator
ENGLISH
10
2. Features
(*) The machine is prepared to be wired: 3 phases, neuter and earth.
3. Accesories
• For Mini models:
1 complete portafilter 2 cups + 1 complete portafilter 1 cup + small flexible hose of 1/2 metre and 1
membrane group cleaning.
• For models: 2, 3 and 4 groups.
2 complete portafilter for two cups, in two groups machine.
3 complete portafilter for two cups, in three groups machine.
4 complete portafilter for two cups, in four groups machine.
+ 1 complete portafilter for 1 cup.
+ 1 small flexible hose of 1/2 metre.
+ 1 membrane cleaning group.
4. Installation of coffee machine
The machine, once it is installed on its coffee cabinet, it should be horizontal as much as posible (use its
adjustable legs) so the coffee will be equally distributed in all the coffee cups.
-Wiring:
Wiring of coffee machine must be done by qualified staff, always following the safety instructions:
a) Before plug in the machine, make sure the voltage of the supply mains correspond to the ratings
indicated on the nameplate featuring the appliance´s technical data.
b) The wall socket must be fitted with an earth contact. Make sure the earth system is efficient and in
conformity with current safety rules. It is compulsory to earth the machine.
c) You should protect the electric line of the installation with a magnetothermic switch for the machine
specified on the nameplate.
d) You should have a differential relay in accordance with the characteristics of the installation.
e) Check the rating of the system and cable are suitable for the power absorbed by the machine.
f) Do not use extensión cable or plug adapter for multiple wall sockets.
-Hydraulic installation:
Using the small flexible hose which is in the machine, hook it up to a stainless connection hose 3/8” male,
with by-pass valve. Placement of a water softener filter between the valve and the machine is compulsary (among
all the spare parts you should have another small flexible hose of 50 cm in order to connect both water softener
filter and valve). In the following chapter we will explain how to regenerate the resines of the water softener filter,
so it can continue trapping the lime.
Model
Number
Group
Sizes mm.
A B C
Boiler
Litres
Power (W)
Heater Total
Voltage
Vac
Weight
Kg.
Mini with
grinder
1 500 600 690 6 2500 3115 230 47
Mini with
grinder
1 500 600 690 6 2000 2615 115 47
Mini 1-2 500 600 510 6 2500 2850 230 40-50
Mini 1-2 500 600 510 6 2000 2350 115 40-50
2 Groups 2 685 600 510 11,5 3000 3235 230 60
2 Groups 2 685 600 510 11,5 4500 4683 (*) 60
2 Groups with
grinder
2 710 600 690 11,5 3050 3675 230 67
3-4 Groups 3-4 975 600 510 17,5 4000 4200 230 85
3-4 Groups 3-4 975 600 510 17,5 6000 6200 (*) 85
ENGLISH
11
Fig. 2
The manufacturer is not liable for the injuries or damages on people and/or animals, as well as
damages on equipment, caused by a improper installation of the coffee machine.
5. Water loading in the boiler
The water level must be between the maximum and the minimum level. To increase the water level press the
manual boiler refill.
- Machines with electronic control panel have electronic boiler refill control.
- Machines without water level indicator, have electronic boiler refill control.
6. Main power switch
For all Mini models:
• The general switch is luminous.
For all models:
• The general switch is a knob, -see (8)Fig.1
7. Pressure gauge
The pressure gauge shows
the pressure
inside the boiler.
Water level indicator
Manual boiler refilling
ON OFF
Fig. 3
Pressure-Temperature Ratio
110
115
120
125
0,6 0,7 0,8 0,9 1 1,1 1,2
Pressure (Bar)
Temperature (ºC)
ENGLISH
