SF776SW
OWNER'S MANUAL
Wall Mount Speaker
Wall Mount Speaker
SF776SW
Safety Tips
Readers
Warning Such as the inappropriate use of staff will cause
injury, death and property damage.
● Please be sure to use the former reading detailed notes.
● Really pay attention to this manual and a safety with the important warning.
● Recommend that you keep this manual for future reference.
When installed loudspeakers
● Restricted by the provisions of the speakers on the voltage, such as the
use of high voltage may cause electric shock or fire disaster. Is no pruning,
distorted, or replacement of damaged wires.
● Avoid instability in the installation or set up speakers, such as shaking the
table or flat surface , the speaker can avoid falling caused personal injury
or property damage.
● Speakers will be installed in support of the speaker or the weight of a solid
shelf. Speaker swap can be avoided caused personal injury or property
damage.
● Wet hands must not be admitted into or plugs, may lead to electric shocks.
● The allocation of plugs, make sure that pull plugs, rather than pull wires.
The use of a damaged power line of machinery may cause fire or electric
shock.
● Mobile speaker, you plug the prior allocated. If the speaker and plugs may
be moving together will cause fire or electric shock.For plugs,identified as
plugs for grip.
● Will not be allowed to speakers on the vent cover. May cause internal
heating caused by the fire.
Common warning signs and security
The manual shown warning signs and security is to prevent the improper
operation due to personal injury arising from the loss of property, please
read before using this product must understand that this manual security
symbols and Warning to indicate fully aware of potential risks.
Dear customers,your use of the broadcasting company speaker series. We
would like to extend my heartfelt thanks to all of the Company manufactured
products have been tested before, the commitment to keep its quality. Loud -
speakers broadcast Pan-for hotels, commercial buildings, supermarkets,
schools, leisure and entertainment venues, is your ideal choice. For your
installation, commissioning and use of this product, the installation please
read this note.
Model
Power Taps@100V
Max Pow er
Imp edance
SPL(1W/1M)
Fre q Resp
Wall Mount Speaker
60W
120 W
166Ω
92d B
60- 20 KHz
SF7 76SW
20.00 mm
40.00 mm
Dimension
Installation
Specifications
Label Stickers
φ
10 mm φ
4m m
φ
13 .5 mm 20 6m m
(Figure:Speaker hole size)
5
5. The completion of speakers in the
walls of the entire installation
process.
1 2
34
Wall Wall
Wall Wall Wall Wall
2. (Figure) With measuring tools, measure
parts speaker hole and the hole size and
the distance between places, and selected
in line with the screw hole will be fixed for-
tunately, speaker wall accessories.
1. Speaker weight of 4.6Kg,
must be chosen by our
body strong and avoid
unstable speakers falling
or injuries.
3. Wall speaker installation method to
choose any of the two.
4. The horn gently into the accessories
have been installed on the walls, the
speakers up and down with two holes
the other two parts align with the nut.
selected in line with the horn screw
hole bit, fixed.
SF776SW
92dB
60-20KHz
340 220 225 mm× ×
4.6Kg
166Ω
60W
120W
SF776SW
SF776SW
Model
Power Taps@100V
Max Power
SPL(1W/1M)
Freq Response
Weight
Dimensions
Impedance
220mm 225mm
340mm
