Installation manual for EK- Supreme HF VGA HD7970 Cu Adapter

for use with - “ ” mounting EK VGA Supreme HF Easy Mount system

This product is intended for installation only by expert users. Please consult with a qualified technician for installation. installation may result in damage to your equipment. EK Water Blocks assumes no liability Improper

whatsoever, expressed or implied, for the use of these products, nor their installation. The following instructions are subject to change without notice. Please visit our web site at for updates. Before www.ekwaterblocks.com

installation of this product please read important notice, disclosure and warranty conditions printed on the back of the box.

The barb hose fittings require only a small amount of force to screw them in; otherwise the high flow fittings might break. These fittings do not need to be tightened with much force because the

liquid seal is made using o- rings. EK recommends only market tested premixed coolants with anticorrosion additive and algaecide for your liquid cooling system.

STEP : 1 PREPARING YOUR HARDWARE STEP 3: ATTACHING WATERBLOCK

CLEANING THE GPU. Wipe off G –abrasive PU (by using non

cloth or Q-tip). EKWB does not recommend using any liquids for

removing paste.

APPLYING THERMAL COMPOUND. Apply thermal compound:

lightly coat

AMD Tahiti

series GPU chip with for example Arctic

Cooling MX or MX- ™ 2 -4 ™ thermal grease. EKWB recommends

to apply thermal grease in cross form for best performance (see

sample picture).

Apply thermal compound on the top of the copper adapter plate

as well!

Tahiti XT / Pro GPU

e.g. Radeon HD 7970/7950

Please make sure to install the waterblock so the G1/4 threaded inlet/outlet ports are turned away

from the PCI ! Only this way you will be able to connect block properly into loop.-e connector slot

REQUIRED TOOLS AND MOUNTING SCREWS:

phili ps screwdriver thermal grease

!!!VERY IMPORTANT!!!

Tahiti XT/PRO GPU:

Use enclosed 0.5mm PVC

washers. Do not use POM

standoffs!

Thumb nut is to be fastened

by hand. Please use enclosed

allen key only if necessary.

Once thumb nut can't be

turned any more the

maximum mounting force has

been reached.

If the mounting screw

eventually starts turning

maximum force has been

reached.

M2.5x6 screws

Spring

Polyamid washers

Mounting

screw

Thumb nut

EK-VGA Supreme

HF HD7970 Cu

Adapter
