Instrukcja obsługi Earthworks P30/C

Earthworks mikrofon P30/C

Przeczytaj poniżej 📖 instrukcję obsługi w języku polskim dla Earthworks P30/C (2 stron) w kategorii mikrofon. Ta instrukcja była pomocna dla 5 osób i została oceniona przez 2 użytkowników na średnio 4.5 gwiazdek

Pobierz PDF
Strona 1/2
earthworksaudio.com
Product Registration
To help you get the most out of your
Earthworks purchase, please take a
moment and register your product with us
online at .earthworksaudio.com/register
Service & Repair
If you have any problems with your
Earthworks products, please contact our
Service & Repairs Department.
Email: returns@earthworksaudio.com
Telephone: (603) 654-2433, ext. 119
MADE IN USA
Printed in USA
User’s Guide
July 11, 2018
Pin 1
“Shield”
Pin 2
“+”
Pin 3
“ ”-
Description
Earthworks P30/C is a directional pre-polarized con-
denser High Denition Microphone™ with a rst-order
cardioid pickup pattern directly coupled to a dedicated
wideband, low output impedance transformerless pre-
amplier. The P30/C requires a standard 24-48V Phan-
tom Power supply. It features a frequency response from
20Hz to 30kHz, fast impulse response, very low handling
noise, uniform polar pattern, and high SPL handling ca-
pabilities. It provides excellent uncolored rejection of
sounds arriving off-axis. Each microphone is delivered
with its own calibration chart providing the individually
measured frequency response curve. A mounting clip is
included with the microphone. The P30/C is protected
by US Patent No. 6,091,829.
Applications
Earthworks P30/C is easy to operate. Connect the mi-
crophone to a microphone preamplier supplying 24-
48V phantom power using a standard XLR microphone
cable. Please allow up to one minute for the microphone
to settle. Plugging in the microphone “hot” (phantom
power already present at the input) will not damage the
microphone, and is actually preferred for faster settling.
It is normal for any phantom powered mic to “pop” when
plugged in or powered up. Make sure to mute the signal
to speakers or headphones when phantom power is rst
applied.
The excellent performance characteristics of the P30/C
give it a very wide range of application possibilities. With
its 5-inch exible neck and small microphone head, this
high-quality microphone could be placed where other
microphones could not, such as under the strings of an
acoustic bass. The P30/C is an ideal choice for record-
ing or live sound applications using percussion, acoustic
or amplied instruments, or choir when using micro-
phone stands. It is superior for choir because it doesn’t
spotlight; rather, it picks up an entire section with no hot
spots.
This microphone has no removable parts.
Care of Microphone
Earthworks P30/C microphone is a precision instrument
designed and built to provide years of excellent perfor-
mance. Following these simple rules will help to protect
your investment in the P30/C:
Avoid touching the front protective screen.
Never attempt to disassemble the microphone –
it cannot be opened.
Avoid extreme heat and condensing humidity.
Allow the microphone to warm up in the case
when bringing it in from the cold weather.
Rough handling may damage the microphone
even if no visible marks are left.
When not in use keep the P30/C in its case.
•
•
•
•
•
XLR Output Connector Assignment of P30/C
Specications
Frequency Response: 20Hz to 30kHz
Polar Pattern: Cardioid
Sensitivity: 20mV/Pa (-34dBV/Pa)
Power Requirements: 24-48V Phantom, 10mA
Peak Acoustic Input: 145dB SPL
Output: XLR-3
Output Impedance: 65Ω, balanced between pins 2 & 3
Minimum Load: 600Ω between pins 2 & 3
Noise: 20dB, A equivalent
Dimensions L x D: 250 x 22 mm (10 x .860 in.)
Weight: 225g (.5lb)
Impulse Response of P30/C (typical)
Polar Response of P30/C (typical)
Specications are subject to change without notice.
Frequency Response of P30/C (typical)
