Datasheet

DIGITUS 1D Barcode Hand Scanner

DA-81001

EAN 4016032473633

1D Barcode Scanner, bi-directional 200 scans/sec, 2 m USB-RJ45

Cable

The DIGITUS® 1D Barcode Scanner operates reliably and

economically. Its ergonomic design makes it easy to handle, an

excellent choice for a wide variety of working environments such as

retail, logistics and commerce of all kinds. With 200 scans per minute,

this bidirectional scanner delivers ideal results. The manual scanner is

suitable for high-resolution barcodes with up to 90 characters. Each

scanning process is confirmed with visual and auditory signals and the

scanner supports the most popular code types. Wide scan angles

ensure even faster barcode detection. The scanner is dust-protected

and water-resistant, impacts are absorbed by the silicon cover to

protect against damage.

High-resolution hand scanner for reliable use in retail and

logistics

• 1D Scan

• Power consumption: 3.3 -5 V DC, 100 mA (1 µA while idle)

• Power supply: USB

• Scan type: bidirectional

• Sensor: Linear

• CPU: ARM 32-Bit Cortex

• Interface: USB

• Light source: 650 nm visual laser diode

• Trigger: Pushbutton

• Number of scans: 200 per second

• Error rate in bits: 1/5 million, 1/20 million

• Resolution: ≥3.3mil

• Scan width: 30 cm

• Depth of field: 3.3 mil @ 2 mm-100 mm, 10 mil @2 mm-350 m;

15.6 mil @ 5 mm - 600 mm; 35 mil @ 10 mm-1000 mm

• Scan angle: Angle of rotation ±30°, angle of inclination ± 45°,

angle of declination ± 60°

• Decoding types: EAN-8, EAN-13, EAN-128, Code 39, Code 93, UPC,

GS1 Databar, GS1-128, ISSN, MSI, Industrial 2 of 5, JAN-8, JAN-13,

Code 32, IATA, ITF, ITF-14, Matrix 2 of 5, ITF-6, Rss limited, Rss

extended, Industrial 25, Code 128, Codabar, Big Code

• Button cycle: 500,000 times

• Laser cycle: 10,000 times

• Compatible with Windows/Android/iOS/Mac/Linux systems

• Material: ABS + PC

• Protection type: IP54

• Operating temperature: -20 °C to +50 °C

• Storage temperature: -40 °C to +70 °C

• Cable: 2 m (USB - RJ45)

• Dimensions (HxWxD): 16.5 x 6.3 x 8.7 cm

• Weight: 110 g

• Color: Black/gray

Package contents

• 1 x Manual Barcode Scanner 1D

• 1 x Scanner holder

• 1 x Cable, USB - RJ45, 2 m

• 1 x QIG

Logistics

Number

(pcs)

Weight

(kg)

Depth

(cm)

Width

(cm)

Height

(cm) cm³

Packaging Unit Carton 40 11.20 41.60 44.00 38.00 69,555.20

Packaging Unit Inside 1 0.28 10.00 18.50 8.00 1,480.00

Packaging Unit Single 1 0.28 10.00 18.50 8.00 1,480.00

Net single without Packaging 1 0.11 8.70 16.50 6.30 904.40

www.digitus.info Druckfehler, Irrtümer und technische Änderungen sind vorbehalten. | Printing errors, falsities and technical changes remain reserved. 1

Datasheet

More images:
