Strona 1/8
HeadLine
Guitar Switching System
User Manual
DACS Ltd, Unit A19 Stonehills, Shields Road, Gateshead, NE10 0HW
www.dacs-audio.com sales@dacs-audio.com
The DACS HeadLine Guitar Switching System
Welcome
Thank you, from all at DACS, for investing in this product.
We take pride in our work and know this HeadLine will give you years of exemplary service. While
this product was initially developed as a client solution, we have pushed the feature set to produce a
fully developed and reliable system for handling multi-amp and cabinet guitar setups.
I have no doubt that it will become an indispensable tool in your studio’s arsenal.
Dr Douglas Doherty
Managing Director
Conformities
This product conforms to the following Directive’s standards
Application of Council Directive:
89/336/EEC
Standards to which Conformity is Declared:
Radiated Emissions to Specification EN50081-1
Conducted Emissions to Specification EN50081-1
Electro Static Discharge to Specification EN50082-1
Fast Burst Transients to Specification EN50082-1
DACS Ltd, Unit A19 Stonehills, Shields Road, Gateshead, NE10 0HW
www.dacs-audio.com sales@dacs-audio.com
Introduction
When Jeff Waters (of Canadian metal band Annihilator) was working on his latest album, he wanted
a way to compare and reconfigure his many boutique amplifiers and cabinets without the lengthy
process of manually swapping cables. Accurate comparisons between the different combinations
were near impossible and the time taken between setup changes interrupted his workflow. Our
design solution allowed Jeff to sit in his control room sweet spot and configure his collection in
seconds; he was achieving in a morning what had often taken up to two days.
What it does
The DACS HeadLine allows you to connect 8 amplifiers and 4 speaker cabinets. From there, you can
select any connected amplifier and route it to a speaker or, if desired, two speakers simultaneously.
The automatically detects whether loudspeakers are connected and only allows you to HeadLine
select channels which have speakers connected.
The is packaged as two 1U rack enclosures. The first unit houses the user interface for the HeadLine
guitarist or engineer and the second unit is a relay switching box that sits next to the amplifiers The .
units connect with a standard RJ45 network cable for easy routing and cable management.
The digitally-controlled relay switching ensures amp loads are maintained and the guitar input is
muted during switching. The illuminated switches on the user interface indicate clearly which amp
and speaker(s) are selected.
