Strona 1/4
Quick Installation Guide
1Connect a computer to the LAN port of the router with an
RJ45 cable properly. If your computer is configured with
a fixed IP, change it to Obtain an IP address automatically.
2Launch a web browser, and enter http://cudy.net/ or
http://192.168.10.1/ in the address bar. Use admin for
password to log in.
Note: If the login window does not appear, please refer to FAQ > Q1.
3After a successful login, you can configure the function by
clicking the menu on the top of the screen.
Enjoy the internet!
Driver & Manual:
www.cudy.com/download
Email:
support@cudy.com
Need help?
Log In
Auto
Password
http://cudy.net/
Internet
Modem
15 4 3 2
WANLAN WAN/LAN
Gigabit VPN Router
Power
System Reset
R700
Connection
R700
Note: Use the power
adapter provided in the
package to power on
the router.
15432
WANLAN WAN/LAN
Gigabit VPN Router
Power
System Res et
R700
Router
PC
System Status General Settings Advanced Settings Diagnostic Tools
WAN1
Status Not connected
Protocol DHCP client
Status -
More Details
DHCP Server
Status Enabled
IP Start XXX.XXX.XX.X
IP End XXX.XXX.XX.X
More Details
LAN
Status Enabled
IP Address XX.XXX.XX.X
MAC-Address XX:XX:XX:XX
More Details
3 Gigabit
WAN/LAN Ports
1 Gigabit
WAN Port
1 Gigabit
LAN Port
Reset
Configure WAN/LAN Ports: -> General Settings WAN Mode
Setup Internet Connection: General Settings WAN Settings ->
Setup VPN Parameters: -> General Settings VPN
Q1: What can I do if the login window does not appear?
A1: If the computer is set to a static IP address, change its settings
to obtain an IP address and DNS server address automatically.
A2: http://cudy.net/ 192.168.10.1 Verify that or is correctly
entered in the web browser .
A3: Use another web browser and try again.
A4: Reboot your router and try again.
A5: Disable and then enable the network adapter being used.
Frequently Asked Questions (FAQ)
FCC Statements:
This device complies with part 15 of the FCC Rules. Operation
is subject to the following two conditions: (1) This device may
not cause harmful interference, and (2) this device must
accept any interference received, including interference that
may cause undesired operation.
EU Declaration of Conformity
Cudy hereby declares that the device is in compliance with the essential
requirements and other relevant provisions of directives 2014/30/EU, 2014/35/EU,
(EU) 2015/863 and 2011/65/EU.
The original EU declaration of conformity can be found at http://www.cudy.com/ce.
Cudy erklärt hiermit, dass das Gerät den grundlegenden Anforderungen und
anderen relevanten Bestimmungen der Richtlinien 2014/30/EU, 2014/35/EU, (EU)
2015/863 und 2011/65/EU entspricht.
Die originale EU-Konformitätserklärung finden Sie unter http://www.cudy.com/ce.
Cudy declara por la presente que el dispositivo cumple con los requisitos esenciales
y otras disposiciones relevantes de las directivas 2014/30/EU, 2014/35/EU, (EU)
2015/863 y 2011/65/EU.
La declaración de conformidad de la UE original se puede encontrar en http://ww-
w.cudy.com/ce.
Cudy dichiara che il dispositivo è conforme ai requisiti essenziali e ad altre
disposizioni pertinenti delle direttive 2014/30/UE, 2014/35/UE, (UE) 2015/863 e
2011/65/UE.
La dichiarazione di conformità UE originale è disponibile all'indirizzo
http://www.cudy.com/ce.
Cudy déclare par la présente que l'appareil est conforme aux exigences essentielles
et aux autres dispositions pertinentes des directives 2014/30/UE, 2014/35/UE, (UE)
2015/863 et 2011/65/UE.
La déclaration de conformité UE originale est disponible sur
http://www.cudy.com/ce.
Ελληνικό:
Η Cudy δηλώνει ότι η συσκευή συμμορφώνεται με τις βασικές απαιτήσεις και άλλες
σχετικές διατάξεις των οδηγιών 2014/30/ΕΕ, 2014/35/ΕΕ, (ΕΕ) 2015/863 και
2011/65/ΕΕ. Η αρχική δήλωση συμμόρφωσης ΕΕ βρίσκεται στη διεύθυνση
http://www.cudy.com/ce.
Cudy verklaart hierbij dat het apparaat voldoet aan de essentiële vereisten en andere
relevante bepalingen van de richtlijnen 2014/30/EU, 2014/35/EU, (EU) 2015/863 en
2011/65/EU.
De originele EU-conformiteitsverklaring is te vinden op http://www.cudy.com/ce.
A Cudy declara que o dispositivo está em conformidade com os requisitos essenciais e
outras disposições relevantes das diretivas 2014/30/UE, 2014/35/UE, (UE) 2015/863 e
2011/65/UE. A declaração de conformidade original da UE pode ser encontrada em
http://www.cudy.com/ce.
Cudy oświadcza niniejszym, że urządzenie jest zgodne z zasadniczymi wymaganiami i
innymi stosownymi postanowieniami dyrektyw 2014/30/UE, 2014/35/UE, (UE) 2015/863
i 2011/65/UE.
Oryginalną deklarację zgodności UE można znaleźć na stronie http://www.cudy.com/ce.
Cudy, cihazın 2014/30/EU, 2014/35/EU, (EU) 2015/863 ve 2011/65/EU direktiflerinin
temel gereksinimlerine ve diğer ilgili hükümlerine uygun olduğunu beyan eder.
Orijinal AB uygunluk beyanı http://www.cudy.com/ce adresinde bulunabilir.
Cudy erklærer herved at enheten er i samsvar med de grunnleggende kravene og
andre relevante bestemmelser i direktivene 2014/30/EU, 2014/35/EU, (EU) 2015/863 og
2011/65/EU.Den originale EU-samsvarserklæringen finner du på
http://www.cudy.com/ce.
Cudy erklærer hermed, at enheden er i overensstemmelse med de væsentlige krav
og andre relevante bestemmelser i direktiverne 2014/30/EU, 2014/35/EU, (EU)
2015/863 og 2011/65/EU.
Den originale EU-overensstemmelseserklæring kan findes på
http://www.cudy.com/ce.
Cudy vakuuttaa täten, että laite on direktiivien 2014/30/EU, 2014/35/EU, (EU)
2015/863 ja 2011/65/EU olennaisten vaatimusten ja muiden asiaankuuluvien
määräysten mukainen. Alkuperäinen EU-säädöstenmukaisuusilmoitus on osoitteessa
http://www.cudy.com/ce.
Cudy intygar härmed att enheten är i överensstämmelse med de väsentliga kraven
och andra relevanta bestämmelser i direktiven 2014/30/EU, 2014/35/EU, (EU)
2015/863 och 2011/65/EU.
Den ursprungliga EU-försäkran om överensstämmelse kan hittas på http://ww-
w.cudy.com/ce.
Cudy tímto prohlašuje, že zařízení je v souladu se základními požadavky a dalšími
příslušnými ustanoveními směrnic 2014/30/EU, 2014/35/EU, (EU) 2015/863 a
2011/65/EU.Originál EU prohlášení o shodě lze nalézt na
http://www.cudy.com/ce.
Cudy týmto vyhlasuje, že zariadenie je v súlade so základnými požiadavkami a
ďalšími príslušnými ustanoveniami smerníc 2014/30/EÚ, 2014/35/EÚ, (EÚ) 2015/863
a 2011/65/EÚ. Originál EU vyhlásenia o zhode možno nájsť na
http://www.cudy.com/ce.
Support
For technical support, the user guide and more information,
please visit:
http://www.cudy.com/support
support@cudy.com
LED and Button
Name Indication
Power
System
Link/Act
Reset
On: Power on
Off: Power off
Blinking slowly: System startup process
Blinking fast: Factory reset process
Steady on: System startup is complete
On: Connecting to a device but no activity
Off: No device connected to the corresponding port
Blinking: Transmitting or receiving data
Press and hold 6 seconds to reset the router to its
factory default settings.
810600159
GNU General Public License Notice
The software code in this product was created by third parties and is
licensed under the GNU General Public License ("GPL"). If applicable,
Cudy ("Cudy" in this context refers to the Cudy entity offering respective
software for download or being in charge of the distribution of products
that contain respective code) makes the corresponding GPL source code
available upon request via the official website, either independently or
with the assistance of third parties (such as Shenzhen Cudy Technology
Co., Ltd.).
For GPL-related questions, email support@cudy.com. In addition, Cudy
offers a GPL-Code-Centre under https://www.cudy.com/gplcodecenter-
download where users can get the GPL source codes used in Cudy
products for free. Please note, that the GPL-Code-Centre is only provided
as a courtesy to Cudy's customers but may neither offer a full set of source
codes used in all products nor always provide the latest or actual version
of such source codes.
The GPL code used in this product is subject to the copyrights of one or
more authors and is supplied WITHOUT ANY WARRANTY.
Specyfikacje produktu
| Marka: | Cudy |
| Kategoria: | router |
| Model: | R700 |
