quickstart guide
CAM-IPTZ-100
www.crestron.com
Specifications subject to
change without notice.
CAM-IPTZ-100
For details, refer to the latest version of the CAPTURE-HD
& CAPTURE-HD-PRO Operations Guide, Doc. 7233.
QUICKSTART DOC. 7322A (2032910) 12.11
PTZ Camera for Capture HD™
The CAM-IPTZ-100 is a Sony® PTZ camera capable of
capturing high-quality video from a wide range of angles.
The CAM-IPTZ-100 captures crystal clear, high-contrast
images even in low light and is capable of dual streaming
in both JPEG and MPEG4 formats. When connected to
Crestron's state of the art Capture HD™ High-Definition
Capture Recorder, the CAM-IPTZ-100 is the perfect
camera for capturing various angles and views of a
presentation.
A. Accessories
The interface cables are available separately.
B. Hookup
Connect the camera to the CAPTURE-HD or CAPTURE-HD-PRO as illustrated to the right.
Connection to the CAPTURE-HD-PRO (not shown) is the same.
C. Installation
Install the camera as described in “Installer Mode” in the “Operation section of the latest ”
version of the CAPTURE-HD and CAPTURE-HD-PRO Operations Guide (Doc. 7233). The
manual is available from the Crestron Web site at www.crestron.com/manuals.
If your installation includes the CAPTURE-TPMC-4SM touch screen controller, refer to the
“Configuration section of the latest version of the CAPTURE-TPMC-4SM Operations Guide ”
(Doc. 7293).
D. Configuration Settings
In preparation for operation in a CaptureLiveHD™ system, Crestron installed a configuration
file that modified the following settings from the camera’s factory default values:
Camera | Video CODEC
• Image 1 CODEC is JPEG
• Image 1 Image Size is 384 X 288
• Image 1 Frame Rate is 15
Network | Hostname
CAM-IPTZ-100-<serial number>
(e.g., if the serial number on the body of the camera is 12345, the hostname will be
“CAM-IPTZ-100-12345”)
NOTE: For additional information and specifications for the CAM-IPTZ-100, refer to the
Crestron® Web site (www.crestron.com). Refer also to the manufacturer’s information and
materials included with the camera. CAM-IPTZ-100
(Sony model
SNC-CH110)
CAPTURE-TPMC-4SM
CEN-SW-POE-5
48 VDC
Power Supply
100-240 VAC
100-240 VAC
12 VDC
Power
Supply
CAPTURE-HD Camera Hookup
NOTE: The camera produces a video stream that can be viewed on the CAPTURE-TPMC-4SM
touch screen controller.
The specific patents that cover Crestron products are listed at www.crestronpatents.com.
Crestron, the Crestron logo, Capture HD, and CaptureLiveHD are either trademarks or registered trademarks of
Crestron Electronics, Inc. in the United States and/or other countries. Sony is either a trademark or registered
trademark of Sony Corporation in the United States and/or other countries. Other trademarks and trade names
may be used in this document to refer to either the entities claiming the marks and names or their products.
Crestron disclaims proprietary interest in the marks and names of others.
© 2011 Crestron Electronics, Inc.
