Instrukcja obsługi Colormetrics P1000
Colormetrics
Skrzynka
P1000
Przeczytaj poniżej 📖 instrukcję obsługi w języku polskim dla Colormetrics P1000 (44 stron) w kategorii Skrzynka. Ta instrukcja była pomocna dla 14 osób i została oceniona przez 2 użytkowników na średnio 4.5 gwiazdek
Strona 1/44
1
www.colormetrics.info metrics P1000Color
Errors excepted; subject to change www.colormetrics.info
P1000
User Manual
Version 1.0
2www.colormetrics.infoColormetrics P1000
Copyright 2018 Colormetrics All Rights Reserved.
This manual, software and rmware described in it are copyrighted by their respective owners and
protected under the laws of the Universal Copyright Convention. You may not reproduce, transmit,
transcribe, store in a retrieval system, or translate into any language, in any form or by any means,
electronic, mechanical, magnetic, optical, chemical, biological, molecular,m manual, or otherwise,
any part of this publication without the express written permission of the publisher.
All products and trade names described within are mentioned for identication purpose only. No
aliation with or endorsement of the manufacturer is made or implied. Product names and brands
appearing in this manual are registered trademarks of their respective companies.
The information published herein has been checked for accuracy as of publishing time. Norepre-
sentation or warranties regarding the tness of this document for any use are made orimplied by the
publisher. We reserve the right to revise this document or make changes in the specications of the
product described therein at any time without notice and without obligation to notify any person of
such revision or change.
COPYRIGHT
3
www.colormetrics.info metrics P1000Color
SAFETY INSTRUCTIONS
1. Read these instructions carefully. Keep these instructions for future reference.
2. Please disconnect this device from AC outlet before cleaning. Do not use liquid or spray
detergent for cleaning. Use moisture sheet or cloth for cleaning.
3. Please keep your device safe from high levels of humidity.
4. Install the device and its driver on a surface plate. Any tilt plate might cause damage.
5. Do not place anything over the power cord. And avoid people from stepping on it
6. Please be aware cautious note or warnings on the device.
7. If the device will not be used for a long time, please unplug the power cord to avoid damages
by transient overvoltage.
8. Never pour any liquid into the device; this could cause re or electrical shock.
9. If one of the following situations happens, get the device checked by a service personnel:
a. The power cord or plug is damaged.
b. Liquid has penetrated into the device.
c. The device has been exposed to moisture.
d. The device does not work well or you cannot get it work according to user manual.
e. The device has dropped and damaged.
10. Do not leave this device in an environment unconditioned, storage temperature below -20°C or
above 60°C, it may damage the device.
11. Unplug the power cord when doing any service or adding optional kits.
Lithium Battery Caution:
1. 1. Danger of explosion can happen if the battery is incorrectly replaced. Replace only the
original or equivalent type recommended by the manufacture. Dispose used batteries
according to the manufacture’s instructions.
2. Do not remove the cover, and ensure no user serviceable components are inside. Take the unit
to the service center for service and repair.
6www.colormetrics.infoColormetrics P1000
MSR
VFD
2nd Display (8",10")
i-button
Barcode Scanner 1D / 2D
System (with stand)
Power cord
Driver Bank
1-1 Standard Accessories
1-2 Optional Accessories
PACKING LIST
7
www.colormetrics.info metrics P1000Color
2-1 Rear View
2-2 Back View
Please make sure the 19V DC is plugged in the right direction before plugging in DC jack.
SYSTEM VIEW
USB Port/MSR/I-Button
(optional)
HDD Bracket
VFD Cover / 2nd Monitor
(optional)
10 www.colormetrics.infoColormetrics P1000
1. LVDS connector Pin Definition
No. No.Definition Definition
16- -bit/8 bit selection 2GND
3DATA3+ DATA34-
5GND 6CLK+
7CLK- 8GND
9DATA2+ DATA210 -
11 GND 12 DATA1+
13 DATA1- 14 GND
15 DATA0+ DATA016 -
17 GND GND18
19 +3.3V +3.3V20
2. DC Jack Pin Definition
No. Definition
1+19V
2Ground
3+19V
PIN DEFINITION
11
www.colormetrics.info metrics P1000Color
You can change the com port voltage by jumper
4. SATA: 22-pin SATA Pin Definition
No. No.Definition Definition
S1 P1GND N/C
S2 SATA_TX0_P P2 N/C
S3 SATA_TX0_N P3 N/C
S4 P4GND GND
S5 SATA_RX0_N P5 GND
S6 SATA_RX0_P P6 GND
S7 P7GND +5V
P8 +5V
P9 +5V
P10 GND
P11 GND
P12 GND
P13 N/C
P14 N/C
P15 N/C
7. Power On/Off connector Pin Definition
No. Definition
1+5V Standby
2+5V Status
3Power On#
4GND
