Strona 1/12

-1-

WIRELESS WEATHER STATION

INSTRUCTION MANUAL

PART NO.: CM7048

Page

1. INTRODUCTION ....................................................................................2

1.1 PACKAGE CONTENTS ....................................................................2

1.2 FEATURES ........................................................................................2

2. INSTALLATION ......................................................................................2

2.1 INSTALLING THE BATTERIES ..........................................................2

2.2 MOUNTING ......................................................................................4

2.2.1 BASE STATION............................................................................4

2.2.2 REMOTE SENSOR......................................................................5

3. OVERVIEW ..............................................................................................5

3.1 BASE UNIT-LCD ................................................................................5

3.2 LED BACKLIGHT ..............................................................................6

3.3 WEATHER FORECASTING ..............................................................6

3.4 WEATHER FORECAST TENDENCY INDICATOR............................7

3.5

PRESSURE SENSITIVITY SETTING FOR WEATHER FORECASTING

........7

3.6 STORM WARNING INDICATOR........................................................7

4. PROGRAM MODE ..................................................................................7

4.1 TIME MODE ......................................................................................8

4.2 INDOOR TEMPERATURE & HUMIDITY MODE ..............................9

4.3 OUTDOOR TEMPERATURE MODE ..............................................10

5. TROUBLESHOOTING ..........................................................................10

6. SPECIFICATION ..................................................................................11

This Operation Manual is part of this product and should be kept in a safe

place for future reference. It contains important notes on setup and operation.

85119 Wireless Weather Station Manual_85119 Wireless Weather Station Man

-2-

1. Introduction

Thank you for purchasing this Wireless Weather Station. Designed for

everyday use, the weather station will prove to be an asset of great

value for your personal use in the home or office. Please read this

instruction manual thoroughly to fully understand the correct operation

of your weather station and benefit from its unique feature.

1.1 Package Contents

• 1 x Weather station base unit

• 1 x remote Sensor with mounting bracket

• Mounting Screws

• Instruction manual

1.2 Feature

1) Indoor humidity (%RH)

2) Wireless outdoor and indoor temperature (°F or °C)

3) Records min. and max. humidity

4) Records min. and max. temperature

5) Weather forecast tendency

6) Forecast icons based on changing barometric pressure

7) Radio controlled time and date with manual setting option

8) Time Zone Setting

9) 12 or 24-hour time display

10) Perpetual calendar

11) Time alarm

12) Can receive up to 3 sensors

13) LED backlight

14) Wall hanging or free standing

15) Included one transmitter

16) Synchronized instant reception

17) Low battery indicator on the receiver

2. Installation

2.1 Installing the Batteries

Note: Please note the polarity when inserting/replacing batteries in

the unit, failure to do so may result in permanent damage. Use good

quality Alkaline Batteries and avoid rechargeable batteries.

85119 Wireless Weather Station Manual_85119 Wireless Weather Station Man

-3-

1) Insert two AAA batteries into the remote sensor. After the remote

sensor is powered up, the sensor will transmit weather data every 8s

for 16 times. After this learning period is over, then the transmitter will

transmit every 48s.

2) Insert two AA batteries into the weather station. When the base

station is powered up, a short beep will sound and all LCD segments

will light up for about 4 seconds before it enters into learning mode

to learn the sensors security code. Every time the remote sensor

is powered up (for example after a change of batteries), a random

security code is transmitted and this code must be synchronized with

the base station to receive weather data. Thus if battery change

happened on remote sensor side, then the base station must be

powered up again to re-Iearn the transmitter.

3) Wait 3 minutes or until the outdoor temperature is displayed in the

weather station. Do not press any keys before outdoor sensor

data received. The wireless weather station can receive up to 3

temperature sensors. If you have purchased additional remote

sensors, repeat step 1) for all extra sensors. However, ensure that

you leave 10 seconds in between the reception of the last sensor and

the set-up of the following sensor. The wireless weather station will

number the sensors in the order of set-up, i.e. the first temperature

sensor will have the temperature displayed with CH1. If you only have

one sensor, won't be displayed.CH1

4) After the learning mode, the base station will start the radio controlled

time reception. The receiver will start RCC time reception period for

10 minutes maximum, and no weather data will be received during

this period of time. If RCC signal can't be synchronized with the

base station within 1 minute, the signal search will be cancelled and

will automatically resume every hour on the hour until the signal is

successfully captured. Regular RF link will be established once RCC

reception routine is finished.

5) Mount the units, ensuring that the receiver can still pick up the signal

from the transmitter. To measure outdoor temperature, place the

transmitter outdoors. It will transmit the temperature from its location.

85119 Wireless Weather Station Manual_85119 Wireless Weather Station Man
