SPM3/SPM3C/SPM3L
Flexible Compact Condenser Microphone for 3.5mm &
Type-C & Lightning Devices
Highlights:
User Manual
SPM3 Introduction:
The SPM3 is a TRRS connector compact directional condenser
microphone optimized for wide range recording& shooting
applications. The unique DSLR & smartphone switch function
makes the microphone output to both camera and smartphone
without auxiliary accessory. The Gain control function is optimized
capturing sounds in frond of it and at greater distances, while
rejecting sounds from the sides and rear. The flexible rotation
180 degrees design makes the microphone capture great range.
The SPM3 includes a furry windscreen for shooting outdoors or in
adverse weather.
Professional supercardioid condenser microphone
Plug & Play working
Flexible rotation 180 degrees design
Camera & Phone function switch
Gain switch with 2 levels(-10dB, 0dB)
No battery needed
①
②
③
① Camera & Phone Switch
② Gain Switch
③ 3.5mm Audio Output
Specification:
Packing List:
Main Feature:
Microphone *1
Furry Windscreen *1
Warranty Card *1
User Manual *1
Shenzhen Shenyao Technology Co., Ltd
CKMOVA is the trademark of Shenzhen Shenyao Technology Co., Ltd
Add: Floor 6, 38th Building, BaoNan Street, LongGang District, Shenzhen
Guangdong, China
Email: sales@ckmova.com
Web: www.ckmova.com
Frequency Response:
SPM3C Introduction:
The SPM3C is a Type-C connector compact directional
condenser microphone optimized for Smartphone, PC & MAC
with Type-C devices. It allows you to adjust low cut function(off
120dB) for clean & crystal sound when recording.
The gain control function is optimized capturing sounds in frond
of it and at greater distances, while rejecting sounds from the
sides and rear. The flexible rotation 180 degrees design makes
the microphone capture great range. The SPM3C includes furry
windscreen for shooting outdoors or in adverse weather.
①
②
③
① Low-cut Switch
② Gain Switch
③ Type-C Audio Output
Main Feature:
SPM3L Introduction:
The SPM3L is a Lightning connector compact directional
condenser microphone optimized for apple Lightning devices.
It allows you to adjust low cut function(off 120dB) for clean &
crystal sound when recording. The gain control function is
optimized capturing sounds in frond of it and at greater distances,
while rejecting sounds from the sides and rear. The flexible
rotation 180 degrees design makes the microphone capture
great range. The SPM3L includes a furry windscreen for shooting
outdoors or in adverse weather.
Type:
Polar Pattern:
Frequency:
Sensitivity:
Signal to Noise Ratio:
Sample Rate/Resolution:
Weight:
Dimension:
Condenser microphone
Supercardioid
50Hz-20KHz
-32dB ± 3dB (0dB=1V/Pa at 1kHz)
72dB SPL
48KHz/16 Bit
12g
81*28*16.4mm(SPM3)
73*28*16.4mm(SPM3C/SPM3L)
③
① Low-cut Switch
② Gain Switch
③ Lightning Audio Output
Main Feature:
①
②
Highlights:
Professional directional condenser microphone
Plug & Play working
Flexible rotation 180 degrees design
Low-cut filter (120Hz)
Gain switch with 2 levels(-10dB, 0dB)
No battery needed
-2.0
0
90
+5.0
0.0
-2.0
-4.0
-6.0
-8.0
-10.0
-12.0
-14.0
-16.0
-18.0
-20.0
-22.0
-24.0 -25.0
180
270o
o
o
o
-10.0
-20.0
Frequency:
dB rel.1V/Pa
500Hz:
1000Hz:
4000Hz:
