READ AND SAVE THESE INSTRUCTIONS
Model HUMCRSTM3134,
HUMXXSTM3034, HUMXXSTM3134
Residential Steam Humidifier
Owner’s Manual
Includes Safety & Operating Instructions
Residential Steam Humidifier
Safety 2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Introduction 4 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Principles of Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Sequence of Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Installation Options and Effect of Water Characteristics. . . . . . . . . . . . . . 6
Operating Modes. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Display Panel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Humidifier Control & Operating Instructions. . . . . . . . . . . . . . . . . . . . . . . . 9
Check the Humidifier Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Additional Information. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Maintenance 10 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
TABLE OF CONTENTS
- 2 -
CAUTION
ATTENTION
Read this manual before installing. This product must be
installed by qualified HVAC and electrical contractors and in
compliance with local, state, federal, and governing codes.
Improper installation can cause property damage, severe
personal injury, or death as a result of electric shock, burns,
or fire.
Read all cautions and instructions.
Read this manual before performing service or maintenance
procedures on any part of the system. Failure to follow all
cautions and instructions could produce the hazardous
situations described, resulting in property damage, personal
injury, or death.
Failure to follow the instructions in this manual can cause
moisture to accumulate, which can cause damage to structure
and furnishings.
EXCESS HUMIDITY
Do not set humidity higher than recommended. Condensation
may cause damage.
SAFETY
- 4 -
The Steam Humidifier delivers humidity in the form of steam to the
conditioned space via the HVAC system duct. The humidifier generates
steam by energizing two electrodes that extend into a canister of water.
Current flowing between the electrodes causes the water to boil, creating
steam. Water is introduced to the humidifier through a fill valve to a fill
cup located in the top of the cabinet. The fill cup serves as an overflow
reservoir and provides an air gap between the humidifier and water
source. The steam canister is filled from the bottom. The canister is seated
in a drain cup assembly which includes a drain valve. The drain and fill
valves work together to maintain water level in the canister to deliver the
rated steam capacity based on the electrical conductivity of the water and
to temper drain water. See for representation of fill and drain Figure 1
system and canister.
Steam is delivered into the airstream through a dispersion tube mounted
in the HVAC system ductwork. Openings in the dispersion tube are fitted
with “tubelets™” which extend into the center of the tube. The design of
the dispersion tube and tubelets distribute steam over a wide area in the
duct and direct any condensed moisture back into the steam hose.
PRINCIPLES OF OPERATION
Thank you for your recent steam humidifier purchase. We appreciate
your business and are pleased to add your name to our growing list of
customers. You have invested in the highest quality equipment available.
Your humidifier will require periodic maintenance to assure continued
consistent performance. See page 10.
Please take a few minutes and read this booklet. This will familiarize
you with the benefits you will receive from the humidifier and help you
understand the routine maintenance that will be required.
INTRODUCTION
Replacement Steam Canisters are available from your installing
contractor. Use only genuine replacement part number 8045HUM.
