Strona 1/4
For more information, contact your local Carrier Controls Expert
©2023 Carrier. All Rights Reserved. Cat. No. 11- -9808 59-01
INTRODUCTION
HyperStat is a wall-mount thermostat. Its thoughtful design ensures that it blends into most
commercial spaces while still giving a fresh and contemporary feel compared to dated
building control interfaces.
PACKAGE CONTENTS
• HyperStat device
• Mounting accessories
SPECIFICATIONS
Power
Power
Power
PowerPower
Power Source: 24V /DC - AC input (+/ 15%)
Peak consumption: 1.4VA Maximum
Operat
Operat
Operat
OperatOperating range
ing range
ing range
ing rangeing range
Temperature 32 to 122°F (0°C to 50°C)
Humidity 20-85% non-condensing.
Commu
Commu
Commu
CommuCommunication
nication
nication
nicationnication
S ensor bus for daisy chained sensor communication and low power 3V dc.
4-wire interface for RS 485 communication @ 115200 baud and 5V
DC, A 100m power source
9 - - 00 928 MHz Mesh IEEE 802.15.4 compliant, for communications to CCU
Bluetooth: BLE 4.1 for commissioning, and communication to wireless sensors
Onboa
Onboa
Onboa
OnboaOnboard Senso
rd Senso
rd Senso
rd Sensord Sensors
rs
rs
rsrs
Temperature range of 32 to 122°F with an accuracy of +/-1°F
Humidity 0 to 100% with an accuracy of 2%
CO2 sensor with a range of - - 0 40,000 ppm, accuracy of +/ 30ppm
VOC sensor; Typical Accuracy: 15% of measured value; TVOC: 0 - 60,000
ppb;
Occupancy sensor based on passive infrared (PIR) with a detection range of
4m with a 15 degree angle-
Light Sensor. Ambient light sensor • <100 LUX resolution • High-accuracy UV
index sensor • Matches erythermal curve
Sound sensor with 40- 120dB response for 100Hz to 10KHz
PM2.5, PM10 sensor (optional). Detection range of 0-1000µg/m3 and accuracy
of +/- 0- - -10µg/m3 (PM2.5, 100µg/m3) or +/ 25µg/m3 (PM10, 0
100µg/m3). - Maximum long term mass concentration precision limit drift:
• 0 to 100 µg/m3 ±1.25 µg/m3/year
• 100 to 1000 µg/m3 ±1.25 % mV/year
Inpu
Inpu
Inpu
InpuInputs
ts
ts
tsts
2 x 10K Type- 2 thermistor inputs with 2% accuracy
2 x 0- A - 10V nalog voltage inputs with 2% detection accuracy (2 10V)
Touch slider for temperature control along with 3 mechanical buttons
HYPERSTAT
(7C- -C2W-X)HS
INSTALLATION GUIDE
Scan this QR
code to get a
more detailed
version of the
Installation
Guide
For more information, contact your local Carrier Controls Expert
©2023 Carrier. All Rights Reserved. Cat. No. 11- -9808 59-01
Outputs
Outputs
Outputs
OutputsOutputs
6 x Relays rated for 24V DC/1A
3 0- - A x 10V or 4 20m analog outputs
2.8" 240x320 pixel TFT display
PRECAUTIONS
:
:
:
: :
• Failure to wire devices with correct polarity when using a shared transformer,
may result in damage to any device powered.
• Never connect or disconnect the wiring with the power ON.
• Do not allow the powered wires to touch the circuit boards.
• Always install complying with all state and local codes.
• Do not assemble the front to the back plate while it is powered on.
• Once Installed the HyperStat takes seven days to auto-calibrate and settles at a
steady state value.
• Avoid mechanical stress on the CO2 sensor to get accurate readings.
MOUNTING
1. HyperStat Interface - Conventional
5. Rubber cover 2
2. HyperStat Main 6. Gang Box
3. Allen head screws
7. PHP screws
4. Rubber cover 1 8. Backplate
For more information, contact your local Carrier Controls Expert
©2023 Carrier. All Rights Reserved. Cat. No. 11- -9808 59-01
1. HyperStat Interface - Conventional
5. Rubber cover 2
2. HyperStat Main 6. Gang Box
3. Allen head screws
7. PHP screws
4. Rubber cover 1 8. External Antenna
1. Place the HyperStat Interface- Conventional and the back plate (only if the gang box is
fixed vertically) on the gang box such that the back plate covers the gang box and fix
these two items to the wall gang box with the PHP screws provided in the box.
2. Now align the HyperStat main to lock onto the HyperStat Interface- Conventional.
3. Use the Allen head screws to make this entire setup tamper- proof.
4. Rubber covers 1 and 2 must be fixed to cover the programming pins.
5. Connect the antenna to the device as shown in the above figure. Rotate the antenna
clockwise to lock in place.it
DIS- ASSEMBLING
1. If the HyperStat is mounted on the wall, hold the front plastic with both hands and pull it
away from the wall.
2. If you are holding the HyperStat in your hands, insert a flat head screwdriver in the notch
provided back (marked by the two arrows shown in the image) between the front and
plastic and twist to separate them.
