Strona 1/13
This thermostat requires 24 Volt AC Power or two (2) properly installed
“AA” Alkaline batteries for proper operation. When connecting 24 Volt
AC Power the batteries may be installed as a backup.
For use only as described in this manual. Any other use
will void warranty.
2020
Single Stage Heat / Cool
Conventional and Heat Pump
1
Specifications
2
About Your Thermostat
3
Installation
4
System Testing
5
Setting User Options
6
Setting Your Program Schedule
7
Operating Your Thermostat
8
Additional Operation Features
9
Thermostat Maintenance
®
Warning
Turn off power to the heating or cooling
equipment before installation.
Attention
For installation by experienced service
technicians only.
2220
Up to 2 Heat / 2 Cool Conventional
Up to 2 Heat / 1 Cool Heat Pump
Read all instructions before proceeding.
This thermostat is compatible with:
 •Singlestageheat/coolconventionalandheatpumpsystems
 •Conventionalsystemsupto2heat/2cool(2220only)
 •
Singlecompressorheatpumpsystemswithanauxiliaryheatstage(2220only)
 •250–750millivoltheatonlysystems
Electrical and control specifications:
 •ElectricalRating:24VoltAC
 •1ampmaximumloadperterminal
 •ACPower:18–30VoltsAC
 •DCPower:3.0VoltDC(2“AA”AlkalineBatteriesIncluded)
 •ControlRange:45°–90°F(7°–32°C)
 •TemperatureAccuracy:+/-1°F(+/-.5°C)
Terminations
 •2020–Rc,Rh,O,B,Y1,W1,G,C
 •2220–Rc,Rh,O,B,Y1,Y2,E/W1,G,W2,C
1
Specifications
2020W-100-05
Model number is located on back of thermostat
Programmable
Thermostats
Detailed
User Guide
1
2
About Your Thermostat
Room Temperature........... Displaysthecurrentroomtemperature
Day of Week......................Displaysthecurrentdayofweek
Program Event Indicator..Indicatesthecurrentprogramevent
Time of Day....................... Displaysthecurrenttimeofday
Low Battery Indicator......
Indicateswhenbatteriesneedtobereplaced
Fan Indicator.................... Indicateswhenthesystemfanisrunning
Hold Mode Indicator.........DisplaysifinHOLDmode
System Status Indicator...Displaysinformationaboutsystemstatus
Set Temperature...............Displaysthecurrentsetpointtemperature
Service Filter Indicator.....Displaysservice/maintenancereminders
1
2
3
4
5
7
5
6
8
9
6
7
8
10
9
10
1
2
4
3
Reset Button..........
Resetsthermostatbacktofactorydefaults
System Switch.......
Selectssystempreference
PROG Button..........Selectsprogrammingmode
HOLD Button.......... Enters/ExitstheHOLDmode(programbypass)
RETURN Button......Returnstonormalfromprogramorsettingmodes
DAY/TIME Button...Usedtosetthetimeanddayofweek
Quick Reference
Instructions........... Storedinslotattopofthermostat
Arrow Buttons....... Usedtoincreaseordecreasesettings
Fan Switch.............Selectsthesystemfanmode
Battery Compartment.... Locatedinbackofthethermostat
11
12
17
13 14 15 16
18
19
11
12
13
14
15
16
17
18
19
2
Install your new Braeburn thermostat in 5 basic steps:
1 InstalltheSub-Base
2 ProvidePower
3 ConnectYourWires
4 SetInstallerSwitches
5 AttachThermostattoSub-Base
Install the Sub-Base:
•Removethesub-basefromthebodyofthethermostat.
•Mountthesub-baseasshownbelow:
1
NOTE: After sub-base installation, you may insert the quick reference card
into the slot on the top of the base.
3
Installation
Warning
Disconnect power before beginning installation.
Thermostat Location
Installthethermostatapproximately5feet(1.5m)abovetheoorinan
areathathasagoodamountofaircirculationandmaintainsanaverage
roomtemperature.
Avoidinstallationinlocationswherethethermostatcanbeaffectedby
drafts,deadairspots,hotorcoldairducts,sunlight,appliances,concealed
pipes,chimneysandoutsidewalls.
Drill 3/16” pilot holes in
your desired location.
Use supplied anchors for
drywall or plaster.
UP UP
