INSTALLATION MANUAL
Column Refrigerator & Freezer
Part # R 000046 revision 0 © Prizer Painter Stove Works, Blandon, PA 19510-
bluestarcooking.com 3
Contents
Safety Informaon 4
Site Preparaon 6
Panel Preparaon 8
Installaon Instrucons 10
Step —Uncrate and Inspect Product1 10
Step —Remove Skid2 10
Step —Hook up Electrical and Water3 11
Step —Levelling4 11
Step —Aach Plasc Connecng Brackets5 11
Step —Install Two Appliances Side Side6-by- 12
Step —Aach Wall Blocking7 13
Step —Install Shoulder Bolts and Set Screws8 13
Step —Install Panel (Panel Ready Models)9- 14
Step —Move Appliance into Posion10 14
Step —Install An Tip Brackets11 - 14
Step —Adjust Panel ( Panel Ready Models)12 - 16
Step —Aach Appliance to Cabinetry13 16
Step —Aach Door Handle14 17
Step —Aach Venng Grill15 17
Tesng and Inial Startup 18
bluestarcooking.com 17
Step 15 — Aach Venng Grille
A forced air system assures venlaon through a grille
posioned in the lower front part of the appliance. Each
BlueStar Column comes with a mm) tall stainless 8 1/2” (216 -
steel grille.
Important: If using a custom grille, it has to be venlated
with holes. Holes can be in any shape and size, as long as the
total area equals 50% of the area dened by dimensions A“ ”
and B below.“ ”
It is imperave that the grille remain unblocked to ensure
proper funconality of the appliance and should be
removable to allow for servicing and condenser cleaning.
Installaon Instrucons
18” 24” 30”
A -16 1/8” (410
mm)
22” (559
mm)
27-15/16” (710
mm)
B > 4” (100 mm)
C 3/8” (10 mm)
Step 14 — Aach Door Handle
A BlueStar handle is provided with stainless door models,
but must be ordered separately for panel ready models.-
• The handle and nameplate kit is located in protecve
packaging taped to the back of the appliance.
• It is recommended that two people work together to
install the handle.
• Ensure handle mounng studs are threaded nger-
ght to the face of the door.
• Slide handle endcaps onto the handle mounng studs.
If the set screw interferes, back out set screw to allow
endcaps to slip over handle mounng studs.
• Posion handle to face of door and with provided hex
wrench ghten set screw in top endcap rst, then
ghten set screw in boom endcap.
