Strona 1/20
24/7 TECHNICAL SUPPORT AT 1.877.877.2269 OR VISIT BLACKBOX.COM
KVX SERIES
4K DP KVM
EXTENDER
KVXLCDP-100, KVXLCDPF-100, KVXLCDP-200, KVXLCDPF-200
QUICK INSTALL GUIDE AND USER MANUAL
DP KVM Extender Transmitter
DP KVM Extender Receiver
PWR LINK
PWR LINK
2
TABLE OF CONTENTS
NE E D HELP ?
LE AVE THE TEC H TO U S
LIVE 24/7
TECHNICAL
SUPPORT
1.877.877.2269
1.877.877.2269 BLAC KBOX.COM
QUICK INSTALLATION GUIDE .......................................................................................................................................................... 3
1. SPECIFICATIONS ........................................................................................................................................................................... 4
2. OVERVIEW ...................................................................................................................................................................................... 6
2.1 Introduction ...............................................................................................................................................................................................6
2.2 Features ....................................................................................................................................................................................................6
2.3 What’s Included ........................................................................................................................................................................................6
2.4 Hardware Description ..............................................................................................................................................................................7
2.4.1 Transmitter ..........................................................................................................................................................................................................7
2.4.2 Receiver..............................................................................................................................................................................................................10
3. CONNECTION DIAGRAM ............................................................................................................................................................ 13
4. INSTALLATION ............................................................................................................................................................................ 14
APPENDIX A. REGULATORY INFORMATION ................................................................................................................................ 15
A.1 FCC Statement .......................................................................................................................................................................................15
A.2 NOM Statement .....................................................................................................................................................................................16
APPENDIX B. DISCLAIMER/TRADEMARKS ................................................................................................................................. 17
B.1 Disclaimer ...............................................................................................................................................................................................17
B.2 Trademarks .............................................................................................................................................................................................17
3
1.877.877.2269 BLACKBOX.COM
NE E D H E L P?
LE AVE THE TE C H TO US
LIVE 24/7
TECHNICAL
SUPPORT
1.877.877.2269
QUICK INSTALLATION GUIDE
Follow these steps to install the extender:
1. If you have the fiber models, install the SFPs in the transmitter and receiver. Compatible SFPs from Black Box are listed in the table
below.
COMPATIBLE SFP MODULES
PART NUMBER DESCRIPTION DISTANCE
1-GBPS CONNECTIONS
LFP441 SFP 1.25-Gb, 850-nm Multimode Fiber, LC 550 m
LFP442 SFP 1.25-Gb, 1310-nm Single-mode Fiber, LC 20 km
LFP412 SFP with Extended Diagnostics - 1250-Mbps Multimode Fiber, 1310-nm 2 km
LFP413 SFP with Extended Diagnostics - 1250-Mbps Single-Mode Fiber, 1310-nm 10 km
LFP414 SFP with Extended Diagnostics - 1250-Mbps, Singlemode Fiber, 1310-nm 30 km
LFP416 SFP 1250-Mbps, Extended Diagnostics, 10/100/1000BASE-T, SGMII Interface, RJ-45 100 m
NOTE: Other SFPs may work but have not been validated by Black Box, we recommend you use the suggested SFPs to avoid technical
incompatibilities. SFP is not included in the package, must be ordered separately.
2. Connect one end of a DisplayPort cable to the DisplayPort port on the source device (e.g. computer, server, or other IT device).
Then connect the other end to the DP IN port located on the TX unit.
3. Connect the DisplayPort display to the DP OUT port on the TX unit.
4. Connect the DisplayPort display to the DP OUT port on the RX unit.
5. Connect the USB ports of the source device and the TX unit with a USB type A-B cable. Then plug a USB keyboard, mouse, or other
USB devices into the USB ports of the RX unit.
6. Connect the RS-232 ports of the source device and the TX unit. Then connect the RS-232 ports of the RS-232 device on the RX unit
side and the RX unit.
7. Connect the microphone/speaker ports of the source device and the TX unit with the audio microphone/speaker combo cable.
Then, plug the microphone and speaker into the microphone and speaker ports of the RX unit.
8. For the CATx model, use a CAT5e cable to connect the CATx link ports on the TX unit and the RX unit.
9. For the fiber model, use two SFP modules and an optical fiber cable to connect the fiber link ports on the TX unit and the RX unit.
10. Plug the power adapter cable into the DC jacks on the TX and RX units.
NOTES:
a. We recommend using the highest quality materials (cables, SFP, etc.) to ensure optimal transmission quality.
b. If the screen does not display when you connect the computer:
1. Make sure the device cables are correctly and firmly attached.
2. Set your display device’s (TV, monitor, etc.) input source as DisplayPort.
3. Check the PC BIOS configuration of the video output setting.
4. Connect your video source to the Display DIRECTLY to check if the video signal gets through.
NOTES:
1. Both the DisplayPort displays respectively connecting to TX and RX units MUST support the same maximum video resolution.
2. SFP module’s bandwidth requirement is 1 Gbps minimum.
3. When plugging into any microphone or speaker ports of TX or RX units, digital DisplayPort audio extension will be disabled and
only analog audio LINE-IN/LINE-OUT extension is enabled.
