The Baby Lock Esante Sewing & Embroidery Machine

Take your projects to the next level with the Baby Lock Esante. With USB

connectivity and on-screen editing, the Esante is the next step in sewing and

embroidery technology. You’ll get all of the convenience you’d expect from a

Baby Lock machine with features such as a Quick-Set, top-loading bobbin, an

LCD Touch Screen and an advanced needle threader. However, the Esante also

includes a 6-1/4” X 10-1/4” (160mm x 260mm) embroidery ﬁeld and hundreds

of built-in designs, lettering, and stitches to give you unlimited options for your

next creation. Experience a new way to embroider with the Baby Lock Esante.

For the love of sewing.

FOR THE LOVE OF SEWIN G

• 313 Built-in stitches including

• 105 Utility with 12 one-step

buttonhole styles

• 57 Combinable Utility stitches

• 110 Decorative

• 15 Wide satin

• 14 Satin

• 12 Cross

• 3 Built-in alphabets

• Stitch length 0.0mm - 5.0mm

• Maximum Utility stitch width: 7mm

• Utility stitch editing capabilities

• Store personal stitch settings for each

Utility stitch

• Decorative stitch editing capabilities

• Edit and combine Character/Decorative

Stitches

• 16 Memory pockets for Character/

Decorative stitches equaling 224KB

• Mirror-imaging

• Lock key for Utility and Decorative stitches

• Lateral and diagonal feeding

• Variable needle positions

• Fully automatic built-in darning

• Twin needle settings

Sewing & Embroidery machine

Advanced Sewing Features

Embroidery Capabilities

• Combine embroidery designs on screen

• Character/Text array function

• Character spacing

• 1°, 10°, and 90° Pattern rotation

• Design enlargement (up to 20%)

• Design reduction (up to 10%)

• Mirror imaging

Embroidery Editing Capabilities • Language conversion capabilities

(13 languages)

• Warranty (25 years limited, 10 years

parts, 5 years computer circuit,

5 years electrical, 1 yr. labor)

• Optional Gold Standard service and

support for your peace of mind

• Optional extension table

• Optional embroidery hoops

• Medium 4” x 4” (100mm x 100mm)

• Small 1” x 2-1/2” (20mm x 60mm)

• Optional thread stand

Additional Information

• Convenient One-Touch Buttons

• Start/Stop

• Reverse sewing

• Needle up/down

• Thread cutter

• Automatic presser foot lift

• Ergonomic knee lift with extra high

presser foot lift

• 10mm automatic and 13mm

manual

• Programmable needle up/down

• Needle plate with scale in inches

and centimeters

• Electronic foot control with separate

power cord

• Free arm with drop feed lever

• Two accessory storage compartments

• Large sewing surface 12-1/4” x 8-1/8”

(312mm x 208mm)

Convenient Sewing Features

• Built-in embroidery design library

• 158 Built-in embroidery designs including 86 Baby Lock

exclusive designs

• 120 Frame combinations

• 9 Font styles including one exclusive script

• Embroiders up to 6” x 10” (160mm x 260mm) embroidery ﬁeld

• 12 Memory pockets for Embroidery and Embroidery Edit equaling

512KB/150,000 stitches

• Reads embroidery designs with a stitch capacity of up to 100,000

stitches per design

• LCD touch screen (240 x 320 dot matrix) shows

• Estimated embroidery time display and stitch count

• Needle position placement (1, 10, or 100 stitch increments)

• Measurements displayed in inches or millimeters (mm)

• Thread color indicator

• On-screen hoop size indicator

• Low bobbin thread indicator

• 300 Color names

• Embroidery speed up to 800 spm

• 8-point trial check points

• Alternate bobbin case for prewound bobbins

• Knee lifter

• Touch pen (stylus)

• USB cable

• 13 Snap-on feet

• Buttonhole

• Embroidery

• Overcasting

• Monogramming

• Zipper

• Zigzag

• Blind stitch

• Button ﬁtting

• Cording (with 3 cord guides)

• Walking

• Blind stitch (with guide)

• Narrow hemmer

• Free-motion quilting

• Hard cover for machine

• Alternate bobbin case for use with

pre-wound bobbins

• Bobbin center pin

• Embroidery bobbin thread

• Bobbins

• Seam ripper

• Twin needle

• Embroidery hoops and grids included:

• Extra large

6-1/4” x 10-1/4”

(160mm x 260mm)

• Large

5” x 7”

(130mm x 180mm)

•

Plus more

Included Accessories

• USB direct connect (type B)

• LCD touch screen (240 x 320 dot matrix) with touch pen

• Embroidery card slot

• Advanced needle threader

• Automatic thread cutter

• Quick-Set, top-loading bobbin with sensor

• Quick-Set, bobbin winder

• Independent bobbin winding system

• Automatic sensors

• Thread tension control makes adjustments to feed thread properly

• Upper and lower thread sensors to alert when threads are broken

• On-screen hoop sensor to recommend size of hoop to use

• 5 LED lights that illuminate the needle and work area

• Sewing speed up to 1,000 spm

Technology Features

LBSP-BLN

www.babylock.com

Downloadable Software from

www.babylock.com

Your Esante will stay current with

future upgrades via USB connection

• Built-in Operational Guide

• Built-in Sewing Application Guide

• Built-in Help Messages

Instructional and Help Resources

800-422-2952

Sewing & Embroidery machine

FOR THE LOVE OF SEWING

esante

Key Embroidery Features

Embroidery Design Library Built-in Embroidery Lettering

313 Built-in Stitches

Embroidery Editing On-Screen

Key Sewing Features

Quick-Set, Top-Loading Bobbin

USB Connectivity

Advanced Needle Threader

LCD Touch Screen (240 x 320

size) with touch pen
