Installation Instructions for AX-TOYRSAV
© COPYRIGHT 2004-2016 METRA ELECTRONICS CORPORATION © COPYRIGHT 2004-2016 METRA ELECTRONICS CORPORATION
REV. 2/3/16 REV. 2/3/16
Installation Instructions for AX-TOYRSAV
axxessinterfaces.com • metraonline.com axxessinterfaces.com • metraonline.com
Axxess Integrate Axxess Integrate
INTRODUCTION
The AX-TOYRSAV is designed to provide an audio/video input
to the OEM overhead video screen from the aftermarket radio
.
AX-TOYRSAV
Toyota RSE Retention Harness
2007-2010
APPLICATIONS
INTERFACE COMPONENTS
AX-TOYRSAV harness
TOOLS REQUIRED
• Cutting Tool • Tape • Crimping Tool
• Connectors (i.e. butt-connectors, bell caps, etc.)
CONNECTIONS TO BE MADE
From the AX-TOYRSAV harness to the aftermarket radio:
• Connect the RCA jack to the right A/V-OUT jack.Red
• Connect the RCA jack to the left A/V-OUT jack.White
• Connect the Yellow RCA jack to the video A/V-OUT jack.
INSTALLING THE AX-TOYRSAV
• Connect the AX-TOYRSAV harness to the factory harness
located in the radio cavity.
TOYOTA (NAV MODELS ONLY)
4-Runner 2008-2009
Highlander 2008-2010
Sequoia 2008-2009
Sienna 2008-2010
Tundra 2007-2009
CAUTION!
All accessories, switches, climate controls panels, and especially air bag
indicator lights must be connected before cycling the ignition. Also, do not remove
the factory radio with the key in the on position, or while the vehicle is running.
© COPYRIGHT 2004-2016 METRA ELECTRONICS CORPORATION © COPYRIGHT 2004-2016 METRA ELECTRONICS CORPORATION
REV. 2/3/16 REV. 2/3/16
Instrucciones de instalación para Instrucciones de instalación para AX-TOYRSAV AX-TOYRSAV
axxessinterfaces.com • metraonline.com axxessinterfaces.com • metraonline.com
Axxess Integrate Axxess Integrate
INTRODUCCIÓN
El AX-TOYRSAV está diseñado para proporcionar una entrada
de audio/video a la pantalla de video OEM para techo del
radio de mercado secundario.
AX-TOYRSAV
Toyota RSE Ars de Retención
2007-2010
APLICACIONES
COMPONENTES DE LA INTERFASE
AX-TOYRSAV harness
HERRAMIENTAS REQUERIDAS
• Cortador • Pelacables • Cinta • Conectores
(p. ej., conectores a tope, tapas acampanadas, etc.)
CONEXIONES QUE SE DEBEN HACER
Desde el arnés AX-TOYRSAV al radio de mercado secundario
:
• Conecte el conector RCA al conector entrada rojo
derecha de A/V-OUT.
• Conecte el conector RCA al conector entrada blanco
derecha de A/V-OUT.
• Conecte el conector RCA al conector de la amarillo
entrada de video A/V-OUT.
INSTALACIÓN DEL AX-TOYRSAV
• Conecte el arnés AX-TOYRSAV al arnés fábrica en la
cavidad de radio.
¡PRECAUCIÓN!
Todos los accesorios, interruptores, paneles de controles de
clima y especialmente las luces del indicador de las bolsas de aire deben
estar conectados antes ciclar la ignición. Además, no quite el radio de fábri-
ca con la llave en la posición o de encendido ni con el vehículo funcionando.
TOYOTA
(SÓLO MODELOS NAV)
4-Runner 2008-2009
Highlander 2008-2010
Sequoia 2008-2009
Sienna 2008-2010
Tundra 2007-2009
