OM3
OVERVIEW:
Designed, assembled and tested by Audix in the USA, the OM3 is a
dynamic vocal microphone used for a wide variety of live, studio and
broadcast applications. The OM3 is known for its clear and accurate
sound reproduction, resistance to feedback and ability to handle very
high sound pressure levels without distortion.
The OM3 is characterized with a tight and uniformly controlled
hypercardioid polar pattern which helps to isolate the vocals from the
rest of the instruments on stage. With a wide frequency range of 50 Hz
- 18 kHz, the OM3 employs a VLM™ (Very Low Mass) diaphragm for a
clean and natural sound with exceptional transient response.
The OM3 is naturally attenuated in the lower mid-bass frequencies in
order to reduce boominess and handling noise. This, in conjunction with
an extremely articulate mid-range, makes the OM3 an excellent choice
for PA systems of all sizes. The OM3 is well balanced, comfortable
to hold, durable and manufactured with high standards and tight
tolerances.
Roadworthy construction includes a precision die cast zinc alloy body,
black e-coat nish, laser etched model and serial number, steel mesh
grill, Switchcraft® XLR connector and heavy duty nylon clip.
FEATURES:
Clear, accurate vocal reproduction
Handles high SPL without distortion
Low handling noise
Provides exceptional gain before feedback
Provides excellent vocal isolation on stage
Dent resistant steel spring grill
5 year warranty
APPLICATIONS:
Lead or backing vocals
Live recording
Broadcast
Home studio - vocal and instrument
Sax, brass, guitar, dobro, flute, percussion, drums
SUPPLIED ACCESSORIES:
Heavy duty nylon mic clip (MC1)
Carrying pouch (P1)
OPTIONAL ACCESSORIES:
WS357 - External foam windscreen
CBL-20 - 20’ XLR-XLR low noise microphone cable
T50K - Low to high impedance matching transformer
MODEL VARIATIONS:
OM3-S - Same as above with On-Off switch
DYNAMIC VOCAL MICROPHONE
OM3
Dynamic Vocal
MC1 WS357 CBL-20 T50K
Transducer Type Dynamic
Frequency Response 50 Hz - 18 kHz
Polar Pattern Hypercardioid
Output Impedance 250 ohms
Sensitivity 1.7 mV / Pa @ 1k
Capsule Technology VLM Type B
Off Axis Rejection > 25 dB
Maximum SPL ≥144 dB
Power Requirements None
Connector Switchcraft® male
XLR connector
Polarity Positive pressure on diaphragm
produces positive voltage on pin 2
relative to pin 3 of output
XLR connector
Housing / Finish Zinc Alloy /
Black E-coat
Weight 307 g / 10.8 ounces
Length 176 mm / 6.9 inches
SPECIFICATIONS: ARCHITECTS AND ENGINEERS SPECIFICATIONS:
The microphone shall be of the dynamic type and the polar pattern of the microphone
shall be hypercardioid. The nominal output impedance shall be equal to 250 ohms at
1 kHz. The microphone shall have a sensitivity of 2.5 mV / Pa at 1 kHz and a sound
pressure level ≥144 dB. The microphone body shall be of zinc alloy and the grill cap
shall be steel wire mesh. The overall dimensions shall be 23 mm in diameter at the
base, 53 mm in diameter at the widest point on the grill and 176 mm in length. The
microphone shall be the Audix OM3.
OPERATION:
The OM3 is a low impedance microphone and should be plugged into the “mic level”
input of your console, mixer, or recording device. Please note that your microphone
does not require phantom power and will not be effected in any way by phantom
power should it be running simultaneously while the microphone is in operation. Avoid
plugging or unplugging the microphone from the PA system unless the channel is
muted or the volume of the system turned down. Failure to do so may result in a loud
“popping” noise which could seriously damage the speakers in the PA system.
USER TIPS:
The OM3 has a very tight pick-up pattern in order to help eliminate sound from other
instruments on stage from “bleeding” into the microphone. For best results, it is
important to sing directly into the mic at close proximity (within 2 inches).
When using oor monitors, position the microphone so that it is parallel to the oor.
When using multiple microphones on a live performance stage, allow a distance of 2-3
feet between mics to avoid phase issues.
*Further miking techniques may be found on our website at www.audixusa.com
www.audixusa.com Call: 503-682-6933 Fax: 503-682-7114
Audix Corporation 9400 SW Barber Street, Wilsonville, OR 97070
SERVICE AND WARRANTY:
This microphone is under warranty for
a period of 5 years from any and all
manufacturing defects. Should your
microphone fail in any way, please con-
tact the Audix Service department at
503-682-6933. A Return Authorization
number is required before returning
any products.
CARE AND MAINTENANCE:
The OM3 is manufactured to exacting specs
with roadworthy construction. However, the
capsule is highly sensitive and should be
handled with care. Avoid extreme temperatures
and be sure to store your microphone in the
pouch provided when not in use. Moisture of
any kind can adversely affect the sound and
performance of your microphone.
FREQUENCY / POLARS:
To register your
microphone, please visit
www.audixusa.com
***All specications subject to change without notice.
DIMENSIONS (mm):
OM3
