RT-AX88U Pro
AX6000 Dual Band Wi-Fi Router
Quick
Start Guide
Hardware Explanations
I/O Ports Overview LED Lights Overview
DC Power adapter DC Output: +19.5V with 2.31A current
DC Output: +19V with 2.37A current
Operating Temperature 0~40oC Storage 0~70oC
Operating Humidity 50~90% Storage 20~90%
Specications:
One Router Setup Steps
Prepare your Modem
01
1
Unplug the power of cable / DSL modem. If it
has a battery backup, remove the battery.
5
Launch [App] ASUS Router App and follow the
instructions to complete the setup.
WE SUGGEST...
Modem back
Install your Router
02
1
Plug the adapter into the DCIN port, and press the Power switch.
2
Connect your modem to WAN port at the back side of the router with the
network cable provided.
3
Power on the modem. Plug modem to the power outlet and power on.
4
Check the modem LED lights to ensure the connection is active.
If you are using DSL for internet,
you will need your username
/ password from your Internet
service provider (ISP) to properly
congure your router.
Modem front
– Or via web browser
3
Connect your PC to LAN port at the back side [Wired]
of the router using an additional network cable.
[Wireless] Connect to the network with default SSID shown on
the product label on the back side of your router “ASUS_XX”.
4
[Wired / Wireless] Open a web browser.
You will be redirected to the ASUS Setup Wizard. If not, navigate to
http://www.asusrouter.com.
Follow the instructions to
complete the setup.
– Via app
3
On your iOS or Android mobile device, go [App]
to the app store, search for , and ASUS Router
download the app.
4
On your iOS or Android mobile device, tap[App] Settings > Wi-Fi, connect
to the default network SSID shown on the product label on the back side of
the router. Or scan the QR code on the product label to connect the default
network SSID.
* XX refers to the last two digits
of MAC address. You can nd
it on the label on the back of
your router.
_
5GHz LED
2.5G/1G WAN
LED
LAN LED
WPS LED
USB 3.2 Gen 1
LEDPower LED
2
The power LED will light up when the hardware is ready.
DCIN port
LAN 1-4 ports
WPS button
Reset button
2.5G/1G WAN port USB 3.2 Gen 1 port
Power button
2.5G/1G LAN
port
2.5G/1G LAN
LED
2.4GHz LED
Modem back
http://www.asusrouter.com/
FAQ FREQUENTLY ASKED QUESTIONS
Q1:
Where can I find more information about the wireless router?
Technical support site: https://www.asus.com/support
Service and Support
https: www.asus.com/support//
Video Tutorials
https://qr.asus.com/wl_videotutorials
E21596_RT-AX88U_Pro_one-page_QSG_V2.indd 1
E21596_RT-AX88U_Pro_one-page_QSG_V2.indd 1
E21596_RT-AX88U_Pro_one-page_QSG_V2.indd 1
E21596_RT-AX88U_Pro_one-page_QSG_V2.indd 1E21596_RT-AX88U_Pro_one-page_QSG_V2.indd 1 2023/1/18 14:37:39
2023/1/18 14:37:39
2023/1/18 14:37:39
2023/1/18 14:37:392023/1/18 14:37:39
ASUS Recycling/Takeback Services
ASUS recycling and takeback programs come from our commitment to the highest standards for protecting our
environment. We believe in providing solutions for you to be able to responsibly recycle our products, batteries, other
components, as well as the packaging materials. Please go to http://csr.asus.com/english/Takeback.htm for the detailed
recycling information in dierent regions.
REACH
Complying with the REACH (Registration, Evaluation, Authorisation, and Restriction of Chemicals) regulatory framework, we
published the chemical substances in our products at ASUS REACH website at
http://csr.asus.com/english/REACH.htm
Federal Communications Commission Statement
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions:
• This device may not cause harmful interference.
• This device must accept any interference received, including interference that may cause undesired operation.
This equipment has been tested and found to comply with the limits for a class B digital device, pursuant to part 15 of
the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential
installation.
This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with
the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference
will not occur in a particular installation. If this equipment does cause harmful interference to radio or
television reception,
which can be determined by turning the equipment o and on, the user is encouraged to try to correct the interference by
one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit dierent from that to which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
WARNING! Any changes or modications not expressly approved by the party responsible for compliance could
void the user’s authority to operate the equipment.
Prohibition of Co-location
This device and its antenna(s) must not be co-located or operating in conjunction with any other antenna or transmitter.
IMPORTANT NOTE:
Radiation Exposure Statement: This equipment complies with FCC radiation exposure limits set forth for an uncontrolled
environment. End users must follow the specic operating instructions for satisfying RF exposure compliance. To maintain
compliance with FCC exposure compliance requirement, please follow operation instruction as documented in this manual.
This device is restricted for indoor use.
WARNING! This equipment must be installed and operated in accordance with provided instructions and the
antenna(s) used for this transmitter must be installed to provide a separation distance of at least 51cm from all
persons and must not be co-located or operating in conjunction with any other antenna or transmitter.
This device is restricted for indoor use.
Compliance Statement of Innovation, Science and Economic Development Canada (ISED)
This device complies with Innovation, Science and Economic Development Canada licence exempt RSS standard(s).
Operation is subject to the following two conditions: (1) this device may not cause interference, and (2) this device must
accept any interference, including interference that may cause undesired operation of the device.
Operation in the band 5150–5250 MHz is only for indoor use to reduce the potential for harmful interference to co-channel
mobile satellite systems.
CAN ICES-003(B)/NMB-003(B)
Radio Frequency (RF) Exposure Information
The radiated output power of the ASUS Wireless Device is below the Innovation, Science and Economic Development
Canada radio frequency exposure limits. The ASUS Wireless Device should be used in such a manner such that the potential
for human contact during normal operation is minimized.
This equipment should be installed and operated with a minimum distance of 31cm between the radiator any part of your
body.
This device has been certied for use in Canada. Status of the listing in the Innovation, Science and Economic Development
Canada’s REL (Radio Equipment List) can be found at the following web address:
http://www.ic.gc.ca/eic/site/ceb-bhst.nsf/eng/h_tt00020.html
Additional Canadian information on RF exposure also can be found at the following web:
https://www.ic.gc.ca/eic/site/smt-gst.nsf/eng/sf08792.html
Déclaration de conformité de Innovation, Sciences et Développement économique Canada (ISED)
Le présent appareil est conforme aux CNR d’Innovation, Sciences et Développement économique Canada applicables
aux appareils radio exempts de licence. L’exploitation est autorisée aux deux conditions suivantes : (1) l’appareil ne doit
pas produire de brouillage, et (2) l’utilisateur de l’appareil doit accepter tout brouillage radioélectrique subi, même si le
brouillage est susceptible d’en compromettre le fonctionnement.
La bande 5150 – 5250 MHz est réservée uniquement pour une utilisation à l’intérieur an de réduire les risques de
brouillage préjudiciable aux systèmes de satellites mobiles utilisant les mêmes canaux.
CAN ICES-003(B)/NMB-003(B)
Informations concernant l’exposition aux fréquences radio (RF)
La puissance de sortie émise par cet appareil sans l est inférieure à la limite d’exposition aux fréquences radio d’Innovation,
Sciences et Développement économique du Canada (ISED). Utilisez l’appareil sans l de façon à minimiser les contacts
humains lors d’un fonctionnement normal.
Cet équipement doit être installé et utilisé avec un minimum de 31cm de distance entre la source de rayonnement et votre
corps.
L’utilisation de cet appareil est autorisée au Canada. Pour consulter l’entrée correspondant à l’appareil dans la liste
d’équipement radio (REL - Radio Equipment List) d’Innovation, Sciences et Développement économique du Canada,
rendez-vous sur : http://www.ic.gc.ca/eic/site/ceb-bhst.nsf/eng/h_tt00020.html
Pour des informations supplémentaires concernant l’exposition aux fréquences radio au Canada, rendez-vous sur :
https://www.ic.gc.ca/eic/site/smt-gst.nsf/eng/sf08792.html
For indoor use only.
Pour une utilisation en intérieur uniquement.
This radio transmitter [3568A-RTAX6800] has been approved by Innovation, Science and Economic Development Canada to
operate with the antenna types listed below, with the maximum permissible gain indicated. Antenna types not included in
this list that have a gain greater than the maximum gain indicated for any type listed are strictly prohibited for use with this
device.
Le présent émetteur radio (3568A-RTAX6800) a été approuvé par Innovation, Sciences et Développement économique
Canada pour fonctionner avec les types d’antenne énumérés ci-dessous et ayant un gain admissible maximal d’antenne.
Les types d’antennes non inclus dans cette liste qui ont un gain supérieur au gain maximal indiqué pour tout type listé sont
strictement interdits pour une utilisation avec cet appareil.
Ant. Brand Name Model Name Antenna Type 2.4GHz 5GHz
UNII 1 UNII 2A UNII2C UNII3
1 PSA RFDPA171300SBLB820 Dipole 2.01 2.66 2.74 3.53 3.93
2 PSA RFDPA171300SBLB820 Dipole 1.25 1.8 1.59 2.37 2.6
3 PSA RFDPA171300SBLB820 Dipole 1.61 2.05 1.47 2.32 2.49
4 PSA RFDPA171300SBLB820 Dipole 1.81 2.7 1.47 3.17 3.83
The maximum antenna gain permitted for devices in the bands 5250-5350 MHz and 5470-5725 MHz shall be such that the
equipment still complies with the e.i.r.p. limit.
le gain maximal d’antenne permis pour les dispositifs utilisant les bandes 5250-5350 MHz et 5470-5725 MHz doit se
conformer à la limite de p.i.r.e.
The maximum antenna gain permitted for devices in the band 5725-5850 MHz shall be such that the equipment still
complies with the e.i.r.p. limits specied for point-to-point and non-point-to-point operation as appropriate.
le gain maximal d’antenne permis (pour les dispositifs utilisant la bande 5725-5850 MHz) doit se conformer à la limite de
p.i.r.e. spéciée pour l’exploitation point à point et non point à point, selon le cas.
Safety Notices
• Use this product in environments with ambient temperatures between 0°C(32°F) and 40°C(104°F).
• Refer to the rating label on the bottom of your product and ensure your power adapter complies with this rating.
• DO NOT place on uneven or unstable work surfaces. Seek servicing if the casing has been damaged.
• DO NOT place or drop objects on top and do not shove any foreign objects into the product.
• DO NOT expose to or use near liquids, rain, or moisture. DO NOT use the modem during electrical storms.
• DO NOT cover the vents on the product to prevent the system from getting overheated.
• DO NOT use damaged power cords, accessories, or other peripherals.
• If the Adapter is broken, do not try to x it by yourself. Contact a qualied service technician or your retailer.
• To prevent electrical shock hazard, disconnect the power cable from the electrical outlet before relocating the system.
• DO NOT mount this equipment higher than 2 meters.
Avertissements de sécurité
• Utilisez ce produit dans un environnement dont la température ambiante est comprise entre 0˚C (32°F) et 40˚C (104°F).
• Référez-vous à l'étiquette située au dessous du produit pour vérier que l'adaptateur secteur répond aux exigences de
tension.
• NE PAS placer sur une surface irrégulière ou instable. Contactez le service après-vente si le châssis a été endommagé.
• NE PAS placer, faire tomber ou insérer d'objets sur/dans le produit.
• NE PAS exposer l'appareil à la pluie ou à l'humidité, tenez-le à distance des liquides. NE PAS utiliser le modem lors d'un
orage.
• NE PAS bloquer les ouvertures destinées à la ventilation du système pour éviter que celui-ci ne surchaue.
• NE PAS utiliser de cordons d'alimentation, d'accessoires ou autres périphériques endommagés.
• Si l'adaptateur est endommagé, n'essayez pas de le réparer vous-même. Contactez un technicien électrique qualié ou
votre revendeur.
• Pour éviter tout risque de choc électrique, débranchez le câble d'alimentation de la prise électrique avant de toucher au
système.
• Ne placez pas cet appareil à une hauteur supérieure à 2 mètres.
Información de seguridad
• Use este producto en entornos sometidos a una temperatura ambiente comprendida entre 0 ˚C (32 ˚F) y 40 ˚C (104 ˚F).
• Consulte la etiqueta de valores nominales situada en la parte inferior del producto y asegúrese de que su adaptador de
alimentación cumple con dichos valores.
• NO coloque el equipo sobre una supercie irregular o inestable. Solicite asistencia técnica si la carcasa resulta dañada.
• NO coloque ni deje caer objetos en la parte superior del producto y no introduzca objetos extraños dentro de él.
• NO exponga el equipo a líquidos, lluvia o humedad, ni lo use cerca de ninguno de tales elementos. NO use el módem
durante tormentas eléctricas.
• Para evitar que el sistema se sobrecaliente, no cubra las ranuras de ventilación del producto.
• NO cubra los oricios de ventilación del equipo de sobremesa para evitar que el sistema se caliente en exceso.
• No intente reparar la fuente de alimentación personalmente si se avería. Póngase en contacto con un técnico de
mantenimiento autorizado o con su distribuidor.
• A n de evitar posibles descargas eléctricas, desconecte el cable de alimentación de la toma de suministro eléctrico antes
de cambiar la posición del sistema.
• NO monte este equipo a una altura superior a 2 metros.
E21596_RT-AX88U_Pro_one-page_QSG_V2.indd 2
E21596_RT-AX88U_Pro_one-page_QSG_V2.indd 2
E21596_RT-AX88U_Pro_one-page_QSG_V2.indd 2
E21596_RT-AX88U_Pro_one-page_QSG_V2.indd 2E21596_RT-AX88U_Pro_one-page_QSG_V2.indd 2 2023/1/18 14:37:40
2023/1/18 14:37:40
2023/1/18 14:37:40
2023/1/18 14:37:402023/1/18 14:37:40
Specyfikacje produktu
| Marka: | Asus |
| Kategoria: | router |
| Model: | RT-AX88U Pro |
Potrzebujesz pomocy?
Jeśli potrzebujesz pomocy z Asus RT-AX88U Pro, zadaj pytanie poniżej, a inni użytkownicy Ci odpowiedzą
Instrukcje router Asus
9 Października 2024
9 Października 2024
9 Października 2024
30 Września 2024
22 Września 2024
21 Września 2024
20 Września 2024
19 Września 2024
16 Września 2024
15 Września 2024
Instrukcje router
- router Tenda
- router Motorola
- router Xiaomi
- router Huawei
- router TCL
- router TP-Link
- router Milwaukee
- router Bosch
- router Hikvision
- router Roland
- router Conceptronic
- router StarTech.com
- router Medion
- router Black & Decker
- router TRENDnet
- router MSI
- router D-Link
- router ATen
- router Siemens
- router Thrustmaster
- router DeWalt
- router Einhell
- router Alcatel
- router Sigma
- router HP
- router Teltonika
- router Manhattan
- router Strong
- router Makita
- router Mikrotik
- router Cisco
- router Moxa
- router Synology
- router ZTE
- router Lindy
- router Zebra
- router ZyXEL
- router Trust
- router LogiLink
- router Linksys
- router Digitus
- router Dahua Technology
- router Kyocera
- router Sabrent
- router AVMATRIX
- router Renkforce
- router Netgear
- router Thomson
- router AVM
- router BT
- router Totolink
- router Black Box
- router Apple
- router Lancom
- router Zoom
- router Iogear
- router Intellinet
- router Devolo
- router Mercusys
- router I-TEC
- router Draytek
- router Edimax
- router Razer
- router AirLive
- router EnGenius
- router Planet
- router Blustream
- router LevelOne
- router Digi
- router Milesight
- router Hama
- router Ubiquiti Networks
- router Western Digital
- router ModeCom
- router Smart-AVI
- router Sagemcom
- router Juniper
- router Cudy
- router QNAP
- router Arris
- router Netis
- router Allnet
- router AJA
- router Media-Tech
- router Atlona
- router FSR
- router Gefen
- router Vivanco
- router Topcom
- router HiKOKI
- router Kathrein
- router JUNG
- router Foscam
- router Alfa
- router Porter-Cable
- router Starlink
- router Keewifi
- router SPL
- router Alfatron
- router KPN
- router Belkin
- router Kramer
- router KanexPro
- router Kopul
- router BZBGear
- router RGBlink
- router Key Digital
- router UPC
- router Lumantek
- router Allied Telesis
- router Eminent
- router Sitecom
- router Sagem
- router Nilox
- router Techly
- router Buffalo
- router Nest
- router Vodafone
- router ICIDU
- router Milan
- router Konig
- router AT&T
- router Sweex
- router Aruba
- router Phicomm
- router Kasda
- router Technicolor
- router Verizon
- router Billion
- router T-Mobile
- router RAVPower
- router Hawking Technologies
- router Nexxt
- router WyreStorm
- router Beafon
- router Zolid
- router Telstra
- router Holzmann
- router SIIG
- router Eero
- router Advantech
- router Mercku
- router Hercules
- router Xantech
- router MuxLab
- router Pentagram
- router Ubee
- router SMC
- router Tele 2
- router Kogan
- router CradlePoint
- router Sixnet
- router AVPro Edge
- router 7inova
- router Predator
- router A-NeuVideo
- router United Telecom
- router F-Secure
- router Rosewill
- router Digicom
- router On Networks
- router Wisetiger
- router Leoxsys
- router Readynet
- router OneAccess
- router Accelerated
- router Nexaira
- router Hamlet
- router Approx
- router T-com
- router Amped Wireless
- router Cambium Networks
- router 3Com
- router Avenview
- router Ruckus Wireless
- router Dovado
- router Mach Power
- router EXSYS
- router NetComm
- router Comtrend
- router Premiertek
- router GL.iNet
- router Shinybow
- router Edgewater
- router Atlantis Land
- router Lantronix
- router PulseAudio
- router Luxul
- router Silentwind
- router Keezel
Najnowsze instrukcje dla router
15 Października 2024
15 Października 2024
15 Października 2024
14 Października 2024
13 Października 2024
12 Października 2024
10 Października 2024
10 Października 2024
10 Października 2024
9 Października 2024
