OS-2130D & OS-2130DE User’s Manual
OS P SERIE RINTERS
OS-2130D
OS-2130DE
U ’ M SER S ANUAL
Website: http://www.argox.com
2
OS-2130D & OS-2130DE User’s Manual
Table of Contents
Introduction....................................................................... 4
Proprietary Statement................................................... 4
Product Improvements ................................................. 4
FCC Compliance Statement ......................................... 4
Liability Disclaimer........................................................ 4
Safety ........................................................................... 5
Getting Started.................................................................. 6
Unpacking Printer......................................................... 6
Package Contents.................................................... 7
Printer Overview........................................................... 8
Front View: OS-2130D and OS-2130DE.................. 8
Rear View: OS-2130D.............................................. 9
Rear View: OS-2130DE ......................................... 10
Interior View I ......................................................... 11
Interior View II ........................................................ 12
Attaching Power ......................................................... 13
Loading Media.............................................................. 4
Preparing Media....................................................... 4
Placing Media Roll ................................................... 4
Printer Operations ............................................................ 8
Printing Media Calibration & Configuration................... 8
Steps to Start Media Calibration & Configuration ..... 8
Sample of Printer Configuration Label ..................... 9
Resetting Printer to Factory Defaults.......................... 11
Printer Controls and Indicators ................................... 12
Troubleshooting by LED and Buzzer Indicators
Diagnosis ................................................................... 16
Miscellaneous............................................................. 20
Recovery .................................................................... 21
3
OS-2130D & OS-2130DE User’s Manual
Communications .............................................................22
Interfaces and Requirements......................................22
USB Interface Requirements ..................................22
Serial (RS-232) Interface Requirements .................22
Ethernet 10/100 Internal Printer Server Option.......23
Ethernet Module Status Indicators..........................23
Communicating with the Printer..................................25
Installing a Plug and Play printer driver (for USB only)
...........................................................................26
Installing a Printer Driver (for other interfaces except
USB)...................................................................32
Caring for Your Printer....................................................39
Print Head Maintenance Guide...................................39
Cleaning Interval.....................................................39
Cleaning Material....................................................39
Cleaning Direction ..................................................40
Product Specification .....................................................41
General Specification..................................................41
Fonts, Barcodes, and Graphics Specification .............45
Printer Programming Language PPLA....................45
Printer Programming Language PPLB....................46
Interface Specification.................................................48
Cash Drawer...........................................................48
USB Interface .........................................................49
Serial Interface........................................................49
Ethernet Interface ...................................................51
Appendix I-Thermal Print Head Replacement...............52
Appendix II-Cutter Installation .......................................54
Appendix III-Dispenser kit Installation ..........................58
4
OS-2130D & OS-2130DE User’s Manual
Introduction
Proprietary Statement
This manual contains proprietary information of Argox Information Co., Ltd. It is
intended solely for the information and use of parties operating and maintaining the
equipment described herein. Such proprietary information may not be used,
reproduced, or disclosed to any other parties for any other purpose without the
expressed written permission of Argox Information Co., Ltd.
Product Improvements
Continuous improvement of products is a policy of Argox Information Co., Ltd. All
specifications and signs are subject to change without notice.
FCC Compliance Statement
This equipment has been tested and found to comply with the limits for a Class A
digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to
provide reasonable protection against harmful interference in a residential installation.
This equipment generates, uses, and can radiate radio frequency energy and, if not
installed and used in accordance with the instructions, may cause harmful
interference to radio communications. However, there is no guarantee that the
interference will not occur in a particular installation. If this equipment does cause
harmful interference to radio or television reception, which can be determined by
turning the equipment off and on, the user is encouraged to try to correct the
interference by the following measures:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and the receiver.
Connect the equipment into a different outlet on a different circuit.
Consult the dealer or an experience Radio/TV technician for help.
This unit was tested with shielded cables on the peripheral devices. Shielded cables
must be used with the unit to insure compliance. The user is cautioned that any
changes or modifications not expressly approved by Argox Information Co., Ltd.
could void the user’s authority to operate the equipment.
Liability Disclaimer
Argox Information Co., Ltd. takes steps to assure that the company’s published
engineering specifications and manuals are correct; however, errors do occur. Argox
Information Co., Ltd. reserves the right to correct any such errors and disclaims any
resulting liability. In no event shall Argox Information Co., Ltd. or anyone else
involved in the creation, production, or delivery of the accompanying product
(including hardware and software) be liable for any damages whatsoever (including,
without limitation, damages for loss of business profits, business interruption, loss of
business information, or other pecuniary loss) arising out of the use of or the results
5
OS-2130D & OS-2130DE User’s Manual
of use of or inability to use such product, even if Argox Information Co., Ltd. has been
advised of the possibility of such damages.
CAUTION:
Any changes or modifications not expressly approved by the party responsible for
compliance could void the user's authority to operate the equipment.
Safety
INDUSTRY CANADA NOTICE:
This device complies with Industry Canada ICES-003 class A requirements.
Cet equipement est conforme a ICES-003 classe A de la norm Industrielle Canadian.
Supplemental Information: This device complies with the requirement
of FCC Part 15 Rules. Operation is subject to the following two
Conditions: (1) This device may not cause harmful interference, and (2)
this device must accept any interference received, including interference
that may cause undesired operation.
Please only use adapters with the following electrical characteristics and
are certified by current legislation. Using other adapters may damage the
device and void the warranty also cause risks to the user.
Features Output: 24VDC, 2.4A
The manufacturer declares under sole responsibility that this product
conforms to the following standards or other normative documents:
EMC: EN 55022:2006+A1:2007, class A
EN 55024:1998+A1:2001+A2:2003
Argox Information Co., Ltd certifies that the following products and/or
components are compliant with the current requirements of the European
Union Restriction on the use of Hazardous Substances (RoHS) Directive,
2002/95/EC.
6
OS-2130D & OS-2130DE User’s Manual
Getting Started
Congratulations on choosing OS-2130D and OS-2130DE printers,
made by Argox Information Co., a leader in the world-wide barcode
industry. OS-2130D and OS-2130DE are ideally designed to easily
bring more efficiency for your business. This manual will help you get
to know your new printer and provide sufficient information needed.
Unpacking Printer
After receiving your printer, please check for possible shipping
damage:
Inspect the outside of both the box and the printer for possible
damage.
1. Open the top cover of the printer to see if all parts are in order.
2. Check whether you have received the following accessories
together with the printer. If there is any item missing, please
contact your local dealer.
Note: If shipping damage has been discovered, contact your
shipping company immediately to file a claim.
