Strona 1/2

nVIDIA GeForce GTX 460

RAM

60mins

Compatibility

Installation of main cooler

Please follow the installation instructions provided with the main cooler.

Installation of RAM and voltage regulator heatsinks

Tips for applying thermal adhesive

Caution: Please make sure the heatsinks are not touching any circuit components as it

may cause a short circuit to your VGA card.

Installation of mounting plate

How to squeeze out all the glue?

Cure time

Accessories

Heatsinks x 5

Heatsinks x 4

Screws (M3) x 2

Mounting plate x 1

*Thermal adhesive x 1

*Be aware that the thermal adhesive comes with a very

short shelf life and shall be used within 1 week. We

recommend storing the thermal adhesive in a cool area to

avoid solidiﬁcation. Refrigerate after opening. Additional

heatsinks and thermal adhesive are available for purchase

at vga.arctic.ac

2. Install replacement mounting plate

comes with the accessories set

1. Uninstall default mounting plate

Heatsinks align to the bottom

Heatsinks align to the left

Heatsinks align to the leftHeatsinks align to the left

Heatsinks align to the right

Heatsinks align to the rightHeatsinks align to the right

Apply pressure

(10 sec)

Apply pressure

(10 sec)

Heatsinks x 1 Heatsinks x 11

Voltage regulator

oltage regulator

oltage regulatorVoltage regulator

Accessories Set VR005

Installation Manual

For further information, please consult www.arctic.ac

No part of this manual including the products described in it, may be reproduced, transmitted, stored in a retrieval system, or translated into any language in any form or by any means, except documentation kept by the purchaser for backup purposes, without the express written permission of ARCTIC

Switzerland. In no event shall ARCTIC its directors or employees be liable for any indirect damages, incidental or consequential damages arising from any defect or error in this manual or product.

ARCTIC Switzerland

Huobstrasse 4

8808, Pfäﬃkon, Switzerland

www.arctic.ac

Specyfikacje produktu

Marka:	Arctic Cooling
Kategoria:	wentylator do PC
Model:	VR005
Kolor produktu:	Srebrny
Odpowiednia lokalizacja:	Karta graficzna
Model:	Radiator
Materiały:	Aluminium
Obsługiwane produkty:	Nvidia GTX460
