1
INSTRUCTIONS FOR INSTALLATION AND USE
Ceiling Fan Model Fresco (FN522XX)
BEFORE YOU START
Proper use:
- This product is intended exclusively for non-commercial use as ceiling fan.
- The product has to be installed and used in accordance with these instructions.
- Any use of this product that is not in accordance with these instructions will void the legal
warranty of the manufacturer.
Please keep the original carton and packaging material as the warranty will only be honored if product
is returned in complete original packaging.
FOR YOUR OWN SAFETY
General safety instructions:
- For the safe use of this product, you need to have read and understood these instructions
before installing or using the product.
- Please follow all safety instructions! If you ignore these safety instructions, you will endanger
yourself and others.
- Keep these instructions for future reference.
- All parts of this product have to be installed properly in order to ensure safe operation.
- Modification of the product and use of non-approved parts are prohibited.
- This product is not intended for use by persons (including children) with reduced physical,
sensory or mental capabilities, or lack of experience and knowledge, unless they have been
given supervision or instruction concerning the use of the product by a person responsible for
their safety. Children should be supervised to ensure that they do not play with the product.
Electrical safety:
- The electrical installation must be performed by a qualified electrician and must be in
accordance with national and local regulations.
- Use a fault-current circuit breaker with a rated residual current of no more than 30 mA.
- Make sure to install an all-pole disconnection switch having a contact separation of at least
3mm between poles in the supply wiring to the ceiling fan.
- Before connecting the appliance to the electrical grid, make sure that it will only be operated
within the specified parameters.
- The fan must be properly grounded to avoid the risk of electric shocks.
- Switch off the power before connecting, repairing or cleaning the fan.
- Install only bulbs of the type intended for your fan.
Storage and transport::
- Always store the fan in a dry environment.
- Protect the fan from damages during transport.
2
Safety instructions specific to this fan:
- Attach the fan only directly to the ceiling structure.
- The carrying capacity of the ceiling structure from which the fan is hung must be at least
100kg.
- The minimum distance between the blades of the fan and the floor must be 2.3m.
- Never mount the fan outside or in a humid or wet environment. The fan can not be installed
within proximity of water (e.g. bath tub, swimming pool, water connection).
- The fan can only be installed horizontally on the ceiling.
- Install only bulbs of the type intended for your fan.
- Switch off the power before connecting, repairing or cleaning the fan.
- The rotor area has to be kept clear of any objects at all times.
- Be careful when working near the rotating blades.
FAN OVERVIEW
1. Motor housing
2. Fan blades
3. Canopy
4. Fan light housing
5. Glass shade
6. Switch for rotating direction
UNPACK THE FAN
- Unpack the fan and check that contents of are complete.
- Dispose of packaging – see also “Disposal”.
Contents of packaging:
Instructions for installation and use Canopy
Mounting bracket Screws
Motor housing Spring washers
Fan blades Flat washers
Fan light housing Transmitter for remote control
Glass shade Receiver for remote control
Note: In case of damaged or missing parts, please contact your retailer.
INSTALLATION
Risk of electric shock: Switch off the electricity using the switch at the circuit breaker box before
installing the fan.
Risk of electric shock: The electrical installation must be performed by a qualified electrician
and must be in accordance with national and local regulations.
Risk of injury: In case you need to drill holes for mounting the fan, make sure that the drills have
sufficient distance to in-ceiling wiring.
3
1. Pass the supply wires through
the hole in the mounting bracket.
Secure the mounting bracket to a
ceiling joist or other structural
ceiling element with two screws,
spring washers and flat washers.
Ensure that the support for the
mounting bracket is capable of
safely holding the moving weight
of the fan.
2. Hang the fan assembly with
the ball joint onto the mounting
bracket. Make sure the guide pin
of the bracket is fitted into the
corresponding slot of the ball
joint. You should feel the guide
pin setting into the slot of the ball
joint.
3. Install the remote control
receiver in the bracket as shown.
Make sure that you do not trap
any wires.
4. Loosen the screw in the sensor
bracket and insert the infra-red
sensor into the hole on the
canopy. Ensure that the infra-red
sensor is held by the metal plate
as shown and tighten the screw.
5. Connect the pair of 3-way
connectors from the bracket to
the remote control receiver.
Then, connect the pair of 4-way
connectors from the remote
control receiver to the fan.
6. Connect wires from supply
and bracket to the wiring
terminals as follows:
Brown wire
Blue wire
Green/yellow striped
wire
7. Slide the slots on the canopy
onto the screws at either end of
the mounting bracket and secure
the canopy with the four screws,
spring washers and star washers
provided.
8. Unscrew the screws and
spring washers from the fan
motor. Install the fan blades onto
the motor by tightening the
screws and spring washers
evenly.
9. Connect the fan light by
clipping together the two plastic
connectors as shown.
10. Attach the fan light housing to
the mounting plate on the fan
housing by using the three fixing
screws and star washers. Ensure
that you do not trap any wires.
11. Install a proper lamp to the
socket (E14, max. 60W,
not included).
12. Install the glass shade onto
the fan light housing by carefully
rotating the lampshade
clockwise.
