Strona 1/6
Compact mobile 1
A
Part of the action
Compact mobile
Operating Instructions
CONTENTS:
1. INTRODUCTION
2. PRECAUTIONARY MEASURES
3. OPERATING ELEMENTS
4. SUMMARY OF OPERATIONS
5. TECHNICAL DATA
1. INTRODUCTION
Welcome to AER. Thank you for purchasing the Compact mobile.
You have chosen a professional, compact and powerful amplifier that was specially
developed to amplify acoustic instruments. The internal battery allows you to play up to
3/6 hours without connecting the amp to the mains.
Two channels make it possible to operate a microphone and an instrument indepen-
dently of each other. The dynamically controlled power amplifier and the broad-spec-
trum loudspeaker system guarantee distortion-free reproduction even at high volumes.
To obtain maximum enjoyment from your amplifier please read this manual carefully
before using your Compact mobile.
2. PRECAUTIONARY MEASURES
When you use your Compact mobile, always take basic safety precautions to reduce to
a minimum the risk of injury by fire or by electric shock.
➧Read all the directions in these operating instructions and make sure that you under
stand them.
➧Pay attention to all warnings, instructions and supplementary text written on the
Compact mobile.
➧Always use a grounded mains connection with the appropriate supply voltage. If you
are uncertain whether the connection is grounded, have a qualified expert check it.
➧Do not let your Compact
mobile come into contact with water and never touch the
amplifier if you have wet hands.
➧Always operate your Compact
mobile in a place where no one can trip over the
cables causing injury to themselves or damage to the cables.
➧Do not operate your Compact
mobile near devices with strong electromagnetic
fields such as large mains transformers, generators, neon lights etc. Do not lay the
signal cable parallel to power lines.
➧Do insure that your Compact
mobile is switched off before plugging in the power
cable to the mains.
➧Before cleaning your Compact
mobile, unplug it from the mains supply. Use a damp
cloth to clean it. Do not use cleaning agents, and be careful that no liquid finds its
way into the amp.
➧There are no parts within your Compact
mobile that can be serviced by the user.
Refer all repairs and servicing to an agent authorised by AER.
Any unauthorised repair or servicing will void the two year warranty!
➧Keep these operating instructions in a safe place.
3. OPERATING ELEMENTS
Front (from left to right):
Channel 1:
Input socket for a 6.3 mm jack plug
High/Low switch to adjust input sensitivity
High impedance only instruments with a piezoelectric pick-up,
Low for instruments with active preamplifiers and magnetic sound pick-ups
Clip overload indicator
Gain input level control
Colour mid-range contour filter
Bass tone control for bass
Middle tone control for mid-range
Treble tone control for treble
Compact mobile 2
A
Part of the action
Channel 2:
Input XLR combination with a socket for a 6.3 mm jack plug and XLR male socket
Line/Mic switch to adjust input sensitivity
Line: sources with line level, instruments with active preamplifiers
and magnetic sound pick-ups, symmetrical microphone inputMic:
with 30 V phantom source
Clip overload indicator
Gain input level control
Bass tone control for bass
Treble tone control for treble
Eff. Pan panorama control to distribute the effects between the channels
Select switch for two effect programmes (reverberation, reverberation/delay)
Return level control for the internal effect
Power power indicator lamp
Master level control for the overall volume
Low batt. low charge indicator lamp
Charge charge indicator lamp
48V on/off 48V phantom power on/off
Aux–Return level control for the Aux–Input (e.g. CD–player)
Rear (from left to right):
Aux–In input for CD and tape
Phones headphone output
Tuner output for a tuner after the master control
Line-out preamplifier output after the master control
DI-out XLR output before the master control
Send output for an external effect device
Return input for an external effect device or another signal source, for example
CD–player
Footswitch connection for a double foot switch with which the effects can be
switched on and off.
12V/DC only connection for an external 12V/DC–battery, not suitable for
a connection to a board–net.
DC on/off On/Off–switch for an external battery–connection.
Power on/off combined mains switch with a mains socket and a fuse-
holder (1 A slowblow) for both operating–modes
Compact mobile 3
A
Part of the action
