Strona 1/27
EN
Owner's Manual
THANK YOU FOR BUYING A WHIRLPOOL PRODUCT
In order to receive a more complete assistance, please
register your product on www .whirlpool. eu/ register
Before using the appliance carefully read the Safety
Instruction.
PRODUCT DESCRIPTION
CONTROL PANEL
1. ON / OFF
For switching the oven on and off.
2. HOME
For gaining quick access to the
main menu.
3. FAVORITE
For retrieving up the list of your
favorite functions.
4. TOOLS
To choose from several options
and also change the oven settings
and preferences.
5. DISPLAY
6. CONTROL LOCK
The “Control Lock” enables you
to lock the buttons on the touch
pad so they cannot be pressed
accidently.
7. LIGHT
To switch on or off the oven lamp.
8. KITCHEN TIMER
This function can be activated
either when using a cooking
function or alone for keeping time.
9. START
To start the cooking function.
PLEASE SCAN THE QR CODE ON
YOUR APPLIANCE IN ORDER TO
REACH MORE INFORMATION
1 3 4 5 92 7 86
1. Control panel
2. Humidity sensor
3. Fan and circular heating element
(non-visible)
4. Shelf guides
(the level is indicated on the front
of the oven)
5. Door
6. Water drawer
7. Upper heating element/grill
8. Lamp
9. Food probe insert point
10. Identification plate
(do not remove)
11. Lower heating element
(non-visible)
5
4
3
2
1
5
4
3
2
1
1
2
3
4
5
9
10
7
6
8
11
ACCESSORIES
WIRE SHELF DRIP TRAY BAKING TRAY SLIDING RUNNERS
Use to cook food or as a
support for pans, cake
tins and other ovenproof
items of cookware.
Use as an oven tray
for cooking meat, fish,
vegetables, focaccia, etc.
or position underneath
the wire shelf to collect
cooking juices.
Use for cooking all bread
and pastry products, but
also for roasts, fish en
papillotte, etc.
To facilitate inserting or
removing accessories.
FOOD PROBE STEAM TRAY AIR FRY TRAY *
To accurately measure
the core temperature
of food during cooking.
Thanks to its rigid
support, it can be used
for meat and fish, and
also for bread, cakes and
baked pastries.
This makes it easier for
steam to circulate, which
helps cook the food
evenly. We recommend
to place the Steam tray
at Level 2 for optimal
cooking performance.
Place the drip tray on the
Level 1 below to collect
the cooking juices. **
To be used when
cooking foods with Air
Fry function, with a
baking tray positioned
at a lower level to collect
possible crumbs and
drip. It can be cleaned in
the dishwasher.
The number and the type of accessories may vary depending on which model is purchased.
Other accessories can be purchased separately; for orders and information contact the after sales service.
* Available only in certain models
** Use for STEAM and SOUS VIDE functions only
INSERTING THE WIRE SHELF AND OTHER
ACCESSORIES
Insert the wire shelf horizontally by sliding it across
the shelf guides, making sure that the side with the
raised edge is facing upwards.
Other accessories, such as the drip tray and the
baking tray, are inserted horizontally in the same way
as the wire shelf.
REMOVING AND REFITTING THE SHELF GUIDES
• To remove the shelf guides, remove the fixing screws
(if present) on both sides with the aid of a coin.
Lift the guides up and pull the lower parts out of their
seatings: the shelf guides can now be removed.
• To refit the shelf guides, first fit them back into their
upper seating. Keeping them held up, side them into
the cooking compartment, then lower them into
position in the lower seating.
The left (“L”) and right (“R”)
shelf guides can be recognized
by the logo indicated in this
picture.
FITTING THE SLIDING RUNNERS
Remove the shelf guides
from the oven and remove
the protective plastic from
the sliding runners.
Fasten the upper clip of the
runner to the shelf guide
and slide it along as far as it
will go. Lower the other clip
into position.
To secure the guide, press
the lower portion of the clip
firmly against the shelf
guide. Make sure that the
runners can move freely.
Repeat these steps on the
other shelf guide on the
same level.
Please note: The sliding runners can be tted on any level.
RL
