DAILY REFERENCE

GUIDE

THANK YOU FOR PURCHASING A

WHIRLPOOL PRODUCT

To receive more comprehensive help and

support, please register your product at

www . whirlpool . eu/ register

You can download the Safety Instructions

and the Use and Care Guide by visiting our

website docs . whirlpool . eu and following the

instructions on the back of this booklet.

Before using the appliance carefully read the Health and Safety guide.

PRODUCT DESCRIPTION

1. Control panel

2. Fan

3. Circular heating element

(not visible)

4. Shelf guides

(the level is indicated on the front

of the oven)

5. Door

6. Upper heating element/grill

7. Lamp

8. Identification plate

(do not remove)

9. Lower heating element

(not visible)

CONTROL PANEL DESCRIPTION

1 2 3 4 5 6 7

1. SELECTION KNOB

For switching the oven on by

selecting a function. Turn to the “0”

position to switch the oven off.

2. BACK

For returning to the previous screen.

During cooking, allows settings to

be changed.

3. STOP

For stopping the function that is

currently active.

4. DISPLAY

5. START

For immediately starting a function.

6. CONFIRM

For confirming a selected function

or a set value.

7. ADJUSTMENT KNOB

For scrolling through the menus and

applying or changing settings.

Please note: The knobs are retractable.

Press the knobs in the middle and they

pop up.

ACCESSORIES

WIRE SHELF DRIP TRAY BAKING TRAY SLIDING RUNNERS *

Use to cook food or as a

support for pans, cake tins

and other ovenproof items of

cookware

Use as an oven tray for

cooking meat, sh,

vegetables, focaccia, etc. or

position underneath the wire

shelf to collect cooking juices.

Use for cooking all bread and

pastry products, but also for

roasts, sh en papillotte, etc.

To facilitate inserting or

removing accessories.

* Available only on certain models

The number and the type of accessories may vary depending on which model is purchased.

Other accessories can be purchased separately from the After-sales Service.

INSERTING THE WIRE SHELF AND OTHER

ACCESSORIES

Insert the wire shelf horizontally by sliding it across the

shelf guides, making sure that the side with the raised

edge is facing upwards.

Other accessories, such as the drip tray and the baking

tray, are inserted horizontally in the same way as the

wire shelf.

REMOVING AND REFITTING THE SHELF GUIDES

• To remove the shelf guides, lift the guides up and

then gently pull the lower part out of its seating: The

shelf guides can now be removed.

• To refit the shelf guides, first fit them back into their

upper seating. Keeping them held up, slide them

into the cooking compartment, then lower them into

position in the lower seating.

FITTING THE SLIDING RUNNERS (IF PRESENT)

Remove the shelf guides from the oven and remove the

protective plastic from the sliding runners.

Fasten the upper clip of the runner to the shelf guide

and slide it along as far as it will go. Lower the other

clip into position. To secure the guide, press the lower

portion of the clip firmly against the shelf guide. Make

sure that the runners can move freely. Repeat these

steps on the other shelf guide on the same level.

Please note: The sliding runners can be tted on any level.

FUNCTIONS

OFF

To switch off the oven.

6th SENSE

These allow a fully automatic cooking for all

types of food (Lasagna, Meat, F Vegetables, Cakes & ish,

Pastries, , Bread, Pizza).Quiches

To get the best from this function, follow the indications

on the relative cooking table.

CONVENTIONAL

For cooking any kind of dish on one shelf only.

FORCED AIR

For cooking different foods that require the same

cooking temperature on several shelves (maximum

three) at the same time. This function can be used to

cook different foods without odours being transferred

from one food to another.

COOK 4 FUNCTIONS

For cooking different foods that require the same

cooking temperature on four levels at the same time.

This function can be used to cook cookies, , round tarts

pizzas (also frozen) and to prepare a complete meal.

Follow the cooking table to obtain the best results.

GRILL FUNCTIONS

For grilling steaks, kebabs and sausages, cooking

vegetables au gratin or toasting bread When.

grilling eat, we recommend using a drip tray to m

collect the ooking juices: Position the tray on any c

of the levels elow the wire shelf and add 500 ml of b

drinking water.

• TURBO RILL G

For roasting large joints of meat (legs, roast beef,

chicken). We recommend using a drip tray to collect

the cooking juices: Position the pan on any of

the levels below the wire shelf and add 500 ml of

• GRILL

drinking water. The turnspit (if provided) can be

used with this function.

CONVECT AKE B

For cooking meat, baking cakes with fillings or

roasting stuffed vegetables on one shelf only. This

function uses gentle, intermittent air circulation to

prevent food from drying out excessively.

SPECIALS

• F T ATAS PREHE

For preheating the oven quickly. Once preheating

has finished, the oven will select the “Conventional”

function automatically Wait for preheating to finish.

before placing food in the oven.

• FROZEN AKE B

The function automatically selects the ideal cooking

temperature and mode for 5 different types of ready

frozen food The oven does not have to be.

preheated.

• MAXI OOKING C

For ing cook large joints of meat (above 2.5 kg). It is

advisable to turn the meat over during cooking, to

obtain even browning on both sides. It is best to

baste the meat every now and again to prevent it

from drying out.

• RISING

For optimal proving of sweet or savoury dough. o T

maintain the quality of proving, do not activate the

function if the oven is still hot following a cooking

cycle.

• DEFROSTING

To speed up defrosting of food. Place food on the

middle shelf. Leave food in its packaging to prevent

it from drying out on the outside.

• KEEP WARM

For keeping just-cooked food hot and crisp.

• ECO FORCED AIR

For cooking stuffed roasting joints and fillets of

meat on a single shelf. Food is prevented from

drying out excessively by gentle, intermittent air

circulation. When this ECO function is in use, the

light will remain switched off during cooking. To

use the ECO cycle and therefore optimise power

consumption, the oven door should not be opened

until the food is completely cooked.

AUTOMATIC OVEN CLEANING - PYRO

For eliminating cooking spatters using a cycle

at very high temperature ( 00 °C Twoover 4 ). selfcleaning

cycles are available: A complete cycle (Pyro) and a

shorter cycle (Pyro Eco We recommend using the ).

quicker cycle at regular intervals and the complete cycle

only when the oven is heavily soiled.

SETTINGS

For adjusting the oven settings.

When “ECO” mode is active the brightness of the display will

be reduced to save energy and lamp switches o after 1

minute. It will be reactivated automatically whenever any of

the buttons are pressed.

When “DEMO” is “On” all commands are active and menus

available but the oven doesn’t heat up. To deactivate this

mode, access “DEMO” from “SETTINGS” menu and select “O”.

By selecting “FACTORY RESET”, the product switches o and

then it returns to rst switch on. All settings will be deleted.

FAVORITE

For retrieving the list of 10 favorite functions.

FIRST TIME USE

1. SELECT THE LANGUAGE

You will need to set the language and the time when

you switch on the appliance for the first time: “English”

will show on the display.

1.English

Turn the to scroll through the list of adjustment knob

available languages and select the one you require.

Press to confirm your selection.

Please note: The language can subsequently be changed by

selecting “LANGUAGE” in “SETTINGS” menu, available by

turning the selection knob on .

2. SET THE POWER CONSUMPTION

The oven is programmed to consume a level of electrical

power that is compatible with a domestic network that

has a rating of more than 3 kW (16): If your household

uses a lower power, you will need to decrease this value

(13).

POWER

Turn the to select 16 “High” or 13 “Low” adjustment knob

and press to confirm.

3. SET THE TIME

After selecting the power, you will need to set the

current time: The two digits for the hour will flash on

the display.

CLOCK

Turn the to set the current hour and adjustment knob

press : The two digits for the minutes will flash on the
