EN
Quick guide
1
THANK YOU FOR BUYING A WHIRLPOOL PRODUCT
In order to receive a more complete assistance, please
register your product on www . whirlpool . eu/ register
Before using the appliance carefully read the Safety
Instruction.
PRODUCT DESCRIPTION
1. Control panel
2. Fan
3. Circular heating element
(not visible)
4. Shelf guides
(the level is indicated on the
front of the oven)
5. Door
6. Upper heating element/grill
7. Lamp
8. Identification plate
(do not remove)
9. Lower heating element
(not visible)
CONTROL PANEL DESCRIPTION
1 2 3 4 5 6 7
1. SELECTION KNOB
For switching the oven on by
selecting a function. Turn to the “0”
position to switch the oven off.
2. BACK
For returning to the previous
screen.
During cooking, allows settings to
be changed.
3. STOP
For stopping the function that is
currently active.
4. DISPLAY
5. START
For immediately starting a
function.
6. CONFIRM
For confirming a selected function
or a set value.
7. ADJUSTMENT KNOB
For scrolling through the menus
and applying or changing settings.
Please note: The knobs are retractable.
Press the knobs in the middle and they
pop up.
5
4
3
2
1
5
4
3
2
1
1
2
3
4
5
8
9
7
6
2
ACCESSORIES
WIRE SHELF DRIP TRAY BAKING TRAY SLIDING RUNNERS *
Use to cook food or as a
support for pans, cake tins
and other ovenproof items of
cookware
Use as an oven tray for
cooking meat, sh,
vegetables, focaccia, etc. or
position underneath the wire
shelf to collect cooking juices.
Use for cooking all bread and
pastry products, but also for
roasts, sh en papillotte, etc.
To facilitate inserting or
removing accessories.
* Available only on certain models
The number and the type of accessories may vary depending on which model is purchased.
Other accessories can be purchased separately from the After-sales Service.
INSERTING THE WIRE SHELF AND OTHER
ACCESSORIES
Insert the wire shelf horizontally by sliding it across
the shelf guides, making sure that the side with the
raised edge is facing upwards.
Other accessories, such as the drip tray and the
baking tray, are inserted horizontally in the same way
as the wire shelf.
REMOVING AND REFITTING THE SHELF GUIDES
• To remove the shelf guides, lift the guides up and
then gently pull the lower part out of its seating:
The shelf guides can now be removed.
• To refit the shelf guides, first fit them back into
their upper seating. Keeping them held up, slide
them into the cooking compartment, then lower
them into position in the lower seating.
FITTING THE SLIDING RUNNERS (IF PRESENT)
Remove the shelf guides from the oven and remove
the protective plastic from the sliding runners.
Fasten the upper clip of the runner to the shelf guide
and slide it along as far as it will go. Lower the other
clip into position. To secure the guide, press the lower
portion of the clip firmly against the shelf guide.
Make sure that the runners can move freely. Repeat
these steps on the other shelf guide on the same
level.
Please note: The sliding runners can be tted on any level.
EN
3
FUNCTIONS
OFF
To switch off the oven.
6th SENSE
These allow a fully automatic cooking for all
types of food (Lasagna, Meat, Fish, Vegetables, Cakes
& Pastries, Salt cakes, Bread, Pizza).
To get the best from this function, follow the
indications on the relative cooking table.
CONVENTIONAL
For cooking any kind of dish on one shelf only.
FORCED AIR
For cooking different foods that require the
same cooking temperature on several shelves
(maximum three) at the same time. This function can
be used to cook different foods without odours being
transferred from one food to another.
COOK 4 FUNCTIONS
For cooking different foods that require the
same cooking temperature on four levels at the same
time. This function can be used to cook cookies,
cakes, round pizzas (also frozen) and to prepare a
complete meal. Follow the cooking table to obtain
the best results.
GRILL
For grilling steaks, kebabs and sausages,
cooking vegetables au gratin or toasting bread. When
grilling meat, we recommend using a drip tray to
collect the cooking juices: Position the tray on any
of the levels below the wire shelf and add 500 ml of
drinking water.
• TURBO GRILL
For roasting large joints of meat (legs, roast beef,
chicken). We recommend using a drip tray to
collect the cooking juices: Position the pan on any
of the levels below the wire shelf and add 500 ml
of drinking water. The turnspit (if provided) can be
used with this function.
CONVECT BAKE
For cooking meat, baking cakes with fillings or
roasting stuffed vegetables on one shelf only. This
function uses gentle, intermittent air circulation to
prevent food from drying out excessively.
SPECIALS
• FAST PREHEAT
For preheating the oven quickly. Once preheating
hasnished, the oven will select the “Conventional”
function automatically. Wait for preheating to nish
before placing food in the oven.
• FROZEN BAKE
The function automatically selects the ideal
cooking temperature and mode for 5 different
types of ready frozen food. The oven does not
have to be preheated.
• MAXI COOKING
For cooking large joints of meat(above 2.5 kg). It is
advisable to turn the meat over during cooking, to
obtain even browning on both sides. It is best to
baste the meat every now and again to prevent it
from drying out.
• RISING
For optimal proving of sweet or savoury dough.
To maintain the quality of proving, do not activate
the function if the oven is still hot following a
cooking cycle.
• DEFROSTING
To speed up defrosting of food. Place food on
the middle shelf. Leave food in its packaging to
prevent it from drying out on the outside.
• KEEP WARM
For keeping just-cooked food hot and crisp.
• ECO FORCED AIR
For cooking stuffed roasting joints and fillets of
meat on a single shelf. Food is prevented from
drying out excessively by gentle, intermittent air
circulation. When this ECO function is in use, the
light will remain switched off during cooking.
To use the ECO cycle and therefore optimise
power consumption, the oven door should not be
opened until the food is completely cooked.
SMARTCLEAN
The action of the steam released during this
special low-temperature cleaning cycle allows dirt
and food residues to be removed with ease. Pour 200
ml of drinking water on the bottom of the oven and
only activate the function when the oven is cold.
SETTINGS
For adjusting the oven settings.
When “ECO” mode is active the brightness of the display will
be reduced to save energy and lamp switches o after 1
minute. It will be reactivated automatically whenever any of
the buttons are pressed.
When “DEMO” is “On” all commands are active and menus
available but the oven doesn’t heat up. To deactivate this
mode, access “DEMO” from “SETTINGS” menu and select “O”.
By selecting “FACTORY RESET”, the product switches o and
then it returns to rst switch on. All settings will be deleted.
FAVORITE
For retrieving the list of 10 favorite functions.
