* Depending on version
•Blue lead A5 (Electronic/Motor Aerial) :
This radio can provide a 12V signal for the
control of an automatic motor aerial or the
supply of an electronic aerial by connection.
Do not use this connection for the supply lead
of the aerial motor!
•Orange lead A6 (Pilot light) : Connect to
the dashboard illumination wiring of the car.
When the car headlights are switched on, the
backlight to the power key remains illuminated
(even when the radio is switched off). When
the set is on with this connection , the
brightness of the display is reduced.
CONNECTOR B (fig.2)
Loudspeakers (use 4 ohm loudspeakers
only)
• Do not connect any of the loudspeaker leads
to earth or directly to a booster/amplifier or via
an external fader!
• Connecting 4 loudspeakers
Front Rear
Left+ Green [B5] White [B7]
Left- Green/black [B6] White/black [B8]
Right+ Grey [B3] Blue [B1]
Right- Grey/black [B4] Blue/black [B2]
– To check the loudspeaker connections keep
the 'SCAN' key pressed and switch on the set.
To cancel switch off the set.
BLUE CONNECTOR C * for a Digital CD
changer (available separately) (fig. 3)
• You can only connect the following CD changer
with a digital output to this set :
- CH0400 or CH0600 or CH1000
Useful tips
Recommended connection instructions between
the CD changer and headunit :
1. Ensure that the Connector A (power supply) is
removed from the headunit.
2. Finish all connections between the CD changer
(see mounting instructions for the CD changer)
and the headunit.
3. Reconnect the Connector A (power supply) to
the headunit.
INSTALLATION
If your car is equipped with ISO connectors,
simply insert them in connectors of the car radio.
If not, you can use an adaptor cable (Refer to the
table on the separate installation card). Ensure all
cables are installed so that they cannot be
damaged by sharp edges or moving parts.
PREPARATION
Voltage and polarity: The set must be connected
to a 12V car battery with negative terminal to
earth (car chassis). Installation in vehicles not
fulfilling these requirements could result in
malfunction, damage or fire.
Warning: To prevent short-circuiting, disconnect
the negative car battery terminal until the set has
been mounted and connected (fig.1 See separate
installation card).
CONNECTOR A (fig.2)
POWER SUPPLY CONNECTIONS
•Red lead A7 : Connect to a permanent 12V
supply. This is the main power supply. Ensure
this connection can handle a current of 10A.
•Yellow/red lead A4 : Connect to a switched
12V supply (switched on/off by car ignition).
•Brown lead A8: Connect to earth (car
chassis).
This connection set up will enable you to make
full use of the ON/OFF LOGIC function of this set
limiting the use of the set to 1 hour after removal
of the ignition key. If this feature does not appear
to be functioning as expected you may require
an adapter cable (EA6259). See reverse of
installation card.
OPTIONAL CONNECTIONS (fig. 2)
•Pink lead A1 * (SDVC AND SPEED
WARNING) :
Speed Dependent Volume Control
automatically increases and decreases the
volume as a result of the car's speed.
Speed Warning can be used to inform you that
you are exceeding a certain speed.
•Connect pin A1 to a signal from the
speedometer of your car. Some cars are
already prepared for it (e.g. certain VW &
Vauxhall/Opel cars), please consult your dealer.
If not, you may need a more detailed
installation requiring extra equipment to
enable your car to become compatible.
This can only be accomplished by persons
familiar with automotive electrical and
mechanical systems. After connection see
‘SPECIAL FUNCTIONS’.
Complies with 21 CFR 1040.10
3
* Depending on version
OTHERS CONNECTIONS (fig.2)
Line-output *
• You can connect a power amplifier (with 2
additional loudspeaker) to this set with the RCA
cable.
– Connect Red socket to Right channel and white
socket to Left channel.
– Connect Blue wire to Amplifier Remote on/off.
Wired Remote Control
You can connect a wired remote control to this
set. Please note that you can also use an infrared
remote control* with this set.
TEMPERATURE SENSOR * (available
separately)
• You can connect a temperature sensor to this
set to automatically give a visible and audible
warning when the outside temperature
becomes lower than 3oC to warn of the
possibility of frost or black ice. The outside
temperature can also be shown by pressing
the 'DISPLAY' key.
– See the mounting instructions for the sensor.
– Connect the temperature sensor to the
connector marked (see separate installation
card).
– See INITIAL SETTINGS; select Option 'TEMP'
and set the Choice to 'C' (Celsius) or 'F'
(Fahrenheit).
This device is an aid only and cannot be
used to determine exact road conditions.
Use your own judgement at all times to decide
whether it is safe to continue driving.
Pink lead wire (Telephone mute)
• If your car telephone or the car kit of your mobile
phone provides a mute signal, it can be used to
automatically interrupt the set's sound output.
– Connect the telephone mute wire to Pink lead
wire (TEL. MUTE).
– See INITIAL SETTINGS; select
1 Option 'TEL' and set the Choice to 'MUTE'
2 Option 'PHONE' and set the Choice to 'LO' or
'HI' according to phone type.
TELEPHONE IN
• If your car telephone or the car kit of your mobile
phone provides both the mute signal and
loudspeaker connection, its output can be
amplified through the car's front speaker.
– Connect the telephone mute wire to Pink lead
wire (TEL. MUTE).
– Connect connector F (yellow) to the
loudspeaker output of your car phone or car
kit.
– See INITIAL SETTINGS; select
1 Option 'TEL' and set the Choice to 'IN'
2 Option 'PHONE' and set the Choice to 'LO' or
'HI' according to phone type.
Useful tips
Do not operate cellular phones near the set or
even in a car without using an outside antenna, it
may cause disturbances to all electrical systems
in the car.
REAR STUD
Screw rubber buffer E onto fixing stud at rear of
set.
AERIAL
Fix antenna adaptor * (EA6257/00) if needed.
• Insert aerial plug into aerial socket (good
reception is only possible with a good aerial).
4
* Depending on version
LEGEND
Briefly press the key.
Press and hold the key.
Press the key until you hear a
confirmation beep.
Turn the rotary knob.
Useful tips
ENVIRONMENT
This booklet is printed on low-chlorine
recyclable paper that can be used for
recycling.
CHECK BEFORE REQUESTING SERVICE
There may be times when you suspect that your
car radio is not functioning as you expected it to.
Before calling for service, please read the
operating / installation instructions and check for
useful tips under each section. You may find that
an apparent malfunction can easily be rectified.
If you still have to send your set for service, always
send the complete set (with detachable front). Do
not try to open the set to service it yourself.
MOUNTING
METAL SLEEVE (fig.4)
• Install the metal sleeve (dimension 182x53 mm) in the dashboard. For optimal performance of
the CD player*, the metal sleeve should be positioned horizontally (between -10
o and +30o).
• Fix metal sleeve into place by pressing the metal tags outwards using a screwdriver.
MOUNTING RADIO
This radio can be properly installed either from conventional Front Mounting or Rear Mounting.
FRONT MOUNTING
• Slide the radio into the metal sleeve until the springs at either side of the radio snap into the openings
of the sleeve (fig.5).
• Finally reconnect the negative car battery terminal (fig.6).
REMOVING RADIO (using the two U- brackets supplied)
• Remove the front, see 'SECURITY', 'DETACHABLE FRONT'.
• Insert both U-brackets into the holes on the front of the set until they lock. Pull out the radio (Fig.7).
REAR MOUNTING (fig.8)
• Remove the trimplate around the front panel and the side springs.
• Select a position where the screw holes of the mounting bracket and the screw holes of the radio
become aligned and tighten the screws at 2 places on each side.
• Only use M5 screws that are not longer than 6mm.
REPLACING FUSE (Fig. 2)
• Replace with a 10A blade-type fuse. The new fuse must be of exactly this value and type otherwise
the set will not be adequately protected. Ignoring this procedure may lead to damage to the set,
which will invalidate the guarantee.
INTERFERENCE SUPPRESSION
• Most modern cars have sufficient interference suppression. If you experience interference generated
by the car, consult your garage.
