Strona 1/20
NOTES
This manual contains information for:
• Important Safeguards
• Installation
• Use and Care
Certain ranges come equipped with special features. Determine from a study of
your range which of the instructions given in this booklet pertain to your range.
This booklet gives valuable instructions covering the installation, adjustment and
use of your range.
HOW TO OBTAIN SERVICE AND/OR PARTS
When your range does not operate in accordance with the instructions in the
manual, you should contact the dealer in the immediate vicinity for service. Or,
the purchaser may contact the service organization noted on the wa
rranty.
Gas Range
Read and Save These Instructions
IMPORTANT
TO THE OWNER OF THE RANGE: Retain this owner's manual for future reference.
TO THE INSTALLER: Leave this owner's manual with the range.
Range
Record in the space provided below the Model No. and Serial No. of this appliance. These
numbers are found on the serial plate located below the lift-up cooktop.
Model No._______________________ Type Number _____________________
Serial No. _______________________ Purchase Date_____________________
Record these numbers for future use.
IMPORTANT: Keep a copy of your bill of sale. The date on the bill establishes the
warranty period should service be required. If service is performed, it is in your best
interest to obtain and keep all receipts.
PLEASE DO THIS NOW!
The PRODUCT REGISTRATION CARD should be lled in completely, signed and
returned. This information will register your product and help us to serve you quickly in
the future if necessary.
Contents
Important Safeguards . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-7
Energy Saving Ideas . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Installation Instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-9
Backguard Installation Instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Wall Clearances . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Alignments and Adjustments. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12-21
Operation of Range . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22-24
Broiling . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
Optional Equipment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25-26
Cleaning the Range . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27-28
Lift-Off Doors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
Trouble Shooting Guide . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
Wiring Diagram . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
Built-In Cooktops . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33
Built-In Wall Ovens . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41
Note: For warranty and service information, please see attachments packaged with range.
If the information in this manual is not followed exactly,
a re or explosion may result causing property damage,
personal injury or death.
2
Do not store or use gasoline or other ammable vapors and liquids in
the vicinity of this or any other appliance.
WHAT TO DO IF YOU SMELL GAS:
• Do not try to light any appliance.
• Do not touch any electrical switch; do not use any phone in your building.
• Immediately call your gas supplier from a neighbor's phone. Follow
the gas supplier's instructions.
• If you cannot reach your gas supplier, call the re department.
Installation and service must be performed by a qualied installer,
service agency or the gas supplier.
39
GAS RECESSED WALL OVEN
Slide the oven unit into the cabinet recess as shown in the diagram. Secure the oven unit to
the cabinet with wood screws. Be sure to use the cabinet spacer with the wood screw as a
“washer” between the wood cabinet and the oven front frame.
The recess in which the oven is installed shall be constructed so as to provide a complete
closure around the recessed portion of the unit and any openings around gas and
electrical service outlets MUST be closed at time of installation. The installation must
conform with local codes. In the absence of local codes, the National Fuel Gas Code
Z223.1 latest edition.
A MANUAL GAS VALVE MUST BE INSTALLED IN AN ACCESSIBLE
LOCATION IN THE GAS LINE EXTERNAL TO THE UNIT FOR THE
PURPOSE OF TURNING ON OR SHUTTING OFF GAS TO THE UNIT.
ELECTRICAL GROUNDING
INSTRUCTIONS
This appliance is equipped with a three prong
grounding plug for your protection against
shock hazard and should be plugged directly
into a properly grounded receptacle. Do not cut
or remove the grounding prong from this plug.
INSURE PROPER
GROUND EXISTS
BEFORE USE.
FLEXIBLE CONNECTORS - If the gas range/oven is connected to a gas supply with a
metal exible connector, move the range/oven with CAUTION for service or cleaning.
Flexible connectors are not intended for repeated bending. Do not allow cleaners to make
contact with exible connectors.
The connector and its ttings are designed for use only on the original
installation and are not to be reused for another appliance or at another
location. Connectors must comply with ANSI Z21.24.
38
INSTALLATION INSTRUCTIONS
BUILT-IN GAS AND ELECTRIC
RECESSED WALL OVENS
IMPORTANT – Read and save these instructions.
Save for local electrical inspector’s use.
Destroy the carton and plastic bags after the range is unpacked. Children should not
use packaging material for play. Cartons covered with rugs, bedspreads, or plastic sheets
can become air-tight chambers. Remove all staples from the carton. Staples can cause
severe cuts and destroy nishes if they come in contact with other appliances or furniture.
Be safety conscious. The preparation of food in an oven requires temperatures that could cause
severe burns. Before using this new appliance, carefully read and follow all instructions.
The California Safe Drinking Water and Toxic Enforcement Act of
1986 (Proposition 65) requires the Governor of California to publish a list of
substances known to the State of California to cause cancer or reproductive
harm. In addition, businesses must warn customers of potential exposure to
such substances.
Users of this appliance are hereby warned there may be some low level exposure to some
of the listed substances including formaldehyde, benzene, soot and carbon monoxide.
This is caused primarily from the incomplete combustion of natural gas or LP fuel.
Properly adjusted burners will minimize incomplete combustion. Exposure to these
substances can also be minimized by properly venting the burners, by opening a window or
using a ventilating hood or fan.
Notice: Never keep pet birds in the kitchen. Birds have a very sensitive respiratory system.
Fumes released during the self-cleaning cycle, overheated cooking oil, fat, margarine or
overheated non-stick cookware may be harmful or fatal to birds.
PROPER INSTALLATION: Be sure your appliance is properly installed and grounded
by a qualied technician in accordance with the National Fuel Gas ANSI Z223.1 - latest
edition, and National Electrical Code ANSI/NFPA No. 70 - latest edition. Install only per
installation instructions provided in the literature package for this range. Be sure leveling legs
are in place at the bottom corners of the range. If necessary, raise or lower the leveling legs
at the base of the range by turning clockwise or counterclockwise to insure a level range.
Ask your dealer to recommend a qualied technician and an authorized repair service.
Have the technician familiarize you with the locations of the manual gas shut off valve and
gas meter in the event it is necessary to shut off gas supply to the unit during an emergency.
The following situations may cause serious bodily harm, death or
property damage.
•
TO REDUCE THE RISK OF TIPPING OF THE RANGE, THE RANGE MUST BE SECURED
BY A PROPERLY INSTALLED ANTI-TIP BRACKET PROVIDED WITH THE RANGE. TO
CHECK IF THE DEVICE IS INSTALLED AND ENGAGED PROPERLY, CAREFULLY TIP
THE RANGE FORWARD. THE ANTI-TIP DEVICE SHOULD ENGAGE AND PREVENT
THE RANGE FROM TIPPING OVER. REFER TO THE INSTALLATION INSTRUCTIONS
PACKAGED WITH THE ANTI-TIP BRACKET FOR PROPER ANTI-TIP BRACKET
INSTALLATION.
• Never leave children alone or unattended in the area where an appliance is in use.
They should never be allowed to sit or stand on any part of the appliance. Never leave
the oven door open when the range is unattended.
• Do not store items of interest to children in the cabinets above a range or on the
backguard of a range. Children climbing on the range to reach items could be
seriously injured. 3
READ THE IMPORTANT SAFEGUARDS AND ALL
INSTRUCTIONS BEFORE USING THE APPLIANCE.
Remove all tape and packaging wrap before using the oven. If any glue remains, touch
the residue with the sticky side of the tape already removed, or use a cloth soaked with
rubbing alcohol. Use caution because rubbing alcohol is ammable. Rinse with warm
water and wipe dry.
